GVA GVA22FLEDA User manual

Instruction Manual
21.5” (54cm) FHD LED LCD TV
/ GVA22FLEDA

Contents
Preface 3
Safety Precautions 3
In the carton 5
Front Back Connections of LED 6
TV Installation Drawings 7
Power Cord Connection 7
Antennas Connection 7
HDMI Connection 8
VGA Connection 8
COAX Connection 9
USB Connection 9
AV Connection 10
YPbPr Connection 10
Remote Control 11
Remote Control Instructions in TV/Media mode 11
Remote Control Setup 13
Menu Operation 14
Installation Guide 14
CHANNEL Menu 14
PICTURE Menu 17
SOUND Menu 19
TIME Menu 20
OPTION Menu 21
LOCK Menu 22
Hotel Setting 23
Input Source 24
EPG and Channel List Menu 25
Multimedia (Media) Menu 26
PVR Menu 32
Troubleshooting and Advise 28
Specications 39

3
Preface
Safety Precautions
Thank you for buying this TV ! Please read this manual thoroughly before operating the TV.
Make sure the TV was not damaged in transit. Should the TV is damaged, do no install it and
contact your dealer. Check that you have all the accessories according to the model.
2
1.PREFACE
Thank you for buying this TV ! Please read this manual thoroughly before operating the TV. Make
sure the TV was not damaged in transit. Should the TV is damaged, do no install it and contact
your dealer. Check that you have all the accessories according to the model.
2.SAFETY PRECAUTIONS
Power cord and cables must be properly routed and protected to prevent
people from stepping on them and causing the TV to fall.
Put the TV on a stable surface.
Do not place any material on the TV.
Do not block or cover the ventilation openings on the
If you have a wall mount, check that it is steady.
TV.
Minimum distances
10cm
20cm
10cm 5cm
Do not use the TV with fixtures other than those provided or
suggested by the manufacturer.
Keep the TV dry and away from humidity.
Put the TV on stable surface.
Do not place any material on the TV.
Do not use the TV with xtures other than those provided or
suggested by the manufacturer.
Do not block or cover the ventilation openings on the
If you have a wall mount, check that it is steady.
TV.
Power cord and cables must be properly routed and protected to
prevent people from stepping on them and causing the TV to fall.
Keep the TV dry and away from humidity.

4
3
Keep the TV away from heat sources.
Unplug the before cleaning it. Do not use solvent or liquid
clean the TV.
TV to
Only clean the TV with a soft and dry cloth.
Unplug the TV during lightening storms or when unused for long
periods of time.
In case of troubleshooting, do not use spare parts other than
those suggested by the manufacturer. Using inadequate spare
parts can lead to electric shocks, short-circuits fire or other
incidents.
1.where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable;
2.A warning that batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
3.A warning that an apparatus with CLASS I construction shall be connected to a MAINS socket
outlet with a protective earthing connection.
IMPORTANT INFORMATI O N
If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due
to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as:
· Using cabinets or stands recommended by the manufacturer of the television.
· Only using furniture that can safely support the television.
· Ensuring the television is not overhanging the edge of the supporting furniture.
· Not placing the television on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television to a suitable support.
· Not standing the televisions on cloth or other materials placed between the television and
supporting furniture.
· Educating children about the dangers of climbing on furniture to reach the television or its controls.
Keep the TV away from heat sources.
Unplug the before cleaning it. Do not use solvent or liquid to
clean the TV. Only clean the TV with a soft and dry cloth.
In case of troubleshooting, do not use spare parts other than
those suggested by the manufacturer. Using inadequate spare
parts can lead to electric shocks, short-circuits re or other
incidents.
Unplug the TV during lightening storms or when unused for long
periods of time.
1. Where the MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable;
2. A warning that batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, re or the like.
3. A warning that an apparatus with CLASS I construction shall be connected to a MAINS
socket outlet with a protective earthing connection.
IMPORTANT INFORMATION
• If a television is not positioned in a suciently stable location, it can be potentially
hazardous due to falling. Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge of the supporting furniture.
• Not placing the television on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and the television to a suitable support.
• Not standing the televisions on cloth or other materials placed between the television
and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television or
its controls.
Safety Precautions

