H3C S9500 Series User manual

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Table of Contents
i
Table of Contents
Chapter 1 MPLS Hybrid Insertion Configuration ....................................................................... 1-1
1.1 Overview of MPLS Hybrid Insertion................................................................................... 1-1
1.1.1 Introduction to Hybrid Insertion...............................................................................1-1
1.1.2 Classification of Hybrid Insertion.............................................................................1-2
1.2 Configuring Hybrid Insertion Based on LPUs with a Suffix of C, CA, or CB......................1-2
1.2.1 Configuring Redirection of MPLS Service at Private Network Side........................1-2
1.2.2 Configuring MPLS Service Loopback Group..........................................................1-3
1.2.3 Configuring Port-based QoS Policy ........................................................................ 1-3
1.3 Configuring Hybrid Insertion Based on L3+ SPUs ............................................................1-4
1.3.1 Configuring MPLS Service Redirection at Public Network Side............................. 1-4
1.3.2 Configuring VPLS Service Redirection at Public Network Side..............................1-5
1.3.3 Binding VPLS Virtual Service Interface with VPLS Instance ..................................1-5
1.3.4 Configuring Backup Interface for Virtual Service Interface.....................................1-6
1.3.5 Displaying and Maintaining Hybrid Insertion Configuration ....................................1-7
1.4 Hybrid Insertion Configuration Example............................................................................1-7
1.4.1 Example for Configuring L3VPN Hybrid Insertion...................................................1-7
1.4.2 Example for Configuring L2VPN Hybrid Insertion.................................................1-13
1.4.3 Example for Configuring L3+ Hybrid Insertion......................................................1-17

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-1
Chapter 1 MPLS Hybrid Insertion Configuration
When configuring MPLS hybrid insertion, go to these sections for information you are
interested in:
zOverview of MPLS Hybrid Insertion
zConfiguring Hybrid Insertion Based on LPUs with a Suffix of C, CA, or CB
zConfiguring Hybrid Insertion Based on L3+ SPUs
zHybrid Insertion Configuration Example
Note:
zFor information about basic configuration of MPLS, refer to MPLS Basics
Configuration.
zMPLS hybrid insertion configuration does not involve the actual networking. It
simply demonstrates the MPLS processing capability, that is, a system that does not
support MPLS can provide MPLS/MPLS VPN services after configuration of MPLS
hybrid insertion.
zFor detailed configuration information about service loopback group, ACL, and QoS,
refer to related manuals.
zA routing switch running MPLS has the functions of a router. The term "router” in this
document refers to a router in a generic sense or a Layer 3 Ethernet switch running
MPLS.
zFor an S9500 Series routing switch, only line processor units (LPUs) with a suffix of
C, CA or CB and VPLS service processor cards (SPCs) support MPLS. For S9500
Series routing switches to support MPLS VPN functions, you need to equip them
with MPLS capable LPUs or VPLS SPCs. You can identify the suffix of an LPU by
the silkscreen in the upper right corner of the LPU’s front panel. As an example, the
silkscreen of an LSB1P4G8CA0 LPU is P4G8CA, and therefore the suffix of the
LPU is CA.
1.1 Overview of MPLS Hybrid Insertion
1.1.1 Introduction to Hybrid Insertion
Currently, the device supports both the SPUs with or without the MPLS function. In the
following description, these two types of SPUs are respectively referred to as MPLS
board and non-MPLS board. In order to provide the MPLS/MPLS VPN service in an
environment that does not support the MPLS, a lot of users require adding MPLS SPUs

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-2
without changing the original networking. To meet this requirement, LPUs supporting
MPLS must be configured to redirect the MPLS service to the MPLS SPUs for service
processing. With the hybrid insertion feature, the MPLS VPN service can be deployed
on boards that do not support MPLS. The device supports the MPLS VPN in several
modes. It provides diversified MPLS VPN services to address different MPLS VPN
requirements, such as service performance, reliability, and port utilization ratio.
1.1.2 Classification of Hybrid Insertion
Although LPUs with a suffix of C, CA, or CB and L3+ SPUs support the MPLS function,
their functions and configurations are different. Accordingly, hybrid insertion is
classified into two types: hybrid insertion based on LPUs with a suffix of C, CA, or CB,
and hybrid insertion based on L3+ SPUs.
