HADEF 238/10 Assembly instructions

5.52.208.00.01.06
Rev.06
HADEF Manual Worm Gear Wire Rope Winch
as standard version
Type 238/10
as galvanized version
Type 238/10GV
as Marine version
Type 238/10MV
Installation,- Operating and
Maintenance Instructions

2
5.52.208.00.01.06
NOTICE!
The installation or mounting instructions for incomplete machines you’ll find in chapter “Installation”
o

by Heinrich de Fries GmbH
Heinrich de Fries GmbH, Gauss Str. 20, D-40235 Düsseldorf
Heinrich De Fries GmbH will be named HADEF in the following text.
Original operating- and maintenance instructions in German language.
Translation in other languages is made of the German original.
A copy may be requested in writing or is available for download on www.hadef.com
Subject to changes.
Table of Contents
1Information.........................................................................................3
2Safety .................................................................................................4
2.1 Warning notice and symbols..........................................................................................4
2.2 Duty of care of the owner................................................................................................4
2.3 Requirements for the operating personnel....................................................................5
2.4 Appropriate use...............................................................................................................5
2.5 Basic safety measures....................................................................................................6
3Transport and Storage......................................................................6
3.1 Transport..........................................................................................................................6
3.2 Safety device for transport..............................................................................................7
3.3 Storage.............................................................................................................................7
4Description.........................................................................................7
4.1 Areas of application.........................................................................................................7
4.2 Design ..............................................................................................................................7
4.3 Functions .........................................................................................................................7
4.4 Important components....................................................................................................8
5Technical data ...................................................................................8
6Installation .........................................................................................8
6.1 Installation of the winch..................................................................................................9
6.2 Selection of wire ropes....................................................................................................9
6.3 Wire rope fastening .........................................................................................................9
6.4 Winding up of wire rope................................................................................................10
6.5 Wire rope deflection ......................................................................................................10
6.6 Tools...............................................................................................................................10
7Operation .........................................................................................11
7.1 Free-wheeling mechanism of the drum........................................................................11
7.2 Brake as slipping clutch to disengage the drum.........................................................11
8Commissioning ...............................................................................12
8.1 General...........................................................................................................................12
8.2 Worm gear......................................................................................................................12
8.3 Wire rope........................................................................................................................12

5.52.208.00.01.06
3
9Safety check .................................................................................... 13
10 Functional test................................................................................. 13
11 Maintenance .................................................................................... 13
11.1 General...........................................................................................................................13
11.2 Monitoring......................................................................................................................13
12 Inspection........................................................................................ 13
12.1 Periodic checks .............................................................................................................13
12.2 Wire rope........................................................................................................................13
12.3 Inspection intervals.......................................................................................................14
13 Service .............................................................................................14
13.1 Wire rope........................................................................................................................14
13.2 Gear................................................................................................................................14
13.3 Gear spring pressure brake..........................................................................................14
13.4 Lubricant - Selection.....................................................................................................14
13.5 Lubricant for food industry – Selection (as option*)...................................................15
14 Trouble............................................................................................. 15
15 Remedy............................................................................................ 15
16 Decommissioning ...........................................................................15
16.1 Temporary decommissioning.......................................................................................15
16.2 Final decommissioning/disposal..................................................................................15
1 Information
The products meet European Union requirements, in particular the valided EU Machine Directive.
The entire company works acc. to a certified quality assurance system as per ISO 9001.
The production of components at our work is subject to strict, intermediate checks.
After assembly, each product is subject to a final test with overload.
For the operation of hoists, the national accident prevention regulations apply in Germany, amongst others.
The stated performance of the devices and meeting any warranty claims require adherence to all instructions
in this manual.
Before delivery, all products are packed properly. Check the goods after receipt for any damage caused
during transport. Report any damage immediately to the forwarding agent.
This manual allows a safe and efficiently use of equipment. Images of this manual are for a principle
understanding and can be different from the real design.
NOTICE!
We refer to the prescribed equipment tests before initial start-up, before putting back into operation and the
regular periodic inspections.
In other countries any additional national regulations must be observed.

