INSTRUCTION MANUAL
GVA18LEDC
18.5” (47cm)
HD LED LCD TV
with Built-in DVD Player

CONTENTS
Important safety instructions 3
Installation 7
Base Stand Assembly Instruction 7
Wall mounting installation guidelines 8
Antenna 9
Keyboard layout 9
REAR AV Connections 10
SIDE AV Connections 10
AV EQUIPMENT connections 11
Audio/Video 12
PC Connections 13
Remote Control 14
Getting started 15
Menu settings 18
Channel Menu 18
DTV Manual tuning 19
ATV Manual tuning 19
Program Edit 19
Picture menu 20
Sound menu 22
Time menu 22
Option Menu 23
EPG Menu
26
EPG Settings 27
PVR function 28
Timeshift function 31
Media player 32
DVD Operation 33
Trouble Shooting 38
Specications 39
26
26
Lock Menu
USB source

3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings, install in
accordance with the instructions.
8) Do not install near any heat sources such as
radiators, air conditioners, stoves, or other
apparatus (including ampliers) that produce heat.
9) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
10) Only use attachments/accessories specied by
the manufacturer.
11) Unplug this apparatus before the approach of
lightning storms or when unused for long periods of
time.
12) Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as
when the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has
been dropped.
13) The Mains plug is used as the power disconnect
device, and the disconnect device shall remain
readily accessible and operable.
14) The ventilation should not be impeded by
covering the ventilation openings with items such as
newspapers, table-cloth, curtains, etc.
15) No naked ame sources, such as lighted
candles, should be placed on or near the apparatus.
16) This device is not warranted for use in
unreasonably hot, cold, or humid environments.
17) The apparatus shall not be exposed to dripping
or splashing and no objects lled with liquids, such
as vases, shall be placed on or near the apparatus.
18) This device is designed for indoor, xed location
use only. It must not be used in portable or mobile
applications as vibration or excessive forces may
damage the unit.

4
IMPORTANT SAFETY INSTRUCTIONS

5
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
Never tamper with any components inside the TV, or any other adjustment controls not
mentioned in this manual. All LCD-TVs are high voltage instruments. When you clean up
dust or water drops on the LCD PANEL or CABINET, the power cord should be physically
removed from the mains outlet. You may then wipe the TV with a dry soft cloth. Before
thunder and lightning storm events arrive, unplug the power cord and antenna cord to
minimise the risk of damage to your TV.
WARNING: All repairs to this TV must only be performed by qualied TV service personnel.
There are no user-serviceable components within this equipment. Changes or modications
to this unit, including changes to parts, components and constructional attributes that are
responsible for safety and regulatory compliance, may result in non-compliant and unsafe
operation of this equipment.
a. Do not expose to dripping or splashing.
b. No objects lled with liquids, such as vases, shall be placed on or near the apparatus.
c. The mains plug of this device is used as the power disconnect device and shall remain
readily accessible and operable.
d. No naked ame sources, such as lighted candles, should be placed on or near the
apparatus.
e. Allow suitable distances around the apparatus for sufcient ventilation. Ventilation should
not be impeded by covering ventilation openings with items such as newspapers, table
cloths, curtains and such like.
f. Do not expose to vibration or shock.
The display panel is a very sensitive high technology product, giving you nely detailed
pictures. Occasionally, a few non-active pixels may appear on the screen as a xed point
of black, blue, green or red. Please note that this does not affect the performance of your
product.
About After- Image:
The extended use of xed image programme material can cause a permanent after - image
on the screen. This background image is viewable on normal programs in the form of a
stationary xed image. This type of irreversible screen deterioration can be limited by:
A. Reduce the brightness/contrast setting to a minimum viewing level.
B. Do not display any xed image for extended periods of time.
C. Turn the power o when not in actual use.

6
IMPORTANT SAFETY INSTRUCTIONS
Important Information Regarding Use of Video Games, Computers,
Captions or Other Fixed Image Displays. Do not allow a still picture to be
displayed for an extended period, as this can cause a permanent after-
image to remain on the screen.
CAUTION:
The permanent after-image on the screen resulting from fixed image use
is not an operating defect. This product is not designed to display fixed
images for extended periods of time.
CAUTION:
The DVD player in this TV is designed for use with 12cm diameter CD and
DVD discs ONLY. Never attempt to insert any other disc types or objects
into the DVD drive, as they may permanently damage the mechanism and
may also not be retrievable from the drive.

