Vented clothes dryer
INSTALLATION INSTRUCTIONS
USER GUIDE
Model: HDV70E1 and HDV50E1

CONTENTS
1
SAFETY AND WARNINGS
INSTALLATION INSTRUCTIONS
CONTROL PANEL
DRYING CYCLES
USING YOUR DRYER
CLEANING YOUR DRYER
BEFORE YOU CALL FOR SERVICE
TROUBLESHOOTING
IMPORTANT!
SAVE THESE INSTRUCTIONS
Please read these instructions carefully before using your tumble dryer.
The instructions contain important information which will help you get the best out
of the device and ensure safe and proper installation, use and maintenance.
12
13
2
5
14
16
17
18

SAFETY AND WARNINGS
2
!WARNING!
Fire Hazard
■ Only dry fabrics that have been washed with water.
■ Do not use heat todry articles containing foam rubber or similarly
textured rubber–like materials, dry on ‘Airing’.
■ Do not stop a tumble clothes dryer before the end of the drying unless
all items are removed and spread out, in order to dissipate the heat.
■ A clothes dryer produces combustible lint; the lint filter must be
cleaned before each drying cycle.
■ Failure tofollow the warnings outlined in these user instructions can
cause a fire hazard.
■ Failure to follow these instructions can result in death or personal injury.
IMPORTANT SAFETY INSTRUCTIONS
WARNING! When using this appliance always exercise basic safety precautions
including the following:
Dryer use
■ The tumble dryer is intended only for drying textile material washed in water.
■ Undergarments that contain metal reinforcements should not be placed in the dryer.
Damage tothe dryer can result if the metal reinforcements come loose during drying.
If you wish todry these items use a drying rack or place in a garment bag.
■ Check and remove all objects from pockets, eg lighters and matches.
■ Never dry rubber articles, or any plastic items or film, eg plastic lined tablecloths
and baby bibs.
■ Clothes should go through the cool down/airing phase in the final part of the cycle.
This ensures items are left at a temperature where theywill not be damaged. If for
any reason the dryer is stopped before the cycle has finished, dry clothes should be
removed immediately and not left in the dryer. Clothes should be quickly spread out
flat tocool so heat can dissipate,not left bunched up, eg in a clothes basket.
■ This dryer has been designed for domestic use only, not for commercial applications,
such as massage/beauty clinics where there maybe increased lint accumulation or
flammable materials in the atmosphere or load.
Meaning of symbols on the dryer
Warning: Risk of fire/Flammable materials
Read the instructions

SAFETY AND WARNINGS
3
■ Do not operate this product without the lint filter in place or allow lint to accumulate
in or around the dryer.
■ This dryer is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless given supervision or instruction concerning the use of the dryer by a person
responsible for their safety.
■ Children should be supervised to ensure they do not play with the dryer.
■ Unplug the machine from the power supply when it is not in use.
■ Do not swing on or put weight on the door.
■ Your dryer is designed to stop operating in the event of power outage. When
power is resumed, the machine will remain off until the ‘Power’ button is
pressed. To restart the dryer, press ‘Power’, select your drying cycle and
press ‘Start / Pause’.
■ Never attempt to repair the dryer yourself.
■The only user-removable parts of the dryer are the lint filter. No other parts are
designed to be removed by anyone other than a Haier Repairer.
■For problems that cannot be solved from information in this User Guide, turn
off and unplug your dryer and contact a Haier Repairer.
■ When disposing of the dryer, it is recommended that the door is removed to
avoid children getting trapped inside, and that the electrical cable is cut off
close to the dryer.
IMPORTANT!
We do not recommend the use of extension cords or portable electrical outlet
devices for safety reasons.
Lint
■ Accumulated lint in the dryer can become a fire hazard; it also reduces the efficiency
of the dryer by causing longer drying times and increased power consumption.
■ Clean the lint filter before every load.
■ Ensure the area around the dryer is clear of lint.
■ At regular intervals have the interior of the dryer cleaned of any accumulated lint.
This must be done by a Haier trained and supported service technician.
This must be done when the dryer installation is changed from free standing or
inverted, or vice versa.
■ The dryer exhaust ducting should be inspected and cleaned periodically to remove
accumulated lint.

