H3C S5500-EI series User manual

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Table of Contents
i
Table of Contents
Chapter 1 Port Mirroring Configuration......................................................................................1-1
1.1 Introduction to Port Mirroring.............................................................................................1-1
1.1.1 Classification of Port Mirroring................................................................................1-1
1.1.2 Implementing Port Mirroring....................................................................................1-2
1.1.3 Other Functions Supported by Port Mirroring.........................................................1-3
1.2 Configuring Local Port Mirroring........................................................................................1-3
1.3 Configuring Remote Port Mirroring....................................................................................1-4
1.3.1 Configuring a Remote Source Mirroring Group ......................................................1-4
1.3.2 Configuring a Remote Destination Port Mirroring Group........................................1-5
1.4 Displaying and Maintaining Port Mirroring.........................................................................1-7
1.5 Port Mirroring Configuration Examples..............................................................................1-7
1.5.1 Local Port Mirroring Configuration Example...........................................................1-7
1.5.2 Remote Port Mirroring Configuration Example.......................................................1-8

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-1
Chapter 1 Port Mirroring Configuration
When configuring port mirroring, go to these sections for information you are interested
in:
zIntroduction to Port Mirroring
zConfiguring Local Port Mirroring
zConfiguring Remote Port Mirroring
zDisplaying and Maintaining Port Mirroring
zPort Mirroring Configuration Examples
1.1 Introduction to Port Mirroring
Port mirroring allows you to duplicate the packets passing specified ports to the
destination mirroring port. As destination mirroring ports usually have data monitoring
devices connected to them, you can analyze the packets duplicated to the destination
mirroring port on these devices so as to monitor and troubleshoot the network.
Host
Data monitoring device
Network
Source
mirroring port
Destination
mirroring port
Figure 1-1 A port mirroring implementation
1.1.1 Classification of Port Mirroring
There are two kinds of port mirroring: local port mirroring and remote port mirroring.
zLocal port mirroring copies packets passing through one or more ports (known as
source ports) of a device to the monitor port (also destination port) for analysis and
monitoring purpose. In this case, the source ports and the destination port are
located on the same device.
zRemote port mirroring implements port mirroring between multiple devices. That is,
the source ports and the destination port can be located on different devices in a
network. Currently, remote port mirroring can only be implemented on Layer 2.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-2
1.1.2 Implementing Port Mirroring
Port mirroring is implemented through port mirroring groups, which fall into these three
categories: local port mirroring group, remote source port mirroring group, and remote
destination port mirroring group. Two port mirroring implementation modes are
introduced in the following section.
I. Local port mirroring
Local port mirroring is implemented by local port mirroring group.
In this mode, the source ports and the destination port are in the same local port
mirroring group. Packets passing through the source ports are duplicated and then
forwarded to the destination port.
II. Remote port mirroring
Remote port mirroring is achieved through the cooperation of remote source port
mirroring group and remote destination port mirroring group.
Figure 1-2 illustrates a remote port mirroring implementation.
Figure 1-2 A remote mirroring implementation
The devices in Figure 1-2 function as follows:
zSource device
Source device contains source mirroring ports, and remote source port mirroring
groups are created on source devices. Asource device duplicates the packets passing
the source ports on it and sends them to the outbound port. The packets are then
broadcast in the remote mirroring VLAN and are received by the intermediate device or
destination device.
zIntermediate device
Intermediate devices are used to connect source devices and destination devices. An
intermediate device forwards the mirrored packets to the next intermediate device or
the destination device. If the source device is directly connected to the destination
device, no intermediate device is needed. In a remote mirroring VLAN, the source
devices and the destination device need to be able to communicate with one another
on Layer 2.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-3
zDestination device
Destination device contains destination mirroring port, and remote destination port
