Hach Ultra ORBISPHERE 3625 User manual

Operator Manual
ORBISPHERE 3625
Revision F - 04/04/2008

3625 Package Analyzer - Important Information
Operator Manual ORBISPHERE
Product Recycling Information
ENGLISH
Electrical equipment marked with this symbol may not be disposed of in European public
disposal systems after 12 August 2005. In conformity with European local and national
regulations (EU Directive 2002/96/EC), European electrical equipment users must now
return old or end-of-life equipment to the manufacturer for disposal at no charge to the
user.
Note: For return for recycling, please contact the equipment manufacturer or supplier for
instructions on how to return end-of-life equipment for proper disposal.
GERMAN
Elektrogeräte, die mit diesem Symbol gekennzeichnet sind, dürfen in Europa nach dem 12. August 2005
nicht mehr über die öffentliche Abfallentsorgung entsorgt werden. In Übereinstimmung mit lokalen und
nationalen europäischen Bestimmungen (EU-Richtlinie 2002/96/EC), müssen Benutzer von
Elektrogeräten in Europa ab diesem Zeitpunkt alte bzw. zu verschrottende Geräte zur Entsorgung
kostenfrei an den Hersteller zurückgeben.
Hinweis: Bitte wenden Sie sich an den Hersteller bzw. an den Händler, von dem Sie das Gerät bezogen
haben, um Informationen zur Rückgabe des Altgeräts zur ordnungsgemäßen Entsorgung zu erhalten.
FRENCH
A partir du 12 août 2005, il est interdit de mettre au rebut le matériel électrique marqué de ce symbole par
les voies habituelles de déchetterie publique. Conformément à la réglementation européenne (directive
UE 2002/96/EC), les utilisateurs de matériel électrique en Europe doivent désormais retourner le matériel
usé ou périmé au fabricant pour élimination, sans frais pour l'utilisateur.
Remarque: Veuillez vous adresser au fabricant ou au fournisseur du matériel pour les instructions de
retour du matériel usé ou périmé aux fins d'élimination conforme.
ITALIAN
Le apparecchiature elettriche con apposto questo simbolo non possono essere smaltite nelle discariche
pubbliche europee successivamente al 12 agosto 2005. In conformità alle normative europee locali e
nazionali (Direttiva UE 2002/96/EC), gli utilizzatori europei di apparecchiature elettriche devono restituire
al produttore le apparecchiature vecchie o a fine vita per lo smaltimento senza alcun costo a carico
dell’utilizzatore.
Nota: Per conoscere le modalità di restituzione delle apparecchiature a fine vita da riciclare, contattare il
produttore o il fornitore dell’apparecchiatura per un corretto smaltimento.
DANISH
Elektriske apparater, der er mærket med dette symbol, må ikke bortskaffes i europæiske offentlige
affaldssystemer efter den 12. august 2005. I henhold til europæiske lokale og nationale regler (EU-
direktiv 2002/96/EF) skal europæiske brugere af elektriske apparater nu returnere gamle eller udtjente
apparater til producenten med henblik på bortskaffelse uden omkostninger for brugeren.
Bemærk: I forbindelse med returnering til genbrug skal du kontakte producenten eller leverandøren af
apparatet for at få instruktioner om, hvordan udtjente apparater bortskaffes korrekt.

