Hach LZV902 User manual

DOC012.97.90371
LZV902
DR 6000
03/2012, Edition 1
User Manual en
Manual del usuario es
Manuel d'utilisation fr
ユーザー マニュアル ja
사용 설명서 ko
Manual do utilizador pt
用户手册 zh

English .............................................................................................................................................. 3
Español ............................................................................................................................................. 9
Français .......................................................................................................................................... 17
英語 ................................................................................................................................................. 25
한국어 ............................................................................................................................................. 33
Português ....................................................................................................................................... 41
英语 ................................................................................................................................................. 49

English 3
English
General information
Safety notes
Read the entire user manual carefully before you unpack, set up or
operate the device. Observe all danger and warning notes. Failure to do
so could lead to serious injury of the operator or to damage to the
device.
To make sure that the device safety features are not impaired, this
device may not be used or installed in any manner other than that
specified in this user manual.
Danger notes in this manual
Note: Information that supplements aspects from the main text.
Warning labels
Read all labels and tags attached to the device. Failure to do so may
result in personal injury or damage to the device. For symbols attached
to the instrument, corresponding warning notes are provided in the user
manual.
DANGER
Indicates a potentially or imminently hazardous situation that, if not avoided, can
result in death or serious injury.
WARNING
Indicates a potentially or imminently hazardous situation that, if not avoided, may
result in death or serious injury.
CAUTION
Indicates a possible dangerous situation that can have minor or moderate injuries
as a result.
NOTICE
Indicates a situation that, if not avoided, could result in damage to the device.
Information that particularly should be emphasized.
This symbol may be attached to the device, and references the
operation and/or safety information in the user manual.
Electrical equipment marked with this symbol may as of August 12,
2005 Europe-wide no longer be disposed of in unsorted house or
industrial waste. According to valid provisions (EU Directive 2002/96/
EC), from this point consumers in the EU must return old electrical
devices to the manufacturer for disposal. This is free for the
consumer.
Note: Contact the manufacturer or supplier to find out you
can return end-of-life devices, manufacturer-supplied
electrical accessories and all auxiliary items for proper
disposal.

English 4
Chemical and biological safety
Normal operation of this instrument may involve the use of hazardous
chemicals or biologically harmful samples.
•Observe all cautionary information printed on the original solution
containers and safety data sheet prior to their use.
•Dispose of all consumed solutions in accordance with national
regulations and laws.
•Select the type of protective equipment suitable to the concentration
and quantity of the dangerous material at the respective work place.
Overview of product
The carousel insert (sample changer) is available in two designs:
•The 10 mm carousel insert (sample changer) can be equipped with
up to seven 10 mm square cells.
•The 1 inch carousel insert (sample changer) can be equipped with
up to five 1 inch square cells.
Various combinations of sample and blank value cells are possible.
These combinations are defined with the corresponding carousel options
before measuring.
Installation
Insert the carousel insert (sample changer)
1. Open the cell compartment.
2. Remove the universal cell adapter.
3. Insert the carousel insert (sample changer) so that the arrow on the
insert points left in the direction of the round cell compartment.
4. Press the carousel insert down until it snaps into place.
Figure 1 Insert the carousel insert
DANGER
Potential danger in the event of contact with chemical/biological materials.
Handling chemical samples, standards and reagents can be dangerous.
Familiarise yourself with the necessary safety procedures and the correct
handling of the chemicals before the work and read and follow all relevant safety
data sheets.

English 5
Operation
Measurements with the carousel insert
Stored programs
1. Select Stored Programs in the main menu.
2. Select the desired test and press Start.
3. Press Options > More > Reading mode.
4. Select Carousel 1 inch square.
5. In the toolbar, select the symbol for the carousel insert. This symbol
opens a window with carousel options; refer to Table 1.
6. Equip the first carousel insert with zero solution and samples, as
per the cell order information. The zero solution is placed in
position 1.
Table 1 "Stored Programs" carousel options
Options Description
Number of samples Number of samples without zero solution (or blank
value), maximum 40 samples possible.
Sample ID
Off: The samples are not assigned a sample ID
Enter Sample ID: The sample is selected and a sample
is entered under Edit. The sample IDs are not saved in
the general sample ID list, rather they only apply to the
current series of measurements.
Select Sample ID: The sample is selected and the
general sample ID list opens under Select. Each
sample is allocated the desired sample ID.
Import external Sample ID list: *.txt and *.csv files can
be imported via a USB stick or network; refer to section
Import an external sample ID.
Cell Order Information
Cell sequence indicator: shows the position in the
carousel insert in which each sample must be placed.
Z1 is the zero solution (blank value). Defined sample
IDs are specified here and make assigning the samples
easier.
Dilution Factor Each sample can be assigned a dilution factor.
Table 1 "Stored Programs" carousel options
Options Description

