Haier HWD100-BP14959S8 User manual

User manual
Washer-dryer
HWD100-BP14959S8

Warning – Important Safety information
General information and tips
Environmental information
Disposal
Protect the environment and human health by recycle
the appliance’s packaging to the designated recycling
bin. Do not dispose appliance marked with this symbol
together with the household waste. Send the appliance
to the local recycling center or contact the municipal
office.
Thank you for purchasing a Haier Product.
Please read this manual thoroughly before operate the appliance. This manual contains
important information on the installation, use and maintenance of the appliance.
Keep this manual in a safe and convenient place for future reference.
Please ensure this manual is along with the appliance if you plan to transfer this
appliance to other. This is to allow the next user understand and familiar the features
and functions of the appliance and safely operate this appliance.
o
Disconnect the appliance from the mains supply. Cut off the mains cable and dispose
f it. Removethe door catch to prevent childrenand pets to get closed in the appliance.
Risk of injury or suffocation!
WARNING!
1
Read the instruction
Thank You

2
1-Safety information................................................................................................ 3
2-Product description.............................................................................................. 7
3-Control panel....................................................................................................... 8
4-Programmes.......................................................................................................11
5-Daily use.............................................................................................................12
6-Eco-friendly washing..........................................................................................17
7-Care and cleaning..............................................................................................18
8-Troubleshooting..................................................................................................21
9-Installation..........................................................................................................25
10-Technical data................................................................................................. 29
Content

3
WARNING!
Check the appliance is free from any transport damage.
Remove all the transport bolts .
Remove and dispose all the packaging materials (plastic bags,
polystyrene, etc) and keep out of children’s reach.
Handle the appliance with at least two persons.
Daily use
Before first use
This appliance can be used by children aged from 8 years and above a-
nd persons with reduced physical, sensory or mental capabilities or lack
of experience and konwledge if they have been given supervision or in-
struction concerning use of the appliance in a safe way and understand
the hazards involved.
Before switching on the appliance for the first time read the following safety
instructions!
Keep children under 3 years of age away from the appliance unless
they are constantly supervised.
Children shall not play with the appliance.
Pull up zips, fix loose threads and take care for small items to prevent l-
aundry from being entangled. If necessary, use laundry bag or net.
Do not let children or pets come close to the appliance when the door is
open. Store washing agents out of reach of children.
Do not press or use the appliance when barefoot or with wet or damp h-
ands or feet.
Do not cover or encase the appliance during operation or afterwards to
allow moisture or dampness to evaporate.
Do not place heavy objects or sources of heat or damp on top of the ap-
pliance.
Do not use or store flammable detergent or dry cleaning agent in close
vicinity to the appliance.
Do not use any flammable sprays in close vicinity to appliance.
Do not wash any garments treated with solvents in the appliance without
having dried them previously in the air.
1-Safety information

4
This appliance is intended to be used in household and similar applications
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- areas for communal use in blocks of flats or in launderettes.
such as:
There must be adequate ventilation to avoid the back flow of gases into the
room from appliances burning fuels, including open fires, when operating
the washer dryer.
Do not dry unwashed items in the washer dryer.
Items that have been soiled with substances such as cooking oil, acetone,
alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax rem-
overs should be washed in hot water with an extra amount of detergent
before being dried in the washer dryer.
Fabric softeners, or similar products, should be used as specified by the
fabric softener instructions.
Remove all objects from pockets such as lighters and matches.
WARNING: Never stop the washer dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that the heat is dis-
sipated.
WARNING: The appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly switched on
and off by a utility.
Exhaust air must not be discharged into a flue which is used for exhausting fu-
mes from appliances burning gas or other fuels.
The appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the tumble dryer, in such a
way that a full opening of the tumble dryer door is restricted.
1-Safety information