mirroring groups are created on destination devices. Upon receiving a mirrored packet,
the destination device checks to see if the VLAN ID of the received packet is the same
as that of the remote mirroring VLAN of the remote destination port mirroring group. If
yes, the destination device forwards the packet to the monitoring device through the
destination mirroring port.
1.1.3 Other Functions Supported by Port Mirroring
In addition, in a port mirroring group, a destination port can monitor multiple source
ports simultaneously in the mirroring group.
1.2 Configuring Local Port Mirroring
Follow these steps to configure local port mirroring:
To do… Use the command… Remarks
Enter system view system-view —
Create a local mirroring
group mirroring-group group-id
local Required
In system
view
mirroring-group group-id
mirroring-port
mirroring-port-list { both |
inbound |outbound }
interface interface-type
interface-number
[mirroring-group group-id ]
mirroring-port { both |
inbound | outbound }
Add ports
to the port
mirroring
group as
source
ports In
interface
view
quit
Use either approach.
You can add ports to a
port mirroring group as
source ports in either
system view or
interface view.
In system view, you
can add multiple ports
to a port mirroring
group at one time.
While in interface view,
you can only add the
current port to a port
mirroring group.
In system
view mirroring-group group-id
monitor-port monitor-port-id
interface interface-type
interface-number
Add a port
to the
mirroring
group as
the
destination
port
In
interface
view [mirroring-group group-id ]
monitor-port
Use either approach.
You can add a
destination port to a
port mirroring group in
either system view or
interface view. They
achieve the same
purpose.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-4
Note:
zA local mirroring group is effective only when it has both source ports and the
destination port configured.
zIt is not recommended to enable STP, RSTP or MSTP on the destination port;
otherwise, the mirroring function may be affected.
zDo not use the destination mirroring port for any purpose other than port mirroring.
zThe source ports and the destination port cannot be the member ports of the current
mirroring group.
zBefore adding the destination port for a port mirroring group, make sure the port
mirroring group exists. A mirroring group can have only one destination port.
1.3 Configuring Remote Port Mirroring
1.3.1 Configuring a Remote Source Mirroring Group
Follow these steps to configure a remote port mirroring group
To do… Use the command… Remarks
Enter system view system-view —
Create a remote
source mirroring group mirroring-group group-id
remote-source Required
In system
view
mirroring-group group-id
mirroring-port mirroring-port-list
{ both | inbound |outbound }
interface interface-type
interface-number
[ mirroring-group group-id ]
mirroring-port { both |inbound
| outbound }
Add ports
to the
mirroring
group as
source
ports
In
interface
view
quit
Use either approach.
You can add ports to
a source port
mirroring group in
either system view or
interface view. They
achieve the same
purpose.
In system
view
mirroring-group group-id
monitor-egress
monitor-egress-port-id
interface interface-type
interface-number
mirroring-group group-id
monitor-egress
Add a
port to
the
mirroring
group as
the
outbound
mirroring
port
In
interface
view
quit
Use either approach.
You can add ports to
a source mirroring
group in either system
view or interface view.
They achieve the
same purpose.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-5
To do… Use the command… Remarks
Configure the remote
port mirroring VLAN for
the mirroring group
mirroring-group group-id
remote-probe vlan
rprobe-vlan-id Required
Note:
zAll ports in a remote mirroring group belong to the same device. A remote source
mirroring group can have only one outbound mirroring port.
zThe outbound mirroring port cannot be a member port of the current mirroring
group.
zIt is not recommended to add the source ports to a remote VLAN, whichcan be used
for remote mirroring only.
zIt is not recommended to configure STP, RSTP, MSTP, 802.1x, IGMP Snooping,
static ARP and MAC address learning on the outbound mirroring port; otherwise,
the mirroring function may be affected.
zOnly existing static VLANs can be configured as remote port mirroring VLANs. To
remove a VLAN operating as aremote port mirroring VLAN, you need to restore it to
a normal VLAN first. A remote port mirroring group gets invalid if the corresponding
remote port mirroring VLAN is removed.
zA port can belong to only one port mirroring group. A VLAN can be the remote port
mirroring VLAN of only one port mirroring group.
1.3.2 Configuring a Remote Destination Port Mirroring Group
Follow these steps to configure a remote destination port mirroring group:
To do… Use the command… Remarks
Enter system view system-view —
Create a remote
destination port mirroring
group
mirroring-group group-id
remote-destination Required
Configure the remote port
mirroring VLAN for the port
mirroring group
mirroring-group group-id
remote-probe vlan
rprobe-vlan-id Required

