Halsey Taylor HT-EBP E Series User manual

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98)Page1
TheseseriesfountainsareamongtheeasiesttoinstallFountainsonthemarket
today. Toassureyouinstallthesemodelseasilyandcorrectly,
PLEASEREADTHESESIMPLEINSTRUCTIONSBEFORESTARTINGTHE
INSTALLATION.CHECKYOURINSTALLATIONFORCOMPLIANCEWITH
PLUMBING,ELECTRICAL,ANDOTHERAPPLICABLECODES.Afterinstallation,
leavetheseinstructionswiththeFountainforfuturereference.
HalseyTaylorOwnersManual
Wall Mount Steel Fountains
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THEGROUNDINGOFELECTRICALEQUIPMENTSUCHASTELEPHONE,COMPUTERS,ETC.TO
WATERLINES IS A COMMONPROCEDURE.THIS GROUNDING MAYBEINTHEBUILDINGOR MAY
OCCURAWAY FROM THE BUILDING. THIS GROUNDINGCANCAUSEELECTRICALFEEDBACK
INTOAFOUNTAIN, CREATINGANELECTROLYSIS WHICH CAUSES AMETALLIC TASTE OR AN
INCREASEINTHEMETALCONTENTOFTHEWATER.THISCONDITIONISAVOIDABLEBYUSING
THEPROPERMATERIALSASINDICATED. ANYDRAINFITTINGSPROVIDEDBYTHEINSTALLER
SHOULDBEMADEOFPLASTICTOELECTRICALLYISOLATETHEFOUNTAINFROMTHEBUILDING
PLUMBINGSYSTEM.
INSTALLER
TUBE IS
SECURED
IN POSITION
SIMPLY PUSH IN
TUBE TO ATTACH PUSH IN COLLET TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
FIG. 1
OPERATIONOFQUICKCONNECTFITTINGS
FIG. 2
NOTE: WATER FLOW
DIRECTION
BUILDINGWATERINLET
SERVICESTOP
(NOT FURNISHED)
1/4"O.D.TUBE
WATERINLET
TOCOOLER
3/8"O.D.UNPLATED
COPPERTUBE CONNECT
COLDWATERSUPPLY

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98) Page2
HT - EBP/SBP/SEBP/ESBP COOLER INSTALLATION
1. Wall should already be framed for the fountain using therough-in dimensions shown
inFig’s. 3,4,5, or6. Shown dimensionspertain to installationlocation (framing mustsupport
upto 150 lbs.weight for singlefountain and300 lbs. fordual fountains). Thesedimensions
are required for compliance with ANSI Standard A117.0.
2. Attach hanger bracket to wall as shown in Fig’s. 3,4,5, or 6 using 5/16" x 3/4" long bolts and
flatwashers (notprovided). Tighten securely.
3. Install back panel. Placethe upper edgeofthe panelabovehanger on thewall. Slide the
paneldown until it engagesthe hanger. Be sureback panel is firmlyengaged before
releasing it.
4. Install rough-in plumbing asshownin Fig’s.3,4,5,or 6. Waste line should extend a
minimumof 2"(51mm) thruthe backpanel. Runsupply waterinletline thru backpanel.
Installaservice stop(notprovided). Turn onsupplywater andflushthoroughly.
5. Remove bottom access panel fromfountainbasin andsave thescrews. Installthe fountain
to the back panel and wall using (4) 5/16 “ x 2” long lag bolts and washers (not provided)
thruholes inback panel.Tightensecurely.
6. Cut waste tube to required length using plumbing hardware and trap (not provided) as a
guide.Install hardwareandtrap. Tighten securely.
7. Make water supply connections fromservicestop tothe fountain strainer.Insertthe
water inlet line into the inlet side of strainer until it reaches a positive stop - about 3/4"
(SeeFig. 2).Turnonwater supplyand checkfor leaks. Newlyinstalled watersupply line
should be insulated after leak check is completed. DO NOT SOLDER TUBES INSERTED
INTO THE STRAINER AS DAMAGE TO THE O-RINGS MAY RESULT.
8. Check stream height from bubbler. Streamheight is factorysetat 45-50 PSI.Ifsupply
pressurevaries greatly fromthis, adjust thescrew onregulator (item 13,on page 7).
Clockwiseadjustment willraise stream heightand counter-clockwisewill lowerstream
height.For bestadjustment stream heightshould beapproximately 1-1/2"(38mm) above
the bubbler guard. (See Figure 8)
9. Water Valve Mechanism - ADJUSTMENT PROCEDURE:
-Turnadjustmentscrew(Item 7,page 7)counter-clockwiseuntil waterflow from
bubbler starts
-Turnadjustmentscrew clockwiseuntil water flowstops, thenturn an additional
1/2 turn
10. Replace bottom access paneltofountain usingthe screws provided.Tightensecurely.