5
In the carton
4
3. IN THE CARTON
Remote Control
1.5V
1.5V
AAA Batteries
TV SET
USER'S MANUAL
User's Manual
Adapter & Power Cord
TV SET Remote Control
4
3. IN THE CARTON
Remote Control
1.5V
1.5V
AAA Batteries
TV SET
USER'S MANUAL
User's Manual
Adapter & Power Cord
Adaptor & Power Cord AAA Batteries
4
3. IN THE CARTON
Remote Control
1.5V
1.5V
AAA Batteries
TV SET
USER'S MANUAL
User's Manual
Adapter & Power Cord
User’s Manual

6
Front & Back Connections of LED
Front View
(Picture are for reference only.)
(The sample is subject to the real product.)
4. FRONT & BACK CONNECTIONS OF LED
Back View and Control Connections
5
: Connect to a headphone set.
9
10
1.DC IN: DC input socket.
USB: Connect to the External drive.
. COMPONENT IN: Connect the YPbPr output
jack of DVD or VCR.
7
.
. COAX:
AV IN Connect the Video Audio output jack
of DVD or VCR.
2.
3. HDMI1/HDMI2: Connect the HDMI output jack
of DVD.
4. VGA: Connect the PC-RGB output jack of PC.
5. PC AUDIO : Connect the right Audio out put jack
of PC.
6
. RF IN: Connect the antenna.
8
Connect the audio amplifier.
. : /
COAX HDMI2 VIDEO L R
AV I N
HDMI1 VGA AUDIO Y Pb Pr
COMP ON EN T IN
PC I N
RF IN
1 2 3456 7 8 310
USBDC IN
9
1. Press“SOURCE”to select the input source.
2. Press “MENU”to bring up the main menu on the screen.
3. Press“CH+”or “CH-”.
4. Press“VOL+”or “VOL-”to increase or decrease the sound level.
5. Press“POWER” button to turn standby mode on or off.
6. .
7. .
to change channels
ON/OFF LED Indicator: Shows red in standby mode and green while your TV is turned on
IR Sensor: Infrared sensor for the remote control
Front View
1. Press“SOURCE”to select the input source.
2. Press“MENU”to bring up the main menu on the screen.
3. Press“CH+”or “CH-” to change channels .
4. Press“VOL+”or “VOL-”to increase or decrease the sound level.
5. Press“POWER”button to turn standby mode on or o.
6. ON/OFF LED Indicator: Shows red in standby mode and green while your TV is turned
on.
7. IR Sensor: Infrared sensor for the remote control.
Back View and Control Connections
4. FRONT & BACK CONNECTIONS OF LED
Back View and Control Connections
5
: Connect to a headphone set.
9
10
1.DC IN: DC input socket.
USB: Connect to the External drive.
. COMPONENT IN: Connect the YPbPr o
utput
jack of DVD or VCR.
7
.
. COAX:
AV IN Connect the Video Audio outp
ut jack
of DVD or VCR.
2.
3. HDMI1/HDMI2: Connect the HDMI outp
ut jack
of DVD.
4. VGA: Connect the PC-RGB output jac
k of PC.
5. PC AUDIO : Connect the right Audio ou
t put jack
of PC.
6
. RF IN: Connect the antenna.
8
Connect the audio amplifier.
. : /
CO AX HDMI2 VI DEO L R
AV I N
HDMI1 VGA AUDIO Y Pb Pr
COMPONENT IN
PC I N
RF IN
1 2 3456 7 8 310
USBDC IN
9
1. Press“SOURCE”to select the input source.
2. Press “MENU”to bring up the main menu on the screen.
3. Press“CH+”or “CH-”.
4. Press“VOL+”or “VOL-”to increase or decrease the sound level.
5. Press“POWER” button to turn standby mode on or off.
6. .
7. .
to change channels
ON/OFF LED Indicator: Shows red in standby mode and green while your TV is turned on
IR Sensor: Infrared sensor for the remote control
Front View
1. DC IN: DC Input socket.
2. USB: Connect to the External drive.
3. HDMI1/HDMI2: Connect the HDMI output jack
of DVD.
4. VGA: Connect the PC-RGB output jack of DVD.
5. PC AUDIO: Connect the right Audio output jack
of PC.
6. COMPONENT IN: Connect the YPbPr output jack
of DV D or VCR.
7. RF IN: Connect the antenna.
8.
4. FRONT & BACK CONNECTIONS OF LED
Back View and Control Connections
5
: Connect to a headphone set.
9
10
1.DC IN: DC input socket.
USB: Connect to the External drive.
. COMPONENT IN: Connect the YPbPr output
jack of DVD or VCR.
7
.
. COAX:
AV IN Connect the Video Audio output jack
of DVD or VCR.
2.
3. HDMI1/HDMI2: Connect the HDMI output jack
of DVD.
4. VGA: Connect the PC-RGB output jack of PC.
5. PC AUDIO : Connect the right Audio out put jack
of PC.
6
. RF IN: Connect the antenna.
8
Connect the audio amplifier.
. : /
COAX HDMI2 VIDEO L R
AV I N
HDMI1 VGA AUDIO Y Pb Pr
COMP ON ENT IN
PC I N
RF IN
1 2 3456 7 8 310
USBDC IN
9
1. Press“SOURCE”to select the input source.
2. Press “MENU”to bring up the main menu on the screen.
3. Press“CH+”or “CH-”.
4. Press“VOL+”or “VOL-”to increase or decrease the sound level.
5. Press“POWER” button to turn standby mode on or off.
6. .
7. .
to change channels
ON/OFF LED Indicator: Shows red in standby mode and green while your TV is turned on
IR Sensor: Infrared sensor for the remote control
Front View
: Connect to a headphone set.
9. COAX: Connect the audio amplier.
10. AV IN: Connect the Video/Audio output jack of
DVD or VCR.

