Haier HWD90-BP14636 User manual

EN
User manual
Washer-dryer
HWD90-BP14636
HWD100-BP14636

Thank You EN
2
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic ap-
pliances. Do not dispose appliances marked with this
symbol with the household waste. Return the product
to your local recycling facility or contact your municipal
oce.
Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions con-
tain important information which will help you get the best out of the appliance and ensure
safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure
you also pass this manual so that the new owner can become familiar with the appliance
and safety warnings.
WARNING!
Risk of injury or suocation!
Disconnect the appliance from the mains supply. Cut o the mains cable and dispose
of it. Remove the door catch to prevent children and pets to get closed in the appliance.

EN Content
3
1- Safety information...........................................................................................................................4
2- Productdescription .........................................................................................................................8
3- Control panel.....................................................................................................................................9
4- Programmes ...................................................................................................................................13
5- Consumption..................................................................................................................................14
6- Daily use ...........................................................................................................................................15
7- Eco-friendly use.............................................................................................................................20
8- Care and cleaning ..........................................................................................................................21
9- Troubleshooting.............................................................................................................................24
10- Installation.....................................................................................................................................28
11- Technical data ..............................................................................................................................32
12- Customer service........................................................................................................................33

1- Safety information EN
4
Before switching on the appliance for the rst time read the follow-
ing safety hints:
WARNING!
Before rst use
▶Make sure there is no transport damage.
▶Make sure all transport bolts are removed.
▶Remove all packaging and keep out of children´s reach.
▶Handle the appliance always with at least two persons because it
is heavy.
Daily use
▶This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
▶Keep away children under 3 years of age from the appliance un-
less they are constantly supervised.
▶Children shall not play with the appliance.
▶Do not let children or pets come close to the appliance when the
door is open.
▶Store washing agents out of reach of children.
▶Pull up zips, x loose threads and take care for small items to pre-
vent laundry from being entangled. If necessary, use an appropri-
ate bag or net.
▶Do not touch or use the appliance when barefoot or with wet or
damp hands or feet.
▶Do not cover or encase the appliance during operation or after-
wards to allow any moisture or dampness to evaporate.
▶Do not place heavy objects or sources of heat or damp on top of
the appliance.
▶Do not use or store flammable detergent, sprays, dry cleaning
agent or flammable gas in close vicinity to the appliance.
▶Do not wash any garments treated with solvents in the appliance
without having dried them previously in the air.

EN 1- Safety information
5
WARNING!
Daily use
▶Do not remove or insert the plug in the presence of flammable
gas
▶Do not hot wash foam rubber or sponge-like materials.
▶Do not wash any laundry which is polluted with flour.
▶Do not open detergent drawer during any wash cycle.
▶Do not touch the door during the washing process, it gets hot.
▶Do not open the door if the water level is visibly over the porthole.
▶Do not force the door to open. The door is tted with a self-lock
device and will open shortly after the washing procedure is ended.
▶Switch o the appliance after each wash programme and before
undertaking any routine maintenance and disconnect the appli-
ance from the electrical supply to save electricity and for safety.
▶Hold the plug, not the cable, when unplugging the appliance.
▶Do make sure the room is dry and well ventilated. The ambient
temperature should be between 5 °C and 35 °C.
▶Do not cover any ventilation openings in the base by a carpet or
similar object.
▶Keep the area around the appliance free of dust and lint.
▶Do make sure that there is only laundry inside the appliance and
no pets or children before you use it.
▶Only dry textiles washed in water.
▶Do make sure not to load more than nominal load.
▶Remove all items such as lighters and matches from pockets.
▶Use fabric softeners or similar products as specied by the
manufacturer´s packaging.
▶Notice that the last part of the drying cycle occurs without heat
(cool down cycle) to ensure remaining the garments at a temper-
ature which does not damage them.
▶Do not leave the appliance unattended during run time for some
time. If a long absence is intended, the drying cycle have to be
interrupted by switching o the unit and unplugging the mains.
▶Do not switch o the appliance except drying cycle is nished,
unless all items are quickly removed and spread out that the heat
can be released.