5
Maintenance/cleaning
Make sure children are supervised if they carry out cleaning and maintena-
nce.
Disconnect the appliance from the electrical supply before undertaking any
routine maintenance.
Keep the lower part of the porthole clean and open door and detergent dr-
awer if appliance is not in use to prevent odours.
Do not use water spray or steam to clean the appliance.
Replace a damaged supply cord only be the manufacturer, its service age-
nt or similarly qualified persons in order to avoid a hazard.
Do not try to repair the appliance by yourself. In case of repair please cont-
act our customer service.
Installation
The appliance should be placed in a well-ventilated place. Ensure a locati-
on which allows opening the door fully.
Never install the appliance outdoor, in a damp place, or in an area which
may be prone to water leaks such as under or near a sink unit, In the
event of a water leak, cut power supply and allow the machine to dry
naturally.
WARNING!
Daily use
Do not remove or insert the plug in the presence of flammable gas.
Do not wash any laundry which is polluted with flour.
Do not open detergent drawer during any wash cycle.
Do not press the door during the washing precess, it gets hot.
Do not open the door if the water level is visibly over the port hole.
Do not force the door to open. The door is fitted with a self-lock device and
will open shortly after the washing procedure is ended.
Switch off the appliance after each wash programme and before under tak-
ing any routine maintenance and disconnect the appliance from the electri-
cal supply to save electricity and for safety.
Hold the plug, not the cable, when unplugging the appliance.
Items such as foam rubber (latex foam), shower caps, waterproof textiles,
rubber backed articles and clothes or pillows fitted with foam rubber pads sh-
ould not be dried in the washer dryer.
1-Safety information

Intended use
This appliance is intended for washing machine-washable laundry only. Any-
time follow the instructions given on the label of each garment label. It is not
intended for commercial or industrial use.
Changes or modifications to the device are not allowed. Unintended use may
cause hazards and loss of all warranty and liability claims.
WARNING!
Installation
Installor use the appliance only where the temperature is above 5 °C.
Do not place the appliance directly on a carpet, or close to a wall or furn-
iture.
Do not install the appliance in direct sunlight or in the near of heat sourc-
es (e.g. stoves, heaters).
Make sure the electrical information on the rating plate agrees with
the power supply. If it does not, contact an electrician.
Do not use multi-plug adapters and extension cables.
Make sure only the new electric cable and hose sets supplied with the
appliance are to be used.
Make sure not to damage the electric cable and the plug. If damaged ha-
ve it replaced by an electrician.
Use an easy accessible and earthed socket for the power supply.
The appliance must be earthed.
Make sure the hose joints and connections are firm and there is no leak-
age.
6
1-Safety information

2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig. 2-3):
Note:
1 Detergent/Softener drawer
2
Control panel
3
Worktop
4 Door
5 Filter cover
6 Adjustable feet
1 Transportation bolts (T1-T4)
2 Backcover
Backcover screws（6 EA）
3
4 Power cord
5 Drain hose
6
2-1 2-2
2-3
Inlet hose
assembly
5 Blanking
plugs+2 Screws
Drain hose
bracket User manual Bottom plate Warranty card
Warranty
card
Due to technical changes and different models,the illustrations in the following ch-
apters may differ from your model.
7
13
2
6
4
5
123 4 5 6
T1
T2
T3
T4
Water inlet valve
I-Refresh
/
2-Product description

I-Refresh
/
Note : Acoustic signal
Infollowing cases an acoustic signal sounds:
▶when pressing a button
▶at the end of program
▶
▶when selecting the program
in case of failures
The acoustic signal can be deselected if necessary; see DAILY USE.
8
1
2 Programme selector
3 Display
4 Detergent / Softener drawer
5 Function buttons
6
“Start/Pause” button
“Power” button
3.2 Programme selector
By turning the knob (Fig. 3-3),you may choose one
from the 12 programme and the corresponding
3.3 Display
The display (Fig. 3-4) shows following information:
▶Washing time
▶End time delay
▶Error codes and service information
Display symbols
Speed,Temperature,etc
▶
▶
3.1 “Power” button
Touch this button (Fig.3-2) gently to swicth on the
appliance, the display is shining, press it again for
about 2 seconds to swicth off. If no panel element
or programme is activated after a while machine
will shut down automatically.
3-1
3-2
3-3
3-4
4 2
6
5
3
1
programme LED icon will light up.
I-Refresh
I-Refresh
3-Control panel

