Haier HP50B, HP42BB, HP60B User manual

Please READ this manual carefully before
operating your TV, and retain it for future
reference.
PLASMA TV
OWNER S MANUAL'
MODELS:
HP42BB
HP50B
HP60B

2 PLASMA TV
THIS SYMBOL INDICATES THAT HIGH VOLTAGE IS PRESENT
INSIDE. IT IS DANGEROUS TO MAKE ANY KIND OF CONTACT
WITH ANY INSIDE PART OF THIS PRODUCT.
WARNING : To reduce the risk of electric shock do not remove cover or back.
No user-serviceable parts inside refer service to qualified service personnel.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rule. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, use and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However ,there is no
guarantee that interference with not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encourage to try to correct the interference by one or
more of the following measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
*Consult the dealer or an experienced radio/TV technician for help.
This device compiles with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may be not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC CAUTION:
To assure continued compliance and possible undesirable interference, the provided ferrite
cores must be used when connecting this plasma display to video equipment; and maintain
at least 40cm spacing to other peripheral device.
CANADIAN NOTICE:
This Class B digital apparatus compiles with Canadian ICES-003.
RISK ELECTRIC SHOCK
DO NOT OPEN
WARNING
Safety of operators has been taken into consideration at the design and manufacture
phase, but inappropriate operation may cause electric shock or fire. To prevent the product
from being damaged, the following rules should be observed for the installation, use and
maintenance of th product. Read the following safety instruction before starting the operation.
The User Manual uses the following symbols to ensure a safe operation and prevent
any damage to operators or properties:
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE APPLIANCE.
FCC STATEMENT

Owner s Manual 3
IMPORTANT SAFETY INSTRUCTIONS
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the following:
1) Read theseinstructions.
2) Keep theseinstructions.
3) Heed allwarnings.
4) Follow allinstructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do notblock any ventilationopenings. Install inaccordance with the manufacturer`s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) thatproduce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or thethird prong are provided for yoursafety. If the provided plug does not fit into your outlet,consult
an electrician forreplacement of the obsolete outlet.
10) Protect the power cordfrom being walked on or pinchedparticularly at plugs, convenience receptacles,
and the pointwhere they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use onlywith the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold withthe apparatus. When a cart isused, use caution when moving thecart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) WARNING-To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture.
Apparatus shallnot be exposed to dripping orsplashing and no objects filled withliquids, such as vases,
shall be placedon the apparatus.
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
The mains plug is used as the disconnect device, remain it readily operable during the
apparatus normal use.

SAVE THESE INSTRUCTIONS
Thank you for using our Haier product. This easy-to-use manual will guide you in
getting the best use of your product. Remember to record the model and serial
number. They are on label in back of the unit.
Model number
serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain warranty service.
4 PLASMA
TV