7
INSTALLATION
Unpacking and preparing the TV
Thank you for purchasing this 18.5” HD LED LCD TV with inbuilt DVD player. Before connection and
operation of this product, please read through this User Manual carefully, and retain the manual for
future reference.
Remove the TV carefully from its packaging, taking care not to apply any pressure to the front of the
LCD screen. Some accessory items may be located in cut-out sections of the internal packaging, so
take care not to miss these items. Once all items are removed from the packaging, use the list below to
check that nothing is missing.
• 18.5” (47cm) LED LCD TV 1 piece
• Desk base stand 1 piece
• Neck bracket (links TV body & base stand) 1 piece
• User Manual 1 piece
• Remote Control 1 piece
• Pack of 4 screws (1 x long, 3 x short) 1 piece
• Pack of 2 “AAA” size batteries 1 piece
• Pack of 4 M4 screws 1 piece
NB. Some TV models will come with the neck bracket already tted to the bottom of the TV’s body, so
there may be fewer screws supplied separately.
Once all the accessory items have been accounted for, prepare a location where you can attach the
base stand to the body of the TV. You will need to arrange a soft cloth that is large enough to cover
the front face of the TV (for protection of the LCD screen), as well as a Philips head screwdriver to
attach the neck bracket and base stand.
Before proceeding to the Getting Started section of this manual, please continue reviewing this Instala-
tion chapter to ensure that your TV is correctly connected to your TV antenna and related AV equip-
ment (eg. DVD or Blu-ray player, amplier, sound bar etc).
Base Stand Assembly Instruction

8
INSTALLATION
1. If not already tted at the factory, locate the bottom neck bracket into the gap in the bottom of
the TV, and check that it is securely held in place by the 1 long screw, as per a) below.
2. Gently slide the now tted neck bracket at the bottom of the TV into the slot in the base stand.
Secure the base stand using the 3pcs supplied screws, as per b) below, and check that each
screw is rmly tightened.
Wall mounting installation guidelines
For wall mounting with an optional bracket, please read the following instructions in conjunction
with the bracket’s instructions. Make sure qualied service personnel perform the operation.
This television can be wall mounted as follows:
1. Place the LED LCD Television face down onto a solid surface. Please place some soft cloth
hmaterial over the front of the screen to help protect it from any damage. The LCD panel is a
fragile component, and must be suitably protected when removing the base stand. Be sure that
no hard or sharp objects can come into contact with the screen’s surface. Do not exert pressure
on the front of the unit at any time, as this may damage the LCD screen.
2. Remove the 1 long screw from the lower part of the television, where the neck bracket joins to
the. TV’s body, and take away the stand (put the stand and screws somewhere safe for future
use).
3. Use the four M4 screws provided with your TV to x it onto your wall mounting bracket (not
included) via the four VESA standard holes on the back of the television.

9
INSTALLATION
Antenna
AC Input
100-240V~ 50/60Hz 28W
N.B. Unwind the mains power cord
to its full length prior to initial use,
and locate it away from other cables
that will be connected to the TV
FRONT PANEL layout
1: Remote control sensor.
2: Power indicator LED:
RED = Stand-by.
3: Keyboard (on side of TV).
4: Main power switch (on bottom
right-hand panel of TV)
The remote control needs to be pointed directly,
within +/- 30 , of the sensor on the front of the
TV for reliable operation.
NB. There will be a 5-10 second delay between
the power indicator LED changing colour and the
TV responding.
KEYBOARD layout (side-panel)
This TV is most easily operated using the supplied Remote Control unit, but in the event that the
Remote is not available, there are various alternative controls for basic functions located on the
right-hand side panel of the TV (when viewed from the front of the TV).
1. OPEN/CLOSE
OPEN or CLOSE DVD slot (N.B. Read the DVD Operation
chapter for important usage warnings).
2. PLAY/PAUSE
PLAY or PAUSE playback.
3. SOURCE
Displays the input source Menu.
4. MENU
Displays the main MENU.
5. CH+/CH-
IN TV mode, press “CH+” or “CH-” to
change the channel up or down.
In MENU mode, press “CH+” or
“CH-” to select items.
6. VOL+/VOL-
Adjuststhe sound level.
In MENU mode, press “VOL+” or “VOL-” to adjust the item that you have selected.
7. STANDBY
Once the TV’s main power switch has been activated, press this button to turn the unit ON from
STANDBY mode. Press it again to return the set back to STANDBY. This Standby button performs the
same operation as the Power/Standby button on the Remote Control.