4
5.52.208.00.01.06
2 Safety
2.1 Warning notice and symbols
Warnings and notice are shown as follows in these instructions:
DANGER!
This means that there is a high risk that leads, if it is not avoided, to death or severe injury.
WARNING!
This means that there is a risk that could lead, if it is not avoided, to death or severe injury.
CAUTION!
This means that there is little risk that could lead, if it is not avoided, to slight injury or damage to the device or its
surrounding.
NOTICE!
Gives advice for use and other useful information.
Danger from electricity.
Danger from explosive area.
2.2 Duty of care of the owner
DANGER!
Failure to follow the instructions of this manual can lead to unpredictable hazards.
For any resulting damage or personal injury, HADEF assumes no liability.
The unit was designed and built following a risk analysis and careful selection of the harmonized standards
that are to be complied with, as well as other technical specifications. It therefore represents state-of-the-art
technology and provides the highest degree of safety.
Our delivery includes the hoist supplied beginning at its suspension and ending at the load hook and if
supplied with control, the control line/hose that leads to the hoist. Further operating material, tools, load
attaching devices as well as main energy supply lines must be assembled according to the valid rules and
regulations. For explosion-proof equipment, all these parts must be approved for use in area prone to
explosion, or they must be suitable for use in area prone to explosion. The owner is responsible for this.
However, in everyday operation this degree of safety can only be achieved if all measures required are
taken. It falls within the duty of care of the owner/user of the devices to plan these measures and to check
that they are being complied with.
Complete the operating and installation instructions by any instructions (regarding supervision or
notifications)that are important for the special kind of use of the equipment, i.e. regarding organization of
work, work flow and human resources.
In particular, the owner/user must ensure that:
The unit is only used appropriately.
The device is only operated in a fault-free, fully functional condition, and the safety components, in
particular, are checked regularly to ensure that it is functioning properly.
The required personal protective equipment for the operators, service and repair personnel is available
and is used.
The operating instructions are always available at the location where the equipment is used and that they
are legible and complete.
The unit is only operated, serviced and repaired by qualified and authorized personnel.
This personnel is regularly trained in all applicable matters regarding safety at work and environmental
protection, and that they are familiar with the operating manual and, in particular, the safety instructions it
contains.
Any safety and warning signs on the devices are not removed and remain legible.
Devices for use in area prone to explosion must (from customer's side) be earthed with a shunting
resistor of < 106Ω against earth.
WARNING!
It is not allowed to make constructive changes of the equipment!

5.52.208.00.01.06
5
2.3 Requirements for the operating personnel
The units may only be operated by qualified persons that are appropriately trained and that are familiar with
it. They must have their employer’s authorization for operation of the units.
Before starting work, the operating personnel must have read the operating and installation instructions,
especially the chapter "Safety Instructions".
This is especially important for operating personnel that rarely uses the equipment, i.e. for installation or
maintenance work.
DANGER!
In order to avoid severe injury, please pay attention to the following when using the equipment:
Use protective clothes/equipment.
Do not wear long hair hanging down open.
Do not wear rings or other jewelry.
Do not wear clothes that are too big/wide.
Do not reach into ropes, chains, drive parts or other moving parts with your hands
2.4 Appropriate use
The permitted safe working load of the devices must not be exceeded! An exception can be made during the
load test before initial operation, carried out by a licensed qualified person.
The permissible ambient temperature during operation of manual driven devices is -20 ° C / + 50 ° C and
at all power driven devices -20 ° C / + 40 ° C!
Defective devices and load suspension devices must not be used until they have been repaired! Only
original spare parts must be used. Non-compliance will result in any warranty claims becoming void.
Liability and warranty will become void if unauthorized modifications of the units are made by the user!
Vertical lifting and lowering of unguided loads, horizontal movement of loads and inclined movement of
loads, movement of flaps, covers etc.
2.4.1 Winches with disengaging clutch (as option)
Only for pulling out the uncharged wire rope
Only for horizontal load
Only for special kinds of use (i.e. lowering of floaters in liquids) when there is no danger for persons or
danger of damage of material.
NOTICE!
If the units are not used appropriately, it is not possible to ensure safe operation.
The owner and operator have sole liability for all personal injury and damage to pr
operty arising from
inappropriate use.
DANGER!
It is not allowed:
pulling loose of stuck loads, dragging of loads and inclined pulling is not allowed.
in explosive atmosphere, except the unit is especially modified for it and marked by an indication label
In reactor containment vessels.
to transport people
The device is not suitable for use on stages and in studios
persons must not stand under a suspended load

