Please read this operation manual before using the air conditioner.
●
Keep this operation manual for future reference
This appliance is filled with R32.
SPLIT TYPE ROOM AIR CONDITION
OPERATION MANUAL
0010589582
ER
Български
AS20S2SN3FA
AS25S2SN3FA
AS35S2SN3FA
AS42S2SN3FA
AS50S2SN3FA
AS71S2SN3FA
AS20S2SN2FA
AS25S2SN2FA
AS35S2SN2FA
AS42S2SN2FA
AS50S2SN2FA
AS71S2SN2FA
Nederlands

WARNING:
·If the supply cord is damaged, it must be replaced by the manufacturer,its service agent or
similarly qualified persons in order to avoid a hazard.
·This appliance can be used by children aged 8 years and above and persons with reduced
physical, sensory or mentao capabilities or lack of experience and knowledge if they have
been given superivision or instruction concering use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
·The wiring method should be in line with the local wiring standard.
user maintenance shall not be made by children without supervision.
All the cables shall have got the European authentication certificate. During installation, when the
·connecting cables break off, it must be assured that the grouding wire is the last one to be broken off.
The explosion-proof breaker of the air conditioner should be all-pole switch. Distance between its two
contacts should not be no less than 3mm. Such means for disconnection must be incorporated in the
·Make sure installation is done according to local wiring regulation by professional persons.
·
·A leakage explosion-proof breaker must be installed.
Make sure ground connection is correct and reliable.
Read the precautions in this manual
carefully before operating the unit. This appliance is filled with R32.
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
·
Keep this manual where the user can easily nd it.
The appliance must be stored in a room without continuously operating ignition sources (for
example: open flames, an operating gas appliance or an operating electric heater).
Do not pierce or burn.
·
·Be aware that refrigerants may not contain an odour.
·The appliance must be installed, operated and stored in a room with a floor area larger than
3 .
·
·
Do not use a refrigerant other than the one indicated on the outdoor unit(R32) when installing,
moving or repairing. Using other refrigerants may cause trouble or damage to the unit, and
personal injury.
The type of connecting wire is H07RN-F.
wiring.

15
1
2
14
11
Contents
PARTS AND FUNCTIONS
OPERATION
INDOOR UNIT INSTALLAION
MAINTENANCE
CAUTIONS
TROUBLE SHOOTING 16

1
Display board
Signal receiver hole
COOL display
HEALTH display
4
2
3
1
5
DRY display
6
Ambient temp.display
When receiving the remote
control signal, display the set
temperature.
2
35
6
4
HEAT display
1
Display board
23
Signal receiver
1
Ambient temp.display
2
3
Operation mode indicator
(lights up when the compressor is on.)
1
Parts and Functions
Indoor Unit Outdoor Unit
Remote controller
Outer side of the controller
OUTLET CONNECTING PIPING
AND ELECTRICAL WIRING
INLET DRAIN HOSE
1. FAN SPEED button
Used to select fan speed:
LOW, MED, HI, AUTO
2. SWING LEFT/RIGHT button
3. DRY button
Used to set DRY operation.
4. HEAT button
Used to set HEAT operation.
(Cooling only unit do not
have displays and functions
related with heating.)
17
QUIET
SOFT
iFP
ECO
TIMER ON OFF
PM
AM
COOL
ON/OFF
HEAT
DRY
FAN
SPEED
2
13
14
15
16
ECO
FAN
COOL
SMART
HEAT
DRY
CTD
SET TEMP.
ROOM TEMP.
AUTO AUTO
AUTO
FAN
SPEED
POWER
11
12
.
4
5. COOL button
Used to set COOL
operation.
6. QUIET button
7. Display of each function
status
8. Operation mode display
9. Signal sending end device
10. Signal sending display
11. TEMP display
12. FAN SPEED display
Swing up/down display
swing left/right display
13. TIMER ON display
TIMER OFF display
CLOCK display
14. ON / OFF button
15. TEMP button
used to change setting
temperature
16. SWING UP/DOWN
button
17. ECO button
power saving function
Outlet
Horizontal flap
Display board
(adjust up and down air flow
Don't adjust it manually)
(adjust left and
ow)
Vertical blade
Emergency
Switch
right air fl
Inlet
Air Purifying Filter
(inside)
Inlet grille
Anion generator
(inside)
(inside)
Actual inlet grille may vary from the one shown in the
manual according to the product purchased