7
TV Installation Drawings
Power Cord Connection
DC12V IN
5. TV INSTALLTION DRAWINGS
75 OHM
ANTENNA
PLUG
POWER PLUG OF
ANTENNA
AMPLIFIER
OUTDOOR
ANTENNA
AMPLIFIER
VHF ANTENNA UHF ANTENNA
INDOOR
ANTENNA
AMPLIFIER
6
Power Cord Connection
Antennas Connection
- Connect the power cord correctly as shown.
- Press the POWER switch of your LED TV to switch on the LED TV.
The power indicator on the front panel lights up in Green or Blue.
RF IN
To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as
Shown can be soured from TV equipment shops, which will provide service for correct installation
and connection. After installation, insert the 75-ohm antenna plug into the antenna jack as shown.
DC12V IN
5. TV INSTALLTION DRAWINGS
75 OHM
ANTENNA
PLUG
POWER PLUG OF
ANTENNA
AMPLIFIER
OUTDOOR
ANTENNA
AMPLIFIER
VHF ANTENNA UHF ANTENNA
INDOOR
ANTENNA
AMPLIFIER
6
Power Cord Connection
Antennas Connection
- Connect the power cord correctly as shown.
- Press the POWER switch of your LED TV to switch on the LED TV.
The power indicator on the front panel lights up in Green or Blue.
RF IN
To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as
Shown can be soured from TV equipment shops, which will provide service for correct installation
and connection. After installation, insert the 75-ohm antenna plug into the antenna jack as shown.
- Connect the power cord correctly as shown.
- Press the POWER switch of your LED TV to switch on the LED TV.
The power indicator on the front panel lights up in Green or Blue.
Antennas Connection
To ensure good picture and sound, TV antenna system needs to be installed. The antenna
system as shown can be soured from TV equipment shops, which will provide service for
correct installation and connection. After installation, insert the 75-ohm antenna plug into
the antenna jack as shown.

8
HDMI Connection
HDMI1 VGA AUDIO Y Pb Pr
COMPONENT IN
PC I N
RF IN
USBDC IN
HDMI1 VGA AUDIO Y Pb Pr
COMPONENT IN
PC I N
RF IN
USBDC IN
7
The HDMI input connection enables the digital transfer of audio/video/control signals through one
cable only.
TV Back
Audio Cable
TV Back
HDMI Connection
VGA Connection
TV Back
VGA Cable
Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output of the
PC to the PC AUDIO jack on the set . Select the VGA input source with using SOURCE button on
the remote control.
CO AX HDMI2 VI DEO L R
AV I N
HDMI Cable
DVD or VCR
DVD or VCR Back
HDMI Cable
DVD or VCR
DVD or VCR Back
The HDMI input connection enables the digital transfer of audio/video/control signals
through one cable only.
VGA Connection
Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output
of the PC to the PC AUDIO jack on the set . Select the VGA input source with using SOURCE
button on the remote control.
HDMI1 VGA AUDIO Y Pb Pr
COMP ON EN T IN
PC I N
RF IN
USBDC IN
HDMI1 VGA AUDIO Y Pb Pr
COMP ON EN T IN
PC I N
RF IN
USBDC IN
7
The HDMI input connection enables the digital transfer of audio/video/control signals through one
cable only.
TV Back
Audio Cable
TV Back
HDMI Connection
VGA Connection
TV Back
VGA Cable
Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output of the
PC to the PC AUDIO jack on the set . Select the VGA input source with using SOURCE button on
the remote control.
COAX HDMI2 VIDEO L R
AV I N
HDMI Cable
DVD or VCR
DVD or VCR Back
HDMI Cable
DVD or VCR
DVD or VCR Back
TV Installation Drawings