Important Information - 3625 Package Analyzer
Operator Manual
ORBISPHERE
SWEDISH
Elektronikutrustning som är märkt med denna symbol kanske inte kan lämnas in på europeiska offentliga
sopstationer efter 2005-08-12. Enligt europeiska lokala och nationella föreskrifter (EU-direktiv 2002/96/
EC) måste användare av elektronikutrustning i Europa nu återlämna gammal eller utrangerad utrustning
till tillverkaren för kassering utan kostnad för användaren.
Obs! Om du ska återlämna utrustning för återvinning ska du kontakta tillverkaren av utrustningen eller
återförsäljaren för att få anvisningar om hur du återlämnar kasserad utrustning för att den ska bortskaffas
på rätt sätt.
SPANISH
A partir del 12 de agosto de 2005, los equipos eléctricos que lleven este símbolo no deberán ser
desechados en los puntos limpios europeos. De conformidad con las normativas europeas locales y
nacionales (Directiva de la UE 2002/96/EC), a partir de esa fecha, los usuarios europeos de equipos
eléctricos deberán devolver los equipos usados u obsoletos al fabricante de los mismos para su
reciclado, sin coste alguno para el usuario.
Nota: Sírvase ponerse en contacto con el fabricante o proveedor de los equipos para solicitar
instrucciones sobre cómo devolver los equipos obsoletos para su correcto reciclado.
DUTCH
Elektrische apparatuur die is voorzien van dit symbool mag na 12 augustus 2005 niet meer worden
afgevoerd naar Europese openbare afvalsystemen. Conform Europese lokale en nationale wetgegeving
(EU-richtlijn 2002/96/EC) dienen gebruikers van elektrische apparaten voortaan hun oude of afgedankte
apparatuur kosteloos voor recycling of vernietiging naar de producent terug te brengen.
Nota: Als u apparatuur voor recycling terugbrengt, moet u contact opnemen met de producent of
leverancier voor instructies voor het terugbrengen van de afgedankte apparatuur voor een juiste
verwerking.
POLISH
Sprzęt elektryczny oznaczony takim symbolem nie może byćlikwidowany w europejskich systemach
utylizacji po dniu 12 sierpnia 2005. Zgodnie z europejskimi, lokalnymi i państwowymi przepisami prawa
(Dyrektywa Unii Europejskiej 2002/96/EC), użytkownicy sprzętu elektrycznego w Europie musząobecie
przekazywaćProducentowi stary sprzęt lub sprzęt po okresie użytkowania do bezpłatnej utylizacji.
Uwaga: Aby przekazaćsprzęt do recyklingu, należy zwrócićsiędo producenta lub dostawcy sprzętu w
celu uzyskania instrukcji dotyczących procedur przekazywania do utylizacji sprzętu po okresie
użytkownia.
PORTUGESE
Qualquer equipamento eléctrico que ostente este símbolo não poderá ser eliminado através dos
sistemas públicos europeus de tratamento de resíduos sólidos a partir de 12 de Agosto de 2005. De
acordo com as normas locais e europeias (Directiva Europeia 2002/96/EC), os utilizadores europeus de
equipamentos eléctricos deverão agora devolver os seus equipamentos velhos ou em fim de vida ao
produtor para o respectivo tratamento sem quaisquer custos para o utilizador.
Nota: No que toca à devolução para reciclagem, por favor, contacte o produtor ou fornecedor do
equipamento para instruções de devolução de equipamento em fim de vida para a sua correcta
eliminação.

3625 Package Analyzer - Important Information
Operator Manual ORBISPHERE
Product Disposal
Note:
The following only applies to European customers.
Hach Ultra is committed to ensuring that the risk of any environmental damage or
pollution caused by any of its products is minimized as far as possible. The European
Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) that came
into force on August 13 2005 aims to reduce the waste arising from electrical and
electronic equipment; and improve the environmental performance of all those involved
in the life cycle of electrical and electronic equipment.
In conformity with European local and national regulations (EU Directive 2002/96/EC
stated above), electrical equipment marked with the above symbol may not be disposed
of in European public disposal systems after 12 August 2005.
Hach Ultra will offer to take back (free of charge to the customer) any old,
unserviceable or redundant analyzers and systems which carry the above symbol, and
which were originally supplied by Hach Ultra. Hach Ultra will then be responsible for the
disposal of this equipment.
In addition, Hach Ultra will offer to take back (at cost to the customer) any old,
unserviceable or redundant analyzers and systems which do not carry the above symbol,
but which were originally supplied by Hach Ultra. Hach Ultra will then be responsible for
the disposal of this equipment.
Should you wish to arrange for the disposal of any piece of equipment originally supplied
by Hach Ultra, please contact your supplier or our After Sales Service department in
Geneva for instructions on how to return this equipment for proper disposal.