Contents
Introduction
Owner s Manual 5
War nin g . . . . . . . ... ... ... ... .. . . . . . . . . . . . . . . . . . . . . . . .
Saf ety I nst ruc tio ns . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...
Introduction
Con tro ls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... ... ... ... ..
Connection Options .. . . . . .. . . . . .. . .. . . . . .............
Universal Remote Controller. ............ . . . .. . .. ......
Installation
Acc ess ori es . . . . . . . . . . . . . . . . . . . . . . . . . . . . .... ... ... ..
Antenna Connection .. . . . . .. . . ..............................
VCR Connection. .. . . . . .. . . . . .. . .. . . . ............... ..
External A/VSource Setup . . . ... . . . . ......................
DVD Connection .. . . . ...... .. . . . . .. . .. . . ................
DTV Connection.....................................................
Digital AudioOutput . . . . .. . . . . .. . .. . . . . ...............
PC Connection. .. . . . . .. . . . . . . . .. . . . . .................
Monitor Out Setup. . . . . .. . . . . .. . .. . . . . ................
HDM I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. ... ... ... ... ... .
Cable Sample.........................................................
Connecting Headphones .. . . . . .. . . . . .. . .. . . ....... .
Pow er so urc e.. ... ... ... ... .. . . . . . . . . . . . . . . . . . . . . . . . . .
Take th e tab le st and o ff . . . . . . . . . . . . . . . . . . . . . . . .. ..
Operation
Switching On/Off the TV set . . . . . ... . . . . . . . . . . . ... ...
Choose the MenuLanguage . . . . ............................
Choose the inputSource.........................................
Channel Menu
Automatic Scan. .. . . . . .. . . . . .............................. .
Man ual S can . . . . ... ... ... ... .. . . . . . . . . . . . . . . . . . . . . .. .
Fine Tune................................................................
Edi t Pro gra m.. ... ... ... ... . . . . . . . . . . . . . . . . . . . . . . . . . ..
Rename .............. .. . . . . .. . . . . .. . .. . . . . .. . ..........
S. . .. . ........... ............ . ...
S. . ............... . . ............ . ...
Mute .............. .. . ............................................ . . ..
Video Menu
Aspect Ratio Control. . . . . . . . . . . . . . . . . . . . .. . . .. . . ..
Audio Menu
SAP Broadcasts Setup............................................
elect the desiredprogram
elect the desiredsound
How to selectpicture modes.....................................
How to customizeyour own picture status .................
How to selectaudio modes......................................
How to customizeyour own audio status ..................
Time Menu
Function Menu
Closed Captions.....................................................
CC mode...............................................................
........................................................
DTV Caption..........................................................
DTV Caption Style..................................................
.........................................................
...........................................................
..................................................
Menu
Screen Setup forPC mode......................................
Lock Menu
Parental Control ratingand categories......................
Others Functions
Bri ef In fo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... ... ... .. . .
Maintenance . . ... ... . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Specifications . . . . . . . . . . . . . . . . . . . . . . .. .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .
Warranty . . . . ... ... ... ... . . . . . . . . . . . . . . . . . . . .. . . . . . .
Date /Time setting...................................................
Timer on setting......................................................
Timer offsetting......................................................
Sleep Timersetting.................................................
Time zone setting...................................................
Daylight Saving setting...........................................
NTSC Caption
OSD Timeout
Blue screen
OSD transparency
Adjust
Quick program view................................................
Setting up yourremote control ................................
Remote Control Codes...........................................

-This is a simplified representation of front panel.
-Here shown may be somewhat different from your TV.
Controls
Introduction
6 PLASMA TV
Front panel controls
1.INPUT:
2.CH-/+ Program minus and plus, menu
options
3.VOL-/+ Volume increase and decrease,
menu reset andentry
4.MENU Menu display
5.
all input sourcedisplay and OK
confirm.
POWER: Is used to activatethe display or
return to standby mode.
1.INPUT: all input source display and
OK confirm.
2.CH -/+ : program minus and plus,
menu options.
3.VOL-/+: volume decrease and
increase, menu resetand entry.
4.MENU: menu display.
5. POWER: Isused to activate the
display or return to standby mode.
HP42BB
HP50B HP60B
1
INPUT
2
3
4
5
MENU
CH+
VOL+
CH-
VOL-
POWER
1
INPUT
2
3
4
5
MENU
CH+
VOL+
CH-
VOL-
POWER

PC
AC IN
HDMI2
ANT IN PrPb
YLRHDMI1
PC/DVI
AUDIO IN
OPTICAL
S-VIDEO
VIDEO L R
AV OUT L R
DVI/PC Audio Input
Connect the audio out from
the external device, used
while using a DVI to HDMI
connector.
Power Cord Socket
This TV operates on AC
power.
The voltage is indicated on
the Specifications page.
Never attempt to operate
the TV on DC power
(for HL26S, It is on the left. )
DVD/DTV Input
(Component )
Connect a component
video device to these
jacks.
Earphone jack:
Earphone audio
output terminal.
PC VIDEO Input
Connect the monitor
output connector from
a PC to the jack
Antenna Input
Connect cable orantenna
signals to theTV,either
directly or throughyour
cable box.
S-Video Input
Connect S-Video outfrom
an S-VIDEO deviceto the
S-VIDEO input.
Audio Output
Connect audio from
various types ofequipment.
Note: In standbymode,
these ports willnot work.
HDMI
connect a
signal to
HDMI/DVI.
AUDIO Input
connect to hear
stereo sound froman
external device.
VIDEO Input
Connects the
video signal
from a video
device.
AUDIO/VIDEO
output
HDMI2
connect a signalto
HDMI/DVI.
Back panel controls
Connection Options
Owner s Manual 7
COMPONENT

