GVA GVA22FLEDCJ User manual

Instruction Manual
21.5” (54cm) FHD LED LCD TV
With Built-in DVD Player
/ GVA22FLEDCJ

Customer Help Line
TEL: [phone]
2
Important safety instructions 3
Connections and functions 8
Accessories list 9
Remote control 10
Inserting batteries 12
Using the remote control 12
Installing the antenna 13
Connecting your equipment to the TV
Connecting a VCR or video camera 14
Connecting earphones 14
Connecting a satellite/cable TV set top box,Watching cable/pay TV 15
Connecting an external DVD player 16
Connecting a PC 17
Getting started
Powering the LED LCD TV 18
Selecting an input source 18
Operating the menus 19
Channel menu 19
Picture menu 23
Sound menu 25
Time menu 26
Option menu 28
Lock menu 29
Other menus 30
Multimedia menus 32
PVR (Personal video recorder) 36
Some points about disc 40
Using the in-built DVD player 41
FAQs 43
Specifications 44
Contents

Customer Help Line
TEL: [phone]
Read this manual thoroughly before first use and keep it in a safe place for
future reference, along with the warranty card, purchase receipt and carton.
The safety precautions enclosed herein reduce the risk of fire, electric shock
and injury when correctly adhered to.
Follow all instructions and take notice of all the warnings.
Importantsafety instructions
CAUTION
RISK OF ELECTRIC SHOCK
DONOT OPEN
CAUTION:
To reduce the risk of electric shock, do not
remove the cover (or back). This unit contains
no user-serviceable parts inside. Refer all
servicing to qualified service personnel only.
The lightning flash with an arrowhead
symbol within an equilateral triangle is
intended to alert you to the presence of
non-insulated dangerous voltage within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equi-
lateral triangle is intended to alert you
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
appliance.
IMPORTANT WARNINGS AND CAUTIONS!
t Only connect this TV set to a mains socket with a protective earthing
connection.
t To prevent damage which may result in fire or an electric shock hazard, do not
expose this appliance to rain or moisture.
t Do not change or modify the appliance in any way.
t Only use the attachments/accessories specified by the manufacturer.

Customer Help Line
TEL: [phone]
4
Installation
t Only install this TV set in accordance with the manufacturer’s instructions.
t If a television is not positioned in a sufficiently stable location, it can
be potentially hazardous due to falling. To prevent injuries from your
television falling, take a few simple precautions:
t Only use furniture that can safely support the television.
t Ensure the TV is not overhanging the edge of the supporting furniture.
t Educate children about the dangers of climbing on furniture to reach
the TV controls.
t Do not place the TV on cloth or other materials.
t Do not place the television on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television to
a suitable support.
t When deciding on where to put the TV set, make sure the place is:
t Well ventilated.
t Away from damp and cold.
t Protected from overheating and away from direct sunlight.
t Away from moisture drips or splashes.
t Protected from excessive dust or grease.
t Do not install this equipment in a confined space such as a bookcase or
similar unit.
t Do not install the TV set near any heat sources such as radiators, stoves or
other audio visual equipment (including amplifiers) that produce heat.
t Do not place containers with any liquids (such as vases) or with small
metallic objects on top of the unit. If liquid enters the unit or any metal
object falls into the unit, it may result in short-circuit, fire or electric shock.
t Do not use or store flammable or combustible materials near the unit.
Doing so may result in fire or explosion.
t Do not place any naked flame sources, such as lit candles, cigarettes or
incense sticks on top of the TV set.
t Install the antenna away from high-voltage power lines and
communication cables and make sure it is installed securely. If the
antenna touches a power line, contact with the antenna could result in
fire, electric shock or serious injury.
t Install the unit at an adequate distance from the wall to ensure sufficient
ventilation. If the temperature inside the unit rises, it may result in fire.
Importantsafety instructions (Cont.)

Customer Help Line
TEL: [phone]
Electrical safety andcord handling
t Before installing this TV set, make sure your outlet voltage corresponds to
the voltage stated on the appliance rating label.
t To reduce the risk of fire or electric shock, do not expose this appliance to
rain or moisture; do not use it anywhere near water.
t Do not touch the power plug with wet hands; doing so may cause an
electric shock.
t Do not use a damaged power cord, plug or loose outlet. Doing so may
cause an electric shock.
t Do not plug several devices into the same outlet. Doing so may cause the
outlet to overheat and start a fire.
t Insert the power plug fully into the outlet. Aloose or improperly inserted
power plug may cause a fire.
t Do not bend, twist or kink the power cord excessively. Do not allow
anything to rest on or roll over the power cord and antenna cable. Doing
so may cause a fire or an electric shock.
t Do not run the power cord near heat-producing appliances such as
radiators, stoves or irons. The excessive heat could melt the insulation and
expose live wires, resulting in fire or electric shock.
t Always grasp the plug when disconnecting the power cord. Pulling the cord
can damage the internal wire and may cause a fire.
t Unplug this TV during lightning storms or when unused for long periods
of time. Not doing so may result in fire or electric shock.
Importantsafety instructions (Cont.)

