H.Koenig KBP40 User manual

Instruction manual
Manuel d'utilisation
Benutzerhandbuch
Gebruiksaanwijzing
Manual de usuario
Manuale d’uso
Manual do usuário
KBP40
ICE CUBE MAKER
MACHINE À GLAÇONS
EISMASCHINE
IJS MACHINE
MÁQUINA DE HIELO
MACCHINA DEL GHIACCIO
MÁQUINA DE FAZER GELO

ENGLISH
IMPORTANT SAFETY
INSTRUCTIONS
To reduce the risk of fire,
explosion, electric shock, or
injury when using your ice maker,
follow these important safety
instructions:
1. Before using check that the
voltage power corresponds to the
one shown on the appliance
nameplate.
2. Do not remove any safety,
warning, or product information
labels from your ice maker.
3. Plug the ice maker into an
exclusive grounded power outlet. No
other appliance should be plugged
into the same outlet. Be sure that
the plug is fully inserted into the
receptacle.

4. This appliance must be grounded.
It is equipped with a power cord
having a grounding plug. The plug
must be plugged into an outlet that
is properly installed and grounded.
5. Avoid the use of an extension
cord because it may overheat and
cause a risk of fire. However, if it is
necessary to use an extension cord:
1) Use only extension cord with
grounding plug.
2) The marked rating of an extension
cord must be equal to or greater
than the rating of this appliance.
6. It should be positioned such that it
does not drape over the counter or
tabletop where it can be pulled on by
children intentionally.
7. Do not operate any appliance with
a damage cord or plug or after the
appliance malfunction or has been

damaged in any manner. Return the
appliance to the nearest authorized
service facility for examination,
repairor
adjustment.
8. If the supply cord is damaged, it
must be replaced by the
manufacturer or its service agent or
a similarly qualified person in order
to avoid a hazard.
9. Do not let cord hang over edge of
table or counter.
10. Do not place on or near a hot
gas or electric burner, or in a heated
oven.
11. Place power cord in such a
way it cannot be pulled on by
children or cause a tripping hazard.
12. Place power cord in such a
way that it is not in contact with hot
surfaces.

13. The use of attachment not
recommended or sold by
manufacturer may cause fire,
electric shock or injury.
14. Do not touch the evaporator
when using the ice maker or making
ice to avoid being suffer from
frostbite.
15. Do not immerse any part of
the product in water.
16. To disconnect, turn any
control to “OFF”, then remove plug
from wall outlet.
17. Do not plug or unplug product
with wet hands.
18. Unplug the product before
cleaning, maintaining and when not
in use.
19. Do not use with water that is
microbiologically unsafe or of
unknown quality.

20. Do not clean your ice maker
with any flammable fluids. The
fumes may create a fire hazard or
explosion.
21. Do not overturn the ice
maker. If the ice maker is overturned
accidentally, make it stand steadily
for 2 hours before power it on again.
22. If the ice maker is brought in
from outside in wintertime, do not
use for a few hours, allowing the unit
to warm up to the room temperature
before operating.
23. Never put flammable,
explosive and corrosive articles into
the ice maker.
24. Never use the ice maker
when there is flammable gas
leakage.
25. Never store or use gas and
other flammable articles near the ice

maker to avoid any fire.
26. Unplug the ice maker before
moving it to avoid damaging the
refrigerating system.
27. Do not attempt to
disassemble, repair, modify, or
replace any part of your product.
28. This appliance can be used
by children aged from leaks and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance in a
safe way and understand the
hazards involved.
29. Children shall not play with
the appliance.
30. Close supervision is
necessary when any appliance is

used by or near children.
31. Do not leave the appliance
unattended while in use.
32. Do not use outdoors.
33. Do not use the appliance for
other than intended use.
34. Please dispose of the
appliance for its flammable
refrigerant and blowing gas
according to local regulations.
35. WARNING: Keep ventilation
openings, in the appliance enclosure
or in the built-in structure, clear of
obstruction.
36. WARNING: Do not use
mechanical devices or other means
to accelerate the defrosting process,
other than those recommended by
the manufacturer.
37. WARNING: Do not damage
the refrigerant circuit.

