H3C MSR Series Installation manual

H3C MSR Series Routers
Probe Command Reference(V7)
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com
Software version: MSR-CMW710-R0007
Document version: 6W100-20140320

Copyright © 2014, Hangzhou H3C Technologies Co., Ltd. and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior
written consent of Hangzhou H3C Technologies Co., Ltd.
Trademarks
H3C, , H3CS, H3CIE, H3CNE, Aolynk, , H3Care, , IRF, NetPilot, Netflow,
SecEngine, SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of
Hangzhou H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their respective owners
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

Preface
The H3C MSR documentation set includes 15 command references, which describe the commands and
command syntax options available for the H3C MSR Series Routers.
The Probe Command Reference(V7) describes the router probe configuration commands.
This preface includes:
•Audience
•Conventions
•About the H3C MSR documentation set
•Obtaining documentation
•Technical support
•Documentation feedback
These configuration guides apply to the following models of the H3C MSR series routers:
Model
MSR 2600 •MSR 26-30
MSR 3600
•MSR 36-10
•MSR 36-20
•MSR 36-40
•MSR 36-60
•MSR3600-28
•MSR3600-51
MSR 5600
•MSR 56-60
•MSR 56-80
Audience
This documentation is intended for:
•Network planners
•Field technical support and servicing engineers
•Network administrators working with the routers

Conventions
This section describes the conventions used in this documentation set.
Command conventions
Convention Descri
p
tion
Boldface Bold text represents commands and keywords that you enter literally as shown.
Italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from which
you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical bars, from
which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by vertical
bars, from which you select at least one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntax choices separated by vertical
bars, from which you select one choice, multiple choices, or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&) sign can
be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
Symbols
Convention Descri
p
tion
WARNING An alert that calls attention to important information that if not understood or followed can
result in personal injury.
CAUTION An alert that calls attention to important information that if not understood or followed can
result in data loss, data corruption, or damage to hardware or software.
IMPORTANT An alert that calls attention to essential information.
NOTE An alert that contains additional or supplementary information.
TIP An alert that provides helpful information.
Port numbering in examples
The port numbers in this document are for illustration only and might be unavailable on your device.
About the H3C MSR documentation set
The H3C MSR documentation set includes:
Cate
g
or
y
Documents Pur
p
oses
Product description and
specifications Marketing brochures Describe product specifications and benefits.

Cate
g
or
y
Documents Pur
p
oses
Hardware specifications
and installation
Installation guide Provides a complete guide to hardware installation
and hardware specifications.
MSR Series Routers
Interface Module Manual
Provide the hardware specifications of cards.
Software configuration
MSR Series Routers
Configuration guides(v7)
Describe software features and configuration
procedures.
MSR Series Routers
Command references(v7)
Provide a quick reference to all available
commands.
Operations and
maintenance Release notes
Provide information about the product release,
including the version history, hardware and software
compatibility matrix, version upgrade information,
technical support information, and software
upgrading.
Obtaining documentation
You can access the most up-to-date H3C product documentation on the World Wide Web
at http://www.h3c.com.
Click the links on the top navigation bar to obtain different categories of product documentation:
[Technical Support & Documents > Technical Documents]—Provides hardware installation, software
upgrading, and software feature configuration and maintenance documentation.
[Products & Solutions]—Provides information about products and technologies, as well as solutions.
[Technical Support & Documents > Software Download]—Provides the documentation released with the
software version.
Technical support
servic[email protected]
http://www.h3c.com
Documentation feedback
You can e-mail your comments about product documentation to [e-mail].
We appreciate your comments.

