H3C RA5300 User manual

H3C RA5300 Router
Installation Guide
New H3C Technologies Co., Ltd.
http://www.h3c.com
Document version: 6W100-20230916

Copyright © 2023, New H3C Technologies Co., Ltd. and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior written
consent of New H3C Technologies Co., Ltd.
Trademarks
Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this
document are the property of their respective owners.
Notice
The information in this document is subject to change without notice. All contents in this document, including
statements, information, and recommendations, are believed to be accurate, but they are presented without
warranty of any kind, express or implied. H3C shall not be liable for technical or editorial errors or omissions
contained herein.

Preface
This document guides you through the installation of the H3C RA5300 router. It provides instructions
on preparing the site for installation, installing the router, and troubleshooting the router.
This preface includes the following topics about the documentation:
•
Audience.
•
Conventions.
•
Documentation feedback.
Audience
This documentation is intended for:
•
Network planners.
•
Field technical support and servicing engineers.
•
Network administrators.
Conventions
The following information describes the conventions used in the documentation.
Command conventions
Convention
Description
Boldface Bold text represents commands and keywords that you enter literally as shown.
Italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from which
you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical bars,
from which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by vertical
bars, from which you select a minimum of one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntaxchoices separated by vertical
bars, from which you select one choice, multiple choices, or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&) sign
can be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
GUI conventions
Convention
Description
Boldface Window names, button names, field names, and menu items are in Boldface. For
example, the New User window opens; click OK.
> Multi-level menus are separated by angle brackets. For example, File > Create >
Folder.

Symbols
Convention
Description
WARNING! An alert that calls attention to important information that if not understood or followed
can result in personal injury.
CAUTION:
An alert that calls attention to important information that if not understood or followed
can result in data loss, data corruption, or damage to hardware or software.
IMPORTANT:
An alert that calls attention to essential information.
NOTE:
An alert that contains additional or supplementary information.
TIP:
An alert that provides helpful information.
Network topology icons
Convention
Description
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that
supports Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the access
controller engine on a unified wired-WLAN switch.
Represents an access point.
Represents a wireless terminator unit.
Represents a wireless terminator.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Represents a security product, such as a firewall, UTM, multiservice security
gateway, or load balancing device.
Represents a security module, such as a firewall, load balancing, NetStream, SSL
VPN, IPS, or ACG module.
Examples provided in this document
Examples in this document might use devices that differ from your device in hardware model,
configuration, or software version. It is normal that the port numbers, sample output, screenshots,
and other information in the examples differ from what you have on your device.
T
T
T
T

Documentation feedback
You can e-mail your comments about product documentation to [e-mail].
We appreciate your comments.