English 6
7. Start the measurement by pressing Read Carousel 1.
The first carousel insert is measured and the results displayed.
8. Remove the carousel insert or cells and load carousel insert 2 with
samples.
9. Start the measurement by pressing Read Carousel 2.
The second carousel insert is measured and the results displayed.
Continue until all samples have been measured.
Note: If Instrument Setup > Data Log Setup > Auto Store: On has
been selected, all measurement data is automatically saved. The
measurement data can be accessed under Recall data > Data Log.
Import an external sample ID
1. Create an external sample ID list with a spreadsheet program.
Four columns are permitted; column 1 contains the sequential
number, column 2 the sample designation, columns 3 and 4 are
optional.
Headings and comment lines must begin with #.
2. Create a folder named "SampleID" on a USB stick or in your
established network.
3. Save the sample ID list in CSV or UNICODE-TXT format in the
"SampleID" folder with Save as.
4. Connect the DR6000 to the USB stick or network.
All *.TXT and *.CSV files in the SampleID folder will be displayed for
selection.
5. Select the desired file with OK.
6. Transfer the displayed sample ID list with Done.
Single wavelength
1. Press Single Wavelength in the main menu.
2. Press Options > More > Reading mode.
3. Select Carousel 1 inch square or Carousel 10 mm square.
4. In the toolbar, select the symbol for the carousel insert. This symbol
opens a window with carousel options; refer to Table 2.
Table 2 Carousel options
Options
Carousel 1 inch
square
Options
Carousel 10 mm
square Description
Zero 1 Read 1–5 Zero 1 Read 1–7
Position 1 zero solution, from position 1 to
5 (or 7) samples
Measurement stops after the zero
measurement. Afterwards, the carousel
insert is measured one a work step.
Zero 1–5
Read 1–5 Zero 1–7 Read 1–7
Position 1 to 5 (or 7) zero solutions,
position 1 to 5 (or 7) samples.
Measurement stops after all zero
measurements. Afterwards, the samples
are measured in a further work step.
Zero 1 Read 2–5 Zero 1 Read 2–7
Position 1 zero solution, from position 2 to
5 (or 7) samples.
Carousel insert is measured in one work
step.
Zero 1, 3
Read 2, 4 Zero 1, 3, 5 Read 2, 4, 6
Always alternating. First zero solution,
then sample.
Carousel insert is measured in one work
step.

English 7
5. Load the carousel insert according to the selected carousel option.
6. Start the measurement by pressing Zero or Read or Zero & Read
according to the selected carousel option.
The carousel insert is measured and the results are displayed.
Note: If Instrument Setup > Data Log Setup > Auto Store: On has
been selected, all measurement data is automatically saved. The
measurement data can be accessed under Recall data > Data Log.
Multi-wavelength
1. Press Multi-Wavelength in the main menu.
2. Press Options > More > Reading mode.
3. Select Carousel 1 inch square or Carousel 10 mm square.
4. In the toolbar, select the symbol for the carousel insert. This symbol
opens a window with carousel options; refer to Table 2.
5. Load the carousel insert according to the selected carousel option.
6. Start the measurement by pressing Zero or Read or Zero & Read
according to the selected carousel option.
Each zero solution and sample is measured with the defined
wavelength and the results are displayed.
Note: If Instrument Setup > Data Log Setup > Auto Store: On has
been selected, all measurement data is automatically saved. The
measurement data can be accessed under Recall data > Data Log.
Wavelength scan
1. Press Wavelength Scan in the main menu.
2. Press Options > More > Reading mode.
3. Select Carousel 1 inch square or Carousel 10 mm square.
4. In the toolbar, select the symbol for the carousel insert. This symbol
opens a window with carousel options; refer to Table 2.
5. Load the carousel insert according to the selected carousel option.
6. Start the measurement by pressing Zero or Read or Zero & Read
according to the selected carousel option.
Each zero solution and sample is measured with the defined
wavelength range; the curve is displayed.
Save the wavelength scan
1. Press Options > Select View and select the cell for which you
want to save the scan.
2. Select Table or Graph; the scan is displayed.
3. Press Options > Store Symbol and select one of the 20 scan
storage locations.
4. Press Store.
5. The measurement data can be accessed in the main menu under
Recall Data > Wavelength Scan.