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98)Page3
FIG. 3
HT - EBP
LEGEND:
A = 3/8” O.D. UNPLATED COPPER TUBE CONNECT (WATER SUPPLY)
B = 1-1/4” O.D. WASTE TUBE (ELBOW AND TRAP NOT PROVIDED)

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98) Page4
FIG. 4
HT - SBP
LEGEND:
A = 3/8” O.D. UNPLATED COPPER TUBE CONNECT (WATER SUPPLY)
B = 1-1/4” O.D. WASTE TUBE (ELBOW AND TRAP NOT PROVIDED)

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98)Page5
FIG. 5
HT - SEBP
LEGEND:
A = 3/8” O.D. UNPLATED COPPER TUBE CONNECT (WATER SUPPLY)
B = 1-1/4” O.D. WASTE TUBE (ELBOW AND TRAP NOT PROVIDED)

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98) Page6
FIG. 6
HT - ESBP
LEGEND:
A = 3/8” O.D. UNPLATED COPPER TUBE CONNECT (WATER SUPPLY)
B = 1-1/4” O.D. WASTE TUBE (ELBOW AND TRAP NOT PROVIDED)

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98)Page7
ITEMIZEDPARTSLIST
ITEMNO. PARTNO. DESCRIPTION
26936C
26935C
27237C
75517C
70378C
75555C
70856C
55859C
101514331640
111411743620
40045C
15005C
61313C
50986C
50198C
55899C
27073C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Push Lever Assy
Mounting Bracket Assy
Bracket - Pushbar
Lever Rod
Pushbar Rod
SpringClip
Screw - #10-24 x .38 PHMS
Pushbar - Side & Front
Pushbar Insert
Nut - 1/4, Self Thread
Regulator Hex Nut
RegulatorRetaining Nut
Regulator
Regulator Holder
Snap Bushing
Pad - Window Filler
BackingPlate
FIG. 8
FIG. 7

HT - EBP*E HT - SBP*E HT - SEBP*K HT - ESBP*K
97086C (Rev. B - 4/98) Page8
PRINTEDINU.S.A.
2222CAMDEN COURT
OAKBROOK,IL60523
ITEMIZEDPARTSLIST
ITEMNO. PARTNO. DESCRIPTION
51546C
45397C
66318C
10080C
100322740560
160270508640
410270508450
161637308640
411637308450
100147140560
66346C
66343C
26868C
26869C
26870C
26871C
23001C
23002C
23189C
23190C
23187C
23188C
27043C
27048C
27261C
27262C
55884C
55885C
70055C
55996C
1
2
3
4
5
6
7
8
9
10
11
12
13
NS
NS
Bubbler-Satin
Bubbler-Golden Bronzetone
Tube Assy-Bubbler
Nipple-Bubbler (Included w/Item No.2)
Gasket-Bubbler (2-Req’d)
Strainer Plate
Strainer Plate-Golden Bronzetone
DrainPlug
Drain Plug-Golden Bronztone
Gasket-Drain
Tube-Waste(HT-EBP)
Tube-Waste (HT-SBP)
Basin-Stainless Steel (HT-EBP)
Basin-Golden Bronzetone (HT-EBP)
Basin-Stainless Steel (HT-SBP)
Basin-Golden Bronzetone (HT-SBP)
Cover-Bottom(HT-EBP)
Cover-Bottom(HT-SBP)
Panel-StainlessSteel (HT-EBP)
Panel-GoldenBronzetone (HT-EBP)
Panel-StainlessSteel(HT-SBP)
Panel-Golden Bronzetone (HT-SBP)
Panel-StainlessSteel (HT-SEBP)
Panel-GoldenBronzetone (HT-SEBP)
Panel-StainlessSteel (HT-ESBP)
Panel-GoldenBronzetone (HT-ESBP)
Elbow-Drain
Nut 1-1/4 Slip Joint
Nut - Speed
Strainer (See Page 1, Fig. 2)
Orifice Assy: Mineral deposits on orifice can cause water flow to spurt or
not regulate. Mineral deposits may be removed from the orifice with a small
round file not over 1/8" diameter or small diameter wire. CAUTION: DO NOT
file or cut orifice material.
Stream Regulator: If orifice is clean, regulate flow as in “START UP”
instructions on page 2. If replacement is necessary, see parts list for
correct regulator part number.
Actuation of Quick Connect Water Fittings: Cooler is provided with
lead-free connectors which utilize an o-ring water seal. To remove tubing
from the fitting, relieve water pressure, push in on the gray collar while
pulling on the tubing.(see Fig.1) To insert tubing, push tube straight into
fitting until it reaches a positive stop, approximately 3/4".
CAUTION: Cleaning of Bronzetone Models requires special care.
Outer surfaces must be cleaned with mild detergent or mixture of vinegar
and water only, rinsed and wiped dry. Abrasive and acidic cleaners may
eventually damage the Bronzetone finish.
TROUBLE SHOOTING & MAINTENANCE