Here, MPLS hybrid insertion includes both L2VPN and L3VPN hybrid insertions.
I. Hybrid insertion based on LPUs with a suffix of C, CA, or CB
zSupport hybrid insertion of LPUs with a suffix of C, CA, or CB and non-MPLS
SPUs.
zThe service at the L3VPN private network side must be redirected to the MPLS
service loopback group on the MPLS board for processing.
II. Hybrid insertion based on L3+ SPUs
zSupport hybrid insertion of L3+ SPUs and non-L3+ SPUs.
zVPLS service and MPLS packets with the outer label assigned by the public
network must be redirected to different virtual service interfaces on the L3+ SPUs
for processing.
1.2 Configuring Hybrid Insertion Based on LPUs with a Suffix
of C, CA, or CB
Before configuring hybrid insertion based on LPUs with a suffix C, CA, or CB, you need
to:
zConfigure the MPLS service loopback group.
zConfigure the QoS policy to redirect the private network packets to the MPLS
service loopback group in the case of L3VPN hybrid insertion.
1.2.1 Configuring Redirection of MPLS Service at Private Network Side
I. Configuration prerequisites
Before redirecting MPLS service at private network side, complete the following tasks:
zConfigure the basic MPLS capability.
zConfigure the service loopback group with the MPLS processing capability.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-3
II. Configuring MPLS service redirection at private network side
Redirect the MPLS service at the private network side to the service loopback group
with the MPLS processing capability.
1.2.2 Configuring MPLS Service Loopback Group
Follow these steps to configure an MPLS service loopback group:
To do... Use the command... Remarks
Enter system view system-view —
Create a manual
aggregation group
link-aggregation group
agg-id mode { manual |
static }
Required
The type of the
aggregation group must
be manual.
Set the type of service
loopback group to MPLS
link-aggregation group
agg-id service-type
{ipv6 | ipv6mc | mpls |
tunnel }
Required
Add the port of MPLS
board to the loopback
group
port link-aggregation
group agg-id Required
1.2.3 Configuring Port-based QoS Policy
Follow these steps to configure a port-based QoS policy:
To do... Use the command... Remarks
Enter system view system-view —
Enter ACL view acl number acl-number
[ match-order { config | auto } ] Required
Configure the IP ACL rule [ rule-id ] { permit | deny }
[ rule-string ] Required
Enter QACL class view traffic classifier tcl-name [ operator
{ and | or } ] Required
Configure the rule if-match match-criteria Required
Enter QACL behavior
view traffic behavior behavior-name Required
Configure the behavior remark service-vlan-id vlan-id-value Required

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-4
To do... Use the command... Remarks
Configure the traffic
redirection action for the
traffic behavior
redirect {cpu |interface
interface-type interface-number |
next-hop { ipv4-add [ ipv4-add ] |
ipv6-add [interface-type
interface-number ] [ ipv6-add
[ interface-type interface-number |
link-aggregation group
group-number ] ] } }
Required
Enter QoS policy view qos policy policy-name Required
Configure the QoS policy classifier tcl-name behavior
behavior-name Required
Apply QoS policy to the
port qos apply policy policy-name { inbound | outbound } Required
Note:
zConfigure the port-based QoS policy only in the case of L3VPN hybrid insertion.
zYou can add multiple ports to an MPLS loopback group for load sharing purpose.
zLSB1GV48DA0, LSB1GV48DB0, and LSB1XP4DB0 do not support L2VPN hybrid
insertion.
1.3 Configuring Hybrid Insertion Based on L3+ SPUs
Before configuring the hybrid insertion based on L3+ SPUs, you need to:
zRedirect the MPLS and VPLS services at the public network side to the virtual
service interface on the L3+ board for processing.
zBind the VPLS instance with different MPLS-VPLS virtual service interfaces to
share the load of VPLS service.
In the configuration of hybrid insertion based on L3+ SPUs, two types of virtual service
interface on the L3+ board are used:
zMPLS virtual service interface
zMPLS-VPLS virtual service interface
1.3.1 Configuring MPLS Service Redirection at Public Network Side
MPLS service redirection is to redirect the MPLS service to the MPLS virtual service
interface on the L3+ board capable of MPLS processing.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-5
Note:
The MPLS service here refers to the service processed by the device that functions as
a P device. It does not include the L3VPN or VLL services on the PE.