English 8
Time course
1. Press the Time Course menu option in the main menu.
2. Press Options > More > Reading mode.
3. Select Carousel 1 inch square or Carousel 10 mm square.
4. In the toolbar, select the symbol for the carousel insert. This symbol
opens a window with carousel options; refer to Table 2.
5. Load the carousel insert according to the selected carousel option.
6. The measurement interval between the individual measurements
must be at least 15 seconds.
7. Start the measurement by pressing Zero or Read or Zero & Read
according to the selected carousel option.
Each zero solution and sample is measured in the defined
measurement interval and the curve is displayed.
Storing the time course
1. Press Options > Select View and select the cell for which you
want to store the elapsed time.
2. Select Table or Graph; the elapsed time is displayed.
3. Press Options > Store Symbol and select one of the 20 cycle
storage locations.
4. Press Store.
5. The measurement data can be accessed in the main menu under
Recall Data > Time Course.
Accessories
Description Order no.
Carousel insert (sample changer) 10 mm LZV902.99.00002
Carousel insert (sample changer) 1 inch LZV902.99.00012
1-inch square cells, 8 matched cells, glass (10 mL) 2495408
10 mm square cells, matched pair, glass (3.5 mL) 2095100
10 mm square cells, quartz 2624410
10 mm disposable square micro cells (1.5 mL) 2629500
10 mm square plastic cells 2743400
Plug, neoprene for 1-inch square cells 1480801

Español 9
Español
Información general
Notas de seguridad
Lea detenidamente el manual del usuario en su totalidad, antes de
retirar el dispositivo del paquete, de configurarlo o hacerlo funcionar.
Respete todas las notas de peligro y advertencia. En caso de no
hacerlo, el usuario puede sufrir lesiones graves o el dispositivo puede
resultar dañado.
A fin de prevenir el deterioro de las funciones de seguridad, este
dispositivo no puede utilizarse ni instalarse de manera diferente a la que
se especifica en este manual.
Notas de peligro en este manual
Nota: Información que complementa algunos aspectos del texto
principal.
Etiquetas de advertencia
Lea todas las etiquetas y rótulos adosados al dispositivo. De lo
contrario, se pueden provocar heridas personales o daños en el
dispositivo. En relación con los símbolos adosados al dispositivo, se
proporcionan las notas de advertencia correspondientes en el manual
del usuario.
PELIGRO
Indica una situación de peligro inminente o potencial, que de no evitarse, podría
causar la muerte o lesiones graves.
ADVERTENCIA
Señala una situación de peligro inminente o potencial, que de no evitarse, podría
causar lesiones graves y la muerte.
ATENCIÓN
Indica una situación de peligro potencial que puede ocasionar lesiones leves o
moderadas.
AVISO
Indica una situación que de no evitarse, podría causar daños al dispositivo.
Información en la que se debería hacer especial hincapié.
Es posible que este símbolo esté adosado al dispositivo y haga
referencia al funcionamiento y a la información de seguridad que
figura en este manual.
El equipo eléctrico marcado con este símbolo no se podrá desechar
como residuo industrial o doméstico no clasificado en toda Europa
después del 12 de agosto de 2005. De conformidad con las
disposiciones válidas (directiva UE 2002/96/CE), los usuarios en
Europa deben retornar ahora los equipos eléctricos antiguos al
fabricante para su eliminación. Esto es gratis para el consumidor.
Nota: Comuníquese con el fabricante o proveedor para
obtener información sobre la eliminación adecuada de
dispositivos fuera de uso, accesorios eléctricos
suministrados por el fabricante y cualquier otro elemento
auxiliar.

Español 10
Seguridad química y biológica
El funcionamiento normal de este instrumento puede implicar el uso de
muestras nocivas químicas y biológicas.
•Observe toda la información de seguridad impresa en los
contenedores originales de las soluciones y hojas de datos de
seguridad antes de utilizarlos.
•Deshágase de todas las soluciones que haya utilizado de acuerdo
con las normativas y leyes nacionales.
•Seleccione el tipo de equipo de protección adecuado a la
concentración y la cantidad de material peligroso en el lugar de
trabajo correspondiente.
Información general del producto
La inserción de carrusel (cambiador de muestra) está disponible en dos
diseños:
•La inserción de carrusel (cambiador de muestra) de 10 mm puede
contener hasta siete cubetas cuadradas de 10 mm.
•La inserción de carrusel (cambiador de muestra) de 1 pulgada
puede contener hasta cinco cubetas cuadradas de 1 pulgada.
Es posible que existan varias combinaciones entre cubetas de valor en
blanco y de muestra. Estas combinaciones se definen mediante las
opciones de carrusel correspondientes antes de realizar las medidas.
Instalación
Inserte la inserción de carrusel (cambiador de
muestra)
1. Abra el compartimiento de la cubeta.
2. Quite el adaptador de cubetas universal.
3. Inserte la inserción de carrusel (cambiador de muestra) de modo
que la flecha en la inserción apunte hacia la izquierda en dirección
al compartimiento redondeado de la cubeta.
4. Presione la inserción de carrusel hasta encaje en su lugar.
Figura 1 Inserte la inserción de carrusel
PELIGRO
Peligro potencial en caso de contacto con materiales químicos o biológicos.
La manipulación de muestras químicas, patrones y reactivos puede ser peligrosa.
Familiarícese con los procedimientos de seguridad necesarios y el manejo
correcto de los productos químicos antes de realizar cualquier trabajo y lea las
hojas de datos de seguridad correspondientes y siga las indicaciones.