Customer Help Line
TEL: [phone]
6
Usageconditions andrestrictions
t Follow the instructions in this manual when installing and adjusting the
TV set. Only adjust those controls that are covered in this instruction
manual, as improper adjustment of other controls may result in damage.
If this happens, unplug the TV set and have it serviced by appropriately
qualified personnel, or phone the after sales support line for advice.
t Do not cover the ventilation openings with items such as newspapers,
tablecloths, curtains etc. as this could impede ventilation.
t Do not insert objects of any kind into this unit through the cabinet slots,
as they could touch the current-carrying parts or short-circuit parts,
resulting in fire, electric shock or damage to the unit.
t If you notice any unusual odours or smoke around the unit, immediately
disconnect the unit from the outlet and contact the service centre. Failure
to do so may result in fire or electric shock.
t When not using the unit for long periods of time, disconnect the power
cord from the wall outlet. Dust could accumulate over time on the unit
and cause it to generate heat and ignite, or deteriorate insulation, which
in turn may result in an electrical fire.
t When moving the unit, be sure to turn off the unit and unplug the power
cord from the wall outlet. Moving the unit with the power cord connected
to the outlet may cause damage to the cord, resulting in fire or electric
shock.
t When removing the batteries from the remote control, make sure children
do not swallow them. Keep the batteries out of reach of infants and
children and seek medical attention immediately if a child has swallowed
a battery.
t This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instructions
concerning use of the appliance by a person responsible for their safety.
t Young children should be supervised to ensure they do not play with the
appliance.
Importantsafety instructions (Cont.)

Customer Help Line
TEL: [phone]
Cleaning andmaintenance
t To reduce the risk of fire and electric shock, always unplug the TV before
cleaning.
t Wipe off any moisture, dirt or dust on the power plug pins with a clean,
dry cloth. Failure to do so may result in fire or electric shock.
t Only use a soft, dry cloth for cleaning the TV set. Do not clean it with a
damp cloth. Never clean with industrial strength polish, wax, benzene,
paint thinner, air freshener, lubricant, detergent or other chemicals.
t Do not attempt to service the unit yourself; never disassemble or modify it
in any way. Doing so may result in fire or electric shock. If the unit requires
repair, contact the after sales support line.
t Refer all servicing to qualified service personnel. Servicing is required
when the TV has been damaged in any way, such as when the power
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the TV, when the TV has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Importantsafety instructions (Cont.)

Customer Help Line
TEL: [phone]
8
1 DC in 12V
2USB
3HDMI 1
4VGA
5PC Audio In
6YPbPr
7Antenna 75Ω
8Earphone out
9SPDIF
10Video and audio (R/L)
11 HDMI 2
12 DVD slot
1Power ON/OFF
2Select the input signals/Exit
the menu (SOURCE)
3MENU
4 TV channel down/down
orientation (CH-)
5 TV channel up/up orientation
(CH+)
6 Volume down/left orientation
(VOL -)
7Volume up/right orientation
(VOL+)
8Open/Close the DVD ( )
9Play/Pause the DVD ( )
10Stop the DVD ( )
Connections andfunctions
SOURC E
1234567
8
9
10

Customer Help Line
TEL: [phone]
Instruction
manual
Remote
control
Adaptor
Batteries
The c ration of the components ma erent. The following
illustration is for representation only.
Accessorieslist

Customer Help Line
TEL: [phone]
10
Remote control
The buttons
The buttons on the remote control and similarlymarked ones on the main
unit perform similar functions.
POWER ( ) Power/standby
MUTE ( ) Press to mute or restore the volume
SOURCE Inputsource
PMODE Picture mode
SMODE Sound mode
AUDIO I/II Select audio mode
SLEEP Sleep timer
0-9 Number (0, 1-9)
-/-- Multi digits (-/--)
Channelreturn
MENU Main menu
EXIT Exit menu(or exit OSD)
TEXT Switch to Teletext*mode
DISPLAY INFO Display program information
OK/ENTER
/ / / Navigation keys
V+/V- Volume control
P+/P- Channelselect
*Teletext
Teletext or Austext is no longer available,nor is there any
plan for a replacement teletext service in Australia. For
more information,please visit the websites of the Australian
channelproviders. However,one teletext option,“closed
captions”, is still working on most Australian television
channels. This service allows youto activate subtitles while
watching normaltelevision programs that provide it.
To access “closed captions” whilewatching a program,press
the teletext button (TEXT/MIX) on the remote control, then
enter the numbers 801 on the remote controlto activate
the subtitles. To exit the subtitles,press the TEXT/MIX
button again.