Follow these steps to configure MPLS service redirection at the public network side:
To do... Use the command... Remarks
Enter system view system-view —
Enter MPLS virtual service interface
view interface MPLS
interface-number —
Redirect the MPLS service to the
MPLS virtual service interface on the
L3+ board capable of MPLS
processing
mpls service binding Required
1.3.2 Configuring VPLS Service Redirection at Public Network Side
VPLS service redirection is to redirect the VPLS service to the MPLS-VPLS virtual
service interface on the L3+ board capable of MPLS processing.
Follow these steps to configure VPLS service redirection at the public network side:
To do... Use the command... Remarks
Enter system view system-view —
Enter MPLS-VPLS virtual service
interface view interface MPLS-VPLS
interface-number —
Redirect the VPLS service to the
MPLS-VPLS virtual service interface
on the L3+ board capable of MPLS
processing
l2vpn-vpls service
binding service-id
service-id
Required
1.3.3 Binding VPLS Virtual Service Interface with VPLS Instance
I. Configuration prerequisites
Before binding the VPLS virtual service interface with the VPLS instance, complete the
following tasks:
zConfigure the VPLS virtual service interface, to which the VPLS service at the
public network side is redirected.
zCreate a VPLS instance, VSI.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-6
Note:
For configuration of VPLS instance, refer to VPLS Configuration.
II. Binding VPLS virtual service interface with VPLS instance
By binding the MPLS-VPLS virtual service interface with the VPLS instance, the load
can be shared among virtual service interfaces on the L3+ board.
Follow these steps to bind a VPLS virtual service interface with an MPLS-VPLS
instance:
To do... Use the command... Remarks
Enter system view system-view —
Enter MPLS-VPLS virtual service
interface view interface MPLS-VPLS
interface-number —
Specify the VPLS instance to be
bound on the MPLS-VPLS virtual
service interface
l2vpn-vpls service
binding vsi vsi-name Required
1.3.4 Configuring Backup Interface for Virtual Service Interface
With the backup interface of virtual serviceinterface, the service can be switched to the
backup interface once the virtual service interface is in down state, thus ensuring
uninterrupted traffic forwarding.
Follow these steps to configure the backup interface for the virtual service interface:
To do... Use the command... Remarks
Enter system view system-view —
Enter virtual service interface
view interface interface-type
interface-number —
Specify the backup interface
for the virtual service interface backup interface interface-type
interface-number Required
Note:
zAt present, you can configure two virtual service interfaces only for an L3+ board:
MPLS virtual service interface and MPLS-VPLS virtual service interface.
zThe backup virtual service interface must be in available state and have the same
interface type as the active virtual service interface.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-7
1.3.5 Displaying and Maintaining Hybrid Insertion Configuration
To do... Use the command... Remarks
Display the current
configuration display
current-configuration Available in any view
Display information about
service loopback groups display link-aggregation service-type [ agg-id ]Available in any view
Display information about
configured IPv4 ACLs display acl { acl-number | all } Available in any view
Display configuration
information about a
specified class or all
classes and the
associated actions in a
specified or all policies
display qos policy
user-defined
[ policy-name [ classifier
tcl-name ] ]
Available in any view
Display configuration and
operation information
about policies of a
specified interface or all
interfaces
display qos policy
interface [ interface-type
interface-number ]
[ inbound | outbound ]
Available in any view
Display information about
configured traffic
behaviors
display traffic behavior
user-defined
[ behavior-name ]Available in any view
Display information about
configured classes display traffic classifier user-defined [ tcl-name ]Available in any view
1.4 Hybrid Insertion Configuration Example
1.4.1 Example for Configuring L3VPN Hybrid Insertion
I. Network requirements
zConfigure the service loopback group with MPLS processing capability.
zRedirect the service at the L3VPN private network side to the above service
loopback group.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-8
II. Network diagram
Figure 1-1 Network diagram for configuring MPLS hybrid insertion
In the figure above:
zCE 1 and CE 3 constitute VPN A. CE 2 and CE 4 constitute VPN B.
zPE 1 and PE 2 are H3C S9500 series routing switches that support the MPLS
function. CE 1 and CE 2 are common low-end or mid-range routing devices. CE 3
and CE 4 are Layer-2 switches that directly connect with users.
zLPU configurations are the same on two PEs. A non-MPLS board with FE ports
resides in Slot 3, and an MPLS board with GE ports in Slot 2.
