GY-HITEC GY-Q4 User manual

200W LED SPOT+BEAM MOVING
HEAD LIGHT
USER MANUAL
KEEP THIS MANUAL FOR FUTURE NEEDS

Operational Manual
Thank you for purchasing this product.To take full advantage of all possibilities and
for your own safety,please read this operating instructions very carefully before you
start using this unit.
BEFORE USE
Before you start using this unit,please check if there is no transportation
damage.Should there be any,do not use the device and consult your dealer first.
This device has left our factory in absolutely perfect condition and well packed.
In order to maintain this condition and to ensure a safe operation, it is absolutely
necessary for the user to follow the safety instructions and warning notes written
in this manual.
The manufacturer will not accept liability for any resulting damages caused by
the non-observance of this manual or any unauthorized modification to the
device.
Please consider that damages caused by manual modifications to the device are
not subject to warranty.
SAFETY INSTRUCTIONS
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK
IS PRESENT WITHIN THIS UNIT!
Caution:To reduce the risk of electric shock,do not remove the top cover.No
user-serviceable parts inside.Refer servicing to qualified service personnel only.
Risk of electric shot!
Keep this device away from rain and moisture!

Read the manual
Unplug the mains power before remove the housing
Indoor use ONLY
Caution: Do not stare at operating lamp.May be harmful to the eye.
To protect the environment,please try to recycle the packing material as much as
possible.
To prevent fire or shock hazard,do not expose this appliance to rain or moisture.
This unit is for indoor use only.
Don’t place metal objects or spill liquid inside the unit.Electric shot or
malfunction may result.If a foreign object enters the unit,immediately disconnect
the mains power.
Locate the fixture in a well ventilated spot, away from any flammable materials
and/or liquids.The fixture must be fixed at least 50cm from surrounding walls.
Don’t cover any ventilation openings as this may result in overheating.
Prevent use in dusty environments and clean the unit regularly.
Keep the unit away from children.
Inexperienced persons should not operate this device.
Maximum safe ambient temperature is 40℃.Don’t use this unit at higher ambient
temperatures.
Make sure the area below the installation place is free from unwanted persons
during rigging,de-rigging and servicing.
Allow the device about 10 minutes to cool down before servicing.
The electrical installation should be carried out by qualified person
only,according to the regulations for electric and mechanical safety in your
country.
Check that the available voltage is not higher than the one stated in the unit.
The power cord should always be in perfect condition.Switch the unit
immediately off when the power cord is squashed or damaged.It must be replaced
by the manufacturer,its service agent or similarly qualified persons in order to
avoid a hazard.
Never led the power-cord come into contact with other cables!

Don’t connect the unit to any dimer pack.
In order to prevent electric shot,do not open the cover.There are no user
serviceable parts inside.
The housing and lenses must be replaced if they are invisibly damaged.
Never repair a fuse or bypass the fuse holder.Always replace a damaged fuse with
a fuse of the same type and electrical specifications!
Due to safety reasons,it is prohibited to make unauthorized modifications to the
unit.
Important:Never look directly into the light source!Don’t use the effect in the
presence of persons suffering from epilepsy.
Mounting and Installation
Important:Fixtures must be installed by a Qualified electrician in accordance
with all national and local electrical and construction codes and regulations.
Overhead Rigging
For overhead installation,the fixture must be always secured with a safety wire
that can bear at least 10 times the weight of the fixture.
Make sure the area below the installation is free from unwanted persons during
rigging,de-rigging and servicing.
Locate the fixture in a well ventilated spot,far away from any flammable
materials and/or liquids.The fixture must be fixed at least 50cm from surrounding
walls.
The device must be installed out of reach of people an outside areas where
persons may walk by or be seated.
Fixture installation must always be secured with a secondary safety
attachment ,such as an appropriate safety cable.
Always use and install the supplied safety cable as a safe cable as safety measure
to prevent accidental damage and /or injury in the event the clamp fails.
The fixture should be well fixed,a free-swinging mounting is dangerous and may
not be considered!

