Please read this operation manual before using the air conditioner.
No.0010573867
B
Operation & Installation
Manual
PACKAGED TYPE AIR CONDITIONER
Please keep this manual carefully and safely.
AP182ACBEA
SWING
ON OFF

1
Cautions
Disposal of the old air conditioner
Before disposing an old air conditioner that
goes out of use, please make sure it's
inoperative and safe. Unplug the air
conditioner in order to avoid the risk of child
entrapment.
It must be noticed that air conditioner
system contains refrigerants, which require
specialized waste disposal. The valuable
materials contained in an air conditioner can
be recycled. Contact your local waste
disposal center for proper disposal of an
old air conditioner and contact your local
authority or your dealer if you have any
question. Please ensure that the pipework
of your air conditioner does not get damaged
prior to being picked up by the relevant
waste disposal center, and contribute to
environmental awareness by insisting on
an appropriate, anti-pollution method of
disposal.
Disposal of the packaging of your
new air conditioner
All the packaging materials employed in the
package of your new air conditioner may
be
disposed without any danger to the
environment.
The cardboard box may be broken or cut into
smaller pieces and given to a waste paper
disposal service. The wrapping bag made of
polyethylene and the polyethylene foam pads
All these valuable materials may be taken
to a waste collecting center and used again
after adequate recycling.
Consult your local authorities for the name
and address of the waste materials
collecting centers and waste paper disposal
services nearest to your house.
Safety Instructions and Warnings
Before starting the air conditioner, read the
information given in the User's Guide
carefully. The User's Guide contains very
important observations relating to the
assembly, operation and maintenance of
the air conditioner.
The manufacturer does not accept
responsibility for any damages that may
arise due to non-observation of the following
instruction.
Damaged air conditioners are not to be
put into operation. In case of doubt, consult
your supplier.
Use of the air conditioner is to be carried
out in strict compliance with the relative
instructions set forth in the User's Guide.
Installation shall be done by professional
people, don't install unit by yourself.
For the purpose of the safety,theair conditioner
must be properly grounded in accordance
with specifications.
Always remember to unplug the air
conditioner before openning inlet grill. Never
unplug your air conditioner by pulling on
the power cord. Always grip plug firmly and
pull straight out from the outlet.
All electrical repairs must be carried out
by qualified electricians. Inadequate repairs
may result in a major source of danger for
the user of the air conditioner.
Do not damage any parts of the air
conditioner that carry refrigerant by piercing
or performating the air conditioner's tubes
with sharp or pointed items , crushing or
twisting any tubes , or scraping the coatings
off the surfaces. If the refrigerant spurts
out and gets into eyes , it may result in
serious eye injuries.

2
Cautions
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into the
inlet/outlet and swing louver.
Do not allow children to play with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak-proof.
1. Applicable ambient temperature range:
2. If the power supply cord is damaged, it
must be replaced by the manufacturer
or its service agent or a similar qualified
person.
3. If the fuse on PC board is broken,please
change it with the type of T3.15A/ 250VAC.
4. The wiring method should be in line with
the local wiring standard.
5. After installation, the power plug should
be easily reached.
6. The waste battery should be disposed
properly.
7. The appliance is not intended for use by
young children or infirm persons without
supervision.
8. Young children should be supervised to
ensure that they do not play with the
applience.
9. A breaker should be used in the circuits,
which should be all-pole cutoff and the
distance between its two contacts should
be not at least 3mm .
10.Please employ the proper power plug,
which fit into the power supply cord.
(2x2.5mm +1x0.75mm )
2
11.The power plug must have acquired the
local attestation.
The machine is adaptive in following
situation
2
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 10
24 26 6
20 27 15
14.5 -- --
7 24 -7
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C

3
Cautions
Please read the following Safety Instructions carefully prior to use.
The instructions are classified into two levels, WARNING and CAUTION according to the
seriousness of possible risks and damages as follows. Compliance to the instructions are
strictly required for safety use.
Safety Instruction
Installation WARNING
Please call Sales/Service Shop for the Installation.
Do not attempt to install the air conditioner by yourself because improper works may
cause electric shock, fire, water leakage.
CAUTION
Installation in an inadequate place may cause accidents. Do not install in the following place.
Connect the earth
cable.
PROHIBITION PROHIBITION
STRICT
ENFORCEMENT
Do not install in the
place where there
is any possibility
of inflammable
gas leakage around
the unit.
Do not get the unit
exposed to vapor
or oil steam.
Check proper
installation of the
drainage securely
Use fuse with specified capacity.
Replacement with steel or copper wires are
absolutely prohibited.
Grounding wire should not be connected to
that of gas pipeline, water pipeline,lighting
arrester or telephone.
FUSE
STEEL WIRE
COPPERWIRE

