HAKO Scrubmaster B5 User manual

Scrubmaster B5 (7150)
Operating manual
Part number 88-10-3353 - 4766-00
Valid as from: 05.2023

200-7150-00.fm
Introduction
Foreword
Dear Customer,
We are certain that the excellent qualities of the machine will justify the faith
you have shown in us by your purchase.
To guarantee safe working with the machine, please read the Safety Notes
chapter before putting it into service.
Your own safety, as well as the safety of others, depends essentially on your
ability to control the machine. Please read this original operating manual
before you use the machine for the first time, act accordingly and keep it for
future reference or subsequent users. The operating manual contains all
important information for operation, maintenance and servicing. We have pro-
vided the places in this operating manual concerning your safety with a dan-
ger pictogram. Your authorised Hako dealer is available at all times to answer
further questions about the machine or the operating manual.
We would expressly advise you that no legal claims may be asserted based
on the contents of this operating manual. In the case of necessary repair
work, please make sure that only original spare parts are used. Spare parts
must be original spare parts to guarantee safety. We reserve the right to make
changes in the interests of further technical development.
Hako GmbH
23843 Bad Oldesloe, Germany
Hamburger Str. 209-239
Phone [phone]
Issue:
Index Book number Change no. Valid as from:
0 88-10-3353 4766-00 05.2023
Introduction

00-7150-00.fm 3
Intended use
TheScrubmasterB5isascrubber-drierforthewetcleaningof hardindoor floor
surfaces. This machine is intended for commercial use, for example in shops,
hotels and schools, as well as confined areas such as kitchens and sanitary fa-
cilities. Any use extending beyond this is not intended use. The manufacturer
is not liable for any damage resulting from this and the user alone bears the
risk. Intended use also includes compliance with the operating, maintenance
and servicing conditions specified by the manufacturer.
The Scrubmaster B5 may be used, maintained and repaired only by persons
who are familiar with this work and instructed about the dangers.
The relevant accident prevention regulations as well as the other generally
recognised safety engineering and occupational medical rules must be
complied with.
The machine corresponds by virtue of its design and construction as well as in
the version distributed by us to the usual healthand safety requirements of the
ECDirectives(seeDeclarationofConformity).Thisdeclarationlosesitsvalidity
in the event of a modification to the machine not authorised by us. The manu-
facturer is not deemed liable for any damage resulting from unauthorised
modifications to the machine.
Notes on warranty
The terms defined in the purchase agreement apply. Claims for compensation
in relation to damage are excluded from the terms of the warranty when the
damage is the result of the failure to observe rules concerning servicing and
maintenance. Maintenance work must be carried out by an authorised Hako
service workshop and confirmed in the “Maintenance Report”, whichserves as
a warranty logbook.
The following are excluded from the terms of warranty: wear and tear through
overuse, defective fuses, improper handling and use and unauthorised modifi-
cations. Claims under the terms of the warranty are also annulled when dam-
age occurs to the machine resulting from the use of parts or accessories not
explicitly approved of by us or from failure to observe maintenance rules.
Introduction

400-7150-00.fm
Acceptance of the machine
Inspect the machine immediately on delivery for signs of transport damage.
You will be compensated for transport damage provided you immediately have
the damage confirmed by the transport company and send in the damage re-
port together with the consignment note to us.
Machine data
Your machine is described clearly by the following data. Please always quote
these data in correspondence or when making a telephone query to your
authorised Hako dealer or our company.
•Machine type:
•Manufacturing no.:
•Start-up on:
Your nearest authorised Hako dealer:
•Address:
•Telephone:
Introduction

88-00-3357-00IVZ.fm 5
Introduction .................................................................... 2
Foreword ......................................................................... 2
Intended use .................................................................... 3
Notes on warranty ........................................................... 3
Acceptance of the machine ............................................. 4
Machine data ................................................................... 4
1 Safety instructions ......................................................... 7
1.1 Warning and danger symbols ......................................... 7
1.2 General safety instructions ............................................. 8
1.3 Operating safety instructions .......................................... 8
1.4 Maintenance instructions ................................................ 9
1.5 Information about special risks ..................................... 10
1.6 Environmental protection instructions and disposal ..... 12
1.7 Labels on the machine ................................................. 13
2 Use................................................................................. 15
2.1 Overviews ..................................................................... 15
2.1.1 Front and rear view ....................................................... 15
2.1.2 Control panel ................................................................ 17
2.2 Controls and display elements ..................................... 18
2.2.1 Control panel ................................................................ 18
2.2.2 Controls at the machine ................................................ 21
2.3 General principle of operation ...................................... 22
2.3.1 Driving with the Delta Cleaning system ........................ 22
2.3.2 Cleaning head .............................................................. 23
2.3.3 Solution tank ................................................................. 23
2.3.4 Squeegee ..................................................................... 23
2.3.5 Waste water tank .......................................................... 23
3 Operation....................................................................... 24
3.1 Initially starting up the machine .................................... 24
3.2 Initial machine start-up ................................................. 24
3.3 Daily start-up ................................................................ 24
3.3.1 Filling the solution tank ................................................. 25
3.4 Cleaning ....................................................................... 26
3.4.1 Suction only .................................................................. 27
3.5 Turning off the machine ................................................ 27
3.6 After cleaning ................................................................ 28
3.7 Loading and transporting .............................................. 29
4 Technical data............................................................... 30
5 Maintenance and servicing.......................................... 32
5.1 Hako system maintenance ........................................... 32
5.2 Maintenance certificate ................................................. 33
5.3 Maintenance plan ......................................................... 34
Table of contents