III. Configuration procedure
1) Configure CE 1
# Establish the EBGP neighbor relationship between CE 1 and PE 1. Inject a directly
connected route and a static route to redistribute the VPN private network user routes
of CE 1 to BGP routes and then advertise injected routes to PE 1.
<CE1> system-view
[CE1] vlan 10
[CE1] interface vlan-interface 10
[CE1-vlan-interface10] ip address 10.10.10.10 255.255.255.0
[CE1-vlan-interface10] quit
[CE1] bgp 65410
[CE1-bgp] group vpna external
[CE1-bgp] peer 10.10.10.1 group vpna as-number 100
[CE1-bgp] import-route direct
[CE1-bgp] import-route static
Note:
The configuration on CE 2 is similar with that on CE 1, and is therefore omitted

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-9
2) Configure PE 1
# Configure the global MPLS.
[PE1] mpls lsr-id 1.1.1.1
[PE1] mpls
[PE1] mpls ldp
# Configure a public network interface and enable MPLS on it.
[PE1] interface loopback 0
[PE1-LoopBack0] ip address 1.1.1.1 32
[PE1-LoopBack0] quit
[PE1] vlan 100
[PE1-vlan100] port GigabitEthernet 2/2/1
[PE1-vlan100] interface vlan-interface 100
[PE1-vlan-interface100] ip address 196.168.1.1 255.255.255.0
[PE1-vlan-interface100] mpls
[PE1-vlan-interface100] mpls ldp
[PE1-vlan-interface100] quit
# Start the OSPF on the interface connecting PE 1 and the P routing device and on the
loopback interface.
[PE1] ospf 1 router-id 1.1.1.1
[PE1-ospf-1] area 0
[PE1-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[PE1-ospf-1-area-0.0.0.0] network 1.1.1.1 0.0.0.0
[PE1-ospf-1-area-0.0.0.0] quit
# Configure the VPN-instance. The configuration on VPN B is similar with that on VPN
A. The following provides the configuration on VPNA only.
<PE1> system-view
[PE1] ip vpn-instance vpna
[PE1-vpn-vpna] route-distinguisher 100:1
[PE1-vpn-vpna] vpn-target 100:1 both
[PE1-vpn-vpna] quit
# Configure the MPLS service loopback group:
[PE1] link-aggregation group 1 mode manual
[PE1] link-aggregation group 1 service-type mpls
# Add multiple ports to the MPLS service loopback group.
[PE1] interface GigabitEthernet 2/2/3
[PE1-GigabitEthernet2/2/3] stp disable
[PE1-GigabitEthernet2/2/3] port link-aggregation group 1
[PE1-GigabitEthernet2/2/3] interface GigabitEthernet 2/2/4
[PE1-GigabitEthernet2/2/4] stp disable

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-10
[PE1-GigabitEthernet2/2/4] port link-aggregation group 1
# Configure the port-based QoS policy.
[PE1] acl number 2000
[PE1-acl-basic-2000] rule 0 permit source any
[PE1] traffic classifier one
[PE1-classifier-one] if-match acl 2000
[PE1-classifier-one] traffic behavior one
[PE1-behavior-one] remark service-vlan-id 10
[PE1-behavior-one] redirect link-aggregation group 1
[PE1] qos policy one
[PE1-qospolicy-one] classifier one behavior one
[PE1-qospolicy-one] interface Ethernet 3/1/1
[PE1-Ethernet3/1/1] qos apply policy one inbound
[PE1-Ethernet3/1/1] quit
# Configure the VLAN interface.
[PE1] vlan 10
[PE1-vlan10] port Ethernet 3/1/1
[PE1-vlan10] interface vlan-interface 10
[PE1-vlan-interface10] quit
# Bind the VPN A to the VLAN interface that connects PE 1 and CE 1.
[PE1-Vlan-interface10] ip binding vpn-instance vpna
[PE1-Vlan-interface10] ip address 10.10.10.1 24
[PE1-Vlan-interface10] quit
# Establish the EBGP neighbor relationship between PE 1 and CE 1 and inject the
interface routes of VPN-instance.
