Quick guide

StartmeasuringandsenddataonlineandwirelesswithBluetooth.


SearchandconnecttothelatestconnectedBluetoothdevice.


SearchandconnecttoaNewBluetoothdevice.


Exitandreturn.

Startmeasuringandsavedatainlocalmemory.

Viewlocaldatarecord.

Cleardatathathasbeenstoredlocally.
Selectanddeleteselectedrecord.


Clearallrecords.MustbeconfirmedwithYESorNObeforeallrecordswillbedeleted.


Exitandreturn.

ProgramsettingsandSystemsettings.


Selectwhichtreespeciestoworkwith.


Programsettings.UseEnterkeytoenableordisablesettings


EnableMDIIanddisableMantaxDigitechmode.StoredatainXMLfile.


EnableMantaxDigitechanddisableMDIImode.
SimulatepreviousmodelMantaxDigitechdataformat.


Enablecrossmeasuringofdiameterandsavemeandiameter.
Icon appearsindisplayleftcornerwhenactive.


Displaycircumferenceinsteadofdiameter.
Iconappearsindisplayleftcornerwhenactive


Iftodisplaydecimal.


Gotocaliperglobalsystemsettings


SetSampletreegeneratorforsampletrees.Onlyforspecie1to4. Function(Kxd
2
/D
2
) 
K=(quote%)between0and99,d=Captureddiameter,D=Averagediameteroftreespecies.


Exitandreturn.

Poweroff/sleepmode.

SwitchtoUSBconnectionmode.

©HaglöfSwedenAB.Allrightsreserved QuickGuideMDII 2016‐09‐21
CHARGINGBATTERIESINMDIITERMINALANDSMARTSCALE.
Normalchargingtime:3‐4hours.ChargingtimeforMDIIterminalshortenswhenunitissetinUSBmode.
NOTE!CHARGEBOTHTHESMARTSCALEANDTHETERMINAL!
CHARGINGMDIITERMINAL
1. ConnecttheUSBcable(Mini‐B)[3]intheUSB
adapter[1]andtheadapteronthedata
terminal.
2. Connecttheotherend(TypeA)[4]toaUSB
portinyourPCortoaUSBcharger.
3. SetinUSBmodeforquickercharge.
CHARGINGSMARTSCALE
1. ConnecttheUSBcable(Mini‐B)[3]intheUSB
adapter[1]andtheadapterontheScale.
2. Connecttheotherend(TypeA)[4]toaUSBport
inyourPCortoaUSBcharger.
3. TheLED[2]indicatorisonwhenchargingthe
SmartScale.WhentheLED[2]blinksthisisan
indicationoflowbattery.Thisindicatorgoesout
whenthebatteryischarged.
4. Thedataterminalwarnsduringmeasuringwhen
powerislowinthescalebattery.

CONNECTTOPC
1. ConnecttheUSBcable[3](Mini‐B)ontheMDIIUSBadapter[1]andconnecttheotherend(TypeA)[4]toa
USBportonthePC.
2. ConnecttheMDIIUSBadapter[1]withtheUSBcableonthedataterminal.
3. GotoUSBmode.NavigatewiththearrowkeystoandpressEnter.USBmodeisnormallyautomatic
whencableconnects).

GenerateXMLdatafile
ThisimageisdisplayedwhentheoutputXMLfileiscreated.
ThetimetogeneratetheXMLfiledependsonamountofdata.

MDIIisinUSBmodebutnotconnected
InUSBmode,theXMLfileiscreatedandwaitingforconnectiontoPC.

MDIIisinUSBmodeandconnectedtoPC
TheMDIInowservesasanexternalmemorydriveandappearsinWindows
ExplorerwithMDIIiconandthedrive.
Example:
MDII(F:)
YourstandardfileExplorercanbeusedtocopy,moveordeletefilesonthe
MDIIdrive.ThedataXMLfileislocatedinthefolderMDII:\DATA\MDII\

1
3
4
1
2
