Haas+Sohn PLANAI Instruction manual

1
Item no 0717542049030
V09 G17
PLANAI Assembly and Installation Instructions
Room for type designation and manufacturing number:
Our supply program: Oil stoves
Fireplaces
Pellet stoves
Tiled and slow-burning stoves for wood and coal
Slow-burning and auxiliary stoves for wood, coal and oil
Fireplace inserts for wood
Accessories for stove and fireplace
Accessories for central oil supply
Air humidifiers
HAAS+SOHN
Sales in Germany
OFENTECHNIK GMBH
Haas+Sohn Ofentechnik GmbH
Urstein Nord 67
Herborner Straße 7-9
A-5412 Puch
D-35764 Sinn
Tel.:[phone]
Telephone: [phone]
Fax: [phone] 210
Fax: [phone]
eMail: of[email protected]
eMail: [email protected]
http://www.haassohn.com

2
1 PRELIMINARY REMARKS
Please read the installation and operating instructions of your fireplace insert before these
installation instructions.
When unpacking the concrete elements you might discover irregularities (cracks or joints) which are
filled with the enclosed adhesive.
2 PREREQUISITES
Before installing your fireplace kit always ascertain the load carrying capacity of the floor. The total
weight of the complete fireplace kit (fireplace with refractory lining and the artificial stone lining) can
range from approximately 240 to roughly 260 kg depending on the model. In the case of wooden
beam ceilings it is imperative to consult a structural engineer.
Important: Observe the regulations of the fire protection authorities and the national building
regulations applicable at the place of installation when installing your fireplace kit: in particular,
protect combustible walls (e.g. wooden walls) or supporting walls made of reinforced concrete from
excessive heating.( look Specification plate)
3 TOOLS
The following tools are required for the installation of the artificial stone lining:
–Water level
–Rubber hammer
–Open-end wrench size 17
–Steel square 90 o
–Pencil
–Paint roller
–Trowel or spatula
–Sponge
4 MATERIAL
–Paint
–Possibly plaster
–Water
5 INSTALLING THE KIT
1. Carefully unpack the artificial stone lining with accessories. Check your kit for completeness
using the enclosed parts list. Sort the parts in accordance with the installation sequence (see
written and illustrated parts list).
2. Align the fireplace at the right height (850-920 mm) by turning the adjusting feet using the open-
end wrench size 17. The ideal height is shown in (Figure 2). For verification, also set up the
base with marble slab or the blind. The lower edge of the panel on the fireplace can be flush
with the understructure of the concrete lining without joint or approximately 1 to 2 millimetre
higher (Note: Bonding slightly changes the overall height: However it is possible to subsequently
adjust the fireplace height by turning the adjusting feet as required.
Important: After this, adjust the fireplace in horizontal position using the water level.

3
3. It is now necessary to secure the flue pipe connection (for instance with double wall lining) in the
fireplace (see installation and operating instructions of the fireplace).
4. Start with the installation of the kit.
6 NOTE
It is not permissible to assemble the kit without bonding the elements together and without securing
the fireplace hood against sliding!
To avoid minor cracks in the wall we recommend filling these with acrylic compound (acrylic
compound can be immediately painted over unlike silicon).
Once the fireplace kit has dried the fireplace can be painted (use mineral-base paint, no depth
primer required). To obtain a fine-grain structure, simply mix some adhesive into the paint for the
first coat. Use only paint for the second coat. Of course you can also use roll-on or rubbing plaster
to finish the surface.
Allow the fireplace kit to dry at least 2 weeks before initial use.
To start the fireplace: Carefully read the operating instructions and start the oven using little wood.
Heating at rated output can then commence after approximately one hour.

4
Artificial stone kit - PLANAI –Parts list
Article No.
No.
Quantity
Designation
Type
Material
0717542040100
1
1
Base plate right
Artificial stone
Artificial stone
0717542040200
2
1
Base plate left
Artificial stone
Artificial stone
0717542040300
3
1
Base element right
Artificial stone
Artificial stone
0717542040400
4
1
Base element left
Artificial stone
Artificial stone
0717542040500
5
1
Base blind front
Artificial stone
Artificial stone
0717542040600
6
1
Base blind rear
Artificial stone
Artificial stone
0717542040700
7
1
Lateral cover
Artificial stone
Artificial stone
0717542040800
8
1
Lateral cover console
Artificial stone
Artificial stone
0717542040900
9
8
Screw M 10x150 mm
steel
steel
0717552050100
10
2
Cover plate 612x214 mm
black
granite
0717552050300
12
4
Decorative plate 60x60 mm
black
granite
0717552050400
13
2
Plate 415x128 mm
black
granite
0717552040100
10
1
Cover plate ri.612x214 mm
terra
Artificial stone
0717552040200
11
1
Cover plate le.612x214 mm
terra
Artificial stone
0717552040300
12
4
Decorative plate 60x60 mm
terra
Artificial stone
0717552040400
13
2
Plate 415x128 mm
terra
Artificial stone
0621800105000
14
1
Adhesive
0621800105050
15
1
Acryl
Assembly instructions artificial stone kit PLANAI
Note: Ensure that the insert is accurately positioned prior to the assembly. Always ensure that the
parts are assembled horizontally and plumb.
1. Assemble the fireplace kit in the dry condition. Check to see whether the elements are plumb
and level. Mark the correct position using the pencil.( figure 3-7)
After this, remove all elements and assemble one by one using the tile adhesive.(figure 3-8)
2. Mix the supplied adhesive (safety adhesive) with water until a consistency similar to toothpaste
is obtained. Bond all elements together and to the wall. The bonding surface should be clean
and slightly moistened to achieve optimum adhesive strength. Remove excess adhesive with
the spatula and a moist cloth.
3. Once the kit has been finish painted, finally glue the plates to the bases.

5
Figure 1: Position fireplace insert
Figure 4: adjust the height
Figure 2: the desired height stop
Assemble the base elements
Figure 3: Position plate, base blind
and screws insert

6
Figure 5 : Assemble the base left and
right
Figure 8 : Assemble the cover plate
Figure 6 : Assemble the base blind
front
Figure 7 : Assemble the side parts
Figure 9 : Assemble the decorative
plate and cover plate

7

8
We wish you lots of pleasure with your fireplace kit by
Figure 10 : Dimensions