6
5.52.208.00.01.06
2.5 Basic safety measures
Observe installation-, operation and maintenance instruction.
Take notice of caution notes at units and in the manual
Observe safety distances.
Take care for a free view on the load.
Only use the hoists appropriately.
The equipment is to be used exclusively for movement of goods. Under no circumstances my persons be
moved.
Never load the devices beyond their working load limit.
Pay attention to the accident prevention regulations (UVV).
Should the hoist be used outside of Germany, please pay attention to the national regulations that apply.
Supporting structures and load-attached devices used in conjunction with this equipment must provide an
adequate safety factor to handle the rated load plus the weight of the equipment. In case of doubt, consult
a structural engineer.
If the equipment has not been used for a period of time, carry out visual checks of all main components
such as chains, load hooks etc. and replace any damaged parts with new, original spare parts before
putting the equipment back into operation!
Do not use a hoist that is defective, pay attention to any abnormal noise it makes during operation.
Stop working immediately in case of disturbances and remedy failures.
Any damage and faults must be reported to a responsible supervisor immediately.
If the unit is put into motion, any persons in the immediate vicinity must be informed by calling to them!
Please pay attention to the regulations for load carrying devices UVV for both positive and non-positive
methods of attaching loads.
The lifting tackle or the load must be securely attached to the hook and be seated at the bottom of the
hook.
The safety catch of hooks must be closed.
When charged, the housing may not be in contact somewhere.
Motor drive is prohibited.
WARNING!
The following is not allowed:
to lift another load than the nominal safe working load
to manipulate the sliding clutch if units are equipped with
The use of elongated or damaged chains or wire ropes. Replace them immediately by new, original
parts.
Never loop the load chain around a load nor place or pull the chain over edges.
Never repair damaged load hooks (e.g. by hammering), but replace them by original hooks.
3 Transport and Storage
CAUTION!
Transport may only be done by qualified personnel. No liability for any damage resulting from improper
transport or improper storage.
3.1 Transport
The devices are checked and if so adequately packed before delivery.
Do not throw or drop the equipment.
Use adequate means of transport.
Transport and means of transport must be suitable for the local conditions.

5.52.208.00.01.06
7
3.2 Safety device for transport
NOTICE!
Should a safety device for transport exist, please remove it before commissioning.
3.3 Storage
Store the equipment at a clean and dry place.
Protect the equipment against dirt, humidity and damage by an appropriate cover.
Protect hooks, wire ropes, chains and brakes against corrosion.
4 Description
4.1 Areas of application
The devices must be as far as possible installed in a covered room.
If they are used in the open, protect the units against the effects of weather such as rain, hail, snow, direct
sunshine, dust, etc. - we recommend to use a cover in parking position. If the device is set up in a
continuously humid environment with strong temperature fluctuations, the correct functionings are
endangered by the forming of condensation.
Ambient temperature -20°C up to +50°C. Power-operated units -20 up to +40°C. Humidity 100 % or less but
not under water
DANGER!
It is not permitted to use the unit in an area at risk from explosion!
4.2 Design
The wirerope winches for stationary use are fitted with holes for installation.
The winch handle is detachable.
The winch can be installed in any position desired, make sure, however, the wire rope exit is correct.
For outside use we recommend to use a protective roof.
Versions:
Type 238/10
Standard
Type 238/10
with separating
partition and two rope
exits*
Type 238/10GV
galvanized version
Type r 238/10MV
Marine-version
*as option
4.3 Functions
The load is lifted/ lowered, by turning the winch handle. The incorporated load-pressure-brake prevents
automatic lowering of the load after release of the winch handle. Little after run of the load or turn of the
winch handle is due to the system and not a mistake.