1- Safety information EN
6
WARNING!
Daily use
▶Do not dry following items in the appliance:
▶Items which are unwashed.
▶Items which have been contaminated with inflammable sub-
stances such as cooking oil, acetone, alcohol, benzine, petrol,
kerosene, spot removers, turpentine, waxes, wax removers
or other chemicals. The fumes can cause a re or explosion.
These items must always be washed rst by hand in hot wa-
ter with an extra amount of detergent and then be dried in the
open air before drying in the appliance.
▶Items which contain padding or llings (e.g. pillows, jackets), as
the lling can get out with the risk of igniting in the appliance.
▶Items which contain a large proportion of rubber, foam rubber
(latex foam) or rubber like materials such as shower caps, wa-
terproof textiles, rubberised articles and items of clothing and
pillows with foam rubber lling.
▶Switch o the appliance after each drying programme to save
electricity and for safety.
Maintenance / cleaning
▶Make sure children are supervised if they carry out cleaning and
maintenance.
▶Disconnect the appliance from the electrical supply before un-
dertaking any routine maintenance.
▶Keep the lower part of the porthole clean and open door and de-
tergent drawer if appliance is not in use to prevent odours.
▶Do not use water spray or steam to clean the appliance.
▶Replace a damaged supply cord only by the manufacturer, its ser-
vice agent or similarly qualied persons in order to avoid a hazard.
▶Do not try to repair the appliance by yourself. In case of repair
please contact our customer service.

EN 1- Safety information
7
Installation
▶Ensure a location which allows opening the door fully. Do not in-
stall the appliance behind a lockable door, a sliding door or a door
with hinges on the opposite side of the appliance door as this lim-
its the full opening of the appliance door.
▶The appliance should be placed in a well-ventilated place. Ensure
a location which allows opening the door fully.
▶Never install the appliance outdoors in a damp place, or in an area
which may be prone to water leaks such as under or near a sink
unit. In the event of a water leak cut power supply and allow the
machine to dry naturally.
▶Installorusetheappliance onlywhere thetemperature is above 5°C.
▶Do not place the appliance directly on a carpet, or close to a wall
or furniture.
▶Do not expose the appliance to any frost, heat or direct sunlight
or in the near of heat sources(e.g. stoves, heaters).
▶Make sure that the electrical information on the rating plate
agrees with the power supply. If it does not, contact an electri-
cian.
▶Do not use multi-plug adapters and extension cables.
▶Make sure only the delivered electric cable and hose set are used.
▶Make sure not to damage the electric cable and the plug. If dam-
aged have it replaced by an electrician.
▶Use a separate earthed socket for the power supply which is easy
accessible after installation. The appliance must be earthed.
Only for UK: The appliance’s power cable is tted with 3-cord
(grounding) plug that ts a standard 3-cord (grounded) socket.
Never cut o or dismount the third pin (grounding). After the ap-
pliance is installed, the plug should be accessible.
▶Make sure the hose joints and connections are rm and there is
no leakage.
Intended use
This appliance is intended for washing and drying machine-washable
laundry only. Anytime follow the instructions given on the label of
each garment label. It is designed exclusively for domestic use inside
the house. It is not intended for commercial or industrial use.
Changes or modications to the device are not allowed. Unintended
use may cause hazards and loss of of all warranty and liability claims.

2- Product description EN
8
2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.:2-3): :
Inlet hose-
assembly 5 Blanking plugs Drain hose bracket User manual
Warranty
card
Bottomcover
board Noise pads
Note:
6
7
5
Temp.Speed Intense Delay Start/Pause
Extra rinse
HW80-BP14636
BLDC motor
+++
A
AutoweightCapacityEnergy
8kg
Self Clean
Temp.Speed Intense Delay Start/Pause
Extra rinse
R
+++
A
Energy Capacity
7kg
rpm
1400
HW70-BP14636
1000
Temp.Speed Intense Delay Start/Pause
5+5kg
Dry
A
capacity
SpinspeedEnergy
1400 8/5kg
HWD80-B14636
Speed up
14
3
2
2-1
T1 T2
T3 S1
S2 S4
S3
T4
134
265
2-2
1 Detergent /Softener drawer
2 Display
3 Worktop
4 Programme selector
5 Rating plate
6 Sevice flap
7 Adjustable feet
1 Transportation bolts (T1-T4)
2 Back cover
3 Back cover screws (S1-S6)
4 Power cord
5 Water inlet vave
6 Drain hose
2-3
1) Type of inlet hose depends on model.
2x
2x
1)
S5 S6