[PE1] bgp 100
[PE1-bgp] ipv4-family vpn-instance vpna
[PE1-bgp-af-vpn-instance] group vpna external
[PE1-bgp-af-vpn-instance] peer 10.10.10.10 group vpna as-number 65410
[PE1-bgp-af-vpn-instance] import-route direct
[PE1-bgp-af-vpn-instance] quit
[PE1-bgp] quit
# Establish the MBGP neighbor relationship between PEs to exchange VPN routing
information among PEs.Activate the IBGP peer in VPNv4 address family view.
[PE1] bgp 100
[PE1-bgp] group 100
[PE1-bgp] peer 2.2.2.2 group 100
[PE1-bgp] peer 2.2.2.2 connect-interface loopback0
[PE1-bgp] ipv4-family vpnv4
[PE1-bgp-af-vpn] peer 100 enable

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-11
[PE1-bgp-af-vpn] peer 2.2.2.2 group 100
3) Configure the P device
# Configure the global MPLS.
[P] mpls lsr-id 3.3.3.3
[P] mpls
[P] mpls ldp
# Configure an interface and enable MPLS on the interface.
[P] interface loopback0
[P-LoopBack0] ip address 3.3.3.3 32
[P-LoopBack0] quit
[P] vlan 100
[P-vlan100] port GigabitEthernet 2/1/1
[P-vlan100] interface vlan-interface 100
[P-vlan-interface100] ip address 196.168.1.2 255.255.255.0
[P-vlan-interface100] mpls
[P-vlan-interface100] mpls ldp
[P-vlan-interface100] quit
[P] vlan 200
[P-vlan200] port GigabitEthernet 2/1/2
[P-vlan200] interface vlan-interface 200
[P-vlan-interface200] ip address 196.168.2.2 255.255.255.0
[P-vlan-interface200] mpls
[P-vlan-interface200] mpls ldp
[P-vlan-interface200] quit
# Configure the OSPF.
[P] ospf 1 router-id 3.3.3.3
[P-ospf-1] area 0
[P-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[P-ospf-1-area-0.0.0.0] network 196.168.2.0 0.0.0.255
[P-ospf-1-area-0.0.0.0] network 3.3.3.3 0.0.0.0
4) Configure PE 2
# Configure the global MPLS.
[PE2] mpls lsr-id 2.2.2.2
[PE2] mpls
[PE2] mpls ldp
# Configure a public network interface and enable MPLS on the interface.
[PE2] interface loopback0
[PE2-LoopBack0] ip address 2.2.2.2 32
[PE2-LoopBack0] quit
[PE2] vlan 200

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-12
[PE2-vlan200] port GigabitEthernet 2/2/1
[PE2-vlan200] interface vlan-interface 200
[PE2-vlan-interface200] ip address 196.168.2.1 255.255.255.0
[PE2-vlan-interface200] mpls
[PE2-vlan-interface200] mpls ldp
[PE2-vlan-interface200] quit
# Start the OSPF on the interface connecting PE 2 and the P routing device and on the
loopback interface.
[PE2] ospf 1 router-id 2.2.2.2
[PE2-ospf-1] area 0
[PE2-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[PE2-ospf-1-area-0.0.0.0] network 2.2.2.2 0.0.0.0
