GW Instek MFG-2000 Series User manual

Multi-Channel Function Generator
MFG-2000 Series
User Manual
GW INSTEK PART NO.82MF32K000EG1
ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will Corporation.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve its products and therefore
reserves the right to change the specifications, equipment, and
maintenance procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

Table of Contents
3
Table of Contents
SAFETY INSTRUCTIONS..................................6
GETTING STARTED .......................................11
Main Features ...................................................................12
Panel Overview..................................................................14
Setting Up the function Generator.....................................25
QUICK REFERENCE .......................................27
How to use the Digital Inputs ...........................................29
How to use the Help Menu ...............................................30
Display area allocation ......................................................33
Selecting a Waveform ........................................................34
Sweep................................................................................45
Burst .................................................................................47
ARB ...................................................................................49
Utility Menu ......................................................................53
Menu Tree .........................................................................54
Default Settings ................................................................72
OPERATION ..................................................74
CH1/CH2 Channel.............................................................76
RF Channel........................................................................90
Pulse Channel ................................................................. 102
Power Amplifier ...............................................................114
MODULATION............................................. 117
Amplitude Modulation(AM) ............................................120
Amplitude Shift Keying(ASK) ...........................................127
Frequency Modulation(FM) .............................................132
Frequency Shift Keying(FSK)............................................141
Phase Modulation(PM) ...................................................148

MFG-2000 Series User Manual
4
Phase Shift Keying(PSK) ..................................................155
Pulse Width Modulation ..................................................160
SUM modulation .............................................................166
Frequency Sweep .............................................................173
Burst Mode .....................................................................183
SECONDARY SYSTEM FUNCTION SETTINGS
.................................................................... 194
Save and Recall ...............................................................195
Selecting the Remote Interface ........................................198
System and Settings ........................................................202
CHANNEL SETTINGS .................................. 207
DUAL CHANNEL OPERATION ..................... 212
ARBITRARY WAVEFORMS............................ 218
Inserting Built-In Waveforms ...........................................219
Display an Arbitrary Waveform ........................................221
Editing an Arbitrary Wavefrom .........................................228
Ouput an Arbitrary Waveform ..........................................238
Saving/Recalling an Arbitrary Waveform ..........................240
REMOTE INTERFACE................................... 248
Establishing a Remote Connection ..................................249
Web Browser Control Interface ........................................254
Command List .................................................................262
System Commands ..........................................................266
Status Register Commands..............................................270
System Remote Commands .............................................273
Apply Commands ............................................................274
Output Commands ..........................................................280
Pulse Configuration Commands ......................................290
Amplitude Modulation (AM) Commands .........................294

Table of Contents
5
Amplitude Shift Keying (ASK) Commands .......................299
Frequency Modulation (FM) Commands .........................302
Frequency-Shift Keying (FSK) Commands ........................307
Phase Modulation (PM)Commands................................. 310
Phase Shift Keying (PSK)Commands ...............................315
SUM Modulation (SUM) Commands ..............................318
Pulse Width Modulation (PWM)Commands.....................323
Frequency Sweep Commands ..........................................327
Burst Mode Commands ...................................................337
Arbitrary Waveform Commands .......................................347
COUNTER .......................................................................355
PHASE.............................................................................357
COUPLE ..........................................................................358
Save and Recall Commands .............................................361
Error Messages ...............................................................363
SCPI Status Register........................................................377
APPENDIX ................................................... 383
Specifications ..................................................................383
EC Declaration of Conformity ..........................................393
GLOBL HEADAQARTERS.................................................394
ARB Built-In Waveforms ..................................................395
INDEX ......................................................... 407

MFG-2000 Series User Manual
6
SAFETY INSTRUCTIONS
This chapter contains important safety instructions
that should be followed when operating and
storing the function generator. Read the following
before any operation to ensure your safety and to
keep the function generator in the best condition.
Safety Symbols
These safety symbols may appear in this manual or on the
instrument.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the function generator or
to other objects or property.
DANGER High Voltage
Attention: Refer to the Manual
Protective Conductor Terminal
Earth (Ground) Terminal
DANGER Hot Surface

SAFETY INSTRUCTIONS
7
Double Insulated
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.
Safety Guidelines
General
Guideline
CAUTION
Do not place heavy objects on the instrument.
Do not place flammable objects on the
instrument.
Avoid severe impact or rough handling that
may damage the function generator.
Avoid discharges of static electricity on or near
the function generator.
Use only mating connectors, not bare wires, for
the terminals.
The instrument should only be disassembled by
a qualified technician.
(Measurement categories) EN 61010-1:2010 (Third Edition)specifies
the measurement categories and their requirements as follows. The
MFG-2000 falls under category II.
Measurement category IV is for measurement performed at the
source of a low-voltage installation.
Measurement category III is for measurement performed in a
building installation.
Measurement category II is for measurement performed on
circuits directly connected to a low voltage installation.
Measurement category I is for measurements performed on
circuits not directly connected to Mains.

MFG-2000 Series User Manual
8
Power Supply
WARNING
AC Input voltage: 100 ~ 240V AC, 50 ~ 60Hz.
Or 100 ~ 120V AC, 220 ~ 240V AC,50 ~ 60Hz
(With power amplifier)
Connect the protective grounding conductor of
the AC power cord to an earth ground to
prevent electric shock.
Fuse
WARNING
Fuse type: T0.5A/250V. T1A/250V(With power
amplifier).
Only qualified technicians should replace the
fuse.
To ensure fire protection, replace the fuse only
with the specified type and rating.
Disconnect the power cord and all test leads
before replacing the fuse.
Make sure the cause of fuse blowout is fixed
before replacing the fuse.
Cleaning the
function
generator
Disconnect the power cord before cleaning the
function generator.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid
into the function generator.
Do not use chemicals containing harsh products
such as benzene, toluene, xylene, and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
and avoid strong magnetic fields.
Relative Humidity: < 80%
Altitude: < 2000m
Temperature: 0°C to 40°C

SAFETY INSTRUCTIONS
9
(Pollution Degree) EN 61010-1:2010(Third Edition)specifies
pollution degrees and their requirements as follows. The function
generator falls under degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.
Storage
environment
Location: Indoor
Relative Humidity: < 70%
Temperature: -10°C to 70°C
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.

MFG-2000 Series User Manual
10
Power cord for the United Kingdom
When using the function generator in the United Kingdom, make sure the
power cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the
following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with the
coloured marking identified in your plug/appliance, proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth
terminal marked with either the letter E, the earth symbol or coloured
Green/Green & Yellow.
The wire which is coloured Blue must be connected to the terminal which is
marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal
marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or contact
the supplier.
This cable/appliance should be protected by a suitably rated and approved
HBC mains fuse: refer to the rating information on the equipment and/or
user instructions for details. As a guide, a cable of 0.75mm2should be
protected by a 3A or 5A fuse. Larger conductors would normally require
13A types, depending on the connection method used.
Any exposed wiring from a cable, plug or connection that is engaged in a
live socket is extremely hazardous. If a cable or plug is deemed hazardous,
turn off the mains power and remove the cable, any fuses and fuse
assemblies. All hazardous wiring must be immediately destroyed and
replaced in accordance to the above standard.