i
Contents
Common probe commands········································································································································· 1
display hardware internal dump ····························································································································1
display hardware internal physical ························································································································1
debugging physical card·········································································································································2
Switching module probe commands ·························································································································· 3
bcm ············································································································································································3
debugging physical lsw···········································································································································3
display hardware internal physical lsw ·················································································································4
display hardware internal physical lsw vlaninfo···································································································5
display hardware internal dump lsw vlantable·····································································································5
display hardware internal dump lsw mactable·····································································································6
display hardware internal dump lsw acltable·······································································································6
debugging physical mgf··········································································································································7
display hardware internal physical mgf debugging ····························································································7
display hardware internal physical mgf ················································································································8
display hardware internal dump chip····················································································································8
debugging physical poe··········································································································································9
display hardware internal physical poe debugging ························································································· 10
display hardware internal physical poe powerinfo··························································································· 10
display hardware internal physical poe ············································································································· 10
display hardware internal physical poe portinfo······························································································· 11
Interface probe commands········································································································································12
display hardware internal physical ····················································································································· 12
display hardware internal physical isrque ········································································································· 12
display hardware internal dump chassis slot inner-port···················································································· 13
display hardware internal dump slot inner-port chip························································································· 13
debugging physical··············································································································································· 14
reset hardware internal dump slot inner-port counter························································································ 14
Voice probe commands·············································································································································16
dsp-capture pcm ···················································································································································· 16
display hardware internal dspmem····················································································································· 16
vpm-mirror ······························································································································································ 17
debugging physical voice fax······························································································································ 17
display hardware internal voice fax debugging································································································ 18
Main board probe commands··································································································································19
display hardware internal pcicfg························································································································· 19
display hardware internal access-space············································································································· 19
switch console························································································································································ 20
Host probe commands···············································································································································21
display hardware internal cpu-version················································································································ 21
restore factory-default············································································································································ 21
Index ···········································································································································································22

1
Common probe commands
display hardware internal dump
Use display hardware internal dump to display the dump register information of a chip.
Syntax
display hardware internal dump if-name [card ]chip chip-num [global | channel ]
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
if-name: Specifies a registered interface or controller by its name.
card: Specifies the card system.
chip-num: Specifies a chip by its number in the range of 0x00 to 0xFF.
global: Specifies the global register.
channel: Specifies the channel register.
Usage guidelines
This command reads the DUMP register information of the specified chip, one group of values each time.
display hardware internal physical
Use display hardware internal physical to display the dump software information.
Syntax
display hardware internal physical if-name [ boardinfo | intinfo | intinfo-priv | rxbd | statistic | txbd ]
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
if-name: Specifies a registered interface or controller by its name.
boardinfo: Displays main board information.
intinfo: Displays basic interface information.

2
intinfo-priv: Displays private interface information.
rxbd: Displays received BD information.
statistic: Displays the statistics.
txbd: Displays sent BD information.
debugging physical card
Use debugging physical card to enable debugging for the card system.
Use undo debugging physical card to disable debugging for the card system.
Syntax
debugging physical if-name card [ all | error | event | packet ]
undo debugging physical if-name card [ all | error | event | packet ]
Default
Debugging for the card system is disabled.
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
if-name: Specifies an interface or controller by its name.
card: Specifies the card system.
all: Specifies all types of debugging.
error: Specifies error debugging.
event: Specifies event debugging.
packet: Specifies packet debugging.
Usage guidelines
Debugging compromises system performance. To troubleshoot the router, enable only required
debugging functions.

3
Switching module probe commands
bcm
Use bcm to execute probe commands for a Broadcom chip.
Syntax
bcm chassis-num slot-num/subslot-num chip-num string
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
chassis-num: Specifies a chassis by its number, which is always 0.
slot-num: Specifies a slot by its number in the range of 0 to 255.
subslot-num: Specifies a subslot by its number in the range of 0 to 255.
chip-num: Specifies a chip by its number in the range of 0 to 31.
string: Specifies probe commands for the Broadcom chip. Use slashes (/) to separate commands.
Usage guidelines
Use this command to execute the specified probe commands for the specified switching chip. If you
specify two or more commands for the string argument, separate the commands with slashes.
debugging physical lsw
Use debugging physical lsw to enable debugging for the specified submodule or all submodules of the
switching module.
Use undo debugging physical lsw to disable submodule debugging.
Syntax
debugging physical lsw {all | acl | ioctl | mac | mc | ni | port | proto | psec | qos | sys | vlan }{all
| error | event | timer }
undo debugging physical lsw {all | acl | ioctl | mac | mc | ni | port | proto | psec | qos | sys | vlan }
{all | error | event | timer }
Default
Submodule debugging is disabled.
Views
Probe view