Important Information - 3625 Package Analyzer
Operator Manual
ORBISPHERE
Restriction of Hazardous Substances
Note:
The following only applies to exports of the product into the People’s Republic of China.
Marking
Products contain toxic or hazardous substances or elements.
Environment Protection Use Period Marking (years).
Toxic or Hazardous Substances and Elements
Part Name Lead
(Pb) Mercury
(Hg) Cadmium
(Cd)
Hexavalent
Chromium
(Cr VI)
Polybrom
Biphenyls
(PBB)
Polybrom
Diphenyls
(PBDE)
1106A Backplane
Board X
1062C Keypad Board X
1100B Logic Board X
1104A Analog Board X
1121B Options Board X
1067C Supply Board X
1063G Supply Board X
1127 Connection
Board X
1117C Measurement
Board X
70467 LCD Board X
Spacer X
O: Indicates that this toxic or hazardous substance contained in all homogeneous material for
this part is below the limit requirement
X: Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement

3625 Package Analyzer - Table of Contents 1 of 90
Operator Manual ORBISPHERE
Table of Contents
1 System Description
1.1 Main components ................................................................................9
1.2 System Layout...................................................................................10
1.3 Package Positioning Systems ...........................................................11
1.4 Package Piercer Components...........................................................12
1.4.1 Package Piercer Manual Operation Sequence ...................13
1.5 Measuring Instrument Controls .........................................................13
1.5.1 Display.................................................................................13
1.5.2 Function Keys......................................................................13
1.5.3 Main Menu...........................................................................14
1.5.4 Entering Values ...................................................................14
1.5.5 OrbiPack V5.00 PC Software ..............................................14
2 Installation
2.1 Installation Steps ...............................................................................15
2.2 Measuring Instrument........................................................................16
2.3 Package Piercer Installation..............................................................16
2.3.1 Sensors Installation .............................................................16
2.3.2 Purge and Forcing Gas Supply ...........................................18
2.3.3 Instrument Back Panel Connections ...................................19
2.3.4 Liquid and Pneumatic Connections.....................................20
2.4 PC Software Installation ....................................................................21
2.5 Installation Completion Check List ....................................................22
3 OrbiPack PC Software
3.1 General Information...........................................................................23
3.1.1 OrbiPack Startup .................................................................23
3.1.2 Getting Help.........................................................................24
3.1.3 Measurement Without the TC Sensor .................................24
3.1.4 Measurement Data Display .................................................25
3.1.5 Process Bar .........................................................................25
3.1.6 Warning Messages..............................................................26
3.1.7 Selecting Measurement Data ..............................................26
3.1.8 Toolbar Shortcuts ................................................................27
3.2 File Menu...........................................................................................27
3.3 Package Menu...................................................................................28
3.3.1 Setup ...................................................................................28
3.3.2 Selection..............................................................................30
3.3.3 Modify ..................................................................................30
3.3.4 Fill Volume...........................................................................30
3.3.5 Info.......................................................................................30
3.4 Table Menu........................................................................................31
3.4.1 Delete ..................................................................................31

