Haier AC160S2SK1FA Installation and operating instructions

CONVERTIBLE TYPE AIR CONDITIONER
OPERATION MANUAL AND INSTALLATION MANUAL
AC160S2SK1FA
Contents
Cautions ....................................................... 1
Move and scrap the air conditioning............ 5
Safety Precautions ....................................... 6
Features and Functions................................ 9
Parts and Functions.................................... 10
Maintenance............................................... 11
Troubleshooting.......................................... 12
Installation Procedure................................. 16
Test Run ..................................................... 25
yThis product must only be installed or serviced by qualied personnel.
Please read this manual carefully before installation. This appliance is lled with
R32. Keep this manual for future reference.
Original instructions
No. 0150544329

Português
Read the precautions in
this manual carefully before
operating the unit.
This appliance is lled with
R32.
Service indicator; Read
technical manual
Read the operator’s manual
Keep this manual where the user can easily nd it.
WARNING
yDo not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
yThe appliance must be stored in a room without continuously operating ignition sources (for example: open ames, an operating
gas appliance or an operating electric heater).
yDo not pierce or burn.
yBe aware that refrigerants may not contain an odour.
yIf the supply cord is damaged, it must be replaced by the manufacturer,its service agent or similarly qualied persons in order to
avoid a hazard.
yThis appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given superivision or instruction concering use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
yThe wiring method should be in line with the local wiring standard.
yAll the cables shall have got the European authentication certicate. During installation, when the connecting cables break off,
it must be assured that the grouding wire is the last one to be broken off. The explosion-proof breaker of the air conditioner
should be all-pole switch. Distance between its two contacts should not be no less than 3mm. Such means for disconnection
must be incorporated in the wiring.
yMake sure installation is done according to local wiring regulation by professional persons. Make sure ground connection is
correct and reliable.
yA leakage explosion-proof breaker must be installed.
yDo not use a refrigerant other than the one indicated on the outdoor unit(R32) when installing, moving or repairing. Using other
refrigerants may cause trouble or damage to the unit, and personal injury.
yThe installation and service of this product shall be carried out by professional personnel, who have been trainedand certied
by national training organizations that areaccredited to teach the relevant national competency standards that may be set in
legislation.
yMechanical connectors used indoors shall comply with ISO 14903. When mechanicalconnectors are reused indoors, sealing
parts shall be renewed. When ared joints arereused indoors, the are part shall be re-fabricated.
yThis appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use
by lay persons.
yDisconnect the appliance from its power source during service and when replacing parts

WARNING
yA brazed, welded, or mechanical connection shall be made before opening the valves to permit refrigerant to ow between
the refrigerating system parts. A vacuum valve shall be provided to evacuate the interconnecting pipe and/or any uncharged
refrigerating system part.
yThe maximum working pressure is 4.3 MPa.
yThis maximum working pressure shall be considered when connecting the outdoor unit to indoor unit.
yThe refrigerant suitable for the indoor unit is R32 or R410A. The indoor unit shall only be connected to outdoor unit suitable for
the same refrigerant.
yThe unit is a partial unit air conditioner, complying with partial unit requirements of the International Standard, and must only be
connected to other units that have been conrmed as complying to corresponding partial unit requirements of the International
Standard.
yThe A-weighted sound pressure level is below 70 dB.
yThe maximum refrigerant charge amount (kg), and the minimum oor area (m2) of the room in which the indoor unit will be
installed, are specied in the table on the page 11.
yPipe-work shall be protected from physical damage and, in the case of ammable refrigerants, shall not be installed in an
unventilated space, if the space is smaller than that specied in the table on the page 10
yThe installation of pipe-work shall be kept to a minimum.
yCompliance with national gas regulations shall be observed.
yMechanical connections shall be accessible for maintenance purposes.
yHandling, installation, cleaning, servicing and disposal of refrigerant shall be carried out as per the specications on the
following pages strictly.
yWarning: Keep any required ventilation openings clear of obstruction.
yNotice: Servicing shall be performed only as recommended by this manual instruction.

