INSTRUCTION MANUAL
GVA22GLEDC
21.5” (54.6cm)
FHD LED TV
with Built-in DVD Player

CONTENTS
Important safety instructions 4
Safety information 4
Battery Handling and Usage 6
DISC Handling and Maintenance 6
Improper disc storage 6
Accessories 7
Features 8
Connections and functions 9
Remote control 11
Remote control preparation 13
Basic installation 14
Connecting to AC power source 14
Connect external antenna to unit 14
Composite video (cvbs) connection 15
Component (YPbPr) connection 15
HDMI Connection 16
PC/VGA Connection 16
Coaxial connection 17
Connect earphone to the unit 17
USB Connection 17
DVD 18
JPEG playback 20
Display 22
General 23
Operating the menu (dtv) 24
Photo 28
Music 29
Movie 30
Text 30

CONTENTS
Main menu 32
Dtv mode 33
Sound 34
Channel 35
Lock system 36
Setup 39
PC mode 41
Maintenance 43
Wall mounting 44
Stand installation 45
Specications 46
General troubleshooting 47

4
IMPORTANT SAFETY INSTRUCTIONS
Safety information
CAUTION:
Dvd/video cd/cd player is a class 1 laser product. However this Dvd/video cd/cd player
uses a visible laser beam which could Cause hazardous radiation exposure if directed. Be
sure to Operate the dvd/video cd/cd player correctly as instructed.
When this dvd/video cd/cd player is plugged to the wall outlet, do Not place your eyes
close to the opening of the disc tray and Other openings to look into the inside of this
player.
Use of controls or adjustments or performance of procedures Other than those specied
herein may result in hazardous Radiation exposure.
Do not open covers and repair yourself. Refer servicing to Qualied personnel.
WARNING:
- To prevent re or shock hazard. Do not use this power cord with An extension cord,
receptacle or other outlet unless the blades Can be fully inserted to prevent blade exposure.
- To prevent re or shock hazard. Do not expose this appliance to Rain or moisture.
CAUTION - laser radiation when open, do not stare into beam. Ventilation warning - the
normal ventilation of the product shall Not be impeded for intended use.
Always follow basic safety precautions when using electrical products, especially when
children are present.
WARNING: To avoid the risk of electrical shock, make sure the product is unplugged from
the electrical outlet before relocating, servicing, or cleaning it.

5
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using
• Do not use this product near water.
• Install the product in accordance with the operating instructions.
• Connect this product to the power outlet which has protective earth connection.
• Do not set the product near heat sources, such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
• Protect the power cord from being walked on or pinched, particularly at
plugs,convenience receptacles, and the point where they exit the product.
• Where the MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
• Unplug the product during lightning storms or when unused for long periods of time.
• The product shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the product.
• Do not place in or expose the product to direct sunlight, extreme heat, humid or dusty
locations.
• Never operate this product if it has a damaged power cord or plug, do not work
properly, has been dropped, damaged, or exposed to moisture, water, or other liquids.
• Do not attempt to examine or repair this product yourself; take the product to a service
center for inspection and repair.
• Keep magnetic objects such as speakers, at a distance from the player.
• Connect this product to the power outlet which has protective earth connection.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modications. Such modications could void the user’s authority to operate
the equipment.
• Operate turning controls and switches as instructed in the manual.
• Before turning on the power for the rst time, make sure that the power plug is properly
installed.
• Store your discs in a cool area to avoid damage from heat.

6
IMPORTANT SAFETY INSTRUCTIONS
Battery Handling and Usage
• Keep batteries away from children and pets. Only adults should handle batteries.
• Never throw batteries into a re or expose them to re or other heat sources.
• Follow the battery safety and usage instructions.
DISC Handling and Maintenance
Handling precautions
• Hold the disc by the edges so the surface will not be soiled with ngerprints.
Fingerprints, dirt and scratches can cause skipping and distortion.
• Do not write on the label side with a ball-point pen or other writing utensils.
• Do not use record cleaning sprays, benzine, thinner, static electricity prevention liquids.
• Be careful not to drop or bend the disc.
• Do not install more than 1 disc on the disc compartment.
• Do not try to close the disc cover when the disc is not installed properly.
• Be sure to store the disc in its exclusive case when not in use.
If the surface is soiled
Wipe gently with a soft, damp (water only) cloth.
When wiping discs, always move the cloth from the center hole toward the outside, which
will not cause distortion. (If you wipe the discs using a circular motion, circular scratches
are likely to occur, which will cause distortion.)
If the disc is brought from a cold to a warm environment, moisture may form on the disc.
Wipe this moisture off with a soft, dry, lint-free cloth before using the disc.
Improper disc storage
You can damage discs if you store them in the following places:
• Areas exposed to direct sunlight
• Humid or dusty areas
• Areas directly exposed to a heat outlet or heating appliance