4
Predefined user roles
network-admin
network-operator
Parameters
all: Specifies all submodules of the switching module.
acl: Specifies the ACL submodule of the switching module.
ioctl: Specifies the ioctl submodule of the switching module.
mac: Specifies the MAC submodule of the switching module.
mc: Specifies the multicast submodule of the switching module.
ni: Specifies the NI submodule of the switching module.
port: Specifies the port submodule of the switching module.
proto: Specifies the protocol submodule of the switching module.
psec: Specifies the port security submodule of the switching module.
qos: Specifies the QoS submodule of the switching module.
sys: Specifies the system submodule of the switching module.
vlan: Specifies the VLAN submodule of the switching module.
all: Specifies all types of debugging.
error: Specifies error debugging.
event: Specifies event debugging.
timer: Specifies timer debugging.
Usage guidelines
Outputting the debugging information affects system operation efficiency. When you diagnose a
network fault, use this command to enable debugging for the specified submodule of the switching
module, rather than multiple submodules.
Related commands
display system internal dump lsw debugging
display hardware internal physical lsw
Use display hardware internal physical lsw to display internal information for the switching module.
Syntax
display hardware internal physical lsw {acltable | boardinfo | chipnoinfo | globalinfo | debugging |
isolationinfo | mactable | multicasttable | qosinfo | stpinfo } [ subslot ]
Views
Probe view
Predefined user roles
network-admin
network-operator

5
Parameters
acltable: Specifies the ACL information.
boardinfo: Specifies the card information.
chipnoinfo: Specifies the chip number information.
globalinfo: Specifies the global variable information.
debugging: Specifies the debugging information.
isolationinfo: Specifies the port isolation information.
mactable: Specifies the MAC address entry information.
multicasttable: Specifies the multicast entry information.
qosinfo: Specifies the QoS information.
stpinfo: Specifies the STP status information.
subslot: Specifies a slot by its number in the range of 0 to 255.
Usage guidelines
This command reads software information of the DUMP switching module.
display hardware internal physical lsw vlaninfo
Use display hardware internal physical lsw vlaninfo to display VLAN information.
Syntax
display hardware internal physical lsw vlaninfo vlan-id
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
vlan-id: Specifies a VLAN by its ID in the range of 0 to 4095.
display hardware internal dump lsw vlantable
Use display hardware internal dump lsw vlantable to display VLAN entry information.
Syntax
display hardware internal dump lsw subslot-num vlantable vlan-id
Views
Probe view
Predefined user roles
network-admin
network-operator

6
Parameters
subslot-num: Specifies a subslot by its number in the range of 0 to 255.
vlan-id: Specifies a VLAN by its ID in the range of 0 to 4095.
display hardware internal dump lsw mactable
Use display hardware internal dump lsw mactable to display MAC address entry information.
Syntax
display hardware internal dump lsw subslot-num mactable [all |vlan vlan-id |interface-type
{ interface-number |interface-number.subnumber } ]
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
subslot-num: Specifies a subslot by its number in the range of 0 to 255.
all: Specifies all MAC address entries.
vlan-id: Specifies a VLAN by its ID in the range of 0 to 4095.
interface-type: Specifies an interface by its type.
interface-number: Specifies an interface by its number.
interface-number.subnumber: Specifies a subinterface by its interface number and subinterface number
in the range of 1 to 4094.
display hardware internal dump lsw acltable
Use display hardware internal dump lsw subslot-num acltable start-index total-num chip-num to display
DUMP ACL entry information.
Syntax
display hardware internal dump lsw subslot-num acltable start-index total-num chip-num
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
subslot-num: Specifies a subslot by its number in the range of 0 to 255.
start-index: Specifies the start index number in the range of 0 to 65535.
total-num: Specifies the total number of ACL entries in the range of 0 to 65535.