SELECT
CH.LIST FAV.LIST
AUDIOLIST
PIP SWAP
AUDIOSWAP POSITION
CC
P.MODE
S.MODE
FREEZE
ENU
TIME
NPUT
INFO
EXIT
R
AC
SAP
SLEEP
VOL+ CH+
Q.VIEW
OK
VO L - CH-
POWER
Turns your TV or any other programmed
equipment on oroff, depending on mode.
- The remote control cannot be operated unless the batteries are properly loaded.
Function introduction
- When using the remote control, aim it at the remote control sensor on the TV.
SAP
Selects MTS sound:Mono, Stereo, andSAP inAnalog
mode. Change theaudio language inDTV mode.
Introduction
FAVORITE
Open the favoritechannel list.
THUMBSTICK
(Up/Down/Left/Right/OK)
Allows you tonavigate the on-screenmenus and adjust
the system settingsto your preference.
CHANNEL UP/DOWN
Selects available channels
P.MODE
Selects the pictureappropriate
for the program'scharacter. FREEZE
Freezes the currently-viewedpicture, but audiocontinues.
Press FREEZE buttonagain to resumethe normal picture.
ARC
(Aspect Ratio Control)
Changes the aspectratio.
S.MODE
Selects the soundappropriate for theprogram's
character.
VOLUME UP/DOWN
Increases/decreases the soundlevel.
Numeric buttons
press to changethe channel.
EXIT
Clears all on-screendisplays and
returns toTV viewingfrom any menu.
INPUT
show the input sourcemode.
MUTE
Switches the soundon or off
CC(closed caption)
Select a closedcaption:
CC MUTE, CCON, CC OFF.
TIME
Shows time.
INFO
When you watchthe TV, press the key, theinformation
displays on bottomof the screen.
MENU
Brings up themain menu to the screen.
PIP function buttons
(no available)
SLEEP button
Displays the SleepTimer option.
Q.VIEW
Switch the currentchannel to thelast channel
you have viewed.
CH.LIST
Open the channellist.
Universal Remote Control
TV DVD VCR SETBOX CABLE AUDIO
Press the SELECT button repeatedly to select one of the
system modes inwhich the remotecontrol can beused.
When the desireddevice is selected,the corresponding
LED lights on5seconds.
VCR/DVD Functions
Control some videocassette recorders orDVD players.
/ Rewind / Fast
/ backward /Forward
Stop
Play/Pause
REC
AUDIO.LIST
Open the audiochannellist.
- button
Press to selectadditional channels
(digital and analog)
being broadcast bythe same station.
For example, toselect channel
“54-3”, press “54”,then press “-”and “3”.
LIGHT
Press the lightbutton, white LEDwill be ON,release
this key,white LED willbe OFF.
8 PLASMA TV

Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an
outdoor antenna .In different places, the suitable antenna type and position are different.
External Equipment Connections
Antenna Connection
Multi-family Dwellings/Apartments
(Connect to wallantenna socket)
Wall Antenna
Socket
Single-family Dwellings /Houses
(Connect to walljack for outdoor antenna)
Outdoor
Antenna
VHF Antenna
UHF Antenna
Turn clockwise to tighten.
RF Coaxial Wire(75 ohm)
Bronze Wire
Be careful notto bend the bronze wire when
connecting the antenna.
Bronze Wire
To improve the picture quality ina poor signalarea,
please purchase asignal amplifier and install properly.
If the antennaneeds to be split for two TV`s, install a 2-
Way Signal Splitter in the connections.
If the antennais not installed properly, contact your dealer
for assistance.
Installation
Accessories
Remote controller Owner`s manual Alkaline battery(AAA) 2 Power cable
SELECT
CH.LIST FAV.LIST
AUDIOLIST
PIP SWAP
AUDIOSWAP POSITION
CC
P.MODE
S.MODE
FREEZE
ENU
UIDE
NPUT
INFO
EXIT
R
AC
SAP
SLEEP
VOL+ CH+
Q.VIEW
OK
VO L - CH-
Please READ this manual carefully before
operating your TV,and retain it for future
reference.
TFT-LCD TV
OWNER S MANUAL'
MODEL:L40A8A
Owner s Manual 9