EN 3- Control panel
9
1 “
2 Programme selector
3 Display
4 Detergent /Softener drawer
5 Function buttons
6 “Delay” button
7 “Start/Pause“ button
Note : Acoustic signal
In following cases an acoustic signal sounds:
▶when pressing a button
▶when turning the programme selector ▶at the end of programme
▶in case of failures
Press this button (Fig. 3-1) gently to switch on, the dis-
playis shining,theindicatorofthe“Start/Pause”button
is flashing. Press it again for about 2 seconds to switch
-
ter a while machine will shut down automatically.
3-1
Temp.Speed Intense Delay Start/Pause
6+6kg
Dry
Acapacity
Spin speedEnergy
1400 10/6kg
HWD100-BP14636
Speed up
4
12
5 6 7
33-0
The acoustic signal can be deselected if necessary:
1. Switch on the appliance.
2. Select the SPIN programme.
3. Press the “Delay “button and “6+6 kg” button at the same time for about 3 seconds.
“bEEP OFF” will be displayed and the buzzer will be deactivated.
For activating the buzzer press these two buttons at the same time again. “bEEP ON” will
be displayed.

3- Control panel EN
10
3.5-Function buttons
The function buttons (Fig. 3-5) enables additional op-
tions in the selected programme before programme
start. The related indicators are displayed.
-
gramme, all options are disabled.
If a button has multiple options, the desired option can
be selected by pressing the button sequentially.
To delete the setting or to cancel the setting process,
press the function button until the desired LED lights
Temp.Speed Intense Delay
Start/Pause
6+6kg
3.5.1 3.5.2 3.5.3 3.5.4 3.5.5
3-5
3.4-Detergent drawer
Open the drawer (Fig. 3-4), three compart-
ments can be seen:
Compartment 1 : Water inlet only, no detergent
Compartment 2 : Detergent for programme
Compartment : Softener, Conditioning agent etc.
The recommendation on the type of detergents is
suitable for the various washing temperatures, please
refer to the manual of detergent.
3-4
Note: Factory settings
there is no special requirement default settings are recommended.
3.2-Programme selector
By turning the knob (Fig. 3-2) one of 16 programmes
can be selected, related LED will light up, its default
settings will be displayed.
3-2
3.3- Display
The display (Fig. 3-3) shows following information:
▶Washing time
▶Drying time
▶End time delay
▶Error codes and service information
3-3

EN 3- Control panel
11
3.5.4-Function button“6+6 kg“
Press this button (Fig. 3-5.4) in order to activate /de-
activate the drying function. This allows washing and
drying of maximum 6 kg laundry without interruption.
By pressing the button sequentially, drying time can be
set(30,60, or150 minutes for Model HWD100 ; 20,If the display
shows 0or no value, the drying function is deactivated.
In combination with programme DRY this function sets
the drying time.
Drying function is not applicable to all programmes
(see PROGRAMMES).
6+6kg
3-5.4
3.5.5-Function “Speed up“
This function saves time and energy. Preferable if
laundry is slightly soiled. Press simultaneously button
“6+6 kg.“ and ”Delay” (Fig. 3-5.5) for about 3 seconds
to activate the “Speed up” function; SPEEd uP is dis-
played. This function is not available in all programmes
(see PROGRAMMES).
Delay
6+6kg
3-5.5
Note: 6+6 kg
Do not overload. Combination of washing and drying cycle only allows a maximum loading
of 6 kg.
3.5.1-Function button ”Temp.“
Press this button (Fig. 3-5.1) to change the washing
temperature of the programme. If no value is illumi-
nated the temperature will be 0 °C.
In conjunction with the “Intense” button, the child lock
3.5.2-Function button “Speed”
Press this button (Fig. 3-5.2) to change or deselect
the spin of the programme. If no value is illuminated
the laundry will not spun.
Temp.
Schleudern Intensiv Zeitvorwahl
5+5 kg
Kurz
Temp.
Speed
Intensiv
5+5 kg
3-5.1 3-5.2
3.5.3-Function button “Intense“
Preferable if laundry is heavily soiled. This extends the
washing time in the main wash cycle.
In conjunction with the “Temp.” button, the child lock
Temp
. Speed Intense
Zeitvorwahl Start/Pause
5+5 kg
Kurz
3-5.3
90,120
30,60, 90 or 120 minutes for Model HWD90).