9
3.5 Function buttons
Choose the extra function from the (Fig. 3-6) before
3.5.1-Function button “Delay”
Note: Factory settings
To get best results in each programme Haier has well defined specific default set-
.tnemeriuqercificepsonsierehtfidednemmocererasgnittestluafeD.sgnit
3.4 Detergent drawer
Open the drawer, two compartments can be seen
The recommendation on the type of detergents is s-
uitable for the various washing temperatures, please
refer to the manual of detergent.
This model does not have a disinfection washing pr-
ogram, and disinfectant can not be added to the di-
sinfection washing inlet.
3.5.2-Function button “Temp.”
2 Compartment 2: Softener, Conditioning agent etc.
1 Compartment 1:Powder or Liquid detergent.
Press this button (Fig.3-7) to start the programme with
a delay. End time delay could be increase in interval of 30
,noitcnufyaledehttcelesuoyretfA.h42-5.0morfsetunim
the total washing time will longer than the default
03:6ffoyalpsid,elpmaxeroF.emitgnihsawemmargorp
means end of programme cycle will b e in 6 hours and 30
minutes. Press Start/Pause” button to activate the time delay.
1
2
Press this button (Fig. 3-8) to change the washing temp-
erature of the programme.If the display showing “0”, the
temperature function will not be activated and the water
(Fig. 3-5):
3-6
3-5
3-8
3-7
the washing cycle start. The related indicators are
light up once selected. You may choose more than
one function by pressing the buttons sequentially.
will not be heated.
3-9
3.5.3 Function button “Speed”
Touch this button (Fig. 3-9) to change or deselect the
spin of the programme.If the display showing “0” the
spinning function is not activated ands spinning will not
be started.
I-Ref resh
/
I-Ref resh
3-Control panel

10
3.5.7 “Start/Pause” button
3.5.4 “I-Refresh” button
3.5.5 “Dry” button
3.5.8 Child lock
3.5.9 Extra Rinse
3.5.6 “Steam” button
Touch this button (Fig. 3-10) , the program can be sele-
cted, I-refresh icon will light up. It is used for fresh odor
removal, dust removal, mites removal, and moisture re-
moval.
Touch this button (Fig. 3-11) in order to activate/deacti-
vate the drying function. By touching the button sequen-
tially, drying time can be seen in combination with pro-
gram Dry this function sets the drying time.The time
is AU、30、60、90min.
Touch this button (Fig 3-12) to select the steam program,
Touch this button (Fig. 3-13) gently to start or pause
then the current program temperature value will be cha-
nged to the maximum allowed value. The maximum te-
mperature value can be viewed on the page of the par-
ameters table in the manual. You can select if you requ-
ire this funtion when programmers “Cotton, Synthetics,
Mix, Baby care, Daily, Hygiene, Jeans” are used. The
icon will light up when using the steam wash function.
3-15
3-10
3-13
3-14
3-16
3-12
the wash cycle.
Touch button “Delay” and “Steam” (Fig. 3-14) for 3
Touch button “Steam” and “Temp.” (Fig. 3-16) for 3
seconds simultaneously to activate the child lock
seconds simultaneously to activate the Extra Rinse,
press these two buttons at the same time to adjust
the times of extra rinse.
feature. The child lock indicator on the display will
light up when it’s activated. Press the two buttons
simultaneously again to deactivate the feature.
This feature is an optional when the machine is running.
The display showing “clol-” (Fig. 3-15) if the child
lock is activated. This feature is to disable controls
and prevent child from changing programme or
operating the appliance.
3-11
I-Ref resh
3-Control panel