688-00-3357-00IVZ.fm
5.4 Solution and waste water tank ...................................... 37
5.4.1 Removing the tanks ...................................................... 37
5.4.2 Cleaning the solution and waste water tank ................. 38
5.4.3 Cleaning the fresh water filter ....................................... 39
5.4.4 Cleaning the waste water suction hose ........................ 39
5.5 Cleaning/replacing the cleaning tools ........................... 40
5.6 Squeegee ..................................................................... 41
5.6.1 Cleaning the squeegee ................................................. 41
5.6.2 Replacing the sealing strips .......................................... 42
5.7 Battery .......................................................................... 43
5.7.1 Checking the charging state ......................................... 43
5.7.2 Charging the batteries .................................................. 43
5.8 Service information ....................................................... 47
EC Declaration of Conformity ................................... 49
Table of contents

01-7150-00.fm 7
Safety instructions
1 Safety instructions
1.1 Warning and danger symbols
Important tasks concerning the safety of the operator and machine are named
as follows in this operating manual and emphasised by symbols.
Danger
Indication of a direct danger with high risk, in which death or severe
physical injury can occur if it is not avoided.
Warning
Indication of a possible danger with average risk, in which death or
severe physical injury can occur if it is not avoided.
Caution
Indication of a danger with low risk, in which light to medium severe
physical injury or material damage can occur if it is not avoided.
Attention
Attention indicates a hazard that can lead to technical damage when
not observed.
Environmental danger
Environmental danger due to the use of substances from which
a health and environmental risk proceeds.
Note
Indication of information that facilitates more effective and
economical use of the machine.

801-7150-00.fm
Safety instructions
1.2 General safety instructions
• Before starting up the machine, please carefully read the operating manual
you receive as well as further separate instructions for additional imple-
ments or attachments and observe them in all aspects of your work.
• The machine may be used, maintained and repaired only by persons who
have been instructed by Hako experts.
• The machine is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or by persons lacking the
required experience and knowledge.
• The operating manual should always be available at the machine’s place of
use and should therefore be stored with the machine.
The short instructions do not replace this operating manual and are only to
be understood as instructions for use.
• Please hand over these documents to the new owner/operator on sale or
rental of the device. Have the hand-over confirmed!
• The labels attached to the machine provide important information for safe
operation. Renew labels that are no longer legible or present.
• With Hako-AntiBac® machine variants, the plastic inner surface of the
solution and waste water tanks contains silver ions in nanoparticle form.
• Spare parts must be original spare parts to guarantee safety.
1.3 Operating safety instructions
Before putting into service
• Before initially starting up the machine, charge the used battery fully and
appropriately with commissioning charge. Please observe the operating
manual of the charger and the operating manual of the battery manufac-
turer, which are enclosed with each Li-Ion battery. Hako assumes no
liability for battery damage resulting from insufficient commissioning
charge.
• Check the machine for operating safety before every start-up! Eliminate
faults immediately.
• Before starting work, the operator must familiarise themselves with all the
equipment, controls and actuating elements as well as with their function!
Note
Before starting up the machine, readthe following safety instructions
and act accordingly. Machine operating errors can be avoided and
trouble-free operation can be guaranteed only with precise factual
knowledge.