38. WARNING: Do not use
electrical appliances inside the food
storage compartments of the
appliance, unless they are of the
type recommended by the
manufacturer.
39. Do not store explosive
substances such as aerosol cans
with a flammable propellant in this
appliance.
40. Warning: Risk of
fire/flammable materials.
41. WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
42. WARNING: Do not locate
multiple portable socket- outlets or
portable power supplies at the rear
of the appliance.
43. This appliance is intended to
be used in household and similar

applications such as
–staff kitchen areas in shops, offices
and other working environments;
–farm houses and by clients in
hotels, motels and other residential
type environments;
–bed and breakfast type
environments;
–catering and similar non-retail
applications.
44. Save these instructions.
45. This appliance may be used
by children of at least 8 years of age,
as long as they are supervised and
have been given instructions about
using the appliance safely and are
fully aware of the dangers involved.
46. Cleaning and maintenance
should not be carried out by children
unless they are at least 8 years of
age and are supervised by an adult.

47. Keep the appliance and its
power cord out of reach of children
under 8 years of age.
48. When using electrical
equipment, safety precautions must
always be taken to prevent the risk
of fire, electric shock and/or injury in
the event of misuse.
49. The device must not be used
if it has been dropped, it obvious
signs of damage are visible or if it
has leaks.
Refrigerant :
The refrigerant gas contained in the
circuit of this appliance is isobutane
(R 600a), a low-polluting but
flammable gas.
- When transporting and installing the
appliance, take care not to damage
any part of the refrigerant circuit.

- Do not use any sharp or pointed
tools to defrost the unit.
- Do not use any electrical appliances
inside the unit. If the refrigeration
system is damaged:
-Do not use a flame near the
appliance.
Avoid sparks - do not light any
electrical appliance or electric lamp.
Ventilate the room immediately.

KNOW YOUR ICE MAKER

CONTROL PANEL
Key (with indicator)
Function
The indicator lights in green when select large ice.
The indicator lights in green when select small ice.
The indicator lights in green when the appliance
needs to be cleaned.
Start or stop the appliance
Select the ice size
The indicator lights in green when making ice.
The indicator lights in red when the water reservoir
is lack of water.
The indicator lights in red when the ice basket is full.

BEFORE FIRST USE
1. Unpack the appliance, then check and make sure
that all the accessories including ice basket and ice scoop
etc. are complete. Please contact with the client service
department if some accessories are missed.
2. Please ensure the ice maker is level and on a stable
table or platform to avoid malfunction.
3. The incline angle of the ice maker cabinet should
not exceed 45°during transportation or use. Do not turn
the ice maker upside down. Doing so could cause the
compressor or refrigerating system to operate incorrectly.
Please allow time for the fluids in the compressor to settle
after the ice maker is moved or transported. Before using
the ice maker for the first time, please wait for 2 hours after
the unit has been leveled and positioned in the proper
place.
4. The appliance must be placed on a dry and level
surface with sufficient ventilation, far from heat sources
such as ovens, heaters and corrosive gases. Leave an 8-
inch (20cm) clearance on all sides of the ice maker for
proper ventilation.
5. Do not fill the water reservoir with hot water. This
may damage the ice maker. It is best to fill the water
reservoir with water of room temperature or lower.
6. Do not use the appliance at a very cold environment
(lower than 5 ℃ ).
7. Clean the appliance by following the operation of
“CLEANING AND MAINTENANCE” before operate.
USING YOUR ICE MAKER
1. Ensure that the drain plug at the bottom of water
reservoir is closedwell.
2. Plug the ice maker into the wall outlet, the “”
indicator blinks.

