Halsey Taylor SCWT4A-CB-Q 1E Series User manual

SCWT4A-CB-Q*1E SCWT8A-CB-Q*1E SCWT14A-CB-Q*1E
97037C (Rev. A - 4/98)PAGE 1
HALSEY TAYLOR OWNERS MANUAL
USES HFC-134A REFRIGERANT
FIG. 1
2,3 4
30 - SEE FIG. 5
1 - SEE FIG. 4
14,15
45
6
12,42,43
37,38
29
44
41
40 - SEE PAGE 3
39
22
7
21
13
16,17,18,19
8,9,10,11 20

SCWT4A-CB-Q*1E SCWT8A-CB-Q*1E SCWT14A-CB-Q*1E
PAGE 297037C (Rev. A - 4/98)
FIG. 2
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGURE UNA VENTILACIÓNADECUADA MANTENIENDO UN ESPACIO E 4" (102mm) (MÍN.) DE HOLGURA ENTRE LA REJILLA DE VENTILACIÓN DEL MUEBLE Y LA PARED ASSUREZ-VOUS UNE BONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LES ÉVENTS DE LENCEINTE ET LE MUR.
F = POWER CORD 4' (1219mm) LONG
CABLE ELÉCTRICO DE 4' (1219mm) PIE, DE LARGO CORDON DALIMENTATION 4' (1219mm)
G = WALL SCREW HOLES
AGUJEROS DE TORNILLOS DE PARED TROUS DE VIS DU MUR
H = 2 X 4 BLOCKING
BLOQUEO DE 2 X 4 BLOC 2 X 4
FINISHED FLOOR PISO ACABADO PLANCHER FINI
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB OUT 1-1/2 IN. (38mm)
FROM WALL SHUT OFF BY OTHERS
SE RECOMIENDA UBICAR ELTUBO CORTO DE CONEXIÓNAL TUBO DE COBRE SIN CHAPAR DE 3/8" DE DIÁM. EXT. A 1-1/2"
(38 mm) FUERADE LALLAVE DE PASO EN LA PARED COLOCADAPOR TERCEROS.
EMPLACEMENT RECOMMANDÉ D'ALIMENTATION EN EAU PAR TUBE EN CUIVRE NON PLAQUÉ DE 3/8 PO. (9,5 mm) D.E.
CONNECTANT UNE TUYAUTERIE DE 1-1/2 PO. (38 mm) DEPUIS LE ROBINET D'ARRÊT FOURNI PAR D'AUTRES.
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN
UBICACIÓN RECOMENDADA PARA EL DRENAJE DE SALIDADE AGUA, DE 1¼ DE DIÁMETRO. EMPLACEMENT RECOMMANDÉ POUR LE DRAIN DE D.E. 1-1/4" DE SORTIE DEAU.
C = 1-1/4 TRAP NOT FURNISHED
PURGADOR DE 1¼ NO PROPORCIONADO SIPHON 1-1/4 NON FOURNI
D = ELECTRICAL OUTLET LOCATION
UBICACIÓN DE LA TOMA DE ELECTRICIDAD EMPLACEMENT DE LA PRISE DE COURANT

SCWT4A-CB-Q*1E SCWT8A-CB-Q*1E SCWT14A-CB-Q*1E
97037C (Rev. A - 4/98)PAGE 3
PUSH BUTTON VALVE ADJUSTMENT
FIG. 4
1
5
242625
23,27,28
CORRECT STREAM HEIGHT
FIG. 3
22111C
22112C
22113C
30980C
31386C
31428C
50787C
70606C
70607C
70640C
70659C
70683C
70793C
22588C
1
2
3
4
5
6
7
8
9
10
11
12
13
NS
PART. NO. DESCRIPTIONITEM NO.
HOT TANK PARTS LIST
Heater Clamping Bracket
Heater Clamping Bracket (thrd)
Retaining Bracket
Heater Element & Jacket
Tank & Tube Assy
Hot Control Assy
Washer-Spacer
Drain Plug
Screw 1/4-20 x 3.00" HSHC
Screw #8-18 x 5/16" HHTC
Belleville Washer
1/4 Union
1/4 Elbow
Hot Tank Mounting Bracket
SERVICING THE HOT CONTROL AND FUSE ASSEMBLY
1. A temperature sensing non-resetable fuse in the wire is located approximately 3" (76mm) from the thermostat.
The fuse is located under the retaining bracket (Item 3) in the groove on the heater element jacket (Item 4).
2. The thermostat must be used with a washer-spacer (Item 7) and be centered in the heater element jacket for
proper temperature control. Locate the heater element jacket about 3/4" (19mm) above the bottom of the tank.
3. The heater element jacket must be fastened VERY TIGHTLY to the tank (45+/-10 inch/lbs. of torque on the mounting
screw Item 9). Failure to TIGHTEN heater element jacket may cause rapid failure of the fuse assembly.
10
3
6
7
9
11
1
2
8
13
4
5
12
ADJUST THIS SCREW TO ELIMINATE VALVE
LEVER "FREE PLAY" OR CONTINUOUS FLOW
FROM BUBBLER
STREAM HEIGHT
ADJUSTMENT SCREW