9
COAX Connection
HDMI1 VGA AUDIO Y Pb Pr
COMP ONENT IN
PC I N
RF IN
USBDC IN
COAX HDMI2 VIDEO L R
AV I N
8
COAX Cable
COAX
the audio amplifier back
Audio amplifier
Connect to Audio Amplifier device to the COAX output jack on the TV.
USB Port
Insert the USB flash drive to the USB port. Select USB channel source via the SOURCE button
on the remote control.
TV Back
TV Back
COAX Connection
USB Connection
Connect to Audio Amplier device to the COAX output jack on the TV.
USB Connection
Insert the USB ash drive to the USB port. Select USB channel source via the SOURCE button
on the remote control.
HDMI1 VGA AUDIO Y Pb Pr
COMP ONENT IN
PC I N
RF IN
USBDC IN
COAX HDMI2 VIDEO L R
AV I N
8
COAX Cable
COAX
the audio amplifier back
Audio amplifier
Connect to Audio Amplifier device to the COAX output jack on the TV.
USB Port
Insert the USB flash drive to the USB port. Select USB channel source via the SOURCE button
on the remote control.
TV Back
TV Back
COAX Connection
USB Connection
TV Installation Drawings

10
AV Connection
HDMI1 VGA AUDIO Y Pb Pr
COMPON EN T IN
PC I N
RF IN
USBDC IN COAX HDMI2
VIDEO L R
AV I N
9
Connect the VIDEO and AUDIO output jack of the DVD or VCR to the VIDEO jacks on the TV set
using the RCA cable. Match the jack colors: Video is yellow, Audio left is white, and Audio right is red.
Select the AV input source via the SOURCE button on the remote control.
TV Back
Video cable
DVD or VCR back
DVD or VCR
Pr
Pb
Y L R
DVD or VCR
DVD or VCR Back
YPbPr Cable
Connect the YPbPr output of the DVD or VCR to the YPbPr input on the TV set. Connect the Audio
output of the DVD or VCR to the Audio input jacks on the TV set using the RCA cable.
Match the jacks colors : Y is green, Pb is blue, Pr is red, Audio left is white and Audio right is red.
Select Component input source via the SOURCE button on the remote control.
Audio Cable
AV Connection
YPbPr Connection
TV BackTV Back
COAX HDMI2 VIDEO L R
AV I N
Connect the VIDEO and AUDIO output jack of the DVD or VCR to the VIDEO jacks on the TV
set using the RCA cable. Match the jack colors: Video is yellow, Audio left is white, and Audio
right is red. Select the AV input source via the SOURCE button on the remote control.
YPbPr Connection
Connect the YPbPr output of the DVD or VCR to the YPbPr input on the TV set. Connect the
Audio output of the DVD or VCR to the Audio input jacks on the TV set using the RCA cable.
Match the jacks colors : Y is green, Pb is blue,Pr is red, Audio left is white and Audio right is
red. Select Component input source via the SOURCE button on the remote control.
HDMI1 VGA AUDIO Y Pb Pr
COMPON EN T IN
PC I N
RF IN
USBDC IN COAX HDMI2
VIDEO L R
AV I N
9
Connect the VIDEO and AUDIO output jack of the DVD or VCR to the VIDEO jacks on the TV set
using the RCA cable. Match the jack colors: Video is yellow, Audio left is white, and Audio right is red.
Select the AV input source via the SOURCE button on the remote control.
TV Back
Video cable
DVD or VCR back
DVD or VCR
Pr
Pb
Y L R
DVD or VCR
DVD or VCR Back
YPbPr Cable
Connect the YPbPr output of the DVD or VCR to the YPbPr input on the TV set. Connect the Audio
output of the DVD or VCR to the Audio input jacks on the TV set using the RCA cable.
Match the jacks colors : Y is green, Pb is blue, Pr is red, Audio left is white and Audio right is red.
Select Component input source via the SOURCE button on the remote control.
Audio Cable
AV Connection
YPbPr Connection
TV BackTV Back
COAX HDMI2 VIDEO L R
AV I N
TV Installation Drawings