Português
CE
All the products are in conformity with the following
European provision:
- Low voltage Directive
- Electomagnetic CompatibilitY
ROHS
The products are fullled with the requirements in the directive
2011/65/EU of the European parliament and of council on the
Restriction of the use of Certain Hazardous Substances in
Electrical and Electronic Equipment(EU RoHS Directive)
WEEE
In accordance with the directive 2012/19/EU of the European
parliament,herewith we inform the consumer about the dis-
posal requirements of the electrical and electronic products.
DISPOSAL REQUIREMENTS:
Your air conditioning product is marked with this symbol.This
means that electrical and electronic products shall not be
mixed with unsorted household waste.Do not try to dismantle
the system yourself: the dismantling of the air
conditioning system,treatment of the refrigerant,of
oil and of other part must be done by a qualied
installer in accordance with relevant local and
national legislation.Air conditioners must be
treated at a specialized treatment facility for reuse,
recycling and recovery. By ensuring this product is disposed
of correctly, you will help to prevent potential negative cons-
equences for the environment and humen health. Please
contact the installer or local authority for more information.
Battery must be removed from the remote controller and dis-
posed of separately in accordance with relevant local and
nationl legislation.
A
B
C
D
kg
kg
kg
R32/R410A
This product contains uorinated greenhouse gases covered
by the Kyoto Protocol.Do not vent into the atmosphere.
Refrigerant type: R32 GWP:675
Refrigerant type: R410A GWP: 2088
GWP=global warming potential
Please ll in with indelible ink,
*1 the factory refrigerant charge of the product
*2 the additional refrigerant amount charged in the eld and
* 1+2 the total refrigerant charge
on the refrigerant charge label supplied with the product. The
lled out label muset be adhered in the proximity of the product
charging port(e.g. onto the inside of the stop value cover).
A contains uorinated greenhouse gases covered by the Kyoto
Protocol
B fatory refrigerant charge of the product: see unit name plate
C additional refrigerant amount charged in the eld
D total refrigerant charge
E outdoor unit
F refrigerant cylinder and manifold for charging
Haier Industrial Park, No.1 Haier road, Qingdao,P.R.China
EUROPEAN REGULATIONS
CONFORMITY FOR THE MODELS
IMPORTANT INFORMATION REGA-
RDING THE REFRIGERANT USED
Contains uorinated greenhouse gases
covered by the Kyoto Protocol
WARNING
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to
avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
The appliances are not intended to be operated by means of an external timer or separate remote-control system.
Keep the appliance and its cord out of reach of children less than 8 years.

1
Cautions
Disposal of the old air conditioner
Before disposing an old air conditioner that goes out of use, please make sure it’s inoperative and safe. Unplug the air conditioner
in order to avoid the risk of child entrapment.
It must be noticed that air conditioner system contains refrigerants, which require specialized waste disposal. The valuable
materials contained in a air conditioner can be recycled. Contact your local waste disposal center for proper disposal of an old air
conditioner and contact your local authority or your dealer if you have any question. Please ensure that the pipework of your air
conditioner does not get damaged prior to being picked up by the relevant waste disposal center, and contribute to environmental
awareness by insisting on an appropriate, anti-pollution method of disposal.
Disposal of the packaging of your new air conditioner
All the packaging materials employed in the package of your new air conditioner may be disposed without any danger to the
environment.
The cardboard box may be broken or cut into smaller pieces and given to a waste paper disposal service. The wrapping bag made
of polyethylene and the polyethylene foam pads contain no uorochloric hydrocarbon.
All these valuable materials may be taken to a waste collecting center and used again after adequate recycling.
Consult your local authorities for the name and address of the waste materials collecting centers and waste paper disposal services
nearest to your house.
Safety Instructions and Warnings
Before starting the air conditioner, read the information given in the User’s Guide carefully. The User’s Guide contains very
important observations relating to the assembly, operation and maintenance of the air conditioner.
The manufacturer does not accept responsibility for any damages that may arise due to non-observation of the following instruction.
yDamaged air conditioners are not to be put into operation. In case of doubt, consult your supplier.
yUse of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User’s Guide.
Installation shall be done by professional people. Don’t install unit by yourself.
yFor the purpose of safety, the air conditioner must be properly grounded in accordance with specications.
yAlways remember to unplug the air conditioner before opening inlet grill. Always grip plug rmly and pull straight out from the
outlet.
yAll electrical repairs must be carried out by qualied electricians. Inadequate repairs may result in a major source of danger for
the user of the air conditoiner.
yDo not damage any parts of the air conditioner that carry refrigerant by piercing or perforating the air conditioner’s tubes with
sharp or pointed items, crushing or twisting any tubes, or scraping the coatings off the surfaces. If the refrigerant spurts out and
gets into eyes, it may result in serious eye injuries.
yDo not obstruct or cover the ventilation grille of the air conditioner. Do not put ngers or any other things into the inlet/outlet and
swing louver.
yDo not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit.
yWhen the indoor unit is turned on, the PCB will test if swing motor is O.K., and then fan motor will start up.So there is a few
seconds to wait.
yIn cooling mode,the aps will swing automatically to a xed position for anti-condensating.
yThis appliance is not intended for use by persons (including children) with reducedphysical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
yChildren should be supervised to ensure that they do not play with the appliance.