ANT IN
VCR connection
NOTE: All cables shown are not included with the TV.
There are severalways to connect your television, dependingon the components you want toconnect
and the qualityof the signal you want to achieve. The following are examples of someways to connect
your TV. Choose the connection which is best for you.
External Equipment Connections
Choose Your Connection
- To avoid picture noise (interference), leave an adequate distancebetween the VCR and TV
Connection Option 1
Set VCR outputswitch to channel 3 or 4 and
then tune theTV to the same channelnumber.
Connection Option 2
1. Connect theaudio and video cables from the
VCR's output jacksto the TV input jacks,as
shown in thefigure.
When connecting theTV to VCR, match the
jack colors (Video = yellow, Audio Left = white,
and AudioRight = red).
If you connectan S-VIDEO output from VCR to
the S-VIDEO input,the picture quality is
improved; compared toconnecting a regular
VCR to theVideo input.
2. Insert avideo tape into the VCR and press
PLAY on the VCR.(Refer to theVCR owner`s
manual.)
3. Select theinput source with using the
INPUT button on theremote control, and
then press / button to selectthe source,
press the OK button to confirm.
Installation
10 PLASMA TV
PrPb
YLRS-VIDEO
VIDEO L R
AV OUT L R
COMPONENT

How to connect
1. Connect theDVD video outputs(COMPONENT) to theY, Pb,
Pr jacks onthe TV and connect theDVD audio outputsto the
YPbPr AudioIN jacks onthe TV, as shownin the figure.
2. If yourDVD only hasan S-VIDEO outputjack, connect this
to the S-VIDEOinput on theTV. as shown in the figure.
NOTE: If your DVDplayer does nothave component video
output, use S-Video.
How to use
1. Turnon the DVDplayer, inserta DVD.
2. Use theINPUT button on the remotecontrol to selectYPbPr
mode.
3. Press Playbutton on externalequipment for programplay.
4. Refer tothe DVD player'smanual for operatinginstructions.
DVD connection
External Equipment Connections
How to connect
Connect the audioand video cables from the external equipment's
output jacks tothe TV input jacks, as shown in the figure.
When connecting theTV to external equipment, match the
jack colors (Video = yellow, Audio Left = white, and Audio
Right = red).
How to use
1. Select theinput source with using the INPUT button on
the remote control.
2. Press the / button to selectthe desired source.
3. Press theok button to confirm
4. Operate thecorresponding external equipment.
External A/V Source Setup
Video Game Set
Camcorder
Component Input ports
Toget better picture quality, connect a DVD player to the component
input ports asshown below.
Installation
Component ports
on the TV
Video output ports
on DVD player
Y Pb Pr
Y Pb Pr
Y B-Y R-Y
Y Cb Cr
Y P P
BR
Owner s Manual 11
PrPb
YLRS-VIDEO
VIDEO L R
AV OUT L R
COMPONENT
PrPb
YLRS-VIDEO
VIDEO L R
AV OUT L R
COMPONENT