SAFETY AND WARNINGS
4
Spontaneous combustion
IMPORTANT!
To reduce the risk of fire in a tumble dryer the following should be observed:
■Items that have been spotted or soaked with vegetable oil or cooking oil are a fire
hazard and should not be placed in a tumble dryer.
■Oil-affected items can ignite spontaneously, especially when exposed to heat
sources such as a tumble dryer. The items become warm causing an oxidation
reaction in the oil. This oxidation creates heat. If the heat cannot escape the items
can become hot enough to catch fire. Piling, stacking or storing oil-affected items
can prevent heat from escaping creating a fire hazard.
■If it is unavoidable that fabrics that contain vegetable oil, cooking oil or have been
contaminated by hair care products be placed in a tumble dryer, they should first
be washed in hot water with extra detergent – this will reduce, but not eliminate
the fire hazard. The cool down cycle of the dryer should be used to reduce the
temperature of these items. They should not be removed from the tumble dryer
and piled or stacked while hot.
■Items that have previously been cleaned in, washed in, soaked in or spotted
with flammable liquids or solids, eg petrol/gasoline, kerosene, dry cleaning
solvents, vegetable or cooking oil, acetone, denatured alcohol, some brands of
spot removers, turpentine, waxes and wax removers or other flammable or
explosive substances should not be placed in a tumble dryer.
■Do not dry unwashed items in the tumble dryer.
■The dryer is not to be used if industrial chemicals have been used for cleaning.
■Fabric Softeners or similar products should not be used in a tumble dryer to
eliminate the effects of static electricity, unless this practice is specifically
recommended by the manufacturer of the fabric softener product.
■Rubber backed articles, foam rubber (latex foam), clothes or pillows fitted with
foam rubber pads, fibreglass, shoes containing rubber, shower caps, baby’s
waterproof napkin covers and waterproof textiles should not be dried in the dryer.
These materials can, when heated, produce fire by spontaneous combustion.
■The maximum mass of dry textiles depends on your model, The HDV70E1 model is
rated at 7kg. The HDV50E1 model is rated at 5kg. Do not overload your dryer.

INSTALLATION INSTRUCTIONS
Please read and follow the ‘Safety and warnings’ and ‘Installation
instructions’ sections carefully before using your dryer.
Unpacking
1 Remove all the packaging.
2 Tilt the dryer backwards and ‘walk’ it off the base one foot at a time.
3 Remove all packaging and accessories from inside the drum and ensure you
remove protective covers from the door and console.
IMPORTANT!
■Ensure packaging materials are kept out of reach of children.
■Please help protect the environment and dispose of the packaging from around
the dryer in an environmentally friendly manner.
Accessories
Please check your dryer model and the following accessories inside the drum:
HDV50E1
■1 x Installation instructions
and user guide
■1 x Wall mounting kit
■2 x Stacking bracket
■1 x Inverted panel
■1 x Warranty card
Location
IMPORTANT!
■ The dryer must be installed in a well-ventilated, dust-
free environment.
■ The dryer must not be installed on any textured floor
coverings (eg carpet, rugs).
■ Do not install the dryer behind a lockable door, sliding
door, or behind a door where the hinge is on the
opposite side to that of the dryer in such a way that the
full opening of the door is inhibited. Ensure the dryer
door can always be opened fully.
■ Do not install the dryer outside, in a damp place, where
there is a risk of freezing, where it may be rained on, in
direct sunlight or close to a source of heat.
■ Do not place your dryer on top of its power cable.
HDV70E1
■1 x Installation instructions
and user guide
■1 x Wall mounting kit
■2 x Stacking bracket
■1 x Hose connector
■1 x Flexible hose
■1 x Flexible hose clip
■1 x Inverted panel
■1 x Warranty card
5