[PE2-ospf-1-area-0.0.0.0] quit
# Configure the VPN-instance. The configuration on VPN B is similar with that on VPN
A. The following provides the configuration on VPNA only.
[PE2] ip vpn-instance vpna
[PE2-vpn-vpna] route-distinguisher 100:1
[PE2-vpn-vpna] vpn-target 100:1 both
[PE2-vpn-vpna] quit
# Configure the MPLS service loopback group:
[PE2] link-aggregation group 1 mode manual
[PE2] link-aggregation group 1 service-type mpls
# Add multiple ports to the MPLS service loopback group.
[PE2] inter GigabitEthernet 2/2/3
[PE2-GigabitEthernet2/2/3] stp disable
[PE2-GigabitEthernet2/2/3] port link-aggregation group 1
[PE2-GigabitEthernet2/2/3] interface GigabitEthernet 2/2/4
[PE2-GigabitEthernet2/2/4] stp disable
[PE2-GigabitEthernet2/2/4] port link-aggregation group 1
# Configure the port-based QoS policy:
[PE2] acl number 2000
[PE2-acl-basic-2000] rule 0 permit source any
[PE2] traffic classifier one
[PE2-classifier-one] if-match acl 2000
[PE2-classifier-one] traffi behavior one
[PE2-behavior-one] remark service-vlan-id 10
[PE2-behavior-one] redirect link-aggregation group 1
[PE2] qos policy one
[PE2-qospolicy-one] classifier one behavior one
[PE2-qospolicy-one] interface e3/1/1

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-13
[PE2-Ethernet3/1/1] qos apply policy one inbound
[PE2-Ethernet3/1/1] quit
# Bind the VPN A to the VLAN interface that connects PE 2 and CE 3.
[PE2] interface vlan-interface 10
[PE2-vlan-interface10] ip binding vpn-instance vpna
[PE2-vlan-interface10] ip address 20.2.1.2 255.255.255.0
[PE2-vlan-interface10] quit
# Inject the PE 2-CE 3 private network interface route for VPNA.
[PE2] bgp 100
[PE2-bgp] ipv4-family vpn-instance vpna
[PE2-bgp-af-vpn-instance] import-route direct
[PE2-bgp-af-vpn-instance] quit
[PE2-bgp] quit
# Establish the MBGP neighbor relationship between PEs to exchange VPN routing
information among PEs.Activate the IBGP peer in VPNv4 address family view.
[PE2] bgp 100
[PE2-bgp] group 100
[PE2-bgp] peer 1.1.1.1 group 100
[PE2-bgp] peer 1.1.1.1 connect-interface loopback0
[PE2-bgp] ipv4-family vpnv4
[PE2-bgp-af-vpn] peer 100 enable
[PE2-bgp-af-vpn] peer 1.1.1.1 group 100
1.4.2 Example for Configuring L2VPN Hybrid Insertion
I. Network requirements
zConfigure the service loopback group with MPLS processing capability.
zRedirect the service at the L2VPN private network side to the above service
loopback group.
II. Network diagram
Figure 1-2 Network diagram for configuring L2VPN hybrid insertion

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-14
In the figure above:
zCE 1 and CE 3 constitute VPNA. CE 2 and CE 3 constitute VPNB.
zPE 1 and PE 2 are H3C S9500 series routing switches that support the MPLS
function. CE 1 and CE 2 are common low-end or mid-range routing devices. CE 3
and CE 4 are Layer-2 switches that directly connect with users.
zLPU configurations are the same on two PEs. A non-MPLS board with FE ports
resides in Slot 3, and an MPLS board with a suffix of CA or CB that provides GE
ports in Slot 2.
III. Configuration procedure
1) Configure CE 1
# Configure the IP address of the interface.
<CE1> system-view
[CE1] vlan 10
[CE1] interface vlan-interface 10
[CE1-vlan-interface10] ip address 10.10.10.1 255.255.255.0
[CE1-vlan-interface10] quit
2) Configure PE 1
# Configure the global MPLS.
[PE1] mpls lsr-id 1.1.1.1
[PE1] mpls
[PE1] mpls ldp
# Configure a public network interface and enable MPLS on the interface.
[PE1] interface loopback0
[PE1-LoopBack0] ip address 1.1.1.1 32
[PE1-LoopBack0] quit
[PE1] vlan 100
[PE1-vlan100] port GigabitEthernet 2/2/1
[PE1-vlan100] interface vlan-interface 100
[PE1-vlan-interface100] ip address 196.168.1.1 255.255.255.0
[PE1-vlan-interface100] mpls
[PE1-vlan-interface100] mpls ldp
[PE1-vlan-interface100] quit
# Start the OSPF on the interface connecting PE 1 and the P routing device and on the
loopback interface.
[PE1] ospf 1 router-id 1.1.1.1
[PE1-ospf-1] area 0
[PE1-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[PE1-ospf-1-area-0.0.0.0] network 1.1.1.1 0.0.0.0
[PE1-ospf-1-area-0.0.0.0] quit