2 of 90 Table of Contents - 3625 Package Analyzer
Operator Manual
ORBISPHERE
3.4.2 Copy ....................................................................................31
3.4.3 Select Package....................................................................31
3.4.4 Select All..............................................................................31
3.4.5 Base Styles..........................................................................31
3.4.6 Table Settings......................................................................32
3.4.7 Resize Rows........................................................................33
3.4.8 Resize Columns...................................................................33
3.5 Tools Menu ........................................................................................33
3.5.1 Statistics ..............................................................................33
3.5.2 Diagnostics ..........................................................................34
3.5.3 File Conversion....................................................................34
3.5.4 Options ................................................................................34
3.5.5 Factory Settings...................................................................38
3.5.6 Can Counter Reset ..............................................................38
3.5.7 Change Supervisor Password .............................................38
3.5.8 User Management ...............................................................39
3.6 View Menu .........................................................................................40
4 Automatic Analysis Sequence
4.1 Start ...................................................................................................41
4.2 Headspace (HS) Measurement .........................................................42
4.3 Product Sampling and Analysis .........................................................44
4.4 Results Calculation and Transfer.......................................................45
4.5 Remove Package, Line Rinsing.........................................................45
4.6 Instrument Warning Messages ..........................................................45
5 Operating Instructions
5.1 Measurement Menu...........................................................................47
5.2 Package Piercer Adjustments............................................................48
5.2.1 Two Step Device for Cans ...................................................48
5.2.2 Change the Piercer Configuration........................................48
5.2.3 Adjust Piercing System Height.............................................48
5.2.4 Adjust the Sampling Tube Lower Stop.................................49
5.3 Turning on the System.......................................................................49
5.3.1 PC Software.........................................................................49
5.3.2 Start the Instrument .............................................................49
5.4 Measurement Process.......................................................................50
5.4.1 Package Pressure Equalization...........................................50
5.4.2 Prepare for Piercing.............................................................50
5.4.3 Pierce the Package..............................................................51
5.4.4 Remove Package.................................................................51
5.5 Daily Cleaning (user maintenance)....................................................52
5.6 When Instrument is not Used ............................................................52
6 Options
6.1 Membrane Selection..........................................................................56

3625 Package Analyzer - Table of Contents 3 of 90
Operator Manual ORBISPHERE
6.2 Serial (RS-232) Output......................................................................56
6.3 Thermal Conductivity Sensor Continuous Purge...............................56
6.4 Sampling System Purge....................................................................57
6.5 Nitrogen TC Sensor Corrections .......................................................57
6.5.1 Humidity Factor Correction..................................................57
6.5.2 Oxygen Factor Correction ...................................................58
6.5.3 Temperature Correction ......................................................59
6.6 Check Routine...................................................................................59
6.7 Oxygen Stability.................................................................................60
7 Calibrations
7.1 Planning Sensor Calibrations ............................................................62
7.1.1 Validation of the Gas Sensors Calibration...........................62
7.1.2 Tools Needed ......................................................................63
7.2 PT-1000 Temperature Sensor Calibration.........................................63
7.3 Barometric (internal) Pressure Sensor Calibration............................64
7.4 Package (external) Pressure Sensor Calibration ..............................64
7.4.1 Two Point Calibration (recommended) ................................64
7.4.2 One Point Calibration ..........................................................65
7.5 Electrochemical Oxygen Sensor Calibration .....................................65
7.5.1 In Air Calibration Method .....................................................65
7.6 Thermal Conductivity CO2and N2Sensor Calibration......................66
7.6.1 Fraction Calibration Method ................................................67
7.6.2 Partial Pressure Calibration.................................................68
7.6.3 Dissolved Calibration with CO2Calibration Kit ....................69
7.6.4 Dissolved Calibration with Reference Sample.....................70
8 Maintenance
8.1 Daily Cleaning (user maintenance) ...................................................71
8.2 Pressure Regulator............................................................................72
8.3 Servicing the Filters...........................................................................72
8.4 Sampling Tube Maintenance.............................................................73
8.5 Replacing Knife and Seals ................................................................73
8.6 Servicing the Manifold .......................................................................74
8.7 Instrument Service.............................................................................75
8.7.1 Fuse Replacement ..............................................................75
8.7.2 AC Voltage Switch...............................................................75
9 Troubleshooting
9.1 Control Valves Check Routine...........................................................77
9.2 OrbiPack Software Error Messages ..................................................78
9.3 Measuring Instrument Error Messages .............................................79
9.4 Troubleshooting Guide ......................................................................80
9.5 Diagnostic Information on PC............................................................81
9.5.1 Diagnostic Information During the Measure Procedure.......81
9.5.2 Diagnostic Information During the Calibrate Procedure ......82