INSTALLATION INSTRUCTIONS
Venting
Correct installation is very important for all dryers to ensure maximum efficiency and
safety.
IMPORTANT!
Never run the dryer unless the airflow system is free from
obstruction.
There must be adequate ventilation to avoid the back flow of gases into the room
from appliances burning fuels, including open fires, when operating the dryer.
Exhaust air must not be discharged into a flue which is used for exhausting fumes
from appliances burning gas or other fuels.
External venting
Your dryer has been designed to be vented outside to provide the following
advantages:
■ Ensures optimum efficiency by preventing recirculation of moist air.
■ Eliminates condensation on walls and ceilings.
■ Reduces the chance of lint being sucked into the dryer.
■ Prevents lint and other fine particles being blown into the room.
The external venting system should be:
■ Made from 100mm diameter flexible plastic pipe where the vent system goes through the
wall.
■ Exhausted outside and not into another confined space, eg the roof cavity of a house.
■ Angled to avoid condensation and rain water running back into the dryer.
■ The vent system should be a maximum of two metres with no more than three 90°
bends.
Internal venting
The dryer is set up in the factory for front venting. If front venting is used there must
be adequate ventilation to avoid the build up of moisture in the room, which can
affect the performance of the dryer. Venting must comply with local by-laws and
regulations.
6

INSTALLATION INSTRUCTIONS
Free standing
The dryer stands on the floor and can easily be moved into position.
1 Move the dryer into the desired position. Do not
lift the dryer by the top panel.
2 Have a minimum clearance on all sides of at
least 20mm.
3 Have a minimum clearance at the rear of 75mm.
The spacers from the accessory wall mounting
kit can be used to set this distance.
4 Install the dryer on a stable and level floor.
IMPORTANT!
Do not put the heavy loads on the top of your dryer,
eg the wet clothes that were taken out of the washing machine.
Inverted wall mounting
Your dryer has been designed to be inverted and mounted on the wall above a
washer or tub. A wall mounting kit must be used. Inverting allows access to the
dryer control panel.
Tools and parts required:
■Drill and 3mm bit
■Phillips head screwdriver
Wall mounting kit includes:
■2 x Plastic spacers
■2 x Wall hanging brackets
■2 x Hanging hooks
■4 x Wood screws
■6 x Screws for hanging hooks
and plastic spacers
Min. 50mm clearance
Min. 880mm
Min. 50mm clearance
7

INSTALLATION INSTRUCTIONS
Mounting dryer on wall
1 Determine the position of the dryer on the wall and mark the bracket position. A
minimum of 50mm is needed between the top of the dryer and the ceiling for ease
of installation. If mounting above a washing machine, allow sufficient room to open
the lid of the washer.
2 Fix the wall hanging brackets to the wall securely, ie into the stud. If the studs are
too far apart, fit a timber slat to the studs and then mount the brackets to the slat. If
a slat is used install a second slat behind the spacers to ensure the dryer is
horizontal. The distance between the centre of each bracket is 555mm (A).
3 To install the hooks onto the dryer, remove one screw from each side (B), reuse
these screws with two more (each side) from the kit to fasten the hooks in place.
4 Remove plastic plugs from the back of the dryer and screw the spacers provided in
place (C).
5 With assistance, mount the dryer on the wall brackets.
6 The inverted control panel is supplied in the accessories with your dryer. Fit inverted
control panel over the existing panel.
7 Adjust the display to read correctly on an inverted panel:
■ Press and hold the ‘Key Lock’ and ‘Option’ buttons for three seconds.
■ The dryer will beep to indicate you have made a correct selection, and the display
will change after three seconds.
■ Repeat the same steps to return the panel to the factory setting.
From centre
of top hole
From bottom
of dryer
C
B
A
835mm
555mm
555mm
8