8
5.52.208.00.01.06
4.4 Important components
Housing
238/10 - made in steel plate
238/10GV - made in steel plate - galvanized
238/10MV - made in steel plate - special coating
Rope drum
238/10 - made in steel
238/10GV - made in steel - galvanized
238/10MV - made in stainless steel
Brake
Gear spring pressure brake
Gear
Worm gear
As option for rope winches with capacity 2000kg - 5000kg
Drum clutch
For a correct pulling of unloaded rope
Drum brake
As sliding clutch for adjusting of braking torque for winches with drum clutch
5 Technical data
Capacity
FEM
group
wir-
erope
Ø
nec.
minimum
breaking
load
useable
wirerope length
number of
rope layers
wire rope
path per
crank turn
crank
effort
weight
without rope
approx.
1st layer
top layer
1st layer
top layer
kg
kg
mm
kN
m
m
mm
daN
kg
250
93
1 Cm
4
9
3
90
12
17
6
13
500
238
1 Cm
6
17
4
63
8
20
10
16
1000
530
1 Cm
8
34
5
65
7
13
13
29
1500
875
1 Dm
10
51
4
36
5
9
14
28
2000
1130
1 Cm
11
67
5
58
6
12 (6)
22 (12)
60
3000
1685
1 Cm
14
101
6
66
6
11 (6)
27 (14)
78
5000
3435
1 Cm
18
168
6
38
4
12 (4)
58 (17)
117
7500
3748
1 Cm
22
251
4
72
8
11(2)
78(15)
190
Winches with separating partition
Capacity
FEM
group
wir-
erope
Ø
2x
nec.
minimum
breaking
load
2x
useable
wire rope length
2x
number of
rope layers
2x
wire rope
path per
crank turn
crank
effort
weight
without rope
approx.
1st layer
top layer
1st layer
top layer
kg
kg
1 Cm
mm
kN
m
m
mm
daN
kg
2 x 125
2 x 45
1 Cm
3
4,5
2
80
16
17
6
13,5
2 x 250
2 x 110
1 Cm
4
9
3
76
13
20
10
16,5
2 x 500
2 x 265
1 Cm
6
17
3
55
9
13
13
27,5
2 x 750
2 x 400
1 Cm
8
34
2
32
7
9
14
28,5
2 x 1000
2 x 525
1 Cm
8
34
3
60
9
12 (6)
22 (12)
62
2 x 1500
2 x 785
1 Cm
10
51
4
70
9
11 (6)
27 (14)
80
2 x 2500
2 x 1540
1 Cm
12
79
4
50
7
12 (4)
58 (17)
119
() with crank changed in position
6 Installation
Please observe the following points in order to avoid any damage to equipment or injury of person:
Wear safety gloves.
Install the winch on a stable ground.
Make sure attachment surface is flat and that installation is made stress-free, - use shim parts if
necessary.