4 of 90 Table of Contents - 3625 Package Analyzer
Operator Manual
ORBISPHERE
10 Spare Parts
10.1 Piercer Parts ......................................................................................83
10.2 Sensor Specific Parts ........................................................................84
Appendix A: Glossary
A.1 Common Units ...................................................................................85
A.2 Terms and Definitions........................................................................85

3625 Package Analyzer - Manual Overview 5 of 90
Operator Manual ORBISPHERE
Manual Overview
About this Manual
The information in this manual has been carefully checked and is believed to be
accurate. However, Hach Ultra assumes no responsibility for any inaccuracies that may
be contained in this manual. In no event will Hach Ultra be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect or omission in
this manual, even if advised of the possibility of such damages. In the interest of
continued product development, Hach Ultra reserves the right to make improvements in
this manual and the products it describes at any time, without notice or obligation.
Published in Europe.
Copyright © 2006 by Hach Ultra. All rights reserved. No part of the contents of this
manual may be reproduced or transmitted in any form or by any means without the
written permission of Hach Ultra.
CAUTION:
This product is designed to work with beverages having no pulps or suspended
particles, as these would rapidly clog the system.
Note:
Depending on the application, the beverage Package Analyzer has either a CO2or a N2
thermal conductivity sensor. Both systems are for the most part identical in operation.
Thus this manual generally describes the CO2procedures, and when appropriate,
specifies any N2related procedure.
Revision History
• Initial Release, January 1999, Orbisphere
• Revision A, March 2003, Hach Ultra Analytics
• Revision B, October 2003, Hach Ultra Analytics
• Revision C, January 2004, Hach Ultra Analytics
• Revision D, February 2006, Hach Ultra
• Revision E, March 2007, Hach Ultra
• Revision F, May 2007, Hach Ultra
Safety Conventions
WARNING
A warning is used to indicate a condition which, if not met, could cause serious personal
injury and/or death. Do not move beyond a warning until all conditions have been met.
CAUTION:
A caution is used to indicate a condition which, if not met, could cause minor or
moderate personal injury and/or damage to the equipment. Do not move beyond a
caution until all conditions have been met.
Note:
A note is used to indicate important information or instructions that should be considered
before operating the equipment.

6 of 90 Manual Overview - 3625 Package Analyzer
Operator Manual
ORBISPHERE
Safety Precautions
Please read the entire manual before unpacking, setting up, or operating this instrument.
Pay particular attention to all warning and caution statements. Failure to do so could
result in serious injury to the operator or damage to the equipment.
To ensure the protection provided by this equipment is not impaired, do not use or install
this equipment in any manner other than that which is specified in this manual.
Safety Recommendations
For safe operation, it is imperative that these service instructions be read before use and
that the safety recommendations mentioned herein be scrupulously respected. If repairs
or adjustments are necessary, the instrument should be returned to an authorized Hach
Ultra service center.
If danger warnings are not heeded to, serious material or bodily injury could occur.
WARNING
In accordance with safety standards, it must be possible to disconnect the power supply
of the instrument in its immediate vicinity.
WARNING
The installation of the instrument should be performed exclusively by personnel
specialized and authorized to work on electrical installations, in accordance with
relevant local regulations.
Service and Repairs
None of the instrument’s components can be serviced by the user. Only personnel from
Hach Ultra or its approved representative(s) is (are) authorized to attempt repairs to the
system and only components formally approved by the manufacturer should be used.
Any attempt at repairing the instrument in contravention of these principles could cause
damage to the instrument and corporal injury to the person carrying out the repair. It
renders the warranty null and void and could compromise the correct working of the
instrument and the electrical integrity or the CE compliance of the instrument.
If you have any problems with installation, starting, or using the instrument please
contact the company that sold it to you. If this is not possible, or if the results of this
approach are not satisfactory, please contact the manufacturer’s Customer Service.
EMC and Safety Requirements
The instrument conforms to the following EMC and safety standards:
EMC Requirements EN 61326:1997 + A1:1998 + A2:2001 + A3:2003
Safety Requirements EN 61010-1