3- Control panel EN
12
3.8 Child lock
Press button “Temp.“ and ”Intense” for 3 seconds si-
multaneously (Fig. 3-8.1) to block all panel elements
against activation. For unlocking please press again
the two buttons.
The display shows cLo
I-
(Fig. 3-8.2) if a button will be
pressed, when the child lock is activated. The change
is not running.
Temp.
Speed Intense
Zeitvorwahl Start/Pause
5+5 kg
Speed up
3-8.1
3-8.2
3.7- “Start/Pause“ button
Press this button (Fig. 3-7) gently to start or inter-
rupt the currently displayed programme. During pro-
gramme setting and during programme run the LED
above the button is shining, or if interrupted blinking. .
Start/Pause
3-7
3.6- “Delay” button
Press this button (Fig. 3-6) to start the programme
with a delay. End time delay could be increased in steps
6:30 means end of programme cycle will be in 6 hours
and 30 minutes. Press “Start/Pause” button to activate
the time delay. It is not applicable to programme SPIN.
Speed Intense
Delay Start/Pause
5+5 kg
Speed up
3-6
Note: Liquid detergent
If using liquiddetergent, it is not recommended to activate the end time delay.

EN 4- Programmes
13
1) Relating to dry laundry.
2) *: water will not heated (no value is iluminated).
3) Choose 90 °C wash temperature only for special hygienic requirements.
4) Reduce detergent amount because programme duration is short.
5) Drying time must be set with function button “6+6 kg”.
Max. load Temperature Preset
spin
speed
in rpm
Function
washing
in kg drying in kg in °C
Preset
Intense 6+6kg Speed up
Programme seletable range 2 1 Fibre type
Cotton 10.0/9.0 6.0 * to 90 30 •º/Cotton 1400 • • •
Synthetic 5.0/4.5 3.0 * to 60 30 •º/Synthetic or mixed
fabric 1200 • • •
Mix 5.0/4.5 3.0 * to 60 30 •º/Lightly soiled mixed- laundry of cotton
and synthetic 1000 • • •
Wool 1.0 / * to 40 * •º/Machine-washable fabric made of wool
or with wool content 800 / / /
Underwear 5.0/4.5 3.0 * to 60 40 •º/Underwear 1000 • • •
Sport 5.0/4.5 / * to 40 20 •º/Sports wear 800 •/ /
Jeans 5.0/4.5 3.0 * to 60 30 •º/Jeans 1000 • • •
Hygienic 5.0/4.5 3.0 90 90 •º/Cotton 1000 • • •
Fast 4) 5.0/4.5 1.0 * to 40 40 •º/Lightly soiled laundry made of cotton or
synthetic 1000 /•/
Express
15 min 4) 1.0 1.0 * to 40 * •º/Cotton / Synthetic 1000 /•/
Daily Wash 5.0/4.5 3.0 * to 60 30 •º/Cotton fabrics 1000 • • •
Baby Care 5.0/4.5 3.0 * to 90 40 •º/Cotton/Synthetic 1000 • • •
Delicate/
Silk 2.5/2.25 / * to 30 30 •º/Delicate laundry and silk 800 / / /
Hand Wash 2.5/2.25 / * to 30 30 •º/Laundry marked with
symbol for hand-
wash 400 / / /
Dry 5) / 6.0 / / / / / Cotton, synthetic,
underwear, jeans //•/
Spin 10.0/9.0 6.0 / / / / / all fabrics 1000 /•/
1)
2)
3)
3)
•
Yes, º Optional, / No
Detergent compartment for:
1Water inlet only,
no detergent
2Detergent
Softener or care product
HWD100/
HWD90

5- Consumption EN
14
Parameter Programme
Cotton *Synthetic
Temperature
in °C 40 °C 60 °C 60 °C 40 °C
Max. load
in kg Washing 5.0/4.5 5.0/4.5 10.0/9.0 -
Drying - - 6.0 -
Energy
in kWh
Washing, spin-
ning and drying - - 6.75/6.1 -
Only for washing
and spinning - - 0.82/0.72 -
Water
in L
Washing, spin-
ning and drying - - 105/98 -
Only for washing
and spinning - - 57/53 -
Time
in h:min
Washing and
drying - - 6:57 -
Spin drying per-
formance in % 53 53 43 49
* Standard programme for the Energy Labelling according to 96/60 EU:
Washing: “Cotton 60 °C” with max. spin speed setting and activated “Intense” function.
Drying: “Dry” with function “6+6 kg”.
The standard 60 °C and 40 °C cotton washing programmes are suitable to clean normally
-
declared cycle temperature.
Note: Auto Weight
The appliance is equipped with a loading recognition. At low loading, energy, water and
washing time will be reduced automatically in some programs.
HWD100-BP14636
HWD90-BP14636