11
1)
*: Water is not heated up.
3) Not suitable for drying more dandruff clothing, such as wool. .
Choose 90°C wash temperature only for special hygienic requirements.
2)
4)
Max. load
washing
in kg
Temperature Preset
spin
speed
in rpm
Function
in °C
1)
4)
Preset
Steam Extra Rinse Delay
Programme
selectable
1 2 Fabric type
Cotton 10
5
5
5
5
5
1.25
2.5
* to 90 30 º º º º º
º
º
º º º
º º º
º º º
º º º
Cotton 1000
Synthetics
* to 60 30 º º
Synthetic or maxed
fabric 1000
Mix
*
to 60
30 º º Lightly soiled mixed-
laundry of cotton and
synthetic
1000
Baby Care *
t o
90 40
30
º º Cotton/ synthetics
Cotton/ synthetics
Cotton/ synthetics
Cotton/ synthetics
1000
*
to
60
º º
º º
Cotton
Jeans
1000
1000
///
/
/
* to 60 º º 1000
Dry Only /
1.25
// / /
* to 40 º º 1000
Jeans
Daily
Hygiene
30
/
/
/
/
/
/
/
/
/
º
º
Drum Clean *90 90 //
Detergent compartment for:
1
2
Detergent
Softener or care product
º
Optional, / No
Delicate *
to 30 30 º º Delicate laundry and
silk 600 /º
Quick 15 ’
2)
3)
*/º
Spin / / 1000 / / /
/
/ /
/ /
/ /
//
Non-fragile fabric
º
º
ºº
º
º
º
º
º
º º
1
2
/
range
Reduce detergent amount because programme duration is short.
Do not use detergent instead of use a special machine cleaner.
drying
in kg
10
I-Refresh Dry
//
º
/
º
º
5)
5) The program Quick 15’, press the Dry button once is quick wash quick drying; Press the button
twice in succession is wisdom drying (Judge drying time intelligently).
6
3
3
3
3
3
1.25
/
6
0.6
/
6
º
6)
7)
6) 7) The program Cotton and Synthetic, When using the I-Refresh function, Only one garment of the
same material can be washed.
4-Programmes

5.3 Preparing laundry
Check the care label on the clothing. Sort out
Separate white clothes from coloured .Wash
coloured textiles first by hand to check if
they fade or run.
Empty pockets (keys, coins, etc.) and remove
harder decorative objects (e.g. brooches).
a
ven textile such as fine curtains are to be put into
wash bag to care for this delicate laundry (hand
or dry cleaning would be better).
Close zippers, velco fastenerand hooks, make
sure the buttons are sewn on tightly.
Garments without hems, delicates and finely wo-
Place sensitive items like laundry without firm
hem, delicate underwear and small items su-
ch as socks, belts, bras, etc. in a wash bag.
Unfold large pieces of fabric such as bed sheets,
bedspreads etc.
Turn jeans and printed, decorated or color-inten-
sive textiles inside out; possibly wash .yletarapes
5-3
5.1 Power supply
Connect the washing machine to a power supply
(220V-240V/50Hz；Fig.5-1). Please refer also to
5.2 Water connection
Check the condition of the water inlet hose before
Tun on the tap (Fig.5-2).
Note: Tightness
Before usecheckfor leakagein the joints between the tap and the inlet hose by turning
on the tap.
CAUTION!
Non-textile, as well as small, loose or sharp-edged items may causemalfunctions and
damage of clothes and appliance.
12
5-1 5-2
connecting it to the water tap.
clothes according to types of fabric (cotton,
synthetics, wool or etc.) and soil level (Fig. 5-3).
section INSTALLATION.
5-Daily use

Care chart
Washing
Washable up to 90°C
normal process
Washable up to 60°C
normal process
Washable up to 60°C
mild process
Washable up to 40°C
normal process
Washable up to 40°C
mild process
Washable up to 40°C
very mild process
Washable up to 30°C
normal process
Washable up to 30°C
mild process
Washable up to 30°C
very mild process
Wash by hand
max. 40°C
Do not wash
Bleaching
Any bleaching allowed Only oxygen/
non-chlorine
Do not bleach
Drying
Tumble drying possible
normal temperature
Tumble drying possible
lower temperature
Do not tumble dryer
Line drying Flat drying
Ironing
I
ron at a maximum
temperature up to
200°C
I
Don’t overload. Note the different maximum load according to programme! Rule of
ron at a medial tem-
perature up to 150°C
Iron at a low temper-
ature up to 110 °C;
without steam (steam
ironing may cause irre-
versible damage)
Do not iron
Professional Textile Care
Dry cleaning in tetra-
chloroethene
Dry cleaning in hy-
drocarbons
Do not dry clean
Professional wet clean Do not professional
wet clean
5.4 Loading the appliance
Put in the laundry piece by piece.
thumb for maximum load: Check if you can put a hand upright on top of load.
Close the door carefully. Make sure that no pieces of laundry are pinched.
13
5-Daily use