3625 Package Analyzer - Manual Overview 7 of 90
Operator Manual ORBISPHERE
Precautionary Labels
Read all labels and tags attached to the instrument. Personal injury or damage to the
instrument could occur if not observed.
Acknowledgements
• Dacron, Delrin, Tedlar, Tefzel, and Viton are registered trademarks of DuPont.
• Halar is a registered trademark of Ausimont U.S.A., Inc.
• Hastelloy is a registered trademark of Haynes International.
• Kynar is a registered trademark of The Pennwalt Corporation.
• Monel is a registered trademark of IMCO Alloys International, Inc.
• Saran is a registered trademark of Dow Chemical Co.
• Swagelok is a registered trademark of Swagelok Co.
• Microsoft and Windows are registered trademarks of Microsoft Corporation.
This symbol, when noted on a product enclosure or barrier, indicates that a risk of
electrical shock and/or electrocution exists and indicates that only individuals
qualified to work with hazardous voltages should open the enclosure or remove
the barrier.
This symbol, when noted on the product, indicates that the marked item can be hot
and should not be touched without care.
This symbol, when noted on the product, indicates the presence of devices
sensitive to electrostatic discharge and indicates that care must be taken to
prevent damage to them.
This symbol, when noted on the product, identifies a risk of chemical harm and
indicates that only individuals qualified and trained to work with chemicals should
handle chemicals or perform maintenance on chemical delivery systems
associated with the equipment.
This symbol, if noted on the product, indicates the need for protective eye wear.
This symbol, when noted on the product, identifies the location of the connection
for protective earth (ground).
Electrical equipment marked with this symbol may not be disposed of in European
public disposal systems. In conformity with European local and national
regulations, European electrical equipment users must now return old or
end-of-life equipment to the manufacturer for disposal at no charge to the user.
Products marked with this symbol indicates that the product contains toxic or
hazardous substances or elements. The number inside the symbol indicates the
environmental protection use period in years.

8 of 90 Manual Overview - 3625 Package Analyzer
Operator Manual
ORBISPHERE

3625 Package Analyzer - System Description 9 of 90
Operator Manual ORBISPHERE
1 System Description
1.1 Main components
Equipment included Part number Notes
Measuring instrument 3625 / 4110
3625 / 5110
with O2& CO2sensors (N2calculated)
with O2& N2 sensors (CO2calculated)
Beverage package piercer 29 995 two step model, with lock release spacer
Cutting knife for PET 32 111A for plastic caps
Piercing knife for metal 32 106A for metal caps and cans
Package positioning plate 32 108 for glass bottle and cans
PET bottle neck positioning fork 32 112 for PET bottles
Inclined base for cans, used with
32108 32 945 for increasing the headspace
O2electrochemical sensor 31 110.02
CO2thermal conductivity sensor, or
N2thermal conductivity sensor
31 450
31 550 without external temp. sensor
OrbiPack V5.00 PC software CD 32 694.E
Calibration flow chamber 32 001.030 Thermal conductivity sensors calibration
Test thimble, in stainless steel 32 820 Pneumatic valve D’ and D” test
Maintenance kit for
O2electrochemical sensors 32 702
Includes membranes 2952A, electrolyte
2959, membrane holding ring 29228,
and tools for sensor maintenance.
Maintenance kit for CO2& N2
thermal conductivity sensors, with
protection cap 29111
32 760
Includes membranes 29561A,
membrane holding ring 29228, 28002
washers, and tools for sensor
maintenance.
Spares kit for 3625 32 944
Includes membranes, O-rings, seals,
filters, tools, and valve cleaning block
assembly.
0°C temperature simulator plug 32 116 Used for PT1000 temperature sensor
calibration