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-15
# Configure the LDP remote session.
[PE1] mpls ldp remote-peer 1
[PE1-mpls-ldp-remote-1] remote-ip 2.2.2.2
# Configure the MPLS service loopback group:
[PE1] link-aggregation group 1 mode manual
[PE1] link-aggregation group 1 service-type mpls
# Add multiple ports to the MPLS service loopback group.
[PE1] interface GigabitEthernet 2/2/3
[PE1-GigabitEthernet2/2/3] stp disable
[PE1-GigabitEthernet2/2/3] port link-aggregation group 1
[PE1-GigabitEthernet2/2/3] interface GigabitEthernet 2/2/4
[PE1-GigabitEthernet2/2/4] stp disable
[PE1-GigabitEthernet2/2/4] port link-aggregation group 1
# Configure the VLAN interface.
[PE1] vlan 10
[PE1-vlan10] port Ethernet 3/1/1
[PE1-vlan10] interface vlan-interface 10
[PE1-vlan-interface10] quit
# Bind the VPNA to the VLAN interface that connects PE 1 and CE 1.
[PE1-Vlan-interface10] mpls l2vc 2.2.2.2 100
[PE1-Vlan-interface10] quit
3) Configure the P device
# Configure the global MPLS.
[P] mpls lsr-id 3.3.3.3
[P] mpls
[P] mpls ldp
# Configure an interface and enable MPLS on the interface.
[P] interface loopback0
[P-LoopBack0] ip address 3.3.3.3 32
[P-LoopBack0] quit
[P] vlan 100
[P-vlan100] port GigabitEthernet 2/1/1
[P-vlan100] interface vlan-interface 100
[P-vlan-interface100] ip address 196.168.1.2 255.255.255.0
[P-vlan-interface100] mpls
[P-vlan-interface100] mpls ldp
[P-vlan-interface100] quit
[P] vlan 200
[P-vlan200] port GigabitEthernet 2/1/2

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-16
[P-vlan200] interface vlan-interface 200
[P-vlan-interface200] ip address 196.168.2.2 255.255.255.0
[P-vlan-interface200] mpls
[P-vlan-interface200] mpls ldp
[P-vlan-interface200] quit
# Configure the OSPF.
[P] ospf 1 router-id 3.3.3.3
[P-ospf-1] area 0
[P-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[P-ospf-1-area-0.0.0.0] network 196.168.2.0 0.0.0.255
[P-ospf-1-area-0.0.0.0] network 3.3.3.3 0.0.0.0
4) Configure PE 2
# Configure the global MPLS.
[PE2] mpls lsr-id 2.2.2.2
[PE2] mpls
[PE2] mpls ldp
# Configure a public network interface and enable MPLS on the interface.
[PE2] interface loopback0
[PE2-LoopBack0] ip address 2.2.2.2 32
[PE2-LoopBack0] quit
[PE2] vlan 200
[PE2-vlan200] port GigabitEthernet 2/2/1
[PE2-vlan200] interface vlan-interface 200
[PE2-vlan-interface200] ip address 196.168.2.1 255.255.255.0
[PE2-vlan-interface200] mpls
[PE2-vlan-interface200] mpls ldp
[PE2-vlan-interface200] quit
# Start the OSPF on the interface connecting PE 2 and the P routing device and on the
loopback interface.
[PE2] ospf 1 router-id 2.2.2.2
[PE2-ospf-1] area 0
[PE2-ospf-1-area-0.0.0.0] network 196.168.1.0 0.0.0.255
[PE2-ospf-1-area-0.0.0.0] network 2.2.2.2 0.0.0.0
[PE2-ospf-1-area-0.0.0.0] quit
# Configure the LDP remote session.
[PE2] mpls ldp remote-peer 1
[PE2-mpls-ldp-remote-1] remote-ip 1.1.1.1
# Configure the MPLS service loopback group:
[PE2] link-aggregation group 1 mode manual

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-17
[PE2] link-aggregation group 1 service-type mpls
# Add multiple ports to the MPLS service loopback group.
[PE2] interface GigabitEthernet 2/2/3
[PE2-GigabitEthernet2/2/3] stp disable
[PE2-GigabitEthernet2/2/3] port link-aggregation group 1
[PE2-GigabitEthernet2/2/3] interface GigabitEthernet 2/2/4
[PE2-GigabitEthernet2/2/4] stp disable
[PE2-GigabitEthernet2/2/4] port link-aggregation group 1
# Bind the VPNA to the VLAN interface that connects PE 2 and CE 3.
[PE2] interface vlan-interface 10
[PE2-vlan-interface10] mpls l2vc 1.1.1.1 100
[PE2-vlan-interface10] quit
Note:
zCurrently, only MPLS boards with a suffix of CA or CB support VLL (L2VPN). Thus,
VLL hybrid insertion includes:
- Hybrid insertion of non-MPLS boards and MPLS boards with a suffix of CA
- Hybrid insertion of MPLS boards with a suffix of C and MPLS boards with a suffix of
CA
zAll MPLS boards support MPLS L3VPN. Thus, L3VPN hybrid insertion refers to
hybrid insertion of non-MPLS boards and MPLS boards only.
zYou need to configure the port-based QoS policy for L3VPN hybrid insertion only,
but not for VLL hybrid insertion.