2
Português
Cautions
- The installation of pipe-work shall be kept to a minimum.
- Pipe-work shall be protected from physical damage and shall not be installed in an unventilated space, if that space is smaller
than Amin(2m2).
- Compliance with national gas regulations shall be observed.
- Mechanical connections shall be accessible for maintenance purposes.
- The minimum oor area of the room: 2 m2.
- The maximum refrigerant charge amount: 1.7 kg.
- Information for handling, installation, cleaning, servicing and disposal of refrigerant.
- Warning: Keep any required ventilation openings clear of obstruction.
- Notice: Servicing shall be performed only as recommended by the manufacturer.
Unventilated areas
- Warning: The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as
specied.
- Warning: The appliance shall be stored in a room without continuously operating open ames (e.g. an operating gas
appliance) and ignition sources (e.g. an operating electric heater).
Qualication of workers
- Specic information about the required qualication of the working personnel for maintenance, service and repair
operations.
- Warning: Every working procedure that affects safety means shall only be carried out by competent persons. Examples
for such working procedures are:
- breaking into the refrigerating circuit.
- opening of sealed components
- opening of ventilated enclosures.
Information on servicing
- Prior to beginning work on systems, safety checks are necessary to ensure that the risk of ignition is minimized.
- Work shall be undertaken under a controlled procedure so as to minimized the risk of ammable gas or vapor being
present while the work is being performed.
- Work in conned spaces shall be avoided. The area around the workspace shall be sectioned off. Ensure that the conditions
within the area have been made safe by control of ammable material.
Checking for presence of refrigerant
- The area shall be checked with an appropriate refrigerant detector prior to and during work. The leak detection equipment
should be suitable for use with all applicable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.
Presence of re extinguisher
- If any hot work is to be conducted, appropriate re extinguishing equipment shall be available to hand. Have a dry powder or
CO2 re extinguisher adjacent to the charging area.
No ignition sources
- All possible ignition sources, including cigarette smoking, should be kept sufciently far away from the site of installation,
repairing, removing and disposal. Prior to work taking place, the area around the equipment is to be surveyed to make sure that
there are no ammable hazards or ignition risks. “No Smoking” signs shall be displayed.
Ventilated area
- Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot
work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse
any released refrigerant and preferably expel it externally into the atmosphere.
Checks to the refrigeration equipment
- Where electrical components are being changed, they shall be t for the purpose and to the correct specication. At all times
the manufacturer’s maintenance and service guidelines shall be followed. If in doubt, consult the manufacturer’s technical
department for assistance.
The following checks shall be applied to installations
- The charge size is in accordance with the room size within which the refrigerant containing parts are installed;
- The ventilation machinery and outlets are operating adequately and are not obstructed;
- If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant;
- Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected;
- Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which
may corrode refrigerant containing components, unless the components are constructed of materials which are inherently
resistant to being corroded or are suitably protected against being so corroded.

3
Cautions
Checks to electrical devices
- Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a
fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt
with. If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall
be used. This shall be reported to the owner of the equipment so all parties are advised.
- Initial safety checks shall include:
• that capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking;
• that no live electrical components and wiring are exposed while charging, recovering or purging the system;
• that there is continuity of earth bonding.
Repairs to sealed components
- During repairs to sealed components, all electrical supplies shall be disconnected prior to any removal of sealed covers, etc. If
it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak
detection shall be located at the most critical point to warn of a potentially hazardous situation.
- Ensure that by working on electrical components, the casing is not altered in such a way that the level of protection is affected,
including damage to cables, excessive number of connections, terminals not made to original specication, damage to seals,
incorrect tting of glands, etc.
- Ensure that the apparatus is mounted securely.
- Ensure that seals or sealing materials have not degraded to the point that they no longer serve the purpose of preventing the
ingress of ammable atmospheres. Replacement parts shall be in accordance with the manufacturer’s specications.
Repair to intrinsically safe components
- Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the
permissible voltage and current permitted for the equipment in use.
- Intrinsically safe components are the only types that can be worked on while live in the presence of a ammable atmosphere.
- Replace components only with parts specied by the manufacturer. Other parts may result in the ignition of refrigerant in the
atmosphere from a leak.
Cabling
- Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse
environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as
compressors or fans.
Detection of ammable refrigerants Removal and evacuation
- The refrigerant charge shall be recovered into the correct recovery cylinders and the system shall be “ushed” with OFN to
render the unit safe. This process may need to be repeated several times.
- Compressed air or oxygen shall not be used for purging refrigerant systems.
- Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to ll until the working pressure is
achieved, then venting to atmosphere, and nally pulling down to a vacuum. This process shall be repeated until no refrigerant
is within the system. When the nal OFN charge is used, the system shall be vented down to atmospheric pressure to enable
work to take place.
- The vacuum pump is not close to any ignition sources and that ventilation is available.
Charging procedures
- Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as
short as possible to minimise the amount of refrigerant contained in them.
- Cylinders shall be kept upright.
- Ensure that the refrigeration system is earthed prior to charging the system with refrigerant.
- Label the system when charging is complete (if not already).
- Extreme care shall be taken not to overll the refrigeration system.
- Prior to recharging the system, it shall be pressure-tested with the appropriate purging gas. The system shall be leak- tested on
completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site.
Decommissioning
- Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail.
- Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re- use of
reclaimed refrigerant.
- Electrical power must be available before the task is commenced.