10 of 90 System Description - 3625 Package Analyzer
Operator Manual
ORBISPHERE
1.2 System Layout
Fig 1-1: System Layout

3625 Package Analyzer - System Description 11 of 90
Operator Manual ORBISPHERE
1.3 Package Positioning Systems
Holding plate for cans and glass bottles
(swivel 90° to accommodate cans or
bottle).
Holding clamp for PET bottle neck, with
a positioning groove (level of cap top)
The wedge plate allows for a higher headspace in cans, to facilitate headspace volume
sampling. This support device must be installed on the piercer mat, having the can
inclined to the right (when facing the piercer). The higher headspace created avoids
sampling foam or liquid during the headspace analysis process.

12 of 90 System Description - 3625 Package Analyzer
Operator Manual
ORBISPHERE
1.4 Package Piercer Components
Components identification
1) Sampling tube insertion device and handles
2) Sampling tube adjustable lower stop
3) Analyzer manifold
4) Two step device (left side) for cans analyze, with release spacer
5) Piercing knife, metal or plastic type
6) Package positioning system (cans, glass, PET bottles)
7) Flow meter to regulate product flow past sensors
8) Piercer lever, to lower or raise the piercing knife
9) Adjustable pressure regulator for purge gas (behind panel)
10) Pressure gauge showing purge gas regulated pressure
11) Purge and forcing gas inlet
12) Locking lever for the package positioning system height adjustment

3625 Package Analyzer - System Description 13 of 90
Operator Manual ORBISPHERE
1.4.1 Package Piercer Manual Operation Sequence
According to instructions given on instrument display and PC:
• Install a package in position
• Pierce the package
• Lower the sampling tube (only when asked !)
• Raise the sampling tube (end of analysis)
• Lift the piercing lever to remove package (slowly to avoid spillage)
Note:
Sequence is controlled by the instrument.
1.5 Measuring Instrument Controls
1.5.1 Display
The instrument front panel provides a two line liquid crystal display (LCD), having 16
characters per line.
1.5.2 Function Keys
•ESC back one step.
•×or Ømove through the loop of available data (selection blinks).
•ENTER confirm selection.
3 position key switch:
OFF: Measuring device power off
ON locked: Function keys locked
(avoids unwanted modification).
Device starts in measuring mode.
ON unlocked:Function keys are active.
Calibration and Options mode.
1.5.1.1 Back light switch:
1.5.1.2 Press to turn on the LCD backlight for 3
minutes.

14 of 90 System Description - 3625 Package Analyzer
Operator Manual
ORBISPHERE
1.5.3 Main Menu
Main menu is reached by pressing ESC as many times as needed:
• MEASURE: Measurement
• OPTIONS: Set up the instrument
• CALIBRATE: Calibration procedures
1.5.4 Entering Values
When entering numbers, several digits are displayed. The caret symbol ^represents the
cursor. After entering the last digit, the new value is saved.
•×Øincrease or decrease the number value
•ENTER move cursor one digit to right
•ESC move cursor one digit to left
•ENTER confirm last value entered
•×Ømove decimal point (when applicable)
•ENTER confirm and exit
Note:
When power is disconnected, the system remembers each value previously saved.
1.5.5 OrbiPack V5.00 PC Software
The Beverage Package Analyzer system works with the OrbiPack software. An RS232
cable must be connected from the PC to the instrument and the software must be
running.
The latest version of the OrbiPack PC software is compatible with all previous versions
and operates under Microsoft Windows® 95/98/NT/2000/ME/XP (min. 7Mb free disk
space required). Refer to “PC Software Installation” on page 21 for instructions on
installing the software, and to “OrbiPack PC Software” on page 23 for information on
using the software.
Note:
Any new OrbiPack fields will be empty when reading previous versions of measurement
files.