10
INSTALLATION
REAR AV Connections
When viewed from the rear of the TV, the following terminals/connections are visible (from left
to right):
• AC mains power cord
• AV INPUT sockets - RCA type socket for Composite type VIDEO input, and RCA type sockets
for Left and Right audio inputs.
• AV OUTPUT sockets - RCA type socket for Composite type VIDEO output, and RCA type sock-
ets for Left and Right audio outputs.
Note: These input and output sockets provide different functionality based on what mode the
TV is in.
- During ATV reception, DVD playback (using the inbuilt player) and AV mode operation, the
AV OUTPUT sockets provide both Video and Audio outputs.
- During DTV reception, USB playback and HDMI input operation, the AV OUTPUT sockets
provide only Audio outputs.
- During AV mode operation, the AV INPUT sockets will disregard the audio inputs unless
they are accompanied by a composite Video input signal.
- Some settings on the TV (eg. the Mute control, Sound Menu settings etc) do not affect the
audio signal from the AV OUTPUT socket.
SIDE AV Connections
When viewed from the side of the TV, the following connections are visible (from left to right):
• HDMI 1 Input, HDMI 2 Input, HDMI 3 Input
• USB socket for HDTV record/playback
• VGA Input (analogue, 15 pin D-type socket)
• PC Audio Input
• Headphone Output (3.5mm stereo socket)
• Coaxial digital Audio Output (RCA socket)
• RF (TV Antenna) Input
Note: When an HDMI port detects a DVI format signal, the matching audio signal is received
through the PC Audio input socket.
- Don’t connect both an HDMI and an AV cable to the same device (eg. Blu-ray player).
- Use USB ash-drives or low-power portable USB hard-drives for HDTV recording.
- Only the HDMI 1 input supports ARC (Audio Return Channel) and you must use an HDMI
cable that supports ARC and CEC operation.
- All HDMI inputs support limited CEC (Consumer Electronics Control) functionality.

11
INSTALLATION
AV EQUIPMENT connections
You can use the input and output terminals on the TV set as follows for basic accessory
inter-connections.
a) HDMI (basic)
HDMI is a digital connection system that can carry both video and audio information. Using
HDMI connections to this TV is recommended where accessory equipment can support
higher resolution modes (such as 1080i/1080p) from products such as upscaling DVD
players, Blu-ray players and high-performance gaming consoles.
For basic HDMI installations, where an external surround sound processor/amplier is not
being used, connect your accessory equipment directly to the HDMI sockets on this TV
using high quality HDMI certied cabling that supports ARC and CEC operation. All the
HDMI inputs support limited HDMI CEC (Consumer Electronics Control) functionality (refer
to page 24 for further details on CEC operation).
b) HDMI (advanced)
When using a Surround/AV amplier system, there are numerous connection possibilities,
depending on the capabilities of the amplier equipment. In most cases, external
accessories (such as a Blu-ray player or gaming console) that were previously connected
directly to the TV would now be connected to the amplier via HDMI, and a seperate HDMI
cable would then be connected between the TV and the AV amplier.
This system then allows the Surround/AV amplier to process the surround channels and
correctly align the video and audio timing. If your Surround/AV amplier supports HDMI
ARC (Audio Return Channel), then the HDMI ARC compliant cable connecting the amplier
and TV together must be connected to the HDMI 1 input on this TV, otherwise a separate
audio connection (either analogue or coaxial digital) would also be required between the TV
and the AV amplier. Refer to the User Manual for your AV amplier for details on its specic
cabling requirements.