Clamp Mounting :
The LED moving head provides a unique mounting bracket assembly that integrates
the bottom of the base, the included ‘omega bracket’ (see the following pic)and the
safety cable rigging point in one unit.When mounting this fixture to truss be sure to
sere to secure an appropriately rated clamp to the included omega bracket using a
M10 screw fitted through the center hole of the ‘omega bracket’.As an added safety
measure be sure to attached at least one properly rated safety cable to the fixture using
on of the safety cable rigging point integrated in the base assembly.
DMX-512 Control Connection
Connect the provided XLR cable to the female 3-pin XLR output of your controller
and the other side to the male 3-pin XLR input of the moving head. You can chain
multiple Moving head together through serial linking. The cable needed should be
two core, screened cable with XLR input and output connectors. Please refer to the
diagram below.

DMX-512 Connection with DMX Terminator
For installations where the DMX cable has to run a long distance or is in an
electrically noisy environment, such as in a discotheque, it is recommended to use a
DMX terminator. This helps in preventing corruption of the digital control signal by
electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor
connected between pins 2 and 3,which is then plugged into the output XLR socket of
the last fixture in the chain. Please see illustrations below.
Technical Specifications
Input power:AC100-240V 50/60 Hz
Power consumption :240W
LED: 200W high power LED
DMX channel:6/18 channels
Pan scan：540°(16bit) Electric correction
Tilt scan：270° (16bit) Electric correction
Color wheel: one color wheel, 7 kinds of color chips in one color wheel
Static Gobo wheel:8 gobo+open
Rotating Gobo Wheel:6 gobo+open
Effect Wheel: Rotation Triple prism
Lens optical system achanical focus .beam Zoom angle 5°/13°
Control mode:DMX512/Master-Slave/Auto run
Display:LCD display
WEIGHT&SIZE
N.W: 11.25 KG
G.W: 13.25 KG

Packing size: 47.5*35.5*38cm
Dimensions
Lumen Chart

Menu Function
MENU (Color Display 2.4'TFT）
DMX Address
001~512
Operating Mode
DMX 6 Ch
DMX 18 Ch
Auto
Perform Mode 1
Perform Mode 2
Perform Mode 3
Perform Mode 4
Perform Mode 5
Perform Mode 6
Perform Mode 7
Perform Mode 8
Sound
Master Auto
Perform Mode 1
Perform Mode 2
Perform Mode 3
Perform Mode 4
Perform Mode 5
Perform Mode 6
Perform Mode 7
Perform Mode 8
Master Sound
Slave
Language Setting
简体中文
English
Advanced Setting
Pan Reverse
Tilt Reverse
Display Reverse
Mic Sensitive
= 000
Reset Motor
Factory Reset
Home Position
Password
Code

=018
PAN
. =000
TILT
. =000
Dimmer
. =255
Color
. =000
fixed Gobo
. =000
Rotation Gobo
. =000
Focus
. =000
Zoom
. =000
Pan/Tilt Speed
. =000
System Info
Current Time
Total Time
Current Mode
Temperature
Software Version
Manual Control
PAN
. =000
PAN-FINE
. =000
TILT
. =000
TILT-FINE
. =000
Pan/Tilt Speed
. =000
Dimmer
. =000
Strobe
. =000
Color
. =000
fixed Gobo
. =000
Rotation Gobo
. =000
Rotation Gobo
Wheel
. =000
Focus
. =000
Prism
. =000
Prism Whell
. =000
Zoom
. =000
DMX-Configuration
6 Channel Mode:
Channel
DMX Value
Function
1
000 - 255
X
2
000 - 255
Y

3
000-255
Dimmer(0-100%)
4
000-004
Shutter closed
005-250
Strobe effect slow to fast
251-255
Shutter open
5
000-007
Empty
008-047
Auto Play 1
048-087
Auto Play 2
088-127
Auto Play 3
128-167
Auto Play 4
168-207
Auto Play 5
208-247
Auto Play 6
248-255
Color Gobo Sound Control
6
000-007
Empty
008-032
X/Y auto run 1
033-058
X/Y auto run 2
059-084
X/Y auto run 3
085-110
X/Y auto run 4
111-136
X/Y auto run 5
137-162
X/Y auto run 6
163-188
X/Y auto run 7
189-214
X/Y auto run 8
215-240
X/Y auto run 9
241-255
X/Y Sound Control
18 Channel Mode:
Channel
DMX Value
Function
1
000 - 255
X
2
000-255
X-Fine
3
000 - 255
Y
4
000-255
Y-Fine
5
000 - 255
XY SPEED
6
000-255
Dimmer(0-100%)
7
000-004
Shutter closed
005-250
Strobe effect slow to fast
251-255
Shutter open
8
000-004
Open(White)
005-013
White/Color1
014-022
Color1
023-031
Color1/Color2

