GVA GVA3 User manual

STEAM MOP
/GVA 3
Instruction Manual

Distributed By:
M.E.W (Australia) Pty Ltd
15 Vaughan Street
Essendon Fields, VIC 3041
ACN 152 719 036
www.gvaproducts.com.au
After Sales Support
AUS: 1300 886 649
Technical Specification
Voltage: 220-240V
Wattage: 1500W
Water tank capacity: 400ml
Cord length: 5.5m
Weight: 2.5kg
Subject to technical change without notice.

2
Machine Overview
1. Handle
2. Upper cord clip
3. Lower cord clip
4. Power cord
5. Clean water tank
6. LED indicator
a) Water heating/power on
(orange LED)
b) Steam ready
(orange LED) + (green LED)
7. Floor head
8. Steam release trigger
9. Microfibre cleaning pad
10. Carpet glider
(dependant on model)
11. Hard water filter (hidden)
(pre-assembled in unit)
12. Screw x 1
1
4
2
3
5
7
8
Accessories
Unit
a
b
6
910
12
11
Distributed By:
M.E.W (Australia) Pty Ltd
15 Vaughan Street
Essendon Fields, VIC 3041
ACN 152 719 036
www.gvaproducts.com.au
After Sales Support
AUS: 1300 886 649
Technical Specification
Voltage: 220-240V
Wattage: 1500W
Water tank capacity: 400ml
Cord length: 5.5m
Weight: 2.5kg
Subject to technical change without notice.

General Safety Information
3
FOR HOUSEHOLD USE ONLY.
When using the steam cleaner, basic safety
precautions should always be observed,
including the following:
IMPORTANT: Please refer to floor
manufacturer’s care recommendations before
use and test the steam cleaner on a discrete
area of flooring to begin with.
When using the steam cleaner, basic safety
precautions should always be observed,
including the following:
WARNING: The stick steam cleaner head gets
very hot during operation.
WARNING: Danger of scalding
1. Do not leave the steam cleaner unattended
when plugged in. Unplug the product from
the socket when not in use.
2. Only use the steam cleaner indoors. Keep the
steam cleaner away from rain and moisture.
3. Turn off the on/off switch on the steam
cleaner controls before disconnecting or
connecting from the mains supply.
4. Always unplug the steam cleaner and allow
it to cool before connecting or disconnecting
the hose or accessories.
5. Children should be supervised to ensure
that they do not play with the appliance.
6. This appliance is not intended for use by
children and persons with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
7. The appliance should only be used as
described in this User Guide.
8. Only Vax recommended attachments
should be used with this appliance.
9. Do not use this steam cleaner if it has been
dropped, damaged, left outdoors or
dropped into water. Do not use this steam
cleaner with a damaged cord or plug. If the
supply cord is damaged return the steam
cleaner to a Vax authorised Service Agent.
10. Do not pull or carry this appliance by the
cord. Do not use the cord as a handle,
close a door on the cord or pull the cord
around sharp edges or corners. Do not run
the steam cleaner over the cord. Keep the
cord away from heated surfaces.
11. Do not unplug the product by pulling
on the cord.
12. Do not handle the plug or the steam cleaner
with wet hands.
13. Do not use without the tank cap in place.
Ensure that the water tank cap has been
screwed down fully before use.
14. Do not touch any hot areas on the steam
cleaner. It is normal for the steam cleaner to
heat up during operation.
15. Accessories will become hot during use
– allow them to cool down before handling.
16. Do not use the steam cleaner to treat any
items of clothing that are still being worn
on the body.
17. The force and heat of the steam may have
an adverse effect on some materials.
Always check whether a surface is suitable
for treatment with the steam by carrying
out a test before hand on a concealed area.
18. The steam cleaner must be kept level
during operation.
19. Never immerse the steam cleaner in water
or in other liquids.
20. Do not operate the steam cleaner without
water in the tank. Always top up with water
in good time.
21. Always remove the mains plug from the socket
and allow the steam cleaner to cool down
completely before topping up with water.
22. Never aim the steam cleaner at people,
animals or plants (there is a risk of scalding).
Never touch the steam jet from a short
distance with your hands. Do not aim the
steam cleaner at electrical items or wires.
23. Keep hair, loose clothing, fingers and all
parts of the body away from openings.
24. Never fill the water tank with anything other
than water. Never put additives (such as
perfume, stain remover or products containing
alcohol) in the water as they may damage the
steam cleaner or make it dangerous to use.
25. Only carry the steam cleaner by the
carry handle.