7
ACCESSORIES
All the pictures in this manual are just for your reference, appearance and
display
Quick Guide
Quick Guide

8
FEATURES
21.5” LED Display
This unit has a built-in 21.5” LED display window to provide clear
vision and low radiation.
Support Digital Broadcasting Reception
Support H.264 High Definition Display
Support Multiple OSD Languages
Support Full Function Remote Control
Support HDMI, PC AUDIO, VGA, YPbPr, CVBS and AUDIO R/L Input
Support Earphone and Coaxial Output
Support Auto TV Scanning
NOTE: For detailed operations, please refer to the guide on Page 34.
Support TV Guide
NOTE: For detailed operations, please refer to the guide on Page 24.
Support TELETEXT Function
NOTE: For detailed operations, please refer to the guide on Page 25.
Support USB Multimedia Playback
NOTE: For detailed operations, please refer to the guide on Page 27.
Support PVR Function
NOTE: For detailed operations, please refer to the guide on Page 26.
Support TIME SHIFT Function
NOTE: For detailed operations, please refer to the guide on Page 26.
With Built-in DVD Player
With Detachable Stand Holder
With External Antenna Jack
With Built-in Speakers
With Noise Reduction Function
Warm Tips: For detailed formats that your memory device supports,
please refer to the specifications on Page 46.

9
CONNECTIONS AND FUNCTIONS
MAIN UNIT
Front View Side View
Back View
1. LED display screen
2. Power indicator- In standby mode the
indicator light is red; when switching
on the unit the indicator light is blue
colour.
3. Remote control sensor
4. Stand holder
5. Disc slot- To insert a disc according to
the silk screen on the side of this slot.
6. - To play or pause playing (DVD).
7. - To open or close the disc compart-
ment.
8. VOLUME +/- button- To increase/
decrease the volume level or move
left/right.
9. CHANNEL +/- button- To select next/
previous channel or move up/down.
10. MENU button- To enter menu setting
page.
11. SOURCE button- To select the input
source.
12. POWER button- To turn the TV ON/
OFF.

10
CONNECTIONS AND FUNCTIONS
Back View
1. EARPHONE output terminal
2. PC AUDIO input terminal
3. VGA input terminal
4. Y / Pb / Pr input terminals
5. COAXIAL output terminal
6. RF input terminal- To connect the external antenna.
7. AUDIO R/L input terminals
8. CVBS (Video) input terminal
9. USB input terminal- For multimedia les playback.
10. HDMI input terminals
11. Built-in speakers

11
REMOTE CONTROL

12
REMOTE CONTROL

13
REMOTE CONTROL PREPARATION
BATTERY INSTALLATION
Install the batteries as the following pictures. Be sure + and – terminals are positioned as indicated in
the battery compartment (Fig1).
SERVICE LIFE OF BATTERIES
- The batteries normally last for one year although this depends on how often the remote control is
used.
- If the remote control fails to work even when it is operated near the player, replace the batteries.
- Use two size AAA dry batteries.
NOTE:
• Do not drop, step on or otherwise impact the remote control. This may damage the parts or lead
to malfunction.
• If the remote control is not going to be used for a long time, remove the batteries.
REMOTE CONTROL OPERATION
Point the remote control from no more
than about 6m from the remote control
Sensor and within about 60°of the
front of the player (Fig2).
NOTES:
- The operating distance may vary
according to the brightness of the
room.
- Do not point bright light at remote
control sensor.
- Do not place objects between the
remote control and the remote control
sensor.
- Do not use this remote control while
simultaneously operating the remote
control of any other acquirements.

14
BASIC INSTALLATION
• Ensure all the cables are disconnected from the main unit before connecting to AC
power source.
• Read through the instructions before connecting other equipment.
Connecting to AC power source
Main unit
To power outlet
Connect external antenna to unit
Install external antenna into antenna jack for best picture.
Power plug
of antenna
amplifier
Indoor
antenna
amplifier
Outdoor
antenna
amplifier
Antenna
75 OHM
antenna
plug

15
Composite video (cvbs) connection
BASIC INSTALLATION
AV cable
(Not included)
For basic connection, use the
composite Audio L/R (white/
red) and CVBS (yellow) cable
to connect the unit with other
devices.
Component (YPbPr) connection
AUDIO cable
(Not included)
YPbPr cable
(Not included)

16
HDMI Connection
BASIC INSTALLATION
HDMI cable
(Not included)
Use HDMI cable to connect
the unit with other devices
to receive high-definition
multimedia signal.
PC/VGA Connection
VGA cable
(Not included)
Audio cable
(Not included)
Use VGA cable and Audio
cable to connect the unit with
TV or PC, and use this product
as a monitor.