i
Contents
1 Preparing for installation··········································································1-1
Safety recommendations ································································································································1-1
Safety symbols········································································································································1-1
General safety recommendations···········································································································1-1
Electricity safety······································································································································1-1
Laser safety·············································································································································1-1
Examining the installation site·························································································································1-2
Temperature and humidity······················································································································1-2
Cleanliness··············································································································································1-2
Cooling system········································································································································1-3
Grounding ···············································································································································1-3
ESD prevention·······································································································································1-3
EMI··························································································································································1-4
Lightning protection·································································································································1-4
Power supply···········································································································································1-4
Installation tools ··············································································································································1-5
Installation accessories···································································································································1-5
Pre-installation checklist··································································································································1-5
2 Installing the router··················································································2-1
Installation prerequisites ·································································································································2-1
Installation flowchart········································································································································2-1
Mounting the router in a rack ··························································································································2-2
Installing the router in a 19-inch rack······································································································2-3
Installing the router in an ETSI rack········································································································2-4
Mounting the router on a workbench···············································································································2-5
Grounding the router·······································································································································2-6
Grounding the router through the grounding point on the left mounting bracket·····································2-6
Grounding the router through the grounding point on the chassis··························································2-7
Installing routing and switching units···············································································································2-8
Installing interface modules·····························································································································2-9
Installing power supplies·······························································································································2-10
Connecting interface cables··························································································································2-11
Connecting an Ethernet cable to a copper port·····················································································2-11
Connecting an optical fiber to a fiber port ·····························································································2-11
Connecting power cords ·······························································································································2-13
Verifying the installation································································································································2-14
Accessing the router ·····································································································································2-14
Using a console cable to connect the router to a configuration terminal···············································2-14
Powering on the router··························································································································2-15
Configuring basic settings·····················································································································2-16
3 Replacement procedure···········································································3-1
Replacing a power supply·······························································································································3-1
Replacing the fan tray·····································································································································3-2
Replacing an RSU···········································································································································3-2
Replacing an interface module ·······················································································································3-3
Replacing a transceiver module······················································································································3-4
Replacing a transceiver module and optical fiber ···················································································3-4
Replacing a QSFP28/SFP28 copper cable·····························································································3-5
4 Hardware management and maintenance···············································4-1
Displaying software and hardware version information for the router·····························································4-1
Displaying operating information about the router ··························································································4-1
Displaying detailed information about the router·····························································································4-2
Displaying electrical label information for the router ·······················································································4-3
Displaying CPU usage information ·················································································································4-4

ii
Displaying memory usage information············································································································4-4
Displaying the fan tray operating status··········································································································4-5
Displaying the power supply operating status·································································································4-6
Displaying router temperature information······································································································4-6
Displaying transceiver module information ·····································································································4-7
Diagnosing transceiver modules·····················································································································4-7
Saving the running configuration ····················································································································4-7
Rebooting the router or a module ···················································································································4-8
5 Troubleshooting·······················································································5-1
Power supply failure········································································································································5-1
Fan tray failure················································································································································5-1
Configuration terminal display issues··············································································································5-1
No terminal display··································································································································5-2
Garbled terminal display ·························································································································5-2
No response from the serial port·············································································································5-2
Interface module, cable, and connection failure ·····························································································5-2
Symptom·················································································································································5-2
Solution···················································································································································5-3
System failure during operation ······················································································································5-3
Guidelines for using the reset button ······································································································5-3

1-1
1 Preparing for installation
Safety recommendations
To avoid bodily injury and damage to the router, read all safety recommendations carefully before
installation. Note that the recommendations do not cover every possible hazardous condition.
Safety symbols
When reading this document, note the following symbols:
WARNING means an alert that calls attention to important information that if not understood or
followed can result in personal injury.
CAUTION means an alert that calls attention to important information that if not understood or
followed can result in data loss, data corruption, or damage to hardware or software.
General safety recommendations
•
Keep the chassis clean and dust-free.
•
Do not place the router on a moist area, and avoid liquid flowing into the router.
•
Make sure the ground is dry and flat and anti-slip measures are in place.
•
Ensure good ventilation in the equipment room and keep the air inlet and outlet vents of the
router free of obstruction.
•
Use a screwdriver to fasten screws.
•
After completing the installation, move the empty packaging materials and installation tools
away from the router area.
•
Keep the chassis and installation tools away from walk areas.
Electricity safety
•
Clear the work area of possible electricity hazards, such as ungrounded power extension
cables, missing safety grounds, and wet floors.
•
Locate the emergency power-off switch in the room before installation so you can quickly shut
power off when an electrical accident occurs.
•
Do not work alone when the router has power.
•
Never assume that power has been disconnected from a circuit. Always check.
Laser safety
WARNING
!
•
Disconnected optical fibers or transceiver modules might emit invisible laser light. Do not stare
into beams or view directly with optical instruments when the router is operating.
•
Before you remove the optical fiber connector from a fiber port, execute the shutdown
command in interface view to shut down the port.