01-7150-00.fm 9
Safety instructions
During operation
• Sturdy and slip-proof shoes must be worn when working with the machine.
• Only those surfaces approved by the contractor or its authorised represent-
ative for use of the machine may be cleaned.
• When working with the machine, pay special attention to third persons,
especially children.
• When driving over thresholds up to 1 cm high, pull the machine over the
threshold in transport position. For thresholds over 1 cm high, lift the
machine by the handle loop and place it over the threshold.
• Only use detergents suitable for automatic machines (foam retarded) and
observe the application, disposal and warning instructions provided by the
detergent manufacturer.
• The machine is not suitable for removing liquids, dusts or materials that are
dangerous to health, combustible or explosive. It is also prohibited to collect
burning objects, e.g. glowing cigarettes. The collection of dry wood dust,
e.g. beech and oak dust, is also prohibited – health hazard!
• The machine must not be used in potentially explosive atmospheres.
• Warning! The machine should only be used on level surfaces with
a maximum slope of 2 %.
• Manipulating the switches and protective devices is forbidden.
1.4 Maintenance instructions
• Daily and weekly maintenance work must be done in accordance with the
maintenance plan by the operating staff. In all other maintenance work,
please contact your nearest Hako service centre.
• The maintenance work and maintenance intervals specified in the
operating manual must be complied with.
• Use suitable tools for the cleaning and maintenance work.
• Have the machine checked for safe condition by an expert in accordance
with the accident prevention regulations at appropriate intervals (we
recommend at least once yearly).
• Spare parts must at least comply with the technical requirements specified
by the manufacturer. This is guaranteed by original spare parts.
• Turn the machine off for cleaning and maintaining the machine as well as
before replacing parts.
• Cleaning the machine with a high-pressure cleaner or steam jet is not
allowed.
• Application of aggressive and corrosive detergents is not allowed.

10 01-7150-00.fm
Safety instructions
1.5 Information about special risks
Magnets
There is a magnet in the area of the solution tank and the waste water tank.
Warning! Magnets can affect the function of pacemakers and implanted
defibrillators.
• If you have such a device, keep a minimum distance of 80 mm to the
magnet.
• Warn people with a pacemaker and implanted defibrillator not to approach
magnets.
Caution! Magnets generate a far-reaching, strong magnetic field that can
damage credit cards, debit cards, mechanical watches and hearing aids.
• Keep objects that can be damaged by strong magnetic fields away from
the magnet.
Electrical system
• If the electrical system is faulty, always turn off the machine and eliminate
the fault.
• Work on the electrical system may be done only in accordance with
electrical engineering standards by a specialist trained for this work.
• Regularly inspect/check the electrical system of the machine. Defects such
as loose connections, loose nuts of electrified bolts, electrical components
or damaged cables must be eliminated immediately.
• Only use original fuses with the specified current. If stronger fuses are
used, the electrical system can be destroyed and there can be fires.

01-7150-00.fm 11
Safety instructions
Batteries
• Observe the operating manuals and safety instructions provided by the
battery manufacturer! The operating manual is enclosed with the battery.
• Only use the Hako charger supplied to charge the battery.
• Make sure that the batteries are never fully discharged; recharge them as
quickly as possible.
• Only instructed operating staff must handle and change batteries.
• Risk of explosion! Do not heat up the battery or place it in a fire.
• Do not drop or damage the battery.
• Caution! Always make sure that the batteries are clean and dry to avoid
creeping currents. Protect the batteries, in particular, against conductive
contamination, e.g. metal dust.
• Risk of short circuits and spark formation! Do not touch the battery
terminals with metal objects and do not insert metal objects through
openings in the battery!
• Risk of short circuit! During storage, keep the battery away from metal
objects such as paper clips, coins, nails or similar.
• If liquid escapes from the battery or there is a strange smell, remove the
battery from all heat sources or flames! There is a risk of fire or breakage
if the escaping liquid or gas ignites.
• Keep the battery out of the reach of children.
• For further safety instructions, see Hako supplementary sheet 88-60-2556
– information for drive batteries.

12 01-7150-00.fm
Safety instructions
1.6 Environmental protection instructions and disposal
If the end of use of the machine or of its components is reached and this is
handed over for scrapping, the components must be correctly disposed of.
Further information about disposal is available through the competent local
authorities and the authorised Hako dealers.
• Observe the applicable laws and local regulations when disposing of dirt,
waste water and detergents.
• Used batteries with the recycling symbol contain reusable commodities.
In accordance with the symbol showing the crossed-out garbage bin, these
batteries must not be disposed of in the domestic waste. Return and
recycling have to be arranged with the authorised Hako dealer!
• Observe the local regulations when disposing of the AntiBac® tanks, e.g.
take the AntiBac® tanks to a suitable disposal site or incineration plant.
Do not dispose of products with this symbol in domestic waste.
Disposal takes place through local collecting points or the
manufacturer.
Recycle used materials with this symbol according to their
labelling and do not dispose of them in domestic waste.