EN 6- Daily use
15
Parameter Programme
Cotton *Synthetic
Temperature
in °C 40 °C 60 °C 60 °C 40 °C
Max. load
in kg
Washing 5.0 5.0 10.0 -
Drying - - 6.0 -
Energy
in kWh
Washing, spin-
ning and drying - - 6.75 -
Only for washing
and spinning - - 0.82 -
Water
in L
Washing, spin-
ning and drying - - 105 -
Only for washing
and spinning - - 57 -
Time
in h:min
Washing and
drying - - 6:57 -
Spin drying per-
formance in % 53 53 43 49
6.1 Power supply
Connect the washing machine to a power supply
(220V to 240V~/50Hz; Fig. 6-1). Please refer also to
section INSTALLATION.
6.2. Water connection
▶Before connecting check the cleanliness and clar-
ity of the water inlet.
▶Tun on the tap (Fig.6-2).
6-2 6-1
6.3 Preparing laundry
▶Sort out clothes according to fabric (cotton, syn-
thetics, wool or silk) and to how dirty they are (Fig.
6-3). Pay attention to the care labelling of wash-
ing labels.
▶Separate white clothes from coloured ones.
Wash coloured textiles rst by hand to check if
they fade or run.
▶Empty pockets (keys, coins, etc.) and remove
6-3
Note: Tightness
Before use check for leakage in the joints between the tap and the inlet hose by turning
on the tap.
harder decorative objects (e.g. brooches) as well as flammable objects (paper tis-
sues, lighters, matches etc.).
▶Garments without hems, delicates and nely woven textile such as ne curtains are to be
put into a wash bag to care for this delicate laundry (hand or dry cleaning would be better).
▶Close zippers, velcro fastener and hooks, make sure the buttons are sewn on tightly.
▶Place sensitive items like laundry without rm hem, delicate underwear (Dessous)
and small items such as socks, belts, bras, etc. in a wash bag.
▶Unfold large pieces of fabric such as bed sheets, bedspreads etc.
▶Turn jeans and printed, decorated or color-intensive textiles inside out; possibly
wash separately.
Note: Special hints for drying
▶Sort clothes according to fabric(cotton, synthetics, etc.) desired dry level and equal
residual moisture. Follow the instructions on the laundry label and dry only machine-
dryable garments
▶Spin the laundry with the maximum spin speed before drying.
▶Do not exceed the max. load of 6 kg.
▶Extra large pieces tend to wind up. If the laundry has not been suciently dry, loosen
up the laundry and dry again with programme DRY.
▶Especially delicate fabrics which can easily shrink or lose their shape, as well as e.g. silk
stockings, lingerie etc. should not be dried with the appliance. Put delicate garments
inside a laundry bag and avoid overdrying them.
▶Jersey and knitwear should not be dried to avoid shrinkage.

6- Daily use EN
16
CAUTION!
Non-textile, as well as small, loose or sharp-edged items may cause malfunctions and
damage of clothes and appliance.
Care chart
Washing
Washable up to 95 °C
normal process Washable up to 60 °C normal process Washable up to 60 °C mild process
Washable up to 40 °C
normal process Washable up to 40 °C mild process Washable up to 40 °C very mild process
Washable up to 30 °C
normal process Washable up to 30 °C mild process Washable up to 30 °C very mild process
Wash by hand
max. 40 °C Do not wash
Bleaching
Any bleaching allowed Only oxygen/
non -chlorine Do not bleach
Drying
Tumbledrying possible
normal temperature Tumble dryingpossible lower temperature Do not tumble dryr
Line drying Flat drying
Ironing
Iron at a maximum
temperature
up to 200 °C
Iron at a medial tem-
perature
up to 150 °C
Iron at a low temper-
ature up to 110 °C;
withoutsteam(steam
ironing may cause irre-
versible damage)
Do not iron
Professional Textile Care
Dry cleaning in tetra-
chloroethene Dry cleaning in hy- drocarbons Do not dry clean
Professional wet clean Do not professional
wet clean
6.4 Loading the appliance
▶Put in the laundry piece by piece.
▶Don‘t overload. Note the dierent maximum load according to programmes! Rule of
thumb for maximum load: Check if you can put a hand upright on top of load.
▶Close the door carefully. Make sure that no pieces of laundry are pinched.