12
INSTALLATION
c) AV (Audio/Video)
This TV provides an AV input and output using line-level analogue stereo Audio and
composite format Video signals for compatibility with earlier accessory devices eg. VCRs,
CRT TVs, basic gaming consoles etc. Refer to page 10 regarding the specic characteristics
of these AV sockets. For optimum composite video quality, use only well shielded 75 ohm
video-grade cables.
d) AUDIO
For installations where you have an existing stereo system and wish to improve your
listening experience, connect a stereo RCA cable between the AV Output L/R sockets on
this TV and the appropriate line-level inputs (eg. AUX input) on your amplier.
NB. Take care when powering up your TV/amp combination, as there may be some click or
pop sounds on the audio output of the TV during its powering up/down phase that can be
amplied by your sound system. It is highly recommended that the TV is rst powered up,
and then when its screen is active, you then power up your amplier. When powering down
the TV/amp system, turn Off your amplier rst and then switch the TV back to its Standby
state.

13
INSTALLATION
PC Connections
This TV provides an analogue VGA input (15pin) for connection to various desktop or laptop
computers. Refer to
your computer’s User manual or support website to determine if your computer may be compatible,
and what
connection cabling will be needed.
STEPS:
Be sure both the TV and computer are set to
Power off.
1.Connect a VGA and audio cable.
2.Connect the power cord.
3.Power on the TV, switch to PC mode.
4.Power on the PC.
This connection and power-up sequence is very
important. Also, for higher resolution
applications, the use of a high quality shielded
VGA cable is recommended.
PRESET MODE
The above resolutions are the only ones guaranteed to be supported. Other resolutions may also be
supported, but this must be assessed by the user on a case-by-case basis. This is also subject to the
limitiations of the computer’s video card.
ADJUSTABLE MODES
While this TV may support higher resolutions thru both the VGA and HDMI inputs, such operation is
dependant on
the capabilities of the attached PC (including its graphics card, system set-up and operating system)
as well as the
user’s ability to adjust the PC’s settings for optimum screen performance. Some PC graphics cards
will not
correctly identify the TV’s capabilities and hence will only allow lower resolution screen displays.

14
REMOTE CONTROL
33-37

15
REMOTE CONTROL /GETTING STARTED
TELETEXT and SUBTITLES
Teletext is an information system broadcast in certain countries which can be consulted like a
newspaper. It may also offer access to subtitles for viewers with hearing problems or who are not
familiar with the transmission language (Refer to your local TV guides or internet program lists to
determine if Teletext is used in your area.)
Getting Started :
Once you have connected your TV antenna and other AV playback equipment (eg. CD, DVD, Blu-ray
player) to the appropriate input sockets on the rear and side of the TV, you will need to be comfortable
with selecting several basic operations before setting up your TV using the Menu system.
Firstly, the TV has two power modes – Standby and On. In Standby mode, the TV is powered up, but
awaits a “power On” command from either the Remote Control or from the Standby push-button locat-
edon the lower right-hand side of the TV.
To switch the TV from off into Standby mode, activate the main On/Off rocker switch located at the
bottom right side of the TV, and wait for the Red power indicator on the front of the TV to light up.
Then, press the red power button on the Remote Control to fully activate the TV (ie. move from Standby
to On mode). The power LED on the front of the TV will change from Red to Blue when the TV is fully
powered up, and after approx 10 seconds the screen will become active and can be commanded using
the Remote Control.

16
GETTING STARTED
First Powering on the TV :
When you first power up your TV, (or you reset the TV to its factory settings), it will
automatically enter the TV Auto Tuning mode. This is where the TV searches for
available TV stations and stores the station details it finds. Make sure your TV
antenna is connected before proceeding with this operation.
By default, an On Screen Display will offer a language selection (pre-set to English), so
just press the OK button on the Remote Control to confirm this option. The OK button is
located in the middle of the cursor arrow button area of the Remote Control.
The TV will then offer a selection of countries, with Australia as the pre-set option.
Again press the OK button to confirm this selection. Your TV will now scan through
all the analogue TV (ATV) and digital TV (DTV) stations that it can receive using the
connected antenna. This process may take several minutes, but once completed, the TV
will skip to the first DTV program.
The “radio” channels found during the TV Auto Tuning function are the sound-only
services provided by some TV stations.
Using the Main Menus :
Once the TV has run through the Auto Tune mode and found the available programs,
you will then need to know how to select the relevant input you want (eg. DTV, AV,
HDMI etc), and also how to select and adjust the various Menus that allow you to tailor
the operation of the TV to suit your application.
The following pages marked “Menu Settings” will cover the usage and settings of the
various menus in more detail. Please read them carefully to gain the most benefit from
your TV.