4
Português
Cautions
- Become familiar with the equipment and its operation.
- Isolate system electrically.
- Before attempting the procedure, ensure that:
• mechanical handling equipment is available, if required, for handling refrigerant cylinders;
• all personal protective equipment is available and being used correctly;
• the recovery process is supervised at all times by a competent person;
• recovery equipment and cylinders conform to the appropriate standards.
- Pump down refrigerant system, if possible.
- If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the system.
- Make sure that cylinder is situated on the scales before recovery takes place.
- Start the recovery machine and operate in accordance with manufacturer’s instructions.
- Do not overll cylinders. (No more than 80 % volume liquid charge).
- Do not exceed the maximum working pressure of the cylinder, even temporarily.
- When the cylinders have been lled correctly and the process completed, make sure that the cylinders and the equipment
are removed from site promptly and all isolation valves on the equipment are closed off.
- Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked.
Labelling
- Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and
signed.
- Ensure that there are labels on the equipment stating the equipment contains ammable refrigerant.
Recovery
- When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed.
- Ensure that the correct number of cylinders for holding the total system charge are available. All cylinders to be used are
designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant).
- Cylinders shall be complete with pressure-relief valve and associated shut-off valves in good working order. Empty recovery
cylinders are evacuated and, if possible, cooled before recovery occurs.
- The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and
shall be suitable for the recovery of all appropriate refrigerants.
- A set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak- free
disconnect couplings and in good condition. Before using the recovery machine, check that it is in satisfactory working order,
has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a
refrigerant release.
- The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder, and the relevant waste
transfer note arranged.
- Do not mix refrigerants in recovery units and especially not in cylinders.
- If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make
certain that ammable refrigerant does not remain within the lubricant.
- The evacuation process shall be carried out prior to returning the compressor to the suppliers.
- Only electric heating to the compressor body shall be employed to accelerate this process.

5
Cautions
Specications
yThe refrigerating circuit is leak-proof.
yFor all the models in this manual, the all-pole discon-nexion connection method should be applied in the power supply. Such
means for disconnection must be incorporation in the xed wiring.
Temperature and Humidity Range
Cooling
Indoor temperature max. DB/WB
min. DB/WB
32/23 °C
18/14 °C
Outdoor temperature max. DB/WB
min. DB/WB
46/26 °C
10/6 °C
Heating
Indoor temperature max. DB/WB
min. DB/WB
27 °C
15 °C
Outdoor temperature max. DB/WB
min. DB/WB
24/18 °C
-15 °C
yIf the air conditioner is used under higher temperature condition than those listed, the built-in protection circuit may operate to
prevent internal circuit damage. Also, during Cooling and Dry modes, if the unit is used under conditions of lower temperature
than those listed above, the heat-exchanger may freeze, leading to water leakage and other damage.
yDo not use this unit for purposes other than cooling, heating, dehumidifying and ventilation of rooms in ordinary dwellings. The
wiring method should be in line with the local wiring standand.
yThe waste battery should be disposed properly.
yIf the fuse on PC board is broken, please change it with the type T 3.15A/250VAC.
Move and scrap the air conditioning
yWhen moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support.
yIn the composition material of air conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls
and polybrominated diphenyl ethers are not more than 0.1%(mass fraction) and cadmium is not more than 0.01% (mass
fraction).
yPlease recycle the refrigerant before scrapping, moving, setting and repairing the air conditioning; for the air conditioning
scrapping, should be dealt with by the qualied enterprises.

6
Português
Safety Precautions
yBefore starting to use the system, read carefully this “SAFETY PRECAUTIONS” to ensure a proper operation of the system.
ySafety precautions described here are classied to “ WARNING” and “ CAUTION”. Precautions which are shown in the
column of “ WANING” means that an improper handing could lead to a grave result like a death, serious injury, etc. However,
even if precautions are shown in the column of “ CAUTION”, a very serious problem could occur depending on situation.
Make sure to observe these safety precautions faithfully because they are very important information to ensure the safety.
ySymbols which appear frequently in the text have following meanings.
Strictly prohibited. Observe instructions faithfully. Provide a positive grounding.
When you have read through the manual, keep it always at hand for read consultation. If the operator is replaced, make sure to
hand over this manual to the new operator.
CAUTIONS FOR INSTALLATION
WARNING
The system should be applied to places
as ofce, restaurant, residence and the
like.
Application to inferior environment such
as an engineering shop, could cause
equipment malfunction and serious injury
or death.
The system should be installed by your
dealer or a professional installer.
Installation by yourself is not encouraged
because it could cause such problems
as water leakage, electrical shock or re
accident by some improper handing.
When you need some optional devices such
as a humidier, electric heater, etc., be sure
to use the products which are recommended
by us. These devices should be attached by
a professional installer.
Installation by yourself is not encouraged
because it could cause such problems
as water leakage, electrical shock or re
accident by some improper handing.
WARNING
Do not install nearby the place where may
have leakage of ammable gas.
If the gas leakes and gathers around, it
may cause the re.
Depending on the place of installation, a
circuit breaker may be necessary.
Unless the circuit breaker is installed, it
could cause elecrical shocks.
Drain pipe should be arranged to provide a
positive draining.
If the pipe is arranged improperly, furniture or
the likes may be damaged by leaked water.
Where strong winds may prevail, the
system should be xed securely to
prevent a collapse.
Bodily injury could result by a collapse.
Install on the place where can endure
the weight of air conditioner.
Bodily injury could result by a careless
installation.
Make sure the system is grounded.
Grounding cable should never be connected
to a gas pipe, city water pipe, lightning
conductor rod or grounding cable of
telephone. If the grounding cable is not set
properly, it could cause electric shocks.
yInstallation Precautions
WARNING!
 