5.52.208.00.01.06
9
The winch must be set up and attached in such a way that it cannot change position neither by the load
nor by other influences.
6.1 Installation of the winch
The winches can be installed in any position desired, make sure, however, that the prescribed rope exit is
correct.
Make sure the attachment surface is flat/plain and that installation is made stress-free to ensure safe
functioning.
Use the screws mentioned in the table for installation. Tighten all screws evenly.
Distance of holes
Capacity
1st layer
holes of the
installation area
fastening screws
4x
A
B
strength
8.8
Tightening
moment
kg
mm
mm
Nm
250 (2x125)
192
100
M12
87
500 (2x250)
223
115
M12
87
1000 (2x500)
254
141
M12
87
1500 (2x750)
254
178
M12
87
2000 (2x1000)
360
196
M20
431
3000 (2x1500)
386
251
M20
431
5000 (2x2500)
386
316
M20
431
7500
455
350
M20
431
*MV 1500
165
210
M16
214
*MV 3000
446
251
M20
431
*MV 5000
456
316
M20
431
*MV = Marine-Version
6.2 Selection of wire ropes
Wire ropes acc. to EN 12385-4 - Lifting ropes
Stainless wire ropes and special wire ropes are available on request.
Diameter and nec. minimum breaking load must be acc. to the data mentioned in the table in chapter
"Technical Data" resp. acc. to the details mentioned on the type plate.
Recommendation of wire ropes
Steel-reinforced wire ropes
For larger pulling rope forces, fibre-core wire ropes can also be used.
For unguided loads, - non-twisting or at least twist-resistant wire ropes.
For several rope layers winded through the drum, - steel-reinforced wire ropes.
WARNING!
It is not allowed to use plastic wire ropes or plastic-coated wire ropes.
6.3 Wire rope fastening
There is a plate on the winch indicating the wind up direction.
Standard Separation partition 250-500kg Separation partition 1000-1500kg
Illustration 1
Illustration 2
Illustration 3
*For winches subject to approval by Germanischer Lloyd, at least 3 rope layers are prescribed to remain on the drum.

10
5.52.208.00.01.06
fasten the sharpened end of the wirerope acc.of suitable image.
make sure that screws and rope key are thighten fast.
Ropefastening for 5000kg at gearside, all others at the opposed limit disc
DANGER!
In case of incorrect winding direction, the load pressure brake is not working.
6.4 Winding up of wire rope
The wire rope must always be winded up tensioned. When the last wire rope layer is winded onto the drum,
the flanged wheel must exceed the top layer by at least 1 1/2 times of the wire rope diameter.
NOTICE!
According to validated regulations and accident prevention regulations, the wire rope length must be
chosen so that at least 2 rope layers remain on the drum when the wire rope is unwinded.
6.5 Wire rope deflection
Wire rope pulleys must be installed in a
position centrically to the rope drum.

In order to ensure correct winding up of the
wire rope on the drum, the max. wire rope
deflection angle must not be exceeded.
maximum wire rope deflection angle
4° for standard wire ropes
2° for non-twisting resp. twist-
resistant wire
ropes

The minimum dimension (M) from the drum
until the middle of the pulley must be adhered
to.
Illustration 4
6.6 Tools
Capacity
Size
Tool
Use
250 – 1500 kg
2000 – 7500 kg
SW19
SW30 Winch fastening
div. Rope installation
div. div.
div. div.
div. div.

5.52.208.00.01.06
11
7 Operation
Only people that are familiar with the operation of the lifting devices and cranes may be entrusted with their
operation. They must be authorized by the employer for the operation of the equipment. The employer must
ensure that the operating instructions are available near the equipment and that they are accessible for the
operating personnel.
Lifting and lowering by turning the hand crank.
Lifting load – turn clockwise.

Hold load – release hand crank. The load holds
automatically. Acc. The different types, the crank
can removed in each position or the crank grip
can fold back. 
Lowering load – turn anti clockwise.

Wirerope winch from 2000 kg capacity and up
By changing the crank to the other driving point, it is easier
to move larger loads.
7.1 Free-wheeling mechanism of the drum
For engaging or disengaging of the drum for controlled feeding-out of the uncharged wirerope.
Disengaging
Turn the drum approx. 40 mm in direction A.
Push the disengaging pin in direction C.
The wirerope can now be unwinded by hand
freely.
Illustration 5
Engaging
Push the disengaging pin in direction B.
Turn the rope drum until it stops.
The winch now is ready to lift again.
DANGER!
The following is not allowed:
Disengaging under load.
Manipulation of the disengaging device.
7.2 Brake as slipping clutch to disengage the drum
Adjustment of the slipping clutch
4 Loosen the safety screws (1)
Adjust the slipping clutch at the set ring (2)
direction A = brake pressure increases,
direction B = brake pressure decreases
4 Tighten the safety screws (1) again.
Illustration 6