Customer Help Line
TEL: [phone]
Remote control (Cont.)
TITLE Return to the titlein DVD mode (TITLE)
GOTO Select the GOTO time in DVD mode
ANGLE Change the anglein DVD mode
(only when it is available)
REPEAT Select repeat mode in DVD mode
A-B Repeat from A to Bin DVD mode
/ / / Shortcutbuttons in TVand Media mode
MEDIA Media select
HOLD Picture freeze (in DTVmode only)
ZOOM Picture zoom
[]DVD/USBPlay/pause / Time-shift recording
[] DVD/USBPrevious
[] DVD/USBNext
[] DVD/USBStop
[] DVD/USBFast-backward
[] DVD/USBFast-forward
[]DTV recording
DVD SETUP Display DVD setupmenu in DVD mode
TV/RADIO TV/Radio Select
EPG Electronic program guide
FAV Favourite channel list
SUBTITLE DTVsubtitle
INDEX Recorded list
[]Open/Close the DVD
D.MENU Return to the ROOT menu in DVD mode
Teletext buttons*
TEXT/MIX
HOLD Teletext hold
SUBTITLE Subtitle
INDEX Teletext index
SIZE Teletext size
/ / / The RED, GREEN, YELLOWand BLUE buttons
are used for quick access to colour-coded pages transmitted by FAST
TEXT broadcast. For example:REDselects city information, BLUE travel
information, GREEN weather information and YELLOWselects TV
programming.
Media, PVR and other buttons

Customer Help Line
TEL: [phone]
12
1. Open the cover at the back of the remote control unit completely.
2. Insert two 1.5V AAA batteries, ensuring the polarities (+ / -) of the
batteries are correctly aligned and the batteries are properly pushed
into place so they can power the remote control unit.
3. Slide the cover back into position.
NOTE:When testing the remote control unit after replacing the batteries,
make sure the TV is properly connected to the mains power supply.
Precautions when using batteries
t Do not use old and new batteries together.
t Do not use different types of battery (for example, Manganese and
Alkaline batteries) together.
t Note that there are chargeable and non-chargeable batteries. Do not
attempt to charge non-chargeable batteries.
t Remove the batteries from the remote control unit if you do not intend to
use the unit for a long time.
t When disposing used batteries, follow any guidelines for recycling and
disposal of batteries that apply in your local area.
Using the remote control
To use the remote control, point it towards the remote sensor at the front of
the television. The remote control has a range of up to approximately ve
metres from the TV at an angle of up to 30 degrees each to the right and left
of the sensor. The remote control will not operate if its path is blocked.
Inserting batteries
Remote control (Cont.)

Customer Help Line
TEL: [phone]
Make sure to connect the coaxial cable to the analog/digital input of the TV.
Installing the antenna
Wall jack with
F-connector
External antenna
Analog + digital 75 Ω
Coaxial antenna cable
Dipole antennas may be used with your VIVID
television by connecting directly to the RF port
on the back of your television (see diagram).
It is recommended you use a digital antenna as
this will provide a better quality signal in areas
with poor reception.
Using adipole antenna

Customer Help Line
TEL: [phone]
14
Connecting aVCR or video camera
Connection to the terminals of other equipment may differ depending on
the brand and model.
Connect the earphone jack into the Earphone Out terminal.
Watching avideo tape
1. Turn on the LED LCD TV.
2. Turn your VCRon.
3.Press the SOURCE button on the TV remote control and use the up/down
navigation keys [ ] to select AV; then press OK.
4. Press the PLAY button on your VCR(or its remote control).
Connect a composite cable from the LED LCD TV’s Composite In terminal to
the VCR’s Composite Out terminal, making sure to match the colours of the
terminals to the colours of the plugs.
Composite cable
Audio cable
Earphones
Video
Connecting yourequipmentto the TV
Connecting earphones