The area of the room in which R32 refrigerant air conditioner is installed cannot be less than the minimum area specied in the
table below, to avoid potential safety problems due to out-of-limit of refrigerant concentration inside the room caused by leakage
of refrigerant from refrigeration system of the indoor unit.
 
Once the horn mouth of connecting lines is fastened, it may not be used again (the air tightness may be affected).
 
A whole connector wire shall be used for indoor/outdoor unit as required in the operation specication of installation process
and operation instructions.
Minimum Room Area
Type LFL
kg/m3
hv
m
Total Mass Charged/kg
Minimum Room Area/m2
R32 0.306
1.224 1.836 2.448 3.672 4.896 6.12 7.956
0.6 29 51 116 206 321 543
1.0 10 19 42 74 116 196
1.8 3 6 13 23 36 60
2.2 2 4 9 15 24 40

12
Safety Precautions
CAUTIONS FOR TRANSFER OR REPAIR
WARNING
Modication of the system is strictly prohibited. When the system needs a
repair, consult your dealer.
Improper practice of repair could cause water leakage, electric shock or
re.
When the air conditioner is relocated, contact your dealer or a
professional installer.
Improper practice of installation could cause water leakage, electric
shock or re.
CAUTIONS FOR OPERATION
WARNING
You should refrain from exposing your body
directly to cool wind for a long time.
It could affect your physical condition or cause
some health problems.
Do not poke the air inlet or outlet with a bar, etc.
Since the internal fan is operating with a high
speed, it could cause an injury.
When any abnormal condition (scorching
smell or others) is found, stop the operation
immediately and turn off the power switch.
Then consult your dealer.
If you continue the operation without
removing the cause, it could result in a
trouble, electric shock or re.
CAUTION
The system should never be used for any other
purposes than intended such as for preservation
of food, ora and fauna, precision devices or work
It could cause deterioration of food or other
problems.
Do not handle switches with a wet hand.
It could cause electric shocks.
Combustion apparatus should not be placed
allowing a direct exposure to wind of air
conditioner.
Incomplete combustion could occur on the
apparatus.
Do not wash the air conditioner with water.
It could cause electric shocks.
Do not install the system where the air outlet
reaches directly the ora and fauna.
It will not be good for their health.
Make sure to use a fuse of proper electric
rating.
Use of steel or copper wire in place of a fuse
is strictly prohibited because it could result in
a trouble or re accident.
Neither stand on the air conditioner nor place
something on it.
There are risks of falling or injury by collapsed
object.
It is strictly prohibited to place a container of
combustible gas or liquid near the air conditioner
or to spray it directly with the gas or liquid.
It could cause a re accident.
Do not operate the system while the air
outlet grill is removed.
There is a risk of injury.
Do not use the power switch to turn on or off the
system.
It could cause a re or water leakage.
Do not touch the air outlet section while the swing
louver is operating.
There is a risk of injury.
Do not use such equipment as a water
heater, etc around the indoor unit or the wire
controller.
If the system is operated at the vicinity of
such equipment which generates steam,
condensed water may drip during cooling
operation or it could cause a fault current or
short-circuit.
When operating the system simultaneously with
a combustion apparatus, indoor air must be
ventilated frequently.
Insufcient ventilation could cause an oxygen
deciency accident.
Check occasionally the support structure of the
unit for any damage after a use of long period of
time.
If the structure is not repaired immediately, the unit
could topple down to cause a personal injury.
When cleaning the system, stop the
operation and turn off the power switch.
Cleaning should never be done while the
internal fans are running with high speed.
Do not put water containers on the unit such as a ower vase, etc.
If the water enters into the unit and damages the electric insulation material, it may cause electric shock.
7