17
Firstly, on the upper-middle section of the Remote Control are the main cursor selector
arrows with the OK button in the middle of them. Directly above and to the left of the
cursor arrows is the Main Menu selector button, which displays the Main Menus on
the TV’s screen. In the following section of the User Manual, when the operation of the
options in the Main Menus are being described, you first need to press the Main Menu
button to activate the Menu function, then press the Left or Right cursor arrow buttons
to select the relevant Menu, and the Up or Down cursor arrow buttons to move within
the options inside each Menu. If at any time you mis-select a Menu or setting, press the
Exit button (located on the bottom right-hand side of the cursor arrow buttons) to exit
the Menu setting.
GETTING STARTED

18
To access the Input Source menu, where you can select ATV or DTV reception, plus
access signals from your connected Audio/Video devices (eg, via AV Composite video,
HDMI, or PC VGA), press the Input Source button located at the top right-hand side
of the cursor selector arrow section of the Remote Control, and once the Input Source
menu appears, use the Up or Down cursor arrow keys to select the desired input, then
press the OK button.
1.CHANNEL MENU
The first item of the MENU is the Channel menu (for ATV or DTV source only). ATV =
Analogue TV, DTV = Digital TV.
1). Auto Tuning:
When Auto Tuning is manually selected via the Channel Menu (rather than when the
TV is first powered On or reset), you will first need to select the Tune Type. You can
select between ATV, DTV, or DTV+ATV searching.
Press to select search type, then press to select country (eg. Australia),
then press the OK
button to start auto tuning.
All the channels including ATV, DTV and Radio can be tuned at once, if the Tune Type
is set to DTV+ATV. Any previously stored channels will be deleted after auto tuning is
carried out.
After auto tuning, the receiver will skip to the first DTV channel.
The radio channels are the ones provided by some TV stations.
MENU SETTINGS

19
MENU SETTINGS
2). DTV Manual tuning:
You can select a DTV channel and find out how many programs are being transmitted
on this channel. Press to select the channel, then press OK to search the
programs.
NOTE:
The Bad Normal Good bar graph on this screen shows the relative signal intensity
during DTV reception only. To obtain more detail regarding the signal quality and
strength of a received DTV station, refer to the Signal Information option in this Menu.
3). ATV Manual tuning :
You can change the sound system, search the analog TV channels and fine tune them,
then store the channels you selected. In Australia and New Zealand, select the “BG”
sound system. This menu is handy if you are using your TV to watch analogue signals
from a VCR or from older equipment using an RF modulator.
NOTE:
Press the teletext red button on the remote control to store the channel details after
manual tuning.
4). Program Edit:
You can Delete, Move, Skip, or FAV most TV programs from the list of TV stations
previously located during the initial Auto Tuning process.

20
MENU SETTINGS
Delete
Press the teletext red button on the Remote Control and the program in the cursor will be
deleted from the list of stations.To restore a deleted channel, perform a complete Auto
Tune.
Skip
Press to choose the program, press the teletext blue button on the Remote Control to
skip this program from future up/down manual channel selections, and the symbol
will show on the right side of the program
name.
Choose the skipped program, press the blue button again, you can cancel the skip and
the symbol will disappear.
Favourite
Press to choose the program, press the FAV button on the remote control and it will
show a symbol on the right side of the program name and it will be added to a
Favourite List in your TV.
Choose the FAV program, press FAV button again, you can cancel the FAV setting and
the symbol will disappear. Once your Favourite List is created, you can press the
FAV key on the remote control during TV reception to quickly access your favourite
channels.
5). Signal Information: Displays the signal information in DTV (digital TV) mode only.
6). Software Update (OAD): This setting should be set to Off in Australia.
7). Software Update (USB):
WARNING: Do not attempt to use this option unless you have a valid software
program for the TV stored on a compatible USB drive, and the drive is connected to
the TV. Remove the antenna cable from the TV RF port, go to the channel Menu, select
“Software Update (USB)” and press OK to run the update.
2. PICTURE MENU
The second item of the MENU is PICTURE MENU. You can adjust picture effects here,
such as contrast, brightness, etc.
Press to move, press OK to adjust.
France
Germany
Italy
Menu
Portugal