PrPb
YLRS-VIDEO
VIDEO L R
AV OUT L R
COMPONENT
LHDMI1
PC/DVI
AUDIO IN
OPTICAL
PC
Digital Set-top Box
- This TV can receive Digital Over-the-air/Cablesignals without anexternal digital set-top box. However, if you doreceive Digital
signals from adigital set-top box or other digital external device, referto the figureas shown below.
- This TV supports HDCP (High-bandwidth Digital Contents Protection)protocol for DigitalContents (480p,720p,1080i).
How to connect
Use the TV`s COMPONENT , PC or HDMI
jack for videoconnections, depending on
your set-top boxconnector. Then, make
the corresponding audioconnections.
How to use
1. Turnon the digital set-top box. (Refer
to the owner`smanual for the digital
set-top box.)
2. Use INPUTon the remote control to select
COMPONENT, PC,or HDMI source.
Send the TV`s audio toexternal audio equipment (stereo system) via
the AudioOutput (Optical) port.
How to connect
1. Connect oneend of an optical cable to the TV Audio (Optical)
Output port.
2. Connect theother end of the optical cable to the digitalaudio (optical)
input on theaudio equipment.
See the externalaudio equipment instruction manual for operation.
Note: When connecting withexternal audio equipments, such as
amplifers or speakers,please turn the TV speakers off.
Audio Output
Caution: Do notlook into the optical output port.
Looking at thelaser beam may damage
your vision.
External Equipment Connections
DTV connection
AC IN
PC/DVI
AUDIO IN
OPTICAL
Installation
Signal
480i
480p
720p
1080i
Yes
Yes
Yes
Yes
HDMI/DVI
Yes
Yes
Yes
Yes
12 PLASMA TV
COMPONENT

PC
HDMI2
ANT IN HDMI1
PC/DVI
AUDIO IN
OPTICAL
How toconnect
1. To get thebest picture quality, adjust thePC graphics card to 1024
2. Use theTV`s PCor DVI (DigitalVisual Interface)AudioIN port forvideo connections, dependingon your PCconnector.
If the graphiccard on thePC does notoutput analog anddigital RGB simultaneously, connect onlyone of eitherPC r DVI INto
display the PCon theTV.
If the graphic card onthe PC doesoutput analog anddigital RGB simultaneously, set theTV toeithe DVI; (the othermode is
set to Plugand Play automaticallyby theTV.)
3. Then,make the correspondingaudio connection. Ifusing a soundcard, adjust thePC sound asrequired.
How touse
1. Turnon the PCand theTV.
2. Turnon the displayby pressing thePOWER button onthe TV'sremote control.
3. Use INPUTon the remotecontrol to selectPC or HDMIsource.
4. Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or brightness in PC
mode. If noiseis present, changethe PC modeto another resolution,change the refreshrate to anotherrate or adjustthe brightness
and contrast onthe menu untilthe picture isclear. Ifthe refresh rateof the PCgraphic card cannot be changed,change the PCgraphic
card or consultthe manufacturer ofthe PC graphiccard.
NOTES:
1 Use a DVIcable.
2Avoid keeping afixed image onthe TV'sscreen for along period oftime. Thefixed image maybecome permanently imprintedon the
screen.
3 The synchronization inputform for Horizontaland Verticalfrequencies is separate.
x768 .
IN o
r PC or
PC connection
Resolution
Frame
frequency
(Hz)
VGA
SVGA
XGA
640*480 60Hz
800*600 60Hz/75Hz
1024*768
60Hz
Mode Resolution
External Equipment Connections
Installation
75Hz
Owner s Manual 13

Pr2Pb2
Y2
Pr1Pb1
Y1
LR
LRS-VIDEO
VIDEO L R
AV OUT L R
External Equipment Connections
The TV has a specialsignal output capability which allows you to
hook up asecond TV or monitor.
Connect the secondTV or monitor to the TV`s AV OUT.
See the OperatingManual of the second TV or monitor for further
details regarding thatdevice`s input settings.
Notes:
COMPONENT, PC, HDMI,DTV inputsources
cannot be usedfor Monitor out.
When connecting with external audio equipments,such as amplifers
or speakers, pleaseturn the TV speakers off.
Monitor Out Setup
Installation
<When the sourcedevice(DVD player or Set TopBox) supports HDMI>
How ToConnect
1. Connect thesource device to HDMI port of this TV with an HDMI cable(not supplied with this product).
2. No separatedaudio connection is necessary.
How ToUse
- If thesource device supports Auto HDMI function, the output resolution of thesource device willbe automatically setto 1280x720p.
- If thesource device does not support Auto HDMI, you need to setthe output resolutionappropriately.
Toget the best picture quality,adjust the output resolution of the source device to 1280x720p.
- Select HDMIinput source in input source option of Select Main source menu.
<When the sourcedevice(DVD player or Set TopBox) supports DVI>
How ToConnect
1. Connect thesource device to HDMI port of this TV with a HDMI-to-DVI cable(not supplied with this product).
2. Aseparated audio connection is necessary.
3. If thesource device has an analog audio output connector, connect the sourcedevice audio outputto DVIAudio In port located on the
left side ofHDMI port.
How ToUse
- If thesource device supports Auto DVI function, the output resolution of thesource device willbe automatically setto 1280x720p.
- If thesource device does not support Auto DVI, you need to setthe output resolutionappropriately.
Toget the best picture quality,adjust the output resolution of the source device to 1280x720p.
- Press theINPUT button toselect HDMI inputsource in input source option of Select Main source menu.
HDMI
14 PLASMA TV