8
Português
Safety Precautions
WARNING
yThe breaker of the air conditioner should be all-pole switch, and the distance between its two contacts should be no less 3 mm.
Such means for disconnection must be incorporation in the xed wiring.
yUse copper wire only. All the cables shall have got the European authentication certicate.
yThe power supply connects from the outdoor side. The connecting cable and the power cable are self-provided.
yThe parameter of connecting cable: H05RN-F 4G 0.75mm2.
DANGER
yDo not attempt to install this air conditioner by yourself.
yThis unit contains no user-serviceable parts. Always consult authorized service personnel for repairs.
yWhen moving, consult authorized service personnel for disconnection and installation of the unit.
yDo not become excessively chilled by staying for lengthy periods in the direct cooling airow.
yDo not insert ngers or objects into the outlet port or intake grills.
yDo not start and stop air conditioner operation by connecting and disconnecting the power supply cord and so on.
yTake care not to damage the power supply cord. If the supply cord is damaged, it must be replaced by the manufacturer or
authoried service agent in order to avoid a hazard.
yIn the event of a malfunction (burning smell, etc.), stop operation immediately, turn off the circuit breaker, and consult authorized
service personnel.
WARNING
yProvide occasional ventilation during use.
yDo not direct air ow at re places or heating apparatuses.
yDo not place objects on the air conditioner or climb onto it.
yDo not hang objects from the indoor unit.
yDo not set ower vases or water containers on top of the air conditioner.
yDo not expose the air conditioner directly to water.
yDo not operate the air conditioner with wet hands.
yDo not pull power supply cord.
yTurn off power source when not using the unit for extended periods.
yCheck the condition of the installation stand for damage.
yDo not place animals or plants in the direct path of the air ow.
yDo not drink the water drained from the air conditioner.
yDo not use in applications involving the storage of foods, plants or animals, precision equipment or art works.
yDo not apply any heavy pressure to radiator ns.
yOperate only with air lters installed.
yDo not block or cover the intake grill and outlet port.
yEnsure that any electronic equipment is at least one metre away from either the indoor or outdoor unit.
yAvoid installing the air conditioner near a replace or other heating apparatuses.
yWhen installing the indoor and outdoor unit, take precautions to prevent access to infants.
yDo not use inammable gases near the air conditioner.

9
Features and Functions
AUTOMATIC OPERATION
yCOOLING TYPE
Merely press the ON/OFF button, and the unit will begin automatic operation in the Cooling or dry modes as appropriate, in
accordance with the thermostat setting and the actual temperature of the room.
yHEAT & COOL TYPE
Merely press the ON/OFF button, and the unit will begin automatic operation in any of the Heating, Cooling and Blow modes as
appropriate, in accordance with the thermostat setting and the actual temperature of the room.
SLEEP
yCOOLING TYPE
When the SLEEP button is pressed during Cooling or Dry mode, the thermostat setting gradually rises during the period of
operation. When the set time is reached, the unit automatically turns off.
yHEAT & COOL TYPE
When the SLEEP button is pressed during Heating mode, the air conditioner’s thermostat setting gradually lowers during the
period of operation; When the set time is reached, the unit automatically turns off.
WIRELESS REMOTE CONTROL UNIT
yThe WIRELESS REMOTE CONTROL UNIT allows convenient control of air conditioner operation.For this type unit, the wireless
remote controllor type is YR-H50.
MILDEW-RESISTANT FILTER
yThe AIR FILTER has been treated to resist mildew growth, thus allowing cleaner use and easier care.

10
Português
Parts and Functions
Indoor Unit
Operating Control Panel 1
(1) Operation Control Panel
(2) Cover Plate
(3) Front Panel
(4) Inlet Grill(Filter inside)
(5) Human Sensor
(6) RUNNING Indicator Lamp
(7) TIMER Indicator Lamp
(8) POWER Indicator Lamp
(9) Emergency Switch
(10) Remote Receiver
Operating Control Panel 2
(1) Operation Control Panel
(2) Cover Plate
(3) Front Panel
(4) Inlet Grill(Filter inside)
(5) Human Sensor
(6) WIFI Indicator Lamp
(7) Display Indicator Lamp
(8) Emergency Switch
(9) Remote Receiver
Operating Control Panel 1
Operating Control Panel 2
Note:
For the wired control type unit, the unit state should be checked by the wired controller, instead of the remote receiver.
And if you set the TIMER function, the TIMER LED on the remote receiver will not be on.
2. The different PANEL for different models.

11
Parts and Functions
“HOT KEEP” function
“HOT KEEP” is operated in the following cases.
yWhen heating is started:
In order to prevent blowing out of cool wind, the indoor unit fan stopped according to the room temperature which heating
operation is started. Wait for approx. 2 to 3 minute, and the operation will be automatically changed to the ordinary heating
mode.
yDefrosting operation (in the heating mode):
When it is liable to frost, the heating operation is stopped automatically for 5 to 12 minutes once per approx. one hour, and
defrosting is operated. After defrosting is completed, operation mode is automatically changed to ordinary heating operation.
yWhen the room thermostat is actuated:
When room temperature increases and room temperature controller actuates, the fan speed is automatically changed to stop
under low temperature condition of indoor heat exchanger. When room temperature decreases, air conditioner automatically
changes over to ordinary heating operation.
Warming operation
yHeat pump type warming
With the heat pump type warming, the mechanism of heat pump that concentrate heat of outdoor air with the help of refrigerant
to warm the indoor space, is utilized.
yDefrosting operation
When a room is warmed with a heat pump type air conditioner, frost accumulates on the heat exchanger of outdoor unit along
with the drop of indoor temperature. Since the accumulated frost reduces the effect of warming, it is necessery to automatically
switch the operation to the defrosting mode. During the defrosting operation, heating operation is interrupted.
yAtmospheric temperature and warming capacity
Warming capacity of heat pump type air conditioner decreases along with the drop of outdoor temperature. When the warming
capacity is not sufcient, it is recommended to use another heating implement.
yPeriod of warm-up
Since the heat pump type air conditioner employs a method to circulate warm winds to warm the
entire space of a room, it takes time before the room temperature rises.
It is recommendable to start the operation a little earlier in a very cold morning.
Maintenance
Clean the air lter
1. Pull the lters upward to remove them from the Intake Grill.
2. Clean the air lter: Remove the dust from the lters by vacuum cleaner or washing them.
After washing, allow the air lters to dry thoroughly in an area protected from sunlight.
3. Re-attach the air lters to the Intake Grill. Press the two buttons on the lters until you hear
a sound of click.
Maintenace of indoor units
yWhen used for extended periods, the unit may accumulate dirt inside, which reduces its performance. We recommend that
the unit is inspected regularly, in addition to your own cleaning and care. For more information, consult authorized service
personnel.
yWhen cleaning the unit’s body, do not use water hotter than 40°C, harsh abrasive cleansers, or volatile agents like benzene or
thinner.
yDo not expose the unit body to liquid insecticides or hairsprays.
yWhen shutting down the unit for one month or more, rst allow the Fan mode to operate continuously for about half a day to
allow internal parts to dry thoroughly.

