Halsey Taylor HCRFERQ-B User manual

97885C (Rev. E - 7/07)
HCRFERQ-B
HalseyTaylorOwnersManual
Refrigerated Fountain with Back Panel
Toassureyouinstallthismodeleasilyandcorrectly,
PLEASEREADTHESESIMPLEINSTRUCTIONSBEFORESTARTINGTHE
INSTALLATION.CHECKYOURINSTALLATIONFORCOMPLIANCEWITH
PLUMBING,ELECTRICALANDOTHERAPPLICABLECODES.Afterinstallation,leave
theseinstructionsinsidethefountainforfuturereference.
IMPORTANT! INSTALLER PLEASE NOTE.
THEGROUNDINGOFELECTRICAL EQUIPMENTSUCHASTELEPHONE, COMPUTERS,ETC.TO
WATER LINES ISACOMMONPROCEDURE.THIS GROUNDING MAYBEINTHE BUILDINGOR MAY
OCCURAWAYFROMTHEBUILDING.THISGROUNDING CANCAUSE ELECTRICALFEEDBACK
INTOAFOUNTAIN,CREATINGAN ELECTROLYSISWHICH CAUSESAMETALLICTASTE ORAN
INCREASEINTHEMETALCONTENTOFTHEWATER.THIS CONDITIONISAVOIDABLEBYUSING
THEPROPERMATERIALSAS INDICATED.ANYDRAINFITTINGS PROVIDEDBYTHEINSTALLER
SHOULDBEMADE OFPLASTICTOELECTRICALLYISOLATETHEFOUNTAINFROMTHEBUILDING
PLUMBINGSYSTEM.
IMPORTANT
ALLSERVICE TOBE PERFORMEDBY AN AUTHORIZEDSERVICE PERSON
FIG. 2FIG. 1
HCRF-ER
Installer
NOTE: WATER FLOW
DIRECTION
BUILDINGWATER INLET
SERVICESTOP
(NOT FURNISHED)
1/4"O.D.TUBE
WATER INLET
TOCHILLER
3/8"O.D.UNPLATED
COPPERTUBECONNECT
COLDWATER SUPPLY

97885C (Rev. E - 7/07)
HCRFERQ-B
FIG. 3
PAGE 2
HCRF-ER ROUGH-IN
LEGEND:
A= 1/4" O.D. TUBE - WATER OUTLET CONNECTION
B = 3/8" O.D. TUBE - WATER INLET CONNECTION
C = 1-1/4" O.D. WASTE TUBE
D= ELECTRICAL INLET ON CHILLER

