PIXEL TW
Architectural Spot and Flood Light INSTALLATION GUIDE

PIXEL TW
Architectural Spot and Flood Light INSTALLATION GUIDE
GVA Lighting, Inc. 2771 Bristol Cir, Oakville, ON L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] IG-PIXEL-TW, 2020-08-26 | Page 2 / 4 gvalighting.com
WARNING CAUTION
Do not attempt to install or use Luminaire(s) until you have read
and understand this guide and all safety labels.
Luminaire(s) must be installed by a qualified professional.
Luminaire(s) must be installed in accordance with all national and
local electrical and construction regulations.
Ensure that main power supply is OFF before installing or wiring
luminaire(s).
Do not exceed specified voltage and current input.
Do not use luminaire(s) with a damaged lens, body, or cable.
Failing to install luminaire(s) according to warnings may result in
a hazardous situation which can cause equipment and property
damage, personal injury, or death.
Do not exceed the maximum number of specified luminaires in a
light run. Doing so will result in a current overload.
GVA Luminaires have no serviceable parts. Do not attempt to
open the units.
Do not hot swap. Ensure power supply is off before connecting or
disconnecting fixtures.
Do not stare into beam or view directly with optical instruments.
Unauthorized feild repairs will void warranty.
1LUMINAIRE
MOUNTING
WARNING Use mounting hardware suitable for the mounting surface. Use of innappropriate hardware may result in
dismounting of the bracket and can result in equipment damage, injuries, or death.
1.A. CLIP MOUNT BRACKET
NOTE: If installing SURFACE MOUNT BRACKET refer to Step 1.B.
Install CLIP MOUNT BRACKET using M3 Panhead Screws (supplied by others) suitable for the mounting surface.
REQUIRED
HARDWARE:
M3 PANHEAD SCREW
(supplied by others)
1X

PIXEL TW
Architectural Spot and Flood Light INSTALLATION GUIDE
GVA Lighting, Inc. 2771 Bristol Cir, Oakville, ON L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] IG-PIXEL-TW, 2020-08-26 | Page 3 / 4 gvalighting.com
1.B. SURFACE MOUNT BRACKET
NOTE: If installing CLIP MOUNT BRACKET refer to Step 1.A.
Install SURFACE MOUNT BRACKET using M3 Panhead Screws (supplied by others) suitable for the mounting surface.
REQUIRED
HARDWARE:
M3 PANHEAD SCREW
(supplied by others)
2X
2CABLE
CONNECTIONS
CAUTION Connectors need to be firmly engaged for the snap to work properly. An audible ‘CLICK’ will be heard when snap
is fully inserted. Failure to connect luminaires correctly may result in fixture malfunction or damage.
Identify the input / ouput connectors and engage clips.
INPUT CONNCETOR
OUTPUT CONNCETOR

PIXEL TW
Architectural Spot and Flood Light INSTALLATION GUIDE
GVA Lighting, Inc. 2771 Bristol Cir, Oakville, ON L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] IG-PIXEL-TW, 2020-08-26 | Page 4 / 4 gvalighting.com
3CONNECTOR
CAP
Install the connector cap on the end of the line.
4LEADER
CABLE
Install the leader cable on the input side of the first string.