7
chip-num: Specifies the chip number in the range of 0 to 31.
debugging physical mgf
Use debugging physical mgf to enable debugging for the forwarding card.
Use undo debugging physical mgf to disable debugging for the forwarding card.
Syntax
debugging physical mgf { all | error | event | packet }
undo debugging physical mgf {all | error | event | packet }
Default
Debugging for the forwarding card is disabled.
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
all: Specifies all types of debugging.
error: Specifies error debugging.
event: Specifies event debugging.
packet: Specifies packet debugging.
Usage guidelines
Outputting the debugging information affects system operation efficiency. When you diagnose a fault,
use this command to enable the specified debugging, rather than all types of debugging.
display hardware internal physical mgf debugging
Use display hardware internal physical mgf debugging to display the enabled MGF debugging.
Syntax
display hardware internal physical mgf debugging
Views
Probe view
Predefined user roles
network-admin
network-operator

8
display hardware internal physical mgf
Use display hardware internal physical mgf to display information about the specified interface on the
MGF.
Syntax
display hardware internal physical mgf [ port-num ]{counter | devicemap | rxbd | softinfo | statistic |
txbd }
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
port-num: Specifies a MGF port by its number in the range of 0 to 63.
display hardware internal dump chip
Use display hardware internal dump chip to display register entry information.
Syntax
display hardware internal dump if-name chip chip-num [acltable | cpuport | devicemap |
multicasttable | meter | mirror | pcieconfig | phy | isolationtable | qosprofile | statistics | stptable |
vlanqos | all | cpld | global | mac | mactable | vlantable ]
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
if-name: Specifies an interface by its name.
chip-num: Specifies a chip by its number in the range of 0x00 to 0xFF.
acltable: Displays ACL entry information.
cpuport: Displays CPU port information.
devicemap: Displays device mapping table information.
multicasttable: Displays multicast entry information.
meter: Displays chip rule information.
mirror: Displays mirroring group information.
pcieconfig: Displays PCIE configuration information.
phy: Displays PHY register information.

9
isolationtable: Displays port isolation group information.
qosprofile: Displays QoS configuration information.
statistics: Displays statistics.
stptable: Displays STP table information.
vlanqos: Displays VLAN QoS configuration information.
all: Displays information about all entries.
cpld: Displays CPLD information.
global: Displays global register information.
mac: Displays MAC register information.
mactable: Displays MAC address table information.
vlantable: Displays VLAN entry information.
Usage guidelines
This command reads DUMP register information for the specified chip. It reads a group of DUMP register
values each time.
debugging physical poe
Use debugging physical poe to enable PoE module debugging.
Use undo debugging physical poe to disable PoE module debugging.
Syntax
debugging physical poe {all | error | event | packet }
undo debugging physical poe {all | error | event | packet }
Default
PoE module debugging is disabled.
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
all: Specifies all types of debugging.
error: Specifies error debugging.
event: Specifies event debugging.
packet: Specifies packet debugging.
Usage guidelines
Outputting the debugging information affects system operation efficiency. When you diagnose a fault,
use this command to enable the specified debugging, rather than all types of debugging.

10
Related commands
display system internal dump poe debugging
display hardware internal physical poe debugging
Use display hardware internal physical poe debugging to display the enabled PoE module debugging.
Syntax
display hardware internal physical poe debugging
Views
Probe view
Predefined user roles
network-admin
network-operator
display hardware internal physical poe powerinfo
Use display hardware internal physical poe powerinfo to display PoE power information.
Syntax
display hardware internal physical poe powerinfo
Views
Probe view
Predefined user roles
network-admin
network-operator
display hardware internal physical poe
Use display hardware internal physical poe to display DUMP card information.
Syntax
display hardware internal physical poe slot-num {queueinfo | serialinfo | subslotinfo }
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
slot-num: Specifies a slot by its number.