1-2
CAUTION:
•
Insert dust caps into open optical fiber connectors to protect them from contamination and ESD
damage.
•
Insert dust plugs into open fiber ports and transceiver module ports to protect them from
contamination and ESD damage.
Examining the installation site
The router must be used indoors. To ensure correct operation and long service life of your router,
make sure the installation site meets the following requirements.
Temperature and humidity
CAUTION:
The operating temperature
range of 50G or 100G transceiver modules is 0°C to 70°C (32°F to
158°F)
. With a 50G or 100G transceiver module installed in the router, the operating temperature
range of the
router is 0°C to 70°C (32°F to 158°F). For information about the models of the 50G or
100G transceiver modules, see H3C RA5300 Router Interface Module Manual.
To ensure correct operation and long lifespan of the router, make sure the temperature and humidity
in the equipment room meet the requirements as described in Table1-1.
•
Lasting high relative humidity tends to cause poor insulation, electricity leakage, mechanical
property change of materials, and corrosion of metal parts.
•
Lasting low relative humidity is likely to cause washer contraction and ESD and cause
problems including loose mounting screws and circuit failure.
•
A high temperature is the most undesirable condition, because it accelerates the aging of
insulation materials and significantly lowers reliability and service life of the router.
Table1-1 Temperature and humidity requirements
Item Operating Storage
Temperature –20°C to +60°C (–4°F to +140°F) –40°C to +70°C (–40°F to +158°F)
Humidity 5% RH to 95% RH, noncondensing 5% RH to 95% RH, noncondensing
Cleanliness
Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of
metal components and contact points, especially when indoor relative humidity is low. In the worst
case, electrostatic adsorption can cause communication failure.
Table1-2 Dust concentration limit in the equipment room
Substance Concentration limit (particles/m3)
Dust particles ≤ 3 × 10
4
(No visible dust on desk in three days)
NOTE:
Dust particle diameter ≥ 5 µm

1-3
The equipment room must also meet limits on salts, acids, and sulfides to eliminate corrosion and
premature aging of components, as shown in Table1-3.
Table1-3 Harmful gas limits in the equipment room
Gas Max. (mg/m3)
SO21.0
H2S 0.5
NH33.0
NO21.0
Cl20.3
Cooling system
The router uses left-to-right airflow for heat dissipation, as shown in Figure1-1.
For adequate cooling of the router, follow these guidelines:
•
Plan the installation location for the router based on its airflow direction.
•
Ensure a minimum clearance of 100 mm (3.94 in) around the air inlet and outlet vents on the
router.
•
Make sure that the installation site has a good cooling system.
Figure1-1 Airflow through the chassis
Grounding
Correctly grounding the router is crucial to lightning protection, anti-interference, and ESD
prevention. Use a good grounding system for the router. Make sure the resistance between the
chassis and the ground is less than 1 ohm.
For more information about grounding the router, see "Grounding the router."
ESD prevention
CAUTION:
Check the resistance of the ESD wrist strap for safety. The resistance reading
must
be in the range
of 1 to 10 megohm (Mohm) between human body and the ground.