INSTALLATION INSTRUCTIONS
Stacking installation
Your dryer has been designed to be able to be stacked on the top of a Haier front load
washing machine, ensure the washing machine is the same width as your dryer.
Tools and parts required:
■Drill and 2.9mm bit
■Phillips head screwdriver
1 Remove 4 screws at two sides of bottom panel, then install the stacking bracket.
4 Screws Stacking bracket
2 Install your dryer with stacking bracket on the top of the front load washing machine.
Drill two holes on both sides of top panel of washing machine with 2.9mm diameter
drill. Detailed drill position as shown on the stacking bracket. Only use the screws
supplied in the stacking bracket. Fix the stacking bracket on the top panel of washing
machine.
■ The models of Haier front load washing machine that
can be stacked installation are followed:
HWF75AW1
HWF80BW1
HWF85AW1
HWM75-B12266
HWM85-B14266
HWM75-1279
HWM85-1479
HWM85-1482
HWM70-1201
HWM80-1401
HW70-1203D
HWM80-1403D
Dryer
Stacking bracket
Front load washing
machine
9
Stacking bracket includes:
■2 x Stacking bracket

INSTALLATION INSTRUCTIONS
Before a rear venting option is installed the dryer must be changed from the front
venting factory setup. Remove the outlet grille from the front left-hand side and
replace with the outlet cover from the rear left-hand side. These covers should be
gently pried at the sides to prevent damage.
Internal venting
Front venting is the only option for internal venting. The dryer is set up for front
venting when it leaves the factory.
Note: where possible all efforts should be made to vent the dryer externally to avoid
moisture build up around the dryer.
External venting
The dryer can be vented directly through the wall with a flexible hose, in combination
with the hose connector supplied with the dryer.
Tools and parts required:
■ Slotted screwdriver
kit part includes:
■ 1 x Hose connector
■ 1xFlexible hose
■ 1xFlexible hose clip
Hose connector
Flexible hose
Flexible hose clip
Connect the narrow end of the connector to the dryer duct pipe mouth at the back of
the dryer. Then connect the flexible hose to the wide end of the connector. Use the
clip to fasten connection point between the flexible hose and connector (fasten clip
with a screwdriver). Extend the flexible hose through the duct hole, make sure the
flexible hose is not twised to allow the air to be vented outside.
Note: The vent system should be a maximum of two metres with no more than three
90° bends.
10

INSTALLATION INSTRUCTIONS
Electrical connection
1 This appliance must be connected to a 220V-240V, 50Hz, sinusoidal, 10A
electrical supply.
2 Uncoil the power cord, remove and discard the plastic pin cover and plug into a
power socket.
3 Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.
■Check the power cord for damage and make sure it is not squashed or twisted when
installing the dryer.
■Always remove the power cord from the power socket by the plug, not by the cord.
IMPORTANT!
■Do not touch or operate the dryer with wet hands or with bare feet.
■A damaged power cord must be replaced by a Haier trained and supported
service technician. The appliance must not be operated until it is repaired, as there
is risk of electric shock.
■Do not operate this dryer if it has been damaged during transport. Contact your
Haier trained and supported service technician.
Product specifications
HDV70E1 HDV50E1
Capacity (kg)* 7
DIMENSIONS (mm)
Width 600
Depth 585
Height 830
ELECTRICAL
Volts 220-240
Hz 50
Amps (maximum) 10
Rated Power (W) 1770
5
600
585
830
220-240
50
10
1750
Waterproof degree IPX4 IPX4
* Capacity refers to the maximum dry weight of items the dryer can dry at any one time.
Rated capacity is determined by a country’s performance standards, so similar dryers may
have different capacities for different markets.
11
WARNING!
The appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by a
utility.