5.5 Selecting detergent
Use only machine wash approved detergent.
Mind always detergent manufacturer recommendations.
D
If needed use specific detergents, e.g. synthetic and woolen fabric.
Washing efficiency and performance is determined by detergent quality.
o not use dry cleaning agents such as trichloroethylene and similar products.
Choose the best detergent
Programme
Kind of detergent
Universal Colour Delicate Special Softener
Cotton √√√ - -
√√√
√
√
√√
√
√
√
√
√
- -
Hygiene
Baby Care - -
Drum Clean
- -
√√√
- -
Synthetics
Delicate
-
- -
- -
-
√
√L
Mix - -
Quick 15’ -
-
Dry Only
Spin
Daily
-
L
√ = Recommended
= gel-/liquid detergent P =powder detergent O = optional _ =no
If using liquid detergent, it is not recommended to activate the time delay.
We recomment by using:
Laundry powder: 20°C to 90°C* (best use:40-60°C).
Color detergent: 20°C to 60°C (best use:30-60°C).
Wool/delicate detergent: 20°C to 30°C (best use:20-30°C).
* Choose 90°C wash temperature only for special hygienic requirements.
-
-
-
-- - -
- -
It is better to use low or free suds detergent powder.
14
√L
√√
-
-
-√L-√√Jeans
5-Daily sue

5.7 Switch on the appliance
5-5
5.6 Adding detergent
1. Slide out the detergent drawer.
2. Put the required chemicals into corresponding
compartments (Fig. 5-4).
3. Push back the drawer gently.
Note:
Remove detergent residues before next wash cycle from the detergent drawer.
Do not overuse detergent or softener.
Pl
Always fill the detergent just before the beginning of the wash cycle.
ease follow the instruction on the detergent package.
Concentrated liquid detergent should be diluted before adding into compartment 2.
The best useof liquid detergent is by using a dosing ball, which is given with the laun-
dry into the washing machine.
Do not use liquid detergent if “end time delay” is selected.
Carefully choose the programme settings according to the care symbolson all laun-
dry labels and according to the programme table.
5.8 Select a programme
To
which fits the degree of soiling and sort of laundry
get the best washing results, select a programme
type.
5-6
5.9 Add individual selections
Select required options and settings
(Fig. 5-7); refer to
CONTROL PANEL.
5-7
Note: Odour removal
amount of detergent in washing agent compartment (2) or special machine cleaner to
remove possibly corruptive residues.
5-4
Before first use we recommended to run programme Drum Clean with no load and small
15
Touch the “Power” button to swicth on the appliance (F-
ig. 5-5).
Turn the programme knob (Fig. 5-6) to select the right
programme.
1
3
2
I-Refresh
5-Daily use

se
1. A
The appliance switches off automatically.
t programme cycle end is displayed.
2.
3. R
Turn off the water supply.
emove laundry as soon as possibleto go easy on it and to prevent more wrinkl-
4.
5. Unplug the power cord.
6. O
ing.
pen the door to prevent formation of moisture and odours.Let it open while not used.
To interrupt a running programme press gently “Start/Pause”. The LED in the button is
flashing. Press it again to resume operation.
To cancel a running programme and all its individual settings:
1. Press “Start/Pause” button to interrupt the running programme.
2.
5.12 After washing
Note: Door lock
Forsafety reasons the door is locked partially duringthe washingcycle. It isonly pos-
sible to open the door at the endof the programme or after the programme was can-
celled correctly (see description above).
In caseof high water level, high water temperature and during spinning it is not pos-
sible to open the door; is displayed.
Note: Standby mode / energy-saving mode
The switched on appliance willgo into standby mode if it willnot be activated within 2
5.10 Start wash programme
Press “Start/Pause” button (Fig. 5-8) to start. Applia-
nce operates according to present settings. Changes
are only possible by cancelling the programme.
5.11 Interrupt / cancel wash programme
5-8
5.13 Act
minutes before starting the programme or at the end of programme. The display s-
ivate or deactivate the buzzer
The acoustic signal can be deselected if necessary:
1. Switch on the appliance.
2. Select the Mix programme.
3. Press the “Temp.” button and “Delay” button at the same time for about 3 seconds.
“ ” will be displayed and the buzzer will be deactivated.
For activating the buzzer press these two buttons at the same time again, then “
” will be displayed.
witches off.
16
Turn the knob to select a new programme and start it.
5-Daily sue