Cable sample
HDMI Cable
(not supplied with the product)
HDMI to DVI Cable
(not supplied with the product)
Analog AudioCable
(Stereo to RCA type)
(not supplied with the product)
Installation
Owner s Manual 15

HDMI1
PC/DVI
AUDIO IN
OPTICAL
Power source
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for
operation onAC. Insert the AC cordplug into
a standard polarizedAC outlet.
NOTES:
Never connect the AC line cord plug to other
than the specified voltage. Use the
attached power cord only.
If the polarized AC cord does not fit into a non-
polarized AC outlet, do not attempt to file or cut
the blade. Itis the user`s responsibility to have
an electrician replacethe obsolete outlet.
If you cause a static discharge when touching
the unit and the unit fails to function, simply
unplug the unit from the AC outlet and plug it
back in. The unit should return to normal operation.
You can connect a set of headphones to your set if you wish to watch a
TV programme withoutdisturbing the other people in theroom.
Connecting Headphones
External Equipment Connections
Note
Prolonged use ofheadphones at a high volume
may damage your hearing.
Youwill not receive sound from thespeakers
when you connectheadphones to the system.
Volume control of headphones is performed in
the menu ,please refer to page 23.
Plug a setof headphones into the 3.5mm
mini-jack socket onthe rear panel of the set.
Installation
16 PLASMA TV
AC Outlet
Polarized AC Cord Plug
Wider Hole
and Blade

You can take off the table stand if you don`twant to use the table stand.
Take the table stand off
Please release the screws 6XM8,
see the picture.
Owner s Manual 17
HP50B HP60B

Switching On/Off the TV set
Choose the Menu Language
When you startusing your set for the first time, you must select the language whichwill be used for displaying menus
and indications.
-In the manual, the OSD (on screen display) may be different from your TV`s, because it is just an
example to help you with the TV operation.
Operation
-There are several options you might need to set up in order for your TV to work properly. Read the
instructions that follow.
Note:
If the TV in power on , thescreen show information according the typeof input signal . the information
will disappear. If there is no signal and blue screen in ON the screen enter in bluescreen and display No signal
on top and center of the screen.
1 Press the MENU button and thenuse / button to select the
Function menu.
2 Press the button and thenuse / button to select Menu
Language.
3 Press the button and thenuse / button to enter the list of
available language. English Spanish or French
4Select your language with the / button and press the OK
button to confirm you selection.
5 When you are satisfied with your choice, press the EXIT button
to return to normal viewing or press MENU button to return to the
previous menu.
1. First, connect power cord correctly, and then press POWER button on the remote control toturn on theTV.
2. Select the viewing source by using INPUT button on the remote control.
3. When finished using the TV, press the POWER button on the remote control. The TV reverts to standby mode.
4. If you intend tobe away on vacation, disconnect thepower plug fromthe wall power outlet.
: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu
English
Spanish
French
Menu Language English
CC Mode On
Basic Caption CC1
Advanced Caption Service1
Caption Type Basic
Caption Style
OSD Timeout Middle
Blue Screen On
OSD transparency Middle
B
C
A
Video
Audio
Time
Channel
Function
Lock
Choose the Input source
- Change thepicture source so you can watchyour TV, cable TV, VCR, DVD, or any otherdevices that are
connected to yourTV.
1. Press the INPUT button to enter the Select Main picture Source menu
and then use / button to select the desired items. Cable/Air TV, ,
, S-VIDEO, 1, 2, PC, HDMI1, HDMI2.
2. Press the OK button to confirm.
3. Press INPUT button to returnto TV viewing or pressEXIT button to return to the
previous menu.
VIDEO1
VIDEO2 COMPONENT COMPONENT
Select Main Source
Air TV
VIDEO1
VIDEO2
SVIDEO
COMPONENT1
COMPONENT2
PC
HDMI1
HDMI2
DVD
STB
PVR
Cable
Game
Up/Down:Move Cursor
OK: Change MP Source
Right:Activale Source Name Edit Menu
Operation
Note:
1. According to your connection device, you can change the name of every source.
2. In channel menu, ifthe Tuner item is setting as Air or Cable,the source menuwill displayAir TV or Cable TV;
3. HP50B&HP60B.VIDEO2 is only aviable for
18 PLASMA TV