11
display hardware internal physical poe portinfo
Use display hardware internal physical poe portinfo to display information about PoE ports in the
specified range.
Syntax
display hardware internal physical poe slot-num start-port<0-63> end-port<0-63> portinfo
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
slot-num: Specifies a slot by its number.
start-port: Specifies the start PoE port number in the range of 0 to 63.
end-port: Specifies the end PoE port number in the range of 0 to 63.

12
Interface probe commands
display hardware internal physical
Use display hardware internal physical to display transmit queues and receive queues on a serial
interface.
Syntax
display hardware internal physical interface-type interface-number {tx_queue |rx_queue }
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
interface-type: Specifies a serial interface.
interface-number: Specifies a serial interface by its number.
tx_queue: Displays transmit queues.
rx_queue: Displays receive queues.
display hardware internal physical isrque
Use display hardware internal physical isrque to display interruption queues on a CPOS interface.
Syntax
display hardware internal physical interface-type interface-number isrque
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
interface-type: Specifies a CPOS interface.
interface-number: Specifies a CPOS interface by its number.
isrque: Displays interruption queues.

13
display hardware internal dump chassis slot inner-port
Use display hardware internal dump chassis slot inner-port to display register information about a
specified internal interface or all internal interfaces in a slot.
Syntax
display hardware internal dump chassis chassis-num slot slot-num inner-port [ inner-port-num ]
[ statistics ]
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
chassis-num:Specifies a chassis by its number, which is always 0.
slot-num: Specifies a slot by its number in the range of 0 to 255.
inner-port-num: Specifies an internal interface by its number in the range of 0 to 255.
inner-port: Displays internal interface information.
statistics: Displays statistics for the specified interfaces.
display hardware internal dump slot inner-port chip
Use display hardware internal dump slot inner-port chip to display software information about an
internal interface.
Syntax
display hardware internal dump slot slot-num inner-port inner-port-num chip chip-num {statistics |rxbd
|txbd |keyregs |priv-info }
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
slot-num: Specifies a slot by its number in the range of 0 to 255.
inner-port-num: Specifies an internal interface by its number in the range of 0 to 255.
chip-num: Specifies a chip by its number in the range of 0 to 255.
statistics: Displays statistics for the specified chip.
txbd: Displays the transmit buffer description.
rxbd: Displays the receive buffer description.

14
keyregs: Displays addresses and values of the key registers.
priv-info: Displays private information.
debugging physical
Use debugging physical to enable IPC-related debugging.
Use undo debugging physical to disable IPC-related debugging.
Syntax
debugging physical chassis chassis-number slot slot-number { mbus |lipc |mbuf-relay } { all |error |
event |input |output }
undo debugging physical chassis chassis-number slot slot-number { mbus |lipc |mbuf-relay } { all |
error |event |input |output }
Default
IPC-related debugging is disabled.
Views
Probe view
Predefined user roles
network-admin
network-operator
Parameters
chassis chassis-num: Specifies a chassis by its number, which is always 0.
slot slot-num: Specifies a slot by its number.
mbus: Specifies the management bus protocol.
lipc: Specifies Leopard IPC.
mbuf-relay: Specifies MBUF relay.
all: Specifies all types of debugging.
error: Specifies error debugging.
event: Specifies event debugging.
input: Specifies input debugging.
output: Specifies output debugging.
Usage guidelines
This command supports enabling debugging for a specified module, facilitating debugging in
development.
reset hardware internal dump slot inner-port counter
Use reset hardware internal dump slot inner-port counter to clear statistics for all internal interfaces in a
slot.