1-4
Preventing electrostatic discharge
To prevent electrostatic discharge (ESD) damage, follow these guidelines:
•
Make sure the router, workbench, and rack are reliably grounded.
•
Take dust-proof measures for the equipment room.
•
Maintain the humidity and temperature at acceptable levels.
•
Always wear an ESD wrist strap and make sure it is reliably grounded when installing FRUs.
•
Place the removed interface module on an antistatic workbench or put it into an antistatic bag,
with the component side facing upward.
•
Hold an interface module by its edges when you observe or move a removed interface module.
Do not touch any electronic components.
Attaching an ESD wrist strap
1. Wear the wrist strap on your wrist.
2. Lock the wrist strap tight around your wrist to keep good contact with the skin.
3. Secure the wrist strap lock and the alligator clip lock together.
4. Attach the alligator clip to the rack or workbench.
5. Make sure the rack or workbench is reliably grounded.
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the router and application
system, adversely affect the router in the following ways:
•
A conduction pattern of capacitance coupling.
•
Inductance coupling.
•
Electromagnetic wave radiation.
•
Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:
•
Take effective measures to filter interference from the power grid.
•
Separate the working earthing system of the router from the grounding facility and lightning
protection facility of the other electrical devices as far as possible.
•
Keep the router far away from high-power transmitting stations and radar stations as well as
high-frequency high-power devices.
•
Use electromagnetic shielding, for example, shielded interface cables, when necessary.
Lightning protection
To better protect the router from lightning, do as follows:
•
Make sure the chassis is reliably grounded.
•
Make sure the grounding terminal of the power receptacle is reliably grounded.
•
Install a lightning arrester at the input end of the power supply to enhance the lightning
protection capability of the power supply.
Power supply
Make sure the power supply system at the installation site is stable and meets the requirements of
the power supplies, including the rated input voltage and input current. For more information about
available power supplies, see H3C RA5300 Router Hardware Information and Specifications.

1-5
Installation tools
No installation tools are provided with the router. Prepare them yourself as required.
Figure1-2 Installation tools
Installation accessories
Figure1-3 Installation accessories
Pre-installation checklist
Table1-4 Pre-installation checklist
Item Requirements Result
Installation site Ventilation
•A minimum clearance of 100 mm (3.94 in) is
reserved around the air inlet and outlet vents.
•The installation site has a good ventilation
system.

1-6
Item Requirements Result
Operating
temperature –20°C to +60°C (–4°F to +140°F)
Operating
humidity 5% RH to 95% RH (noncondensing).
Cleanliness •Dust concentration ≤ 3 × 104 particles/m3.
•No visible dust on desk within three days.
Grounding
requirements
•
The grounding specifications for the equipment
room comply with national and industry
standards.
•All communication devices in the equipment
room are reliably grounded.
•The working earthing and protective earthing
systems of the communication power supplies
use the same earthing conductor set with the
protective earthing system of the
communication devices.
ESD prevention
•The router, rack and workbench are reliably
grounded.
•Dust-proof measures are taken in the
equipment room.
•Humidity and temperature are maintained at
acceptable levels.
•Wear an ESD wrist strap and make sure it
makes good skin contact and is reliably
grounded when installing FRUs.
•Place the removed interface module on an
antistatic workbench or put it into an antistatic
bag, with the component side facing upward.
•Hold an interface module by its edges when
you observe or move a removed interface
module. Do not touch any electronic
components.
EMI prevention
•Effective measures are taken for filtering
interference from the power grid.
•The working earthing of the router is away from
the grounding facility of power equipment or
lightning protection grounding facility.
•The router is far away from radio transmitting
stations, radar stations, and high-frequency
high-current devices.
•Electromagnetic shielding, for example,
shielded interface cables, is used as required.
Lightning
protection
•The router is reliably grounded.
•The grounding point of the power receptacle is
reliably grounded.
•(Optional.) Network port lightning arresters are
available.
•(Optional.) Power lightning arresters are
available.
Electricity safety
•An uninterrupted power supply (UPS) is
available.
•The power-off switch in the equipment room is
located so that the power can be immediately
shut off when an accident occurs.

1-7
Item Requirements Result
Workbench •The workbench is sturdy and stable.
•The workbench is reliably grounded.
Rack
•The rack has a good ventilation system.
•The rack is sturdy and can support the router
and its accessories.
•The rack has a size that can accommodate the
router.
•A minimum distance of 0.8 m (2.62 ft) is
reserved between the rack and walls or other
devices.
Safety
precautions
•The router is far away from any moist area and heat source.
•The power-off switch in the equipment room is located.
Tools •Installation accessories supplied with the router are available.
•User-supplied tools are available.
Reference •Documents shipped with the router are available.
•Online documents are available.