12
Português
Troubleshooting
Followings are not problems
Sound of water owing is not a problem. During unit operation or at stop, a swishing or gurgling noise may be heard. This
noise is generated by refrigerant owing in the system.
Sound of cracking is heard. During unit operation, a cracking noise may be heard.
This noise is generated by the casing expanding or shrinking because of temperature
changes.
Smell are generated. This is because the system circulates smells from the interior air such as the smell of
cigarettes or the painting on the furniture.
During operation, white fog or steam
comes out from the indoor unit.
When unit is running at places like restaurant, etc. where dense edible oil fumes
always exist, this will happen.
In cooling operation, unit switches to
blowing operation.
To prevent frost from accumulating on indoor heat exchanger, unit will switch to
blowing operation for a while then resume cooling operation.
Unit will not restart after stop.
Won’t start?
Though ON/OFF button is set to ON, the unit won’t resume cooling, dry or heating
operation in 3 min after it is stopped, this is because of 3-min-delay protection circuit.
Please wait 3 minutes
No outlet air or fan speed can’t be
changed in dry mode.
Unit will reduce fan speed repeatedly and automatically if room temp. is too low in dry
operation.
In heating operation, water or steam r are
blown out of outdoor unit.
This occurs when frost accumulated on the outdoor unit is removed.
(during defrosting operation)
In heating operation, indoorfan won’t stop
even if unit is stopped.
After unit stop, indoor fan will go on running until indoor unit cools down.

13
Troubleshooting
Before ask for services, please rst check your unit against the following.
Air conditioner won’t start.
Is power supply switch turned on?
Power supply switch is not set at ON.
Is city power supply normal? Is leakage current breaker activated?
This is very dangerous, please disconnect
power supply immediately and contact
your dealer.
Poor cooling or heating
Are operation control adjusted correctly as
specied?
Is air lter too dirty? Are there any obstacles in inlet or outlet
grill?
Are horizontal louvers at up position (in
heating mode)?
Any doors or windows left open?
Poor cooling
Is there any direct sunlight in the room? If there are unexpected heat sources in the
room?
Too many people in the room?
Cold air blows out (in heating mode). Is air conditioner in standby condition in heating mode?
If your unit still can’t work properly after above mentioned checks, or following problems occur, please stop it immediately and
contact your dealer.
yFuses or circuit breakers often blow out.
y’Water comes out in cooling/dry operation.
yOperation is abnormal orsound is heard.
Power
failure?