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-6
To do… Use the command… Remarks
In system
view mirroring-group group-id
monitor-port monitor-port-id
interface interface-type
interface-number
[mirroring-group group-id ]
monitor-port
Add a port
to the port
mirroring
group as
the
destination
port
In interface
view
quit
Use either
approach.
You can add a
port to a remote
port mirroring
group as the
destination port in
either system
view or interface
view. They
achieve the same
purpose.
Enter destination interface
view interface interface-type
interface-number —
The port is
an access
port port access vlan rprobe-vlan-id
The port is a
trunk port port trunk permit vlan
rprobe-vlan-id
Add the
port to the
remote
port
mirroring
VLAN The port is a
hybrid port port hybrid vlan rprobe-vlan-id { tagged | untagged }
Perform one of
these three
operations
according to the
port type.
Note:
zThe remote destination mirroring port cannot be a member port of the current
mirroring group.
zThe remote destination mirroring port can be an access, trunk, or hybrid port. It must
be assigned to the remote mirroring VLAN.
zDo not enable STP, RSTP or MSTP on the remote destination mirroring port.
Otherwise, the mirroring function may be affected.
zDo not use the remote destination mirroring port for any purpose other than port
mirroring.
zOnly existing static VLANs can be configured as remote port mirroring VLANs. To
remove a VLAN operating as aremote port mirroring VLAN, you need to restore it to
a normal VLAN first. A remote port mirroring group gets invalid if the corresponding
remote port mirroring VLAN is removed.
zUse a remote port mirroring VLAN for remote port mirroring only.
zA port can belong to only one port mirroring group. A VLAN can be the remote port
mirroring VLAN of only one port mirroring group.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-7
1.4 Displaying and Maintaining Port Mirroring
To do… Use the command… Remarks
Display the configuration
of a port mirroring group
display mirroring-group
{group-id |all | local |
remote-destination |
remote-source }
Available in any view
1.5 Port Mirroring Configuration Examples
1.5.1 Local Port Mirroring Configuration Example
I. Network requirements
The departments of a company connect to each other through Ethernet switches:
zResearch and Development (R&D) department is connected to Switch C through
GigabitEthernet 1/0/1.
zMarketing department is connected to Switch C through GigabitEthernet 1/0/2.
zData monitoring device is connected to Switch C through GigabitEthernet 1/0/3
The administrator wants to monitor the packets received on and sent from the R&D
department and the marketing department through the data monitoring device.
Use the local port mirroring function to meet the requirement. Perform the following
configurations on Switch C.
zConfigure GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 as mirroring source
ports.
zConfigure GigabitEthernet 1/0/3 as the mirroring destination port.
II. Network diagram
Switch C Data monitoring
device
R&D
department
Switch A
Switch B
GE1/0/2
GE1/0/1
GE1/0/3
Marketing
department
Figure 1-3 Network diagram for local port mirroring configuration

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-8
III. Configuration procedure
Configure Switch C.
# Create a local port mirroring group.
<SwitchC> system-view
[SwitchC] mirroring-group 1 local
# Add port GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 to the port mirroring group
as source ports. Add port GigabitEthernet 1/0/3 to the port mirroring group as the
destination port.
[SwitchC] mirroring-group 1 mirroring-port GigabitEthernet 1/0/1
GigabitEthernet 1/0/2 both
[SwitchC] mirroring-group 1 monitor-port GigabitEthernet 1/0/3
# Display the configuration of all the port mirroring groups.
[SwitchC] display mirroring-group all
mirroring-group 1:
type: local
status: active
mirroring port:
GigabitEthernet1/0/1 both
GigabitEthernet1/0/2 both
monitor port: GigabitEthernet1/0/3
After finishing the configuration, you can monitor all the packets received and sent by
R&D department and Marketing department on the Data monitoring device.
1.5.2 Remote Port Mirroring Configuration Example
I. Network requirements
The departments of a company connect to each other through Ethernet switches:
zDepartment 1 is connected to GigabitEthernet 1/0/1 of Switch A.
zDepartment 2 is connected to GigabitEthernet 1/0/2 of Switch A.
zGigabitEthernet 1/0/3 of Switch A connects to GigabitEthernet 1/0/1 of Switch B.
zGigabitEthernet 1/0/2 of Switch B connects to GigabitEthernet 1/0/1 of Switch C.
zThe data monitoring device is connected to GigabitEthernet 1/0/2 of Switch C.
The administrator wants to monitor the packets sent from Department 1 and 2 through
the data monitoring device.
Use the remote port mirroring function to meet the requirement. Perform the following
configurations:
zUse Switch A as the source device, Switch B as the intermediate device, and
Switch C as the destination device.