4
When abnormality such as burnt-small found, immediately
stop the operation button and contact sales shop.
Connect power supply cord to the
outlet completely. After installed, the unit shall be
tested for electric leakage.
Take care not to damage the
power supply cord.
Do not use power supply cord in
a bundle.
Do not use power supply cord
extended or connected in halfway.
Do not insert objects into the air
inlet or outlet.
Do not try to repair or reconstruct
by yourself.
PROHIBITION
PROHIBITION
PROHIBITION PROHIBITION
PROHIBITION
OFF STRICT
ENFORCEMENT
STRICT
ENFORCEMENT
Use an exclusive power source with a circuit breaker.
CAUTION
Do not use for the purpose of
storage of food, art work, precise
equipment, breeding , or cultivation.
Take fresh air occasionally
especially when gas appliance is
running at the same time.
Do not operate the switch with wet
hand.
Do not pour water onto the unit
for cleaning.
Check good condition of the
installation stand.
Do not install the unit near a fireplace
or other heating apparatus.
Do not place animals or plants in
the direct path of the air flow. Do not place any objects on or climb on the unit. Do not place flower vase or water
containers on the top of the unit.
PROHIBITION
PROHIBITION
PROHIBITIONPROHIBITION
PROHIBITION
PROHIBITION PROHIBITION
PROHIBITION
STRICT
ENFORCEMENT
Cautions
WARNING
Use of Air Conditioner
Do not channel the air flow directly
at people, especially at infants or
the aged.
Do not start or stop the operation
by disconnecting the power supply
cord and so on.
PROHIBITION

5
Parts and Functions
2
3
4
1
Indoor unit
1.OUTLET
2.CONTROL PANEL
3.INLET
4.FILTER ( inside )
SWING
ON OFF
1.
2.
3.
4.
5.
6.
7.
8.
9.
1
2
3
4
3
5
6
7
8
9

6
Parts and Functions

EMERGENCY OPERATION AND TEST OPERATION
EMERGENCY OPERATION
MODE TEMP FAN POWER
EMERGENCY SWITCH
MODE TEMP FAN POWER
TEST SWITCH
Room
temperature Designated temperature Timer mode Air flow speed
Operation
mode
More than 26
Less than 23
26
23
Designated
temperature
None AUTO
AUTO HEAT
COOL
o
C
None
Anion
None
None
o
C
o
C
o
C
Operation
l Carry out this operation only when the remote
controller is defective or lost.
l Unit start
When the emergency operation switch is
pressed, a sound you can hear, which
means the start of this operation.
l Follow the requirements below.
l Unit stop ( to cancel emergency operation)
Press the emergency switch and hear a sound ,the unit stops.Control panel only
display the room temperature
TEST OPERATION
l Use this switch in the test operation when the room
temperature is less 16o
C , do not it in the normal
operation.
l Unit start
Continue to press the test operation switch
for more than 5 seconds. After you hear the
" Hua " sound twice,release your finger from
the switch, the test operation startsand the
air conditioner starts with the air flow speed
setting "Hi".
l
Unit stop (to cancel test operation)
Push the test run switch or operate with remote controller to cancel the test run.
If you use the remote controller to cancel the test run, the conditioner will then run as
per the working mode displayed on the remote controller.
Each time the power supply is switched off, and then is switched on, the conditioner
will play music once automatically. It will stop playing automatically when the starting
signal is received.
Push the On/Off button and Temp +/- button, the conditioner will play the reminding
sound.The On and Temp are rising tone. The Off and Temp are dropping tone.
7

8
Operation hints

9
Maintenance
Cleaning of the unit
Turn off the power switch Do not touch with wet hand Do not clean with hot
water or solvent
Take off the air inlet grate
First switch off the power supply,take off the
screw cap,loosen the screw with cross screwdriver .
Clean the filter
Use water or vacuum cleaner to remove
dust. If it is too dirt, clean with detergent or
neutral soap water.
Rinsing with fresh water, dry the filter and
re-assemble.
Caution:
Do not wash filter in hot water above 40∞C,
which will damage the filter.
Do carefully wipe the filter.
Clean the indoor(outdoor) unit
Clean with warm cloth or neutral detergent,
then wipe away moisture with dry cloth. Do
not use too hot water(above 40∞C),which will
cause discoloration or deformation. Do not
use pesticide or other chemical detergents.