SCWT4A-CB-Q*1E SCWT8A-CB-Q*1E SCWT14A-CB-Q*1E
PAGE 497037C (Rev. A - 4/98)
ITEM NO. PART NO. DESCRIPTION
51544C
10-26399-31-640
16-02705-08-640
40-15018-42-590
55880C
66324C
66325C
66327C
35839C
35787C
35762C
31034C
31027C
19-42439-01-550
35766C
45689C
45697C
66251C
66252C
10-14534-31-640
10-15075-31-550
31490C
10-42095-43-730
70018C
40-26720-43-730
66201C
66202C
66258C
66245C
19-26685-51-550
15005C
26860C
26861C
26862C
50986C
61314C
55996C
40580C
33659000
40596C
40597C
51543C
70921C
92712C
21591C
30010C
55832C
31397C
22588C
55913C
55885C
See Color Table
See Color Table
See Color Table
Bubbler
Drain Plug
Strainer Plate
Basin
Bracket-Regulator Mounting
Evaporator (4 GPH)
Evaporator (8 GPH)
Evaporator (14 GPH)
Cold Control
Compressor Serv. Pak (4 & 8 GPH)
Compressor Serv. Pak (14 GPH)
Overload/Relay Assy (4 & 8 GPH)
Overload/Relay Assy (14 GPH)
Electrical Shield
Relay Cover
Tailpipe Assy (4 GPH)
Precooler (8/14 GPH) Includes 55 & 56
Condenser (4 & 8 GPH)
Condenser (14 GPH)
Cap Push Button
Push Button Stem
Fan Motor
Fan Blade
Fan Blade Nut
Fan Motor Bracket
Drier (4 & 8 GPH)
Drier (14 GPH)
Heat Exchanger (4 & 8 GPH)
Heat Exchanger (14 GPH)
Power Cord
Regulator Retaining Nut
Regulator Lever
Pivot Bracket
Regulator Retaining Bracket
Regulator Holder
Regulator
Strainer
Hot Valve Assy
Gasket-Body
Shroud
Gooseneck
Lever Handle
Mounting Nut
Stem Assy
Hot Tank Switch Bracket
Hot Tank Toggle Switch
Flow Regulator Assy
Hot Tank Assy
Hot Tank Mounting Bracket
Adaptor-Drain W/O Holes
Nut 1-1/4 Slip Joint
Side Panel - Right
Side Panel - Left
Front Panel
Platinum (PV)
Almond (AV)
Slate (SV)
Stnlss Stl (SS)
401536248410
26912C
401536248440
401536242830
401536348410
26908C
401536348440
401536342830
401507448410
26904C
401507448440
401507442830
2222 CAMDEN COURT
OAK BROOK, IL 60523
630.574.3500
PRINTED IN U.S.A.
IMPRESO EN LOS E.E.U.U.
IMPRIMÉ AUX É.-U.
RIGHT PANEL FRONT PANEL
COLOR LEFT PANEL
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY, REPLACE
WITH SAME COMPRESSOR USED IN ORIGINALASSEMBLY.
NOTE: All correspondence pertaining to any of the above water coolers or
orders for repair parts MUST include Model No. and Serial No. of cooler, name
and part number of replacement part.
ITEMIZED PARTS LIST
1
2
3
4
5
6
7
8*
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
NS
WIRING DIAGRAM
This Drawing is merely for illustrating the
components of the electrical system.
FIG. 5
33 36
32
31
34
35