2-1
2 Installing the router
WARNING
!
To avoid injury, do not touch bare wires, terminals, or parts with high-voltage hazard signs.
IMPORTANT:
•
The barcode on the router chassis contains product information that must be provided to local
sales agent when you return a faulty router for service.
•
Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to
open the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any
consequence.
Installation prerequisites
•
You have read "Preparing for installation" carefully.
•
All the requirements described in "Preparing for installation" are met.
Installation flowchart
You can install the router on a workbench or in a rack. Select an installation method according to the
installation environment, and follow the installation flowchart shown in Figure2-1.

2-2
Figure2-1 Installation flowchart
Mounting the router in a rack
WARNING
!
To avoid bodily injury and router damage, use a minimum of two persons to install the router.
CAUTION:
The mounting brackets can support only the weight of
the router. Do not place objects on the
router.
End
Determine the
installation position
Mount the router in a
rack
Ground the router
Install RSUs
Install power
supplies
Verify the installation
Operating
correctly ? Troubleshoot the
router
No
Yes
Install interface
modules
Mount the router on
a workbench
Start
Connect power cords
Connect interface
cables

2-3
Installing the router in a 19-inch rack
1. Use a 19-inch rack mounting bracket to mark the cage nut installation holes in the front rack
posts and install cage nuts.
Figure2-2 Installing cage nuts
2. Use M4 mounting bracket screws to attach the 19-inch rack mounting brackets to both sides of
the router.
Figure2-3 Attaching the 19-inch rack mounting brackets to the router
3. Position the router in the 19-inch rack. Use M6 rack screws to attach the 19-inch rack
mounting brackets on the router to the front rack posts, as shown in Figure2-4.

2-4
Figure2-4 Securing the router to the 19-inch rack
Installing the router in an ETSI rack
1. Attach the 19-inch rack mounting brackets to both sides of the router. For more information,
see "Installing the router in a 19-inch rack."
2. Use M6 rack screws to attach the ETSI rack mounting brackets to the 19-inch rack mounting
brackets.
Figure2-5 Attaching the ETSI rack mounting brackets to the 19-inch rack mounting
brackets
3. Install cage nuts. For more information, see "Installing the router in a 19-inch rack."
4. Position the router in the ETSI rack. Use M6 rack screws to attach the ETSI rack mounting
brackets on the router to the front rack posts, as shown in Figure2-6.

2-5
Figure2-6 Securing the router to the ETSI rack
Mounting the router on a workbench
IM
PORTANT:
To
mount the router on a workbench, follow these guidelines:
•
Make sure the workbench is clean, stable, and reliably grounded.
•
Enable a minimum clearance of 100 mm (3.94 in) around the chassis for heat dissipation.
•Do not place heavy objects on the router.
To mount the router on a workbench:
1. Place the router upside down on the workbench.
2. Attach the rubber feet to the four round holes in the chassis bottom.
3. Place the router on the workbench with the top panel facing up.
Figure2-7 Mounting the router on a workbench

2-6
Grounding the router
CAUTION:
•
Correctly connecting the grounding cable is crucial to lightning protection and EMI protection.
Before using the router, make sure the router is reliably grounded.
•
Connect the grounding cable to the grounding system in the equipment room. Do not connect it
to a fire main or lightning rod.
The router has two grounding points: one on the chassis and one on the left 19-inch rack mounting
bracket. Select a grounding point as required.
Grounding the router through the grounding point on the left
mounting bracket
IMPORTANT:
You can use the grounding point on the left mounting bracket only when the mounting brackets are
installed at the front of the chassis.
To ground the router through the grounding point on the left mounting bracket:
1. Remove the grounding screw from the grounding point on the router chassis.
2. Use the grounding screw to attach the ring terminal (M6) of the grounding cable to the
grounding point on the mounting bracket and then fasten the screw.
3. Connect the ring terminal (M8) at the other end of the grounding cable to the grounding point
on the rack.