17
BASIC INSTALLATION
Coaxial connection
Use coaxial cable to connect the unit with amplifier or
other audio decoding devices for coaxial audio signal
output.
(Coaxial cable is not included)
Connect earphone to the unit
USB Connection
EARPHONE cable
(Not included)
USB device
(Not included)

18
BASIC OPERATIONS
Make sure all the equipment and power plug are connected properly
and the unit is set in correct mode before kinds of operations.
• Press POWER button on the unit or remote control to power ON the unit (indicator
will glow blue); press it again to power OFF (standby mode) the unit (indicator will
glow red).
DVD
Press SOURCE button on the unit or remote control to switch the unit to DVD mode.
1. Basic play
a) Make sure the disc compartment has no disc. Place a disc into the disc compartment.
Hold the disc without touching either of its surfaces, position it with the readable
(mirror) side facing towards you, then the disc will automatically enter into the disc
compartment; or you can press button remote control to enter the disc into the disc
compartment.
b) Once the disc is in the disc compartment, the player starts to read the disc
immediately.
c) When a menu screen appears on the unit, press the navigation buttons or press the
number buttons to select preferred track number, then press OK button to confirm.
d) To stop playing and return to the menu screen, press TITLE or D.MENU button.
2. Stopping play
Press █ (STOP) button to stop playing.
NOTE: When player is stopped, the player records the point where STOP was pressed
(RESUME function). Press button again, playback will resume from this point. When
the tray is taken out or █ (STOP) is pressed again, the RESUME function will be cleared.
3. Skipping ahead or backward
Skipping ahead
During playback, press button to skip the next chapter (DVD) or a track (Video CD/
CD).
Skipping backward
During playing, press button to skip the previous chapter (DVD) or track (Video
CD/CD).

19
BASIC OPERATIONS
4. Fast forward/Fast backward
During playback, press button or button
to fast forward/backward.
Press button to resume normal play.
5. Pause/play
During playback, press button to pause
playing, press it again to resume normal
playback.
6. Music playback
a) Insert the disc which contains music files and after a
few seconds, the screen will show all the folders on the
disc.
b) Select the folder you want to play by navigation
buttons and press the OK button to confirm.
c) The files in this folder are displayed and select the
desired song by navigation buttons, then press the
or OK button to start playback.
d) In file selecting page, press or button to
turn to next or previous page.
e) Press REPEAT button on remote control to change play mode.
- SINGLE: play one file only.
- REPEAT ONE: repeat one file.
- REPEAT FOLDER: all the files in the folder will be played repeatedly.
- FOLDER: all the files in the folder will be played.
NOTE: The available repeat modes may vary for different disc.
7. Movie playback
a) Insert the disc which contains movie files and after a
few seconds, the screen will show all the folders on the
disc.
b) Select the folder you want to play by navigation
buttons and press the OK button to confirm.
c) The files in this folder are displayed and select the
desired file by navigation buttons, then press the
or OK button to start playback.

20
d) During normal playing, press or button, the player will play the next or
previous file.
e) Press REPEAT button to change play mode.
- SINGLE: play one file only.
- REPEAT ONE: repeat one file.
- REPEAT FOLDER: all the files in the folder will be played repeatedly.
- FOLDER: all the files in the folder will be played.
NOTE: The available repeat modes may vary for different disc.
f) Press D.MENU button to return to play list page.
8. JPEG playback
For JPEG picture CD, select the folder you want to play
by the navigation buttons and press OK button to
confirm. The files in this folder are displayed and select
your pictures by using the up/down navigation buttons
and press OK button to start playback. Thumbnail of
picture will be displayed while you scrolling across the
file name. Then press the or OK button to start
playback.
NOTE: The time of loading and displaying a picture
depends on its size.
During playback, press D.MENU button to return to file selecting page.
Press REPEAT button to change play mode.
- SINGLE: play one file only.
- REPEAT ONE: repeat one file.
- REPEAT FOLDER: all the files in the folder will be played repeatedly.
- FOLDER: all the files in the folder will be played.
NOTE: The available repeat modes may vary for different disc.
Skip to next/previous picture
Press button to skip to the next picture or button to skip to the previous picture. If
no key
is pressed for 3 seconds, it will skip to next picture automatically.
Rotating pictures
- Press RIGHT navigation button to rotate the picture clockwise.
- Press LEFT navigation button to rotate the picture counter-clockwise.
BASIC OPERATIONS