This TV set has three methods to set channels, which are respectively Auto Scan, manual Scan fine tune.
In this section, how to use the remote control to set channel is explained. You can also use buttons on the TV
set to set channel.
Apassword is required to gain access to Channel menu if the Lock of Edit program menu is turned on.
Automatic Scan
Note : Channel menu only available after selecting Air TV or Cable
TV in the input menu.
Channel menu
- Automatically finds all channels available through antenna or cable inputs, and
stores them inmemory on the All ChannelList.
When Air is selected, the TV will detect antenna signals and will
search for antenna TV (NTSC and ATSC) channels available in
your local area.
When Cable is selected, the TV will detect cable company supplied
signals and will search for cable TV channels available in your area.
1 Press the MENU button and thenuse / button to select the
Channel menu.
2 Press the button and thenuse / button to select Tuner.
3 Press the button and thenuse / button to Select Cable or
Air mode.
4Press the OK button
5 When you are satisfied with your choice, press MENU button to
return to the previous menu.
6 Press the / button to select Auto Scan.
7Press the button and pressthe OK button to start searching.
8 To cancel searching, press the OK button.
: Move cursor, /OK: Go to submenu, EXIT/ MENU: Exit main menu
B
C
A
Video
Audio
Time
Channel
Function
Lock
Tuner Air
Auto Scan
Manual Scan
Fine Tune
Edit Program
Rename
Air
Cable
B
C
A
Video
Audio
Time
Channel
Function
Lock
OK Cancel
Air Tuner Number: 47
Found: 1
Tuner Air
Auto Scan
Manual Scan
Fine Tune
Edit Program
Rename
Operation
: Move cursor, OK: Enter, MENU: Return to upper menu,
EXIT:Exit main menu
Owner s Manual 19

Manual Scan
Channel menu
If excessive channel signals of unwanted programs are received in local area,
manual search function is recommended.
1 Press the MENU button and thenuse / button to select the
Channel menu.
2 Press the button and thenuse / button to select Tuner.
3 Press the button and thenuse / button to Select Cable or Air
mode.
4Press the OK button.
5 When you are satisfied with your choice, press MENU button to return
to the previous menu.
6 Press the / button to select Manual Scan.
7Press the button and thenuse digital buttons to select channelnumber you want to add ordelete.
8Press the button to select OK item and pressOK button to add for the channel number.
9 Press EXIT button to return to TV viewing orpress MENU button to return to the previous menu.
Fine Tune (only in anolog signal )
1 Press the MENU button and thenuse / button to select the
Channel menu.
2 Press the / button to select Fine Tune.
3 Press the or OK button
4Press the button to tune.
5 Press EXIT button to return to TV viewing or press MENU button
to return to the previous menu.
/
B
C
A
Video
Audio
Time
Channel
Function
Lock
Tuner Air
Auto Scan
Manual Scan
Fine Tune
Edit Program
Rename
Type Air
Channel NO
Frequency
0k
4
67.250MHz
B
C
A
Video
Audio
Time
Channel
Function
Lock
Tuner Air
Auto Scan
Manual Scan
Fine Tune
Edit Program
Rename
For the tune of the analog channels
Operation
: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu,
EXIT: Exit main menu
: Move cursor, /OK: Go to submenu, / ME NU: Return to upper menu,
EXIT: Exit main menu
20 PLASMA TV