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-9
zOn Switch A, create a remote source mirroring group; create VLAN 2 and
configure it as the remote port mirroring VLAN; add port GigabitEthernet 1/0/1 and
GigabitEthernet 1/0/2 to the port mirroring group as two source ports. Configure
port GigabitEthernet 1/0/3 as the outbound mirroring port.
zConfigure port GigabitEthernet 1/0/3 of Switch A, port GigabitEthernet 1/0/1 and
GigabitEthernet 1/0/2 of Switch B, and port GigabitEthernet 1/0/1 of Switch C as
trunk ports and configure them to permit packets of VLAN 2.
zCreate a remote destination mirroring group on Switch C. Configure VLAN 2 as
the remote port mirroring VLAN and port GigabitEthernet 1/0/2, to which the data
monitoring device is connected, as the destination port.
II. Network diagram
Figure 1-4 Network diagram for remote port mirroring configuration
III. Configuration procedure
1) Configure Switch A (the source device).
# Create a remote source port mirroring group.
<SwitchA> system-view
[SwitchA] mirroring-group 1 remote-source
# Create VLAN 2.
[SwitchA] vlan 2
[SwitchA-vlan2] quit
# Configure VLAN 2 as the remote port mirroring VLAN of the remote port mirroring
group. Add port GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 to the remote port
mirroring group as source ports. Configure port GigabitEthernet 1/0/3 as the outbound
mirroring port.
[SwitchA] mirroring-group 1 remote-probe vlan 2
[SwitchA] mirroring-group 1 mirroring-port GigabitEthernet 1/0/1
GigabitEthernet 1/0/2 inbound
[SwitchA] mirroring-group 1 monitor-egress GigabitEthernet 1/0/3

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-10
# Configure port GigabitEthernet 1/0/3 as a trunk port and configure the port to permit
the packets of VLAN 2.
[SwitchA] interface GigabitEthernet 1/0/3
[SwitchA-GigabitEthernet1/0/3] port link-type trunk
[SwitchA-GigabitEthernet1/0/3] port trunk permit vlan 2
2) Configure Switch B (the intermediate device).
# Configure port GigabitEthernet 1/0/1 as a trunk port and configure the port to permit
the packets of VLAN 2.
<SwitchB> system-view
[SwitchB] interface GigabitEthernet 1/0/1
[SwitchB-GigabitEthernet1/0/1] port link-type trunk
[SwitchB-GigabitEthernet1/0/1] port trunk permit vlan 2
[SwitchB-GigabitEthernet1/0/1] quit
# Configure port GigabitEthernet 1/0/2 as a trunk port and configure the port to permit
the packets of VLAN 2.
[SwitchB] interface GigabitEthernet 1/0/2
[SwitchB-GigabitEthernet1/0/2] port link-type trunk
[SwitchB-GigabitEthernet1/0/2] port trunk permit vlan 2
3) Configure Switch C (the destination device).
# Configure port GigabitEthernet 1/0/1 as a trunk port and configure the port to permit
the packets of VLAN 2.
<SwitchC> system-view
[SwitchC] interface GigabitEthernet 1/0/1
[SwitchC-GigabitEthernet1/0/1] port link-type trunk
[SwitchC-GigabitEthernet1/0/1] port trunk permit vlan 2
[SwitchC-GigabitEthernet1/0/1] quit
# Create a remote destination port mirroring group.
[SwitchC] mirroring-group 1 remote-destination
# Create VLAN 2.
[SwitchC] vlan 2
[SwitchC-vlan2] quit
# Configure VLAN 2 as the remote port mirroring VLAN of the remote destination port
mirroring group.Add port GigabitEthernet 1/0/2 to the remote destination port mirroring
group as the destination port.
[SwitchC] mirroring-group 1 remote-probe vlan 2
[SwitchC] mirroring-group 1 monitor-port GigabitEthernet 1/0/2
[SwitchC] interface GigabitEthernet 1/0/2
[SwitchC-GigabitEthernet1/0/2] port access vlan 2

Operation Manual – Port Mirroring
H3C S5500-EI Series Ethernet Switches Chapter 1 Port Mirroring Configuration
1-11
After finishing the configuration, you can monitor all the packets sent by Department 1
and Department 2 on the Data monitoring device.
