Haier HWF05XC3 User manual

HWF05XC3
0010546415

11-13
14-15

2-way
airflow
control
panel
easy
access
filters
2. MODE Set Knob

setting setting
hours
Also when you shut off the air conditioner wait for 3 minutes
beforeturning it on again.

window seal gasket
short screws 13/32"
wood screws 31/32"
top rail

11
Insert the side curtains into the
top and bottom rails of the air
conditioner. Fasten the curtains
to the unit with 8 short screws
13/32".
Install top rail with 3 short
screws13/32".
ASSEMBLE
CURTAINS/TOP RAIL
HWF05XC3
12 3
5
13 2
5
33 1
5
22 1
2
12 7
16
18 9
16
133
8
53
25

1. This unit is designed for installation in standard double hung windows
with actual opening widths of 22 to 36 . The upper and lower sash
must open sufficiently to allow a clear vertical opening of 14 from the
bottom of the sash to the window stool.
2. If storm window presents interference, fasten a 2 wide wood strip(not
included) (OUTER SILL) to the inner window sill across the full width of
the sill. The wood strip should be thick enough to raise the height of
the window sill so that the unit can be installed without interference by
the storm window frame (STORM WINDOW FRAME) or wood strip
(OUTDOORS) to help condensation to drain properly to the outside.
3. Install a second wood strip (approximately 6 long by 3/2 wide and
same thickness as first strip) in the center of the outer sill flush against
the back off the inner sill. This will raise basepan angle .
4. If the distance between STORM WINDOW FRAME and WOOD STRIP
MOUNTED ON TOP OF INNER SILL is more than 1 , two of wood
strip are not necessary.
INNER
SILL
OUTER
SILL
I
N
D
O
O
R
S
O
U
T
D
O
O
R
S
WOOD STRIP
MOUNTED ON
TOP OF INNER SILL
WOOD STRIP
FOR BASEPAN
ANGLE
STORM
WINDOW FRAME
1 MAX.
3/4 CLEARANCE
I
N
D
O
O
R
S
O
U
T
D
O
O
R
S
INNER
SILL
OUTER
SILL
LOCATING UNIT IN
WINDOW
Open the window and mark center line on the
center of the inner sill.
CENTER LINE
INNER SILL
INDOOR SIDE
ATTACH BASEPAN
ANGLE
CENTER LINE
SHORT SCREW13/32"
INNER SILL
OUTER SILL
SHORT SIDE
BASEPAN ANGLE
8
8
OUTSIDE
INSIDE
Install the basepan angle behind the inner window sill, with
the short side of basepan angle as shown. Use the 2 short
screws13/32" provided.
The basepan angle helps to hold unit securely in place.
Be sure to place basepan angle edge flush against back
of inner sill.
12
2

INSTALL THE AIR CONDITIONER
IN THE WINDOW
Carefully lift the air conditioner and slide it into the open
window. Make sure the bottom guide of the air conditioner
drops into the notches of the basepan angle.
While steadying the air conditioner ,carefully bring the
window sash down behind the upper guide of the air
conditioner.
WINDOW FRAME
UPPER GUIDE
BOTTOM GUIDE
BASEPAN ANGLE
ABOUT 1/4
INSTALL THE SEAL GASKET
AND SASH LOCK
Extend the side curtains to fill the
window opening using 4 wood screws
31/32" to secure them.
Cut the seal gasket to the window
width. Stuff the sash seal between the
glass and the window to prevent air
and insects from getting into the room.
Fasten the basepan angle, using a
short screw13/32".
WINDOW SEAL GASKET
BASEPAN ANGLE
SHORT SCREW13/32"
WOOD SCREW31/32"

AIR FILTER
(INSIDE)
TABS
14
Always use a soft cloth dampened with water or mild soap
and water solution to wipe the front if the cabinet.
To clean the front panels or the cabinet DO NOT use harsh
chemicals, abrasives, ammonia, chlorine, bleach, concentrated
detergents, solvents or metal scouring pads.
The filter can be slid out
by drawing the left and right tabs located on the air filter.
Air filter needs to be cleaned at least once a mouth for your
unit to operate at optimum efficiency.
DO NOT use your air conditioner without the air filter in place.
Always unplug your air conditioner before cleaning.

15

16
(see page 7)
(see page 13)

17