Customer Help Line
TEL: [phone]
Connecting yourequipmentto the TV (Cont.)
Connecting asatellite/cable TV set top box
Connecting to the Composite terminal
In order to watch cable/pay TV, you must subscribe to your local pay TV
provider and install its separate receiver (set top box). Connection to the
terminals of other equipment may differ depending on brand and model.
Connect a composite cable from the LED LCD TV’s Composite In terminal
to the Composite Out terminal of the cable/pay TV receiver (set top box),
making sure to match the colours of the terminals with the colours of the
plugs.
Connecting to the HDMI terminal
Connect an HDMI cable from the HDMI terminal of the set top box to the
HDMI terminal of the LED LCD TV.
Watching cable/pay TV
1. Turn on the LED LCD TV.
2. Press the SOURCE button on the remote control of the LED LCD TV and
use the up/down navigation keys [ ] to select AV; then press
OK or, if the HDMI cable has been connected, select HDMI and then press
OK.
3. Turn your cable broadcasting receiver (set top box) on and select the
channel you wish to view.
Cable broadcasting receiver
Composite cable
Cable broadcasting receiver
HDMI cable

Customer Help Line
TEL: [phone]
16
Connecting to the HDMI terminal
Connect an HDMI cable from the HDMI terminal of the DVD player to the
HDMI terminal of the LED LCD TV.
Connecting an external DVDplayer
Connecting to the Componentterminal
Connection to the terminals of other equipment may differ depending on
the brand and model.
Playing aDVDfrom an external DVDplayer
1. Turn on the LED LCD TV.
2. Press the SOURCE button and use the up/down navigation keys
[] to select the YPbPr option; then press OK to confirm or,
if the HDMI cable has been connected, select HDMI and then press OK.
3. Turn on your external DVD player, insert a DVD and press the PLAY button.
1. Connect a component cable from the LED LCD TV’s Y, Pb, Pr terminals to
the DVD’s Out terminals.
2. Connect an audio cable from the LED LCD TV’s Audio terminals (RL and
AV1) to the DVD’s Audio Out (left and right) terminals.
DVD
DVD
Component connection cable
HDMI connecting cable
Connecting yourequipmentto the TV (Cont.)

Customer Help Line
TEL: [phone]
Connecting aPC
Connection to the terminals of other equipment may differ depending on
the brand and model.
NOTE:Please check your PC instruction manual for the correct settings.
1. Connect a D-Sub cable from the LED LCD TV’s PC Input terminal to the
PC’s RGB terminal.
2. Connect an audio cable from the LED LCD TV’s PC Audio terminal to the
PC’s Audio terminal.
NOTE:Only for PCs that have an audio terminal.
Using yourLEDLCD TV as aPC monitor
1. Turn on the LED LCD TV.
2. Press the SOURCE button and use the up/down navigation keys
[] to select the VGAoption; then press OK to confirm.
PC Audio Cable
PC
Analog RGB (D-Sub 15 pin) cable
Connecting yourequipmentto the TV (Cont.)

Customer Help Line
TEL: [phone]
18
Powering the LEDLCD TV
To turn the power ON or OFF:
1 Make sure the power cable is properly plugged in.
2 Turn on the power by pressing the switch at the back of the TV.
3Press the POWERbutton on the remote control.
NOTE:Make sure you are aiming the remote control unit at the sensor at
the front of the TV.
You can select between the TV signal and the input signal of other
equipment connected to the TV.
Use this function to switch to the input source you wish to view.
Selecting an inputsource
Press the SOURCE button on the remote control.
Press the up/down navigation keys to move to the
desired input source.
Press the OK button to confirm your selection.
SOURCE
Getting started

Customer Help Line
TEL: [phone]
1. Press the MENU button on the remote control, the on-screen menu will
appear on the screen.
2. Use the left and right navigation keys to select your main option.
The main menu items, from left to right, are:
Channel Picture Sound Time Option Lock
Operating the menus
Channel menu
From the Channel menu you can search channels, either automatically or
manually, and set up a variety of channel options.
NOTE: You can only select the Channel menu in ATV/DTV mode.
NOTE: All default settings have been selected for Australia.

Customer Help Line
TEL: [phone]
20
Auto Scan
In the Auto Scan submenu you can select your country and the tune type:
DTV+ATV, DTV only and ATV only.
Press / / / to make your selection, then press ENTERto start scanning.
When DTV+ATV is selected, half the scanning is for analog TV channels and
the other half for digital channels.
When ATV tuning, you can press EXIT to skip ATV tuning and start DTV
tuning, as below:
Operating the menus (Cont.)