1.4.3 Example for Configuring L3+ Hybrid Insertion
I. Network requirements
zBind the VPLS virtual service interface with the VPLS instance.
zConfigure the backup virtual service interface.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-18
II. Network diagram
Figure 1-3 Network diagram for configuring L3+ hybrid insertion
III. Configuration procedure
1) Configure PE 1
# Configure the IGP protocol, which is OSPF in this example.
# Configure the basic MPLS capability.
<Sysname> system-view
[Sysname] sysname PE1
[PE1] interface LoopBack 0
[PE1-LoopBack0] ip address 1.1.1.9 32
[PE1-LoopBack0] quit
[PE1] mpls lsr-id 1.1.1.9
[PE1] mpls
[PE1-mpls] quit
[PE1] mpls ldp
[PE1-mpls-ldp] quit
# Redirect the service to the virtual service interface onthe L3+ board and configure the
backup interface for the virtual service interface.
[PE1] interface MPLS-VPLS 0/0/2
[PE1-MPLS-VPLS0/0/2] l2vpn-vpls service binding service-id 1
[PE1-MPLS-VPLS0/0/2] backup interface MPLS-VPLS 1/0/2
[PE1-MPLS-VPLS0/0/2] quit
# Configure VLAN 10 and create VLAN-interface 10.
[PE1] vlan 10
[PE1-vlan10] port Ethernet 4/1/1
[PE1-vlan10] quit
[PE1] interface Vlan-interface 10
[PE1-Vlan-interface10] ip address 10.10.10.10 24
# Configure the basic MPLS capability on the VLAN interface.

Operation Manual – MPLS Hybrid Insertion
H3C S9500 Series Routing Switches Chapter 1 MPLS Hybrid Insertion Configuration
1-19
[PE1-Vlan-interface10] mpls
[PE1-Vlan-interface10] mpls ldp
[PE1-Vlan-interface10] quit
# Configure MPLS L2VPN.
[PE1] mpls l2vpn
# Configure LDP VPLS instance aaa.
[PE1] vsi aaa static
[PE1-vsi-aaa] pwsignal ldp
[PE1-vsi-aaa-ldp] vsi-id 500
[PE1-vsi-aaa-ldp] peer 2.2.2.9
[PE1-vsi-aaa-ldp] quit
[PE1-vsi-aaa] quit
# Bind the MPLS-VPLS virtual service interface with the VPLS instance aaa.
[PE1] interface MPLS-VPLS 0/0/2
[PE1-MPLS-VPLS0/0/2] l2vpn-vpls service binding vsi aaa
[PE1-MPLS-VPLS0/0/2] quit
# Configure VLAN 100 and create VLAN-interface 100.
[PE1] vlan 100
[PE1-Vlan-100] port Ethernet 4/1/2
[PE1-Vlan-100] interface Vlan-interface 100
# Bind VPLS instance aaa with VLAN-interface 100.
[PE1-Vlan-interface100] l2 binding vsi aaa
2) Configure PE 2
# Configure the IGP protocol, which is OSPF in this example.
# Configure the basic MPLS capability.
<Sysname> system-view
[Sysname] sysname PE2
[PE2] interface Lookback 0
[PE2-LoopBack0] ip address 2.2.2.9 32
[PE2-LoopBack0] quit
[PE2] mpls lsr-id 2.2.2.9
[PE2] mpls
[PE2-mpls] quit
[PE2] mpls ldp
[PE2-mpls-ldp] quit
# Redirect the service to the virtual service interface onthe L3+ board and configure the
backup interface for the virtual service interface.
[PE2] interface MPLS-VPLS 0/0/2
[PE2-MPLS-VPLS0/0/2] l2vpn-vpls service binding service-id 1