CONTROL PANEL
12
APress ‘Power’ button to activate your dryer. Press it again to switch the dryer off.
B ‘Key Lock’ can be used to lock the buttons on your dryer.This will avoid accidental
button presses.
CThere are two drying settings with your dryer, Sensor Dry and Time Dry. The default
cycle is “Normal – Sensor Dry”.
DPress the ‘Temperature’ button until the light next to your desired drying temperature
is illuminated.
E The ‘Alarm’ and ‘Anti-crease’ Option automatically defaults for all cycles. This means
a series of beeps will sound to alert at the end of a cycle, and the drum will rotate
periodically and cool air will be circulated through the load to minimise wrinkling and
creasing.
FThe ‘Delay’ option enables you to delay the start of the drying cycle. If you have
programmed a ‘Delay’ time, the delay light is on.
G The screen displays the remaining time for a program and delay time.
HThe progress lights indicate what part of the cycle the dryer is currently on.
IPress the ‘Start / Pause’ button to start or pause the cycle.
A B C D E F G IH

DRYING CYCLES
DESCRIPTION MAX. LOAD SIZE (KG) CYCLE TEMPERATURE
7
High
4Med
Low
Sensor dry
Your dryer has three dryness levels from ‘Damp’ through to ‘Extra’. Choose the
dryness level to suit your load depending on how dry you wish for your load to be.
The default temperature for sensor dry cycle is ‘High’ temperature. You can select
the most appropriate temperature for each particular load to ensure you get the best
result.
HDV70E1 HDV50E1
High heat cycle for rapid drying of
everyday clothing, eg cotton fabrics,
t-shirts, sheets, trousers.
5
Cooler cycle for carefully drying delicate
fabrics, eg synthetics fabrics.
4
A low heat cycle for the special care of
heat sensitive fabrics. eg synthetics
fabrics, woolen, silk products.
4 4
‘Extra’, ‘High’ dry temperature is the recommended cycle of HDV70E1 model for everyday cotton items.
‘Normal’, ‘High’ dry temperature is the recommended cycle of HDV50E1 model for everyday cotton items.
Time dry
It is suitable for some fabrics that you wish to dry for a specific time period. You can
select 30, 60, 90, 120, 150 and 180 minute drying times.
Customising dryer cycles
After using your dryer a few times you may discover there are some drying options
you prefer for some cycles. You can programme your dryer to remember the drying
options you prefer for each drying cycle. For instance, you may want to set the
‘Normal’ cycle to a lower drying temperature.
To customise a cycle:
1 Turn on your dryer.
2 Select the cycle you wish to customise.
3 Press and hold any of the drying options buttons for 3 seconds. The lights will flash
and the display will show to indicate the dryer is in cycle adjustment mode.
4 Select the ‘Temperature’ and ‘Option’ function options you prefer by pressing the
relevant option button.
5 Press and hold ‘Key Lock’ for 3 seconds to save the selected setting. Your dryer will
then beep to indicate your customised cycle has been saved.
Factory reset
Your dryer will now be reset to the default settings it left the factory with:
Selection the ‘30min.’ cycle, press and hold the ‘Key Lock’ and ‘Delay’ buttons
together for three seconds. You can reset your dryer to the default settings.
*
Sensor
Dry*
13