032-040
Color2
041-049
Color2/Color3
050-058
Color3
059-067
Color3/Color4
068-076
Color4
077-085
Color4/Color5
086-094
Color5
095-103
Color5/Color6
104-112
Color6
113-121
Color6/Color7
122-130
Color7
131-139
Open(White)
140-195
Forward rainbow effect from fast to slow
196-199
Rotation stop
200-255
Backward rainbow effect from slow to fast
9
000-005
Open(White)
006-014
Gobo1
015-023
Gobo2
024-032
Gobo3
033-041
Gobo4
042-050
Gobo5
051-059
Gobo6
060-068
Gobo7
069-077
Gobo8
078-084
Gobo1 Shake
085-091
Gobo2 Shake
092-098
Gobo3 Shake
099-105
Gobo4 Shake
106-112
Gobo5 Shake
113-119
Gobo6 Shake
120-126
Gobo7 Shake
127-133
Gobo8 Shake
134-194
Forward rainbow effect from fast to slow
195-255
Backward rainbow effect from slow to fast
10
000-007
Open(White)
008-019
Gobo1
020-031
Gobo2
032-043
Gobo3
044-055
Gobo4

056-067
Gobo5
068-079
Gobo6
080-088
Gobo1 Shake
089-097
Gobo2 Shake
098-106
Gobo3 Shake
107-115
Gobo4 Shake
116-124
Gobo5 Shake
125-133
Gobo6 Shake
134-194
Forward rainbow effect from fast to slow
195-255
Backward rainbow effect from slow to fast
11
000-009
Stop
010-129
Forward Gobo2 Rotation from fast to slow
130-134
Stop
135-255
Backward Gobo2 Rotation from slow to fast
12
000-255
Focus
13
000-015
Open(White)
016-255
Prism
14
000-005
Stop
006-129
Forward Prism Rotation from fast to slow
130-134
Stop
135-255
Backward Prism Rotation from slow to fast
15
000-127
Open
128-255
Zoom
16
000-007
Empty
008-047
Auto Play 1
048-087
Auto Play 2
088-127
Auto Play 3
128-167
Auto Play 4
168-207
Auto Play 5
208-247
Auto Play 6
248-255
Color Gobo Sound Control
17
000-007
Empty
008-032
X/Y auto run 1
033-058
X/Y auto run 2
059-084
X/Y auto run 3
085-110
X/Y auto run 4
111-136
X/Y auto run 5
137-162
X/Y auto run 6
163-188
X/Y auto run 7

189-214
X/Y auto run 8
215-240
X/Y auto run 9
241-255
X/Y Sound Control
18
250-255
RESET(10S)
Maintenance
DANGER !
Disconnect from the mains before starting any maintenance work.
Make sure the are below is free from any unwanted persons during servicing.
Switch off the unit,unplug the mains cable and wait until the unit is cool down.
During inspection the following points should be checked:
All screws used for installing the device and any of its parts should be tightly
fastened and may not be corroded.
Housing,fixations and installations spots (ceiling,truss,suspensions) should be
totally free from any deformation.
When an optical lens is visibly damaged due to cracks or deep scratches,it must
be replaced.
The mains cables must be in impeccable condition and should be replaced
immediately when even a small problem is detected.
In order to protect the device from overheat the cooling fans(if any) and
ventilation opening should be cleaned monthly.
The interior of the device should be cleaned annually using a vacuum cleaner or
air-jet.
The cleaning of in internal and external optical lenses and/or mirrors must be
carried out periodically to optimize light output.Cleaning frequency depends on
the environment which the fixture operates:damp,smoky or particularly dirty
surroundings can cause greater accumulation of dirt on the unit’s optics.
Clean with a soft cloth using normal glass cleaning products.
Always dry the parts carefully.
Clean the external optics at least every 30 days.
Clean the internal optics at least every 90 days.
Important:we strongly recommend internal cleaning to be carried out by
qualified personnel!