Environmentally responsible use
To achieve best useof energy, water, detergent andtime you shoulduse the recom
mended maximum load size.
Do not overload (hand width clearance above laundry).
For slightly soiled laundry select the Quick 15’ programme.
Apply exact dosages of each washing agent.
Choose the lowest adequate washing temperature - low suds detergents are ef
ficiently cleaning below 60 °C.
17
Change to different function only if the laundries soil level is high, otherwise use
the default setting.
6-Eco-friendly washing

7.1 Cleaning the detergent drawer
(Fig. 7-1):
1. Pull out the drawer until it stops.
2. Press there release button and remove the drawer.
3. Flush the drawer with water until it is clean and
insert the drawer back in the appliance.
7.2 Cleaning the machine
▶Unplug the machine during cleaning and mainte-
nance.
▶Use a soft cloth with soap liquid to clean the ma-
chine case (Fig. 7-2) and rubber components.
▶Do not use organic chemicalsor corrosive sol-
vents.
7-1
7-2
Note: Drum Clean
For regular maintenance we recommend to run programme with no load in
order to remove possiblecorruptive residuesquarterly. Add a small amount of deterg-
ent in washing agent compartment (2) - or use a special machine cleaner.
7.4 Cleaning the drum
▶Remove accidentally washed metal parts such as
pins, coins, etc. from the drum (Fig. 7-4) because
they cause rust stains and damage.
▶Use a non-chloride cleaner for removing rust
stains. Observe the warning hints of the cleaning
agent manufacturer.
▶Do not use any hard objects or steel wool for clea-
ning.
7-4
Drum Clean
To prevent blockage of water supply by solid subst-
▶
supply.
▶Unscrew the water inlet hose at the back of the
appliance as well as on the tap (Fig. 7-3.1).
▶
▶
7.3 Water inlet valve and inlet valve filter
ances like lime clean regularly the inlet valve filter.
Unplug the power cord and turn off the water
Remove the filters and flush them with water and
a brush (Fig. 7-3.2).
Insert the filter and install the inlet hose.
18
1
3
2
7-3.1 7-3.2
Clean the drawer regularly to ensure there are no
detergent residues.
I-Refresh
/
7-Care and cleaning

1. Turn off and unplug the machine (Fig. 7-6.1).
2. Open (Fig. 7-6.2).
3. Provide a flat container to catch leach water
(Fig. 7-6.3). There could be bigger amounts!
4. Pull the drain hose out and hold its end abovethe
container (Fig. 7-6.3).
5. Take the sealing plug out of the drainhose (Fig.
7-6.3).
6. After complete drainage close drainhose (Fig.
7-6.4). and push it back into the machine.
7. Unscrew and removecounter clock wise the pump
8. Remove contaminants and dirt (Fig. 7-6.6).
filter (Fig. 7-6.5).
7-6.3 7-6.4
7-6.5 7-6.6
7
7.6 Pump filter
.5 Long periods of disuse
If the appliance is left idle for a longer period:
1. Pull out the electrical plug (Fig. 7-5.1).
2. Turn off water supply (Fig. 7-5.2).
3. Open the door to prevent formation of moisture
and odours. Let door open while not used.
Before next usage check carefully power cord, water
inlet and drain hose. Make sure everything is properly
installed and without leakage.
7-5.1 7-5.2
WARNING!
Scalding Risk! Water in the pump filter can be very
hot! Before any action please ensure water has co-
oled down.
Note: Hygiene
After long periods of disuse we recommended to run programme Drum Clean with no
load and small amount of detergent in washing agent compartment (2) or special m-
achine cleaner to remove possibly corruptive residues.
f
Clean the filter once a month and check the pump
or instance if the appliance:
Doesn´t drain the water.
Doesn´t spin.
Cause unusual noise while running.
7-6.27-6.1
filter
19
Filter cover
7-Care and cleaning