12
5.52.208.00.01.06
8 Commissioning
8.1 General
Should the unit be used in Germany:
Please observe the validated, national accident prevention regulations.
For other countries:
Inspections as above. Please observe the national rules and regulations and the instructions in this manual!
NOTICE!
Hoists up to 1000 kg capacity and without motor-driven trolleys of hoisting unit must be tested by a “qualified
person” before putting into operation for the first time.
Hoists of 1000 kg capacity and up or with more than one motor-driven hoist movement; i.e. lifting and trolley
movement, must be tested by a “licensed qualified person” before putting in operation.
An exception is “hoists ready for operation” acc. validated national regulations with EU-declaration of
conformity.
Definition “qualified person” (former expert)
A “qualified person” has learned, due to occupational training and experience and the job that the person has
done, the skills needed to tests the material for one’s work.
Definition “licensed qualified person” (former approved expert)
A “licensed qualified person” has, due through special occupational training, knowledge about testing of the
material for one’s work and knows the national accident prevention regulations and other prescriptions and
technical regulations. This person must test the material for one’s work regularly with regard to design and
kind of use. The license will be given to qualified person be the approved supervision authorities (ZÜS).
8.2 Worm gear
In order to guarantee long product lifetime, we recommend to
operate the winch for some time long at the start.
Effect approx. five full drum rotations with approx. 50% of the
nominal load.
Remove the protection plate and distribute the fat with a paint
brush over the worm gear wheel and the shaft.
Make sure that no fat gets on the load pressure brake (A).
Install the protection plate again.
NOTICE!
To ensure correct functioning of the load pressure brake, the winch must be loaded with at least 5 % of the
nominal load.
8.3 Wire rope
Wire ropes must be free from corrosion, dirt or damage.
They must be lubricated before commissioning.
No lubrication shortens the lifetime of the wire rope and the maintenance intervals.
WARNING!
It is not allowed to use plastic wire ropes or plastic-coated wire ropes.

5.52.208.00.01.06
13
9 Safety check
Before putting into service initially or when putting back into service, it must be checked whether:
All fastening screws (if existent), socket pins, flap socket and safety devices are tightened and secured.
The wire ropes are winded up correctly, are lubricated and are in good condition.
10 Functional test
The functional test must be effected with the load capacity mentioned on the type plate.
Check the brake when lifting/lowering - it must hold the load safely.
Check the condition of the wire rope and the supporting structures.
Check screw connections.
11 Maintenance
11.1 General
All monitoring, servicing and maintenance operations are to ensure correct functioning of the equipment;
they must be effected with utmost care.
Only “qualified persons” may do this work.
Servicing and maintenance work must only be done when the hoist is not loaded.
Records must be kept of all test results and measures taken.
11.2 Monitoring
The monitoring and servicing intervals stated are valid for operation under normal conditions and single-shift
operation. In case of severe operating conditions (e.g. frequent operation with full load) or special
environmental conditions (e.g., heat, dust, etc.), the intervals must be shortened correspondingly
12 Inspection
12.1 Periodic checks
Independently from the regulations of the individual countries, lifting devices must be checked at least yearly
by a qualified person or licensed qualified person regarding its functional safety.
12.2 Wire rope
Adequate performance of the servicing and monitoring work acc. to the validated, national regulations
“Basics for cable drives – monitoring during use”.
A visual check must be effected before every new work shift.
Wear
Deformation
Fissures
Corrosion
Report any damage immediately to the responsible person and exchange damaged or worn wire ropes and
load tackles.