NOTE : Please make the ice maker be rested for 30
minutes before plug if it has been moved.
3. Open the top lid and remove the ice basket.
4. WARNING: Fill the water reservoir with potable
water only.
NOTE : Do not fill above the MAX water level mark.
5. Alternatively, you can operate the Ice Maker under
the condition that it is supplied with water continuously by
following the operation as below:
(1) Firstly prepare a 1/4 water tube (outer
diameter:φ6.35mm) about 2m in length and then insert its
one end into the water inlet of Ice Maker.
(2) Check and make sure that the three-way ball valve
equipped is compatible with the water tube and water
faucet in your home.
(3) After checking, connect the three-way ball valve
with the tap water.
(4) Connect the other end of the 1/4 water tube with the
1/4 tube connector of the three-way ball valve.
(5) Check and make sure all the connection of water
tubes are tightly connected and then open the three-way
ball valve after confirmation.
6. Replace the ice basket and close the top lid.
7. Press “” key to select the ice size, “ ” means
small ice while “” means large ice.
8. Press the “ ” key and the “ ”indicator lights
solidly.
9. The ice-making cycle will last approximately 7-15
minutes, depending on the ambient temperature and
water temperature
10. The ice-making cycle starts with water being pumped
into the ice tray situated below the evaporator. Over the next
7-15 minutes ice forms on the evaporator. Once this has
completed, the ice tray will tilt backwards and the remaining

water in the ice tray is drained back into the water reservoir.
The ice cubes are then dropped from the evaporator and
pushed forward into the ice basket by the ice shovel. The ice
tray will automatically move back into position under the
evaporator and start the next cycle.
11. The “ ” indicator will light up when the ice basket
is full and then the ice maker will stop the ice-making cycle
automatically. Gently remove the ice from the ice basket with
the ice scoop. About 5 seconds later, the ice maker will
restart its ice making function automatically.
12. The “ ” indicator will light up when the water
reservoir is lack of water and the ice-making cycle will stop
automatically. At that time, remove the ice basket and add
water to the water
reservoir, and then press “ ” key again to restart the ice-
making cycle. And the “ ” indicator will not light up if the Ice
Maker is operated under the condition that it is supplied with
water continuously.
13. When you have got your desired amount of ice, stop
the ice making cycle by pressing the “” key and unplug the
unit from the wall outlet.
14. Open the top lid and transfer the ice to a freezer.
NOTE: The ice will last in the ice maker for up to a 18 hour
period, depending on the ambient temperature.
15. Allow the ice maker to wall up to room temperature.
16. Suggest replacing the water every a week. Please
empty the water reservoir if the ice maker is not used for a
long time.

CLEANING AND MAINTENANCE
To keep your ice tasting fresh and
your ice maker looking great, we
recommend cleaning your ice maker
at least once per week.
1. Stop the ice-making cycle by
pressing the “ ”key, unplug the
ice maker from the wall outlet and
allow it to warm up to room
temperature.
2. If residual water is found in the
ice tray, gently push the ice tray
back so that all water drains into the
water reservoir.
3. Move the appliance forward to a
place 60mm away from the
working table and open the drain
plug to drain out excess water
(see Fig.1, Fig.2 and Fig.3).

4. Check and make sure the drain
plug must be closed
well. Fill the water reservoir with
clean water, press “ ” until the ‘ ’
indicator flashes, then press the “”
key , the pump will start to pump
water and keep running for 6
minutes, and it will enter into
standby condition after running for 6
minutes, finally, open the drain plug
and empty the water.
5. Remove the ice basket.
6. Clean the ice maker interior with
a soft cloth soaked with warm water
and vinegar, then rinse with clean
water and then drain all the water.
7. Replace the drain plug well in
position. Wash the ice basket and
ice scoop in warm soapy water.
Rinse anddry.

8. Clean the exterior of the ice
maker with a soft damp
cloth. Use a mild dishwashing soap, if
necessary.
NOTE: Do not use organic
solvent, boiled water, detergent,
strong acid and strong alkali etc.
for cleaning.
9. Please empty the water
reservoir and dry it for storage if
the ice maker is not used for a
longtime.
Fig.1