14
Português
Troubleshooting
When failure happens,the fan of indoor unit stop running.The method of check failure code as follow.
For outdoor failure,the failure code is outdoor failure LED ash times + 20.
For example,the failure code of outdoor unit is 2. the wired controller of indoor unit will display 16(using hexadecimal method).
Ta: ambient temperature sensor
Tm: coil temoerature sensor
OUTDOOR UNIT TROUBLE SHOOTING
Error
code Malfunction Description Diagnosis and Analysis. Remark
1 EEPROM malfunction EEPROM chip damaged or data wrong or related circuit
damaged.
Non-resumable
2PIM (power intelligent module)
hardware over current
Input over current occured been detected by PIM’s hardware. Resumable
3 Compressor over current during
deceleration
Over current occured during compressor deceleration period. Non-resumable
4 Communication abnormal
between control board and
compressor driver module
Control board can not communicating with compressor driver
module over 4 minutes
Resumable
5 Compressor overcurrent detected by
control board
Compressor over current been detected by control board Non-resumable
6 DC voltage or AC voltage high AC power supply of the driver module get voltage over 280VAC
or driver module get high DC-BUS voltage over 390VDC.
Resumable
7 Compressor current sampling circuit
fault
The driver module’s Compressor current sampling circuit
damaged.
Non-resumable
8 Discharge temperature too high
protection
Compressor discharge temperature over 115°C, error clear
within 3 minutes if temperature goes down and lower than
115°C. Error status lock if it occurs 3 times
in 1 hour.
Non-resumable
9 DC fan motor fault DC fan motor damage or not connected or related circuit broken.
Error status conrm and lock if occurs 3
times within 30 minutes.
Non-resumable
10 Outdoor defrosting temp, sensor Te
abnormal
Sensor temperature been detected below -55°C or higher than
9Q°C or been detected as short circuit or open circuit..
Resumable
11 Suction temp,sensor Ts abnormal
12 Outdoor ambient temp, sensor Ta
abnormal
Sensor temperature been detected below -40°C or higher than
90°C or been detected short circuit or open circuit.
Resumable
13 Discharging temp, sensor Td
abnormal
Sensor temperature been detected below -40°C or higher than
150°C or been detected short circuit or open circuit.
Resumable
14 PFC circuit loop high voltage Overvoltage been detected in driver module’s power factor
correction circuit loop.
Resumable
15 Communication abnormal
between indoor unit and outdoor
unit
Outdoor unit control board can not communicating with intdoor
unit control board over 4 minutes.
Resumable
16 Lack of refrigerant or discharging pipe
blocked
Discharge & suction temperatureTd-Ts ≥ 80°C after compressor
started 10 minutes.Error status lock if it occurs 3 times in 1 hour.
Non-resumable
17 4-way vavle converse abnormal Indoor pipe & indoor ambient temperature
Tm-Tai ≥ 5°C after compress- or started 10 minutes.
Error status lock if it occurs 3 times in 1 hour.
Non-resumable
18 Compressor motor desynchronizing Rotor desynchronizing occured, caused by overload or load
sharply uctuating or compressor current sensor cicuit abnormal
or one of the inverter’s gate drive signal missing.
Non-resumable

15
Troubleshooting
Error
code Malfunction Description Diagnosis and Analysis Remark
19 DC voltage or AC voltage low
AC power supply of the driver module get voltage lower than
155VAC or driver module get high DC-BUS voltage lower than
180VDC.
Resumable
20 Indoor pipe temperature too high
protection
Indoor pipe temperature Tm over 63°C, error clear within
3 minutes if temperature goes down and lower than
52°C.
Resumable
21 Indoor pipe sensor temperature too
low protection
Indoor pipe temperature too low,outdoor unit stop to prevent
indoor heat exchange system icing and to prevent the indoor unit
outlet air too low at the same time
Resumable
22 PFC circuit loop overcurrent Overcurrent been detected in power factor correction circuit
loop. Resumable
23 Temperature too high for compressor
driver module
Compressor driver module’s PIM temperature over 90°C, Error
stat-us lock if it occurs 3 times in 1 hour. Non-resumable
24 Compressor start failure Compressor start failure been detected by driver driver module. Non-resumable
25 Input overcurrent of the drive module
Input current of the compressor drive module higher than 32A
(double fan model) or 27A (single fan), Lock if it occurs 3 times
in 1 hour.
Non-resumable
26 Lack phase ofthe drive module Lack phase of the drive module’s power supply.(three phase
type) Non-resumable
27 Input current sampling circuit fault The driver module’s input current sampling circuit damaged. Resumable
28 No wiring of the compressor No wiring between compressor and it’s driver module. Non-resumable
37 Compressor overcurrent detected by
compressor driver module
Compressor phase U or V or W current over 27A (single phase
model) or 19.1 A (single phase model) occured during non-rated
period.
Resumable
38 Drive module’s ambient temp, sensor
abnormal
The temperature detected is not within the range of -25°C to 150
°C. Resumable
39 Mid-condenser temp, sensor TC
abnormal
The temperature detected is not within the range of -55°C to 90
°C. Resumable
42 High pressure switch abnormal
After compressor running for 3 minutes, switch been detected
open circuit for 30seconds, Error lock if it occurs 3 times in 1
hour.
Non-resumable
43 Low pressure switch abnormal
After compressor running for 3 minutes, switch been detected
uncon-nected for 60seconds or unconnected for 30seconds at
standby.
Non-resumable
44 Outdoor condenser temperatureTC
too high protection
The maximum temperature value of Tc and Te is over 65 °C,
Error lock if it occurs 3 times in 30 minutes. Non-resumable
45 System low pressure protection
The minimum temperature value of indoor pipe Tm and
outdoorTs is lower than-45 °C at cooling mode or minimum
temperature value of outdoor Tc and outdoor Te is lower than-45
°C.
Non-resumable
Note:
1. The ou. tdoor control board’s LED3 indicates the outdoor error code, for example, the error code 12, LED3 will display 12 and
keep ashing.
2. NO-resumable means error will not clear unless: a. clean out the fault factor b. Cut the power supply off and reoffer again after
point a achieved.
3. The indoor unit can also indictes the outdoor malfuction code too. Please refer to indoor unit manul to get the method