14
5.52.208.00.01.06
12.3 Inspection intervals
on commissioning
daily checks
1st service after 3
months
inspection,
service every 3
months
inspection,
service every 12
months
Inspection of the equipment by a qualified person (periodic
inspection)
X
Check screw connections
X
X
Check brake function
X
X
check brake air gap (only for electric devices) *)
X
check overload protection if existent
X
clean and lubricate the wire rope
X
X
X
check wire rope and wire rope end fastenings for damage
and wear
X
check the load tackle and load hook for cracks and
deformation
X
*) not for EX design
13 Service
13.1 Wire rope
Wire ropes have to be exchanged by new, original wire ropes if they show corrosion, fracture or if they are
worn.
Checks:
Fastening screws must be checked before commissioning and at least every 3 months, - tighten them if
necessary.
Kind and number of broken threads.
Position of the broken threads
Timing sequence of occurrence of breaks.
Reduction of the wire rope diameter.
Corrosion
Abrasion
Deformation
Heat influence
Operation time
Wire rope fastening
CAUTION!
The wire rope must be replaced immediately should even one strand be broken.
13.2 Gear
quarterly: lubricate the worm gear wheel and the worm gear shaft
Recommended lubricant: grease, FUCHS Renolit FEP 2, or similar
13.3 Gear spring pressure brake
During the check, brake lining wear is verified. The brake linings must be replaced when the wear limit is
already reached at one position of the lining, - as this can be the case when wear of the linings is irregular.
CAUTION!
The brake linings must be free from fracture. Avoid oil, grease, dirt and humidity on the brake linings as this
increases wear.
13.4 Lubricant - Selection
FUCHS SHELL ESSO MOBIL TOTAL CASTROL KLÜBER
Renolit FEP 2 Alvania EP 2 Unirex EP 2 Mobilux EP 2 MULTIS EP2 -- --
Stabylan 5006 -- -- -- -- Optimol Viscoleb 1500 Klüberoil 4UH 1-1500
-- -- -- -- -- -- Wolfracoat 99113
Chain lubricant OKS 451

5.52.208.00.01.06
15
13.5 Lubricant for food industry – Selection (as option*)
SHELL MOBIL CASTROL
KLÜBER
Gearing
FM Grease HD2 Mobilgrease FM 222
--
Klüberoil 4UH 1-1500 N
Load chain
-- Lubricant FM 100
Optimol Viscoleb 1500
--
Load hook;
Pulleys
Gear rim;
Drive pinion
FM Grease HD2 Mobilgrease FM 222
-- --
* must be mentioned by order
14 Trouble
Please pay attention to the following in case of problems:
Troubles with the equipment must only be repaired by qualified personnel.
Secure the unit against unintended operation start.
Put up a warning note indicating that the unit is not to be used.
Secure the working area of moving parts of the unit.
Please read the chapter "Safety instructions".
Notes on the repair of faults are found in the following table.
For the repair of failures please contact our service department.
CAUTION!
Trouble caused by wear or damage to parts such as wire ropes, chains, chain wheels, axes, bearings,
brake parts, etc., must be remedied by replacing the parts with original spare parts.
15 Remedy
Trouble
Cause
Remedy
It is difficult to turn the crank if unloaded not lubricated worm gear is dirty
wrong installation
lubricate the worm gear and the worm gear shaft,
clean and lubricate again
straighten supporting surfaces and install correctly, if
necessary
load is not lifted, resp. held
rope is not winded correctly - rope turning direction for
lifting is not correct
place the wire rope correctly
brake is worn or defective
check brake parts and replace parts that are worn
brake discs are humid or oiled
clean brake discs or replace them by new ones
load pressure brake does not open. brake mechanism or brake disc is stuck, possibly due to
seldom use
loosen the brake by slightly pushing the winch handle by
hand (in direction lowering)
replace the brake discs if necessary
16 Decommissioning
WARNING!
It is essential that the following points are observed in order to prevent damage to the equipment or critical
injury when the device is being decommissioned:
It is mandatory that all steps for decommissioning the machine are carried out in the indicated sequence:
First secure the working area for decommissioning, leaving plenty of space.
Read the chapter "Safety instructions".
Disassembly is carried out in reverse order to the assembly.
Please make sure that all operating material is disposed of in accordance with environmental regulations.
16.1 Temporary decommissioning
Measures are as above.
Also read the chapter “Transport and storage”.
16.2 Final decommissioning/disposal
Measures are as above.
After disassembly, ensure that the disposal of the equipment and any materials it contains is carried out
in accordance with environmental regulations.