USING YOUR DRYER
IMPORTANT!
■ Check the lint filter is clean before every load. Ensure it is replaced correctly before
using your dryer.
■ The lint filter indicator light will flash at the beginning of every cycle when the machine
is switched on, as a reminder to check the lint filter.
■ Sort and load items into the dryer drum, ensuring no items are in the way of the door.
■ Close the door.
■ Ensure your dryer connect to an appropriate power supply(220V-240V, 50Hz).
Preparing your load
■ Check whether the loads have been spun by washing machine.
■ Check pockets for items that could damage your clothes or get caught in the dryer.
■ Close zippers, hooks, fastenings (ie fasten the openings of duvet/doona covers), and
remove loose bra wires. These may damage both your dryer and your clothes.
■ Make sure that the laundry is suitable for drying in the tumble dryer. You can find
some information on the laundry labels.
Loading the dryer
Garments need to be loaded correctly to minimise creasing and wrinkling, and to
ensure the load is dried evenly. Make sure there is plenty of room for the garments
to tumble freely while drying.
To reduce tangling and creasing
■ Load items individually.
■ Ensure duvet/doona covers are fastened before placing in the dryer.
■ Shake clothes out and load individually to help items dry evenly.
■ Launder permanent press garments separately, eg business shirts.
■ Allow enough room in the dryer for clothes to tumble freely.
■ Hang garments as soon as the drying cycle is complete to reduce the need for
ironing.
IMPORTANT!
■ Do not overload your dryer, as this may damage your dryer and clothes.
■ Never put dripping wet clothes in or on top of the dryer as excess water may
cause an electrical hazard.
■ Do not place an item in your dryer unless the care label specifically states it is
safe to do so.
■ Always follow the instructions on the care label.
■ Do not dry curtains in your dryer. Sunlight makes them brittle and they may
disintegrate during drying.
14

USING YOUR DRYER
Switch on the power supply
Press the ‘Power’ button to power on your dryer.
Selecting program
Select your desired drying cycle by turning the control dial.
As you rotate the dial, the drying cycle selected will
illuminate, along with the default settings for that cycle on
the right side of the control panel.
Selecting temperature option
There are four drying temperatures you can choose from:
High: Clothes temperatures reach up to 80°C.
Med: Clothes temperatures reach up to 70°C.
Low: Clothes temperatures reach up to 45°C.
Airing: Cool air is blown through the dryer for the period selected.
Selecting additional option
‘Alarm’ means a series of beeps will sound at the end of a cycle,
to alert you that the dryer has finished.
‘Anti-crease’ operates up to 1 hour after your drying cycle has ended
with cool air to minimise wrinkling and creasing.
Selecting delay start time
The ‘Delay’ option enables you to delay the start of the drying cycle
from between 5 minutes and 12 hours. Times you can select are
5 min, 15 min, 30 min, 1 hour, then hourly up to 12 hours. This can
be useful to time your drying to finish when you arrive home from
work, or to start when power rates are lower.
IMPORTANT!
We suggest that you avoid using ‘Delay’ for non-colourfast
items as this may cause dye run to occur.
Start the dryer
Press ‘Start / Pause’ button to start your dryer.
KeyLock
To turn keylock mode on or off, at any time when the dryer is powered on:
Press and hold the ‘Key Lock’ button for 2 seconds.
Note: when activated, the light under the ‘Key Lock’ button is illuminated.
15

CLEANING YOUR DRYER
IMPORTANT!
■ If you wish to stop the dryer before the cycle has finished you MUST remove
the clothes IMMEDIATELY and spread them out to cool. DO NOT leave the
clothes in the dryer or bunched up in a clothes basket. Take extreme care as
the drum and the load items may be extremely hot.
■ Failure to follow the advice in this guide may result in damage to your
garments and your expectations of drying performance may not be met.
■ Do not dry shoes or other rubber items in you dryer.
When you have finished using your dryer
■ Unplug the dryer from the power socket.
■ Wipe around the door to remove any remaining condensation and/or foreign matter.
■ Clear the lint filter.
Cleaning your dryer
Before you start cleaning your dryer, ensure that it is disconnected from the power
(ie unplug the dryer from the power socket).
Cleaning the control panel and outer surfaces of the dryer
Use a soft damp cloth to wipe all surfaces, then wipe dry. Avoid using chemical or
scouring cleaners, as these will damage the paint and plastic surfaces of your dryer.
Cleaning the inside of your dryer
It is important that you occasionally clean the inside of your dryer. If the drum has
any residual dirt or lint stuck to it, remove this and wipe it clean with a damp cloth.
Do not leave any metal objects in the drum, as these may cause rust.
Cleaning the lint filter
■ Lint is generally formed during wearing and washing.
Fibres (ie lint) released from clothes during the drying
cycle are collected in the lint filter.
■ It is important to clean the lint filter after every load, as
the lint produced in the drying process can become a
fire hazard if it is allowed to accumulate in or around
your dryer.
■ The lint filter is located in the door opening (at the bottom).
■ There is a warning light that will flash at the beginning of
every cycle to remind you to clean the filter. Lint becomes a
fire hazard if left to build up, and will reduce the efficiency
of your dryer.
Lint filter
16