General Safety Information
4
26. Store the steam cleaner in a cool, dry area.
27. Do not use an extension cord with this product.
28. Using improper voltage may result in
damage to the steam cleaner and possible
injury to the user. The correct voltage is listed
on the rating label.
29. Do not use your steam cleaner if it is
damaged or faulty. Please make sure that
the product is unplugged from the mains
and call the Vax Careline on
AU 1300 361 505 / NZ 0800 800 900.
30. Do not use the unit on leather, wax
polished furniture or floors, synthetic
fabrics, velvet or other delicate steam or
water sensitive materials.
31. Do not use on acrylic surfaces.
32. In wet rooms, e.g. bathrooms, connect the
appliance to sockets with an RCD adaptor
connected in series.
33. The device should not be used to clean
electrical appliances such as ovens,
microwaves, televisions and electrical
heating systems etc.
34. Be very careful when cleaning tiled walls
with sockets.
35. Keep the unit on the floor.
36. Empty the water tank when the steam cleaner
is not in use.
37. Do not overfill the tank. Do not exceed the
maximum prescribed filling level. Please
use the measuring jug and funnel included.
38. Always show these instructions to a third
party if you are passing the steam cleaner
on to them.
39. Please ensure all parts are correctly fitted
before using the product.
40. Do not attempt to remove blockages with
sharp objects as they may cause damage.
41. Do not use without the hard water filter in place.
42. Take extra care when cleaning on the stairs.
43. Keep cleaning area well lit.
44. Please refer to the manufacturers care
recommendations before use and test the
steam cleaner on a discrete area of flooring
to begin with.
WARNING: Always switch off and unplug the
steam cleaner from the electrical outlet before
assembling, opening or emptying the water
tank, or before connecting/disconnecting the
attachments.
IMPORTANT: The liquid or steam must not be
directed towards equipment containing electrical
components, such as the interior of ovens.
IMPORTANT: The steam cleaner is equipped
with a thermostat and a thermal cut-out. If for
any reason the unit should overheat, the
thermostat will automatically turn the unit off.
Should this occur, unplug the steam cleaner
from the electrical outlet and turn off the
switch. Let the unit cool, remove and empty the
water tank. To re-start the machine, plug it into
an electrical outlet and switch it back on.
IMPORTANT: We recommend the use of a
Residual Current Device with a Residual
Current rating of 30mA or less.
WARNING: Never leave the steam cleaner in
one spot on any surface for an extended period
of time as this may damage the floor surface.
IMPORTANT: This steam cleaner may not be
suitable for all floating floorboards or sealed
floors – please check with your floorboard
manufacturer first prior to use.
DAMAGE TO THE VACUUM CLEANER CAUSED
AS A DIRECT RESULT OF NOT ADHERING TO
THE GENERAL SAFETY INFORMATION AND
THE INSTRUCTIONS IN THIS USER GUIDE
INVALIDATES THE WARRANTY.
This machine is intended for household use only,
and NOT for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR
FURTHER USE.

5
Operation
Assembling your steam cleaner
Before you begin cleaning
Push handle into
main body.
Remove the clean
water tank.
I M P O R TA N T: Please refer to floor manufacturer’s care recommendations before use and test the
steamer on a discrete area of flooring to begin with.
WARNING: To reduce the risk of personal injury, unplug the steamer when assembling the unit.
I M P O R TA N T: Do not over-fill the water tank.
Attach microfibre pad
to floor head.
Fill the tank with 400ml
of water and replace
the water cap, Tighten
by twisting clockwise.
Screw handle in place.
Twist the cap anti-
clockwise to remove.
Replace the clean
water tank, clicking
into place making sure
the hard water filter is
in place.

6
Operation
Before you begin cleaning
Attaching the microfibre cleaning pad
Place microfibre
cleaning pad over the
floor head.
WARNING: To reduce the risk of personal injury, unplug the steamer when assembling the accessories.
I M P O R TA N T: Never use the stick steam cleaner without the microfibre cleaning pad correctly
attached to the floor head.
AOrange LED will illuminate when the unit is
switched on at the plug and water is heating.
BAfter approximately 1 minute the green LED
will also illuminate showing steamer is ready
to use. The green LED will go off when unit
water is re-heating.
Tighten the drawstring
so the microfibre
cleaning pad is fitted
securely.

7
Operation
Steam cleaning hard floors
Plug into mains and
wait for the green light
(on the main body) to
switch on after 1 min.
I M P O R TA N T: Please refer to floor manufacturer’s care recommendations before use and test the
steamer on a discrete area of flooring to begin with.
WARNING: Never leave the stick steam cleaner in one spot on any surface for an extended period
of time with a damp or wet microfibre cleaning pad attached as this may damage the floor surface.
WARNING: Your steam cleaner should only be used on tiles, lino or sealed wood flooring.
Do not use on laminate flooring.
I M P O R TA N T: Never use the steam cleaner without the microfibre cleaning pad properly attached
to the floor head.
WARNING: To reduce the risk of personal injury, unplug the steamer when assembling the accessories.
To produce steam
squeeze the trigger.
To recline the unit place
foot on floor head and
tilt handle.
Move the stick
steam cleaner slowly
backwards and
forwards across the
floor paying particular
attention to high
traffic areas.

8
Operation
Refreshing carpets
Attach carpet glider
attachment to floor
head.
I M P O R TA N T: When using on carpets, always ensure the microfibre cleaning pad is properly
attached to the floor head.
To produce steam
squeeze the trigger.
To recline the unit place
foot on floor head and
tilt handle.
Move the stick
steam cleaner slowly
backwards and
forwards across the
floor paying particular
attention to high
traffic areas.

9
Maintenance
Empty the water tank
Remove the microfibre cleaning pad from the unit
Remove the clean
water tank.
Undo drawstring.
I M P O R TA N T: Allow the unit to fully cool down before performing any maintenance or
troubleshooting checks.
I M P O R TA N T: Allow the unit to fully cool down before performing any maintenance or
troubleshooting checks.
Empty any excess
water over the sink,
replace water cap and
return to the unit.
Twist the cap anti-
clockwise to remove.
Remove microfibre
cleaning pad.

10
Maintenance
Replacing the hard water filter
Cleaning the microfibre cleaning pad
I M P O R TA N T: : Allow the unit to cool down fully before performing maintenance
or troubleshooting checks.
I M P O R TA N T: The condition of the filter affects the performance of your machine. Check and
change filter (depending on level of use).
Your machine is fitted with a hard water filter. If you live in an area of hard water the filter will
discolour/darken over time (2). Depending on water hardness and/or frequency of use the filter
should be changed every 6 months, or once the filter has completely darkened.
I M P O R TA N T: Never use bleach or fabric softener when washing the microfibre cleaning pad.
1Machine washable at max temperature 40°C. Always use a mild detergent.
2Leave the pad to dry for 24 hours.