EN 6- Daily use
17
6.5 Selecting detergent
▶Washing eciency and performance is determined by used detergent quality.
▶Use only machine wash approved detergent.
▶If needed use specic detergents, e.g. for synthetic and woolen fabric.
▶Mind always detergent manufacturer recommendations.
▶Do not use dry cleaning agents such as trichloroethylene and similar products.
L = gel-/liquid detergent P = powder detergent O = optional _= no
If using liquid detergent, it is not recommended to activate the time delay.
We recomment by using:
▶Laundry powder: 20 °C to 90 °C* (best use: 40-60 °C)
▶Color detergent: 20 °C to 60 °C (best use: 30-60 °C)
▶Wool/delicate detergent: 20 °C to 30 °C (= best use:)
Choose the best detergent
Programme
Kind of detergent
Universal Colour Delicate Special Softener
Cotton L/P L/P - - o
Synthetic L/P L/P L - o
Mix L/P L/P - - o
Wool - - - L o
Underwear L/P L/P - - o
Sport - - - L o
Jeans L/P L/P L - o
Hygienic L/P L/P L - o
Fast L L - - o
Express 15 min L L - - o
Daily Wash L/P L/P L - o
Baby Care L/P L/P - - o
Delicate/Silk - - L - o
Hand Wash - - - L o
* Choose 90 °C wash temperature only for special hygienic requirements.

6- Daily use EN
18
6.7 Switch on the appliance
(Fig. 6-7). The LED of the „Start/Pause“ button is flas-
hing.
6-7 6-8
6.6 Adding detergent
1. Slide out the detergent drawer.
2. Put the required chemicals into corresponding
compartments. (Fig. 6-6).
3. Push back the drawer gently.
Note:
▶Remove detergent residues before next wash cycle from the detergent drawer.
▶Do not overuse detergent or softener.
▶Please follow the instruction on the detergent package.
▶
▶Concentrated liquid detergent should be diluted before adding into compartment 2.
▶The best use of liquid detergent is by using a dosing ball, which is given with the laun-
dry into the washing machine.
▶Do not use liquid detergent if „end time delay“ is selected.
▶Carefully choose the programme settings according to the care symbols on all laun-
dry labels and according to the programme table.
6.8 Select a programme
To get the best washing results, select a programme
type.
Turn the programme knob (Fig. 6-8). to select the right
programme. Related programme LED and the default
settings are displayed.
6.9 Add individual selections
Select required options and settings (Fig. 6-9) ;refer to
CONTROL PANEL.
Temp.Speed Intense Delay
Start/Pause
6+6kg
6-9
Note: Odour removal
amount of detergent in washing agent compartment (2) or special machine cleaner to
remove possibly corruptive residues.
6-6

EN 6- Daily use
19
6.11 Interrupt - cancel wash programme
To interrupt a running programme press gently “Start/Pause“. The LED above the button
is flashing. Press it again to resume operation.
To cancel a running programme and all its individual settings
1. Press “Start/Pause” button to interrupt the running programme.
2.
3.
4. Select a new programme and start it.
Note: Standby mode / energy-saving mode
The switched on appliance will go into standby mode if Pause-button is pressed. This
Pause“ button.
6.10 Start wash programme
Press “Start/Pause“ button (Fig. 6-10) to start. Appli-
ance operates according to present settings. Changes
are only possible by cancelling the programme.
Start/Pause
6-10
Note: Door lock
▶For safety reasons the door is locked partially during the washing /drying cycle. It is
only possible to open the door at the end of the programme or after the programme
was cancelled correctly (see description above).
▶In case of high water level, high water temperature and during spinning it is not pos-
sible to open the door;
Loc1-
is displayed.
6.12 After washing
1. At programme cycle end EnD is displayed.
2.
3. Remove laundry as soon as possible to go easy on it and to prevent more wrinkling.
4.
5. Unplug the power cord.
6. Open the door to prevent formation of moisture and odours. Let it open while not used.
Note: Cool down cycle for drying cycle
The last part of the drying cycle occurs without heat to ensure remaining the garments
at a temperature which does not damage them.

7-Eco-friendly use EN
20
Environmentally responsible use
Washing
▶To achieve best use of energy, water, detergent and time you should use the recom-
mended maximum load size.
▶Do not overload (hand width clearance above laundry).
▶For slightly soiled laundry select the Quick Wash programme.
▶Apply exact dosages of each washing agent.
▶Choose the lowest adequate washing temperature - modern detergents are ef-
▶Raise default settings only due to heavy staining.
▶Spin the laundry with the maximum spin speed if you want to use a drying pro-
gramme afterwards.
Drying
▶
▶Loosen up the laundry before starting the drying programme.
▶Do not use softener when washing, because the laundry will become fl
the dryer programme.
6