2
English
Operation
Loading of the battery
Clock set
Load the batteries as illustrated. 2 R-03 batteries,
resetting key (cylinder); Be sure that the loading is
in line with the “+”/“-”;
Load the battery, then put on the cover again.
Press CLOCK button,
Press “+” or “-” to set
correct time.
Each press will increase or
decrease 1min. If the button is
kept pressed, time will change
quickly.
press CONFIRM, “AM” and
starts working.
Note:
The distance between the signal transmission head and
the receiver hole should be within 7m without any obstacle
change-over wireless telephone is installed in the type
in receiving the signals, so the distance to the indoor unit
should be shorter.
Full display or unclear display during operation indicates the
batteries have been used up. Please change batteries.
If the remote controller can’t run normally during operation,
please remove the batteries and reload several minutes later.
Inner side of the controller
CHILD
LOCK
SLEEPSMART
FAN
COOL
SMART
HEAT
DRY
CTD
SET TEMP.
ROOM TEMP.
AUTO AUTO
AUTO
FAN
SPEED
POWER
SOFT
iFP
ECO
TIMER ON OFF
PM
AM
19
20
21
22
23
24
25
27
28
30
31
18
26
FRESH
LIGHT
10
QUIET
29
32
33
18. nottubEDOC
Used to select CODE A or b
with a press, A or b will be
displayed on LCD. Please
select A without special
explanation.
19. TESER button
When the remote controller
appears abnormal, use
a sharp pointed article to
press this button to reset
the controller normal.
20. nottubERIUQNI
Inquire the external
environmental temperature
and the operating power
of the machine. (e.g. when
the panel display “01”, the
operating power is 100W;
when the panel display
“02”, the operating power
is 200W, and so forth)
21. POWER button
22. LIGHT button
Control the lightening and
extinguishing of the indoor
LED display board.
23. HEALTH AIRFLOW button
24. HEALTH button
25. SMART button
Used to set SMART
operation. (This function
is unavailable on some
models.)
26. SLEEP button
27. 10 ºC button
special heating set
function: 10 degree
heating maintaining
(valuable for RS)
28. CHILDLOCK button
If pressed, the other
buttons will be disabled.
Press it once again, lock
will be cancelled.
29. FRESH button
30. TIMER ON / OFF button
31. HOUR button
used to change clock or
timer
32. CANCEL/CONFIRM
button
clock settings.
33. CLOCK button
The following functions and related displays are not
available: 20
Remove the battery cover;
1
2
3
1
2
3
PM
AM
QUIET
SMART SLEEP
10
LIGHT
CHILD
LOCK
FRESH
Hint:
Remove the batteries in case unit won’t be in usage for
a long period. If there are any display after taking-out,
just need to press reset key.

3
QUIET Operation COOL,HEAT and DRY Operation
QUIET Operation
Unit start.
Select operation mode.
Press the COOL button on
the remote control.
Press the HEAT button on the remote control.
Press the DRY button on the remote control.
You can use this function when silence is needed for rest or
reading.
For each press, SOFT is displayed Air conditioner starts
POWER function operation. In SOFT operation mode, fan
speed automatically takes low speed of AUTO fan mode.
Press SOFT button again, SOFT disappears, the operation
stops.
Operation
1. In DRY mode, when room temperature becomes
lower than temp. setting +2 ºC, unit will run
intermittently ai LOW speed regardless of FAN
setting.
2. Remote controller can memorize each operation
status. When starting it next time, just press ON/
OFF button and unit will run in previous status.
AM
QUIET
FAN
SPEED
ECO
SOFT
.
QUIET
QUIET
1
2
AM
QUIET
FAN
SPEED
ECO
.

4
Unit will start running to reach the
temp. setting on LCD.
COOL/DRY:
For each press of “ ” button, air
displays as follows according to
different operation modes:
FAN Operation
LOW MED HI AUTO
Press FAN SPEED button. For each press, fan speed
changes as follows:
Unit will run at selected fan speed.
Press TEMP button.
Every time the button is
pressed, temp. setting
increases 1 ºC.
Every time the button is
pressed, temp. setting
decreases 1 ºC.
Operation
When humidity is high, condensate water might occur
at air outlet if all vertical louvers are adjusted to left or
right.
position for a long time in COOL or DRY mode,
otherwise, condensate water might occur.
better air circulation.
1
2
AM
QUIET
ECO
FAN
SPEED
..
1
2
AM
QUIET
ECO
FAN
SPEED
.HEAT:
SMART:
Initial state
Initial state
For each press of “ ” buttor, remote controller
displays as follows:
remote controller:

The water-ion generator in the
airconditioner can generate a lot
of anion effectively balance the
quantity of position and anion in
the air and also to kill bacteria
and speed up the dust sediment
air in the room.
and outlet grills of the air conditioner are opened, and
the unit goes on working under the condition before the
grille will close automatically.
Notice:
Cannot pull direct the outlet grille by hand. Otherwise, the
grille will run incorrectly. If the grille is not run correctly,
stop for a minute and then start, adjusting by remote
controller.
Remote controller can memorize each operation status.
when starting it next time, just press ON/OFF button and
unit will run in previous status.
The setting of
function
The cancel of
function
Press HEALTH
button
Press HEALTH button for twice press,
disappears, the operation stops.
For each press, is displayed
Air conditioner starts health anion
function operation.
Operation
When indoor fan motor is running, it has healthy
process function. (It’s available under any mode)
When the fan in the indoor unit does not work, the
health lamp lights up, but the anion generator does
not release anion.
HEALTH Operation HEALTH AIRFLOW Operation
AM
SMART SLEEP
LIGHT CHILD
LOCK
FRESH
QUIET
AM
SMART SLEEP
LIGHT CHILD
LOCK
FRESH
QUIET
appears on the display. Avoid
the body.
again, appears on the display.
direct to the body.
Note:
2. In heating, it is better to select the mode.
3. In cooling, it is better to select the mode.
4. In cooling and dry, using the air conditioner for a
long time under the high air humidity, a phenomenon
falling drips of water occurs at the outlet grille.
5. Select the appropriate fan direction according to the
actual conditions.
5
(This function is unavailable for
models with R32)

Set Clock correctly before starting Timer operation. You can
let unit start or stop automatically a following times: Before
you wake up in the morning, or get back from outside or
after you fall asleep at night.
POWER Operation
When you need rapid cooling,
you can use this function.
Select your desired operation
mode.
Time setting.
Remote controller: “
TIMER ON
”
Remote controller: “
TIMER OFF
”
“
ON
” or “
OFF
”
TIMER ON OFF / TIMER ON OFF
procedure in “Time setting for TIMER OFF”
Remote controller:
TIMER ON OFF
procedure in “Time setting for TIMER ON”
Remote controller:
TIMER ON OFF
Every time the button is pressed,
time setting increases or decreases
Select your desired
TIMER ON.
Select your desired
TIMER OFF.
For each press, is displayed Air conditioner
starts POWER function operation.
In COOL mode, fan speed automatically takes high
speed of AUTO fan mode.
Press POWER button again,
POWER
disappears, the
operation stops.
POWER Operation TIMER Operation
AUTO
POWER
AM
SMART SLEEP
LIGHT CHILD
LOCK
FRESH
QUIET
Hints:
During POWER operation, in rapid COOL mode,
the room will show inhomogeneous temperature
distribution.
To cancel TIMER mode
Just press CANCEL button several times until TIMER
3
QUIET
1
TIMER ON
AM
SMART SLEEP
LIGHT CHILD
LOCK
FRESH
1
2
1 min, if kept depressed, it will increase rapidly. It can be
adjusted within 24 hours.
Operation
6

7
Before going to bed, you can simply press the SLEEP
button and unit will operate in SLEEP mode and bring you
a sound sleep.
3 hours then stops. Temp. is lower than temp. setting
so that room temperature won’t be too high for your
sleep.
Approx. 6hrs
Temp. setting
Decreases 2 ºC
Decreases 2 ºC
Unit stop
Rises 1 ºC
Rises 1 ºC
Rises 1 ºC
Temp. setting
In COOL, DRY mode
In HEAT mode
Unit stop
1 hr
1 hr
1 hr
3 hrs
3 hrs
1 hr
SLEEP
operation starts
SLEEP
operation starts
SLEEP
operation stops
SLEEP
operation stops
Press SLEEP
button.
Operation Mode
1. In COOL, DRY mode
1 hours after SLEEP mode
starts, temp. will become 1 ºC
higher than temp. setting. After
another 1 hours, temp. rises by
1 ºC further. The unit will run for
further 6 hours then stops Temp.
is higher than temp. setting so
that room temperature won’t be
too low for your sleep.
2. In HEAT mode
1 hours after SLEEP mode starts, temp will become
2 ºC lower than temp. setting. After another 1 hours,
temp decrease by 2 ºC further. After more another
3 hours, temp. rises by 1 ºC further. The unit will run for
further
3. In SMART mode
The unit operates in corresponding sleep mode, which
adapted to the automatically selected operation mode.
4. When quiet sleeping function is set to 8 hours the
quiet sleeping time can not be adjusted. When TIMER
function is set, the quiet sleeping function can’t be
set up. After the sleeping function is set up, if user
resets TIMER function, the sleeping function will be
cancelled; the machine will be in the state of timing-
on, if the two modes are set up at the same time, either
automatically, and the other mode will be cancelled.
Power Failure Resume Function
not start running unless 3 minutes have elapsed. When
the power resumes after power failure, the unit will run
automatically, and 3 minutes later the compressor starts
running.
Note to the power failure resume:
enter function after hearing four sounds. And press the
this function after hearing two sounds.
Comfortable SLEEP
Operation
AUTO
AM
QUIET
SMART SLEEP
LIGHT CHILD
LOCK
FRESH