BEFORE YOU CALL FOR SERVICE
To clean the filter:
1 Open the dryer door.
2 Remove the lint filter by pulling it up and out of the filter slot.
3 Open it out and wipe the surface clean with your hand.
4 Close the lint filter and place it back in the opening. Ensure the filter is fitted
correctly back in place before operating the dryer.
IMPORTANT!
If the lint filter becomes damaged, contact your Haier trained and supported
service technician to arrange for a replacement filter. Do not operate your
dryer with a damaged lint filter or without the filter in place, as this will cause
damage to your dryer.
Your dryer is capable of diagnosing a number of its own problems. It will sound a
continuous series of beeps and display a code when it has a problem that you can
correct yourself.
User warnings
PROBLEM DISPLAYED AS WHAT TO DO
The door is not
closed
Close the door fully and press ‘Start / Pause’.
Try opening and closing the door again.
Reposition the load, make sure the load is correctly in the
drum and that protruding items are not stopping the door
from closing.
Dryer has been
paused Press the ‘Start / Pause’ to resume the cycle.
Fault codes
When a continuous series of beeps is sounded, all the lights turn off on the control
panel and a number appears on the display, a fault has occurred. The fault code will
be displayed as followed by a number on the digital display. Record the fault
code and call your Haier trained and supported service technician to arrange service.
If a fault code is being displayed, you can still turn your dryer off by pressing ‘Power’
button.
17
deactivate the Keylock.
Keylock is
activated
Touch and hold the ‘Key Lock’ button for 2 seconds to

TROUBLESHOOTING
The following is a list of problems you may encounter when using this appliance and
some suggestions that may help to correct the problem. If you still have problems,
please contact your Haier Repairer.
PROBLEM POSSIBLE CAUSES WHAT TO DO
Pressing ‘Power’
does not turn
on the dryer.
Fault with household power
supply.
Try plugging in and turning on another
electrical appliance.
Pressing
‘Start / Pause’
does not start the
drying cycle.
Dryer could be displaying a user
warning or fault code.
Refer to page 17.
‘Delay’ function is set. Refer to page 15 for more information.
Dryer keeps
stopping and
starting.
The ‘Anti-crease’ option has
been selected.
Dryer stops
working mid-cycle.
Power failure. Press ‘Power’ and restart the desired
cycle.
Dryer has been paused. Press the ‘Start / Pause’ button to restart
the cycle.
Dryer door is open. Ensure the door is firmly shut.
Dryer is taking too
long/results were
not satisfactory.
Drying cycle selected not
appropriate for the load.
Select an appropriate cycle for the load.
Refer to pages 13, 14 and 15.
Selected drying temp, not
appropriate for the load.
Select a higher drying temp. Refer to
page 15.
Dryer overloaded for the cycle. Some cycles have a lower max. load size.
Refer to page 13.
Try dividing the load in half and dry
half at a time.
Lint filter is blocked. Clean the lint filter.
Load overly wet at the start of
cycle.
Remove more water from the load before
placing it in the dryer, eg select a faster
spin on your washer, a speed appropriate
for your load.
Clothes getting too
hot or damaged.
Cycle selected not appropriate
for the load.
Ensure the cycle selected is appropriate
for items in the load.
Refer to pages 13 and 15.
Items removed from dryer before
the end of cycle cool down had
finished.
Removing items before cool down may
damage clothing if it is not spread out and
exposed to cooler air once removed from
the dryer.
Refer to page 15 for more information.
18