01-7150-00.fm 13
Safety instructions
1.7 Labels on the machine
The following safety and instruction labels are affixed to the machine in a
clearly visible and legible manner. Renew missing or illegible labels promptly!
A
B
C
D
Fig. 1
E
A
B
F
C
E
1 2
3
B
D
F
G
G

14 01-7150-00.fm
Safety instructions
Hako company logo
The Hako company logo Fig. 1-A is located on the front of the waste water
tank.
Label: Machine type:
The label Fig. 1-B is located on both sides underneath the solution tank.
Type plate
The type plate Fig. 1-C is located above the solution tank.
Label:
- Read and observe the operating manual Fig. 1-D1
- Never clean the machine with a high-pressure cleaner Fig. 1-D2
- Maximum permissible slope 2 % when cleaning Fig. 1-D3
The label is located on the electronics cover.
Label: QR code
The label Fig. 1-E is located on the container holder.
Label: AGR
The label Fig. 1-F is located on the tank cap.
Printing – Do not dispose of AntiBac® tanks in the domestic waste –
observe the information stipulated in the operating manual!
The printing is located on the AntiBac®tanks.
Label: Magnets
Magnets can affect the function of pacemakers and implanted defibrillators.
The label is located under the magnet on the chassis.

02-7150-00.fm 15
Use
2 Use
2.1 Overviews
2.1.1 Front and rear view
Item Designation
1Operating handle
2Bar
Fig. 2
1
2
3
4
7
8
9
10
711
12
13
6
14
15

16 02-7150-00.fm
Use
3Tank cap
4Waste water tank with handle
5Handle loop
6Battery
7Cleaning tools
8Rotary lock of operating bar
9Locking bolt of tank locking device
10 Solution tank
11 Squeegee
12 Stand for park position
13 Suction turbine hose
14 Waste water suction hose
15 Level indicator for waste water tank

02-7150-00.fm 17
Use
2.1.2 Control panel
Item Designation
1Button – fresh water dosing
2Button – drive of the cleaning tools
3Button – ON/OFF
4Button – suction turbine
5Button – ECO mode
6Symbol – drive of the cleaning tools
7Symbol – suction turbine
8Indicator – operating hours meter / service code
9Symbol – ECO mode
10 Indicator – battery charging state
11 No function
12 Indicator – water quantity
Fig. 3 5 4
6
3 2 1
8
7
9
10
11
12

18 02-7150-00.fm
Use
2.2 Controls and display elements
2.2.1 Control panel
The individual functions of the buttons on the control panel are described
below. The respective active functions are visible as corresponding symbols
in white on the display panel. If the symbols are shown in yellow, the functions
are in standby mode.
ON/OFF button Fig. 3-3
The machine is turned on and off with this button.
• Press the button for approx. 3 seconds: The machine is turned on.
Note
If the machine is not operated immediately, it goes into Machine lock mode
after approx. 10 seconds. The Lock symbol appears on the display panel.
Briefly press the ON/OFF button again to deactivate the machine lock.
• Press the button briefly: The suction turbine is switched on and off.
After unlocking the operating bar, the drive of the cleaning tools and the
water supply start.
Note
After switching off, the suction turbine continues to run for
approx. 10 seconds to absorb residual water.
• Press the button for approx. 3 seconds: The machine is turned off.
Suction turbine button Fig. 3-4
The suction turbine is switched on and off irrespective of the drive of the
cleaning tools with this button.

02-7150-00.fm 19
Use
ECO mode button Fig. 3-5
ECO mode is switched on and off with this button.
After turning on the machine, ECO mode starts automatically.
If ECO mode is switched off, the speed of the cleaning tools increases.
Cleaning tools button Fig. 3-2
The drive of the cleaning tools is switched on and off with this button.
Fresh water dosing button Fig. 3-1
The fresh water quantity can be set or switched off in three levels with this
button.
Push the button to increase the water quantity by one level. After reaching
level 3, push the button again to deactivate the water supply. Pushing the
button again activates the water supply with the lowest water quantity
(level 1).
L
Operating hours meter / Service code indicator Fig. 3-8
The current status of the operating hours is displayed.
If a service case occurs, the red spanner appears with a four-digit service
code, see section 5.8.

20 02-7150-00.fm
Use
Charging state indicator Fig. 3-10
The charging state of the battery is indicated on the display panel during
operation. The number of bars shown indicates the charging state:
• Five green bars visible: Battery is 100 % charged.
• Four green bars visible: Battery is approx. 80 % charged.
• Three green bars visible: Battery is approx. 60 % charged.
• Two green bars visible: Battery is approx. 40 % charged.
• One green bar visible: Battery is approx. 20 % charged.
• One yellow bar visible: Machine can only be operated for
approx. 2 minutes.
Charge the battery immediately!
• One red bar visible: Battery is empty. All functions are switched off.