97885C (Rev. E - 7/07)
HCRFERQ-B
PAGE 3
FIG. 4
HCRF- ER COOLER INSTALLATION
1. Install remote chiller. Remove front panel of chiller. Remove and discard cardboard inner pack from between compressor
and side panel. Slide chiller onto the shelf and position it to the left within the guides on the shelf.
NOTE: Building construction must allow for adequate air flow on both sides, top, and back of chiller. A minimum of 4" (102mm) on
both sides and top are required. See chiller instructions for additional instructions.
2. Make water supply connections. The inlet port is marked on the chiller (1/4" O.D. copper tube). Bend the copper tube (provided) at
an appropriate length from chiller to opening in frame. Install the in-line strainer (provided with chiller) by pushing it in until it reachs
a positive stop, approximately 3/4" (19mm) on the marked chiller inlet port. Attach an unplated and deburred copper water inlet line
and a service stop (not provided) to the in-line strainer. Turn on the water supply and flush the line thoroughly. DO NOT SOLDER
TUBES WHILE INSERTED INTO THE STRAINERAS DAMAGE TO THE O-RINGS MAY RESULT. (See Fig. 4)
3. Hang the upper panel on the mounting frame hanger. Align holes in the panel with the holes in the mounting frame.
Be sure that panel is engaged with hanger at top of frame before releasing it.
4. Install the fountain. Remove access cover plate on underside of fountain and save the screws. Mount the fountain to the
upper panel and the wall frame with (4) 5/16" x 3/4" (19mm) long bolts and nuts (provided). Tighten securely.
5. Insert waste tube (provided) into drain on fountain. Attach waste tube (1 1/4" O.D.) to 1 1/4" O.D. slip trap (provided by others).
6. Make connections between remote chiller outlet tube and fountain. Outlet port is marked on the chiller (1/4" O.D. copper tube).
Install a 1/4" union (provided) on the marked chiller outlet port. Insert the 1/4" poly tubing coming from the fountain into the union.
Turn on the water supply and check for leaks. DO NOT SOLDER TUBES WHILE INSERTED INTO THE UNION AS DAMAGE TO
THE O-RINGS MAY RESULT. (See Fig. 4)
7. These products are designed to operate on 20-105 PSIG supply line pressure. If inlet pressure is above 105 PSIG, a pressure
regulator must be installed in the supply line. Any damage caused by reason of connecting these products to supply line
pressures lower than 20 PSIG or higher than 105 PSIG is not covered by warranty.
8. Make electrical connections to the chiller. See chiller instructions.
9. Check stream height from bubbler. Stream height is factory set at 35-40 PSI. If supply pressure varies greatly from this,
remove items 3 & 4 and adjust the screw on regulator (Item 8). Clockwise adjustment will raise stream height and counter-
clockwise will lower stream height. For best adjustment stream height should be approximately 1 1/2" (38mm) above the
bubbler guard. (See Figure 6)
10. Mount lower panel. Loosen the (2) #10-24 x 5/8" (16mm) screws at frame bottom lip. Slide upper tongue of lower panel under
lower edge of already installed upper panel. Tighten previously loosened screws securely.
11. Replace bottom access panel to fountain basin using screws provided. Tighten securely.
TROUBLESHOOTINGAND MAINTENANCE
1. Orifice Assy: Mineral deposits on orifice can cause water flow to spurt or not regulate. Mineral deposits may be removed
from orifice with a small round file not over 1/8" diameter or a small diameter wire.
CAUTION: Do not file or cut orifice materials.
2. Stream Regulator: If orifice is clean, regulate flow as in "START UP" instructions. If replacement is necessary, see parts
list for correct regulator part number.
3. Actuation of Quick Connect Water Fittings: Cooler is provided with lead-free connectors which utilize an o-ring water
seal. To remove tubing from the fitting, relieve water pressure, push in on the gray collar while pulling on the tubing (See Fig. 2)
To insert tubing, push tube straight into the fitting until it reaches a positive stop, approximately 3/4".
18 11
19
19- TO
BUBBLER
CHILLER
INLET
CHILLER
OUTLET

97885C (Rev. E - 7/07)
HCRFERQ-B
PAGE 4
PARTNO.ITEMNO. PARTSLIST
Strainer
RetainingNut
Push Button
Push Button Sleeve
Regulator Holder
Bubbler
Bubbler Nipple Assy
Regulator
Set screw - #6-32 x .31"
Screw - #10-24 X .50 PHTC
Strainer
FountainArm
BottomCover Plate
BackPanel
Hex Nut
Regulator Mounting Bracket
Lower Panel
Union - 1/4
Poly Tubing (Cut To Length)
Drain-Tail Pipe
Drain Adapter
Gasket - Tail Pipe
Gasket
Nut-RegulatorMounting
Set screw - #6-32 x .12"
EdgeTrim
Screw - Mach 5/16-18 x 3/4
Nut - Hex 5/16-18
40575C
15005C
45662C
45737C
50986C
51544C
56159C
61313C
70022C
112627543890
55996C
55001129
55000665
28280C
40045C
28291C
28281C
70683C
56092C
45769C
45805C
50074C
100322740560
45736C
70023C
56280C
111577243890
111577343890
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
NS
NS
DESCRIPTION
FIG.7
REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
2222CAMDENCOURT
OAKBROOK, IL60523
630.574.3500 PRINTEDINU.S.A.
FIG. 6
FIG. 5
6
7
12
19
SEE FIG. 5
19 13,10
1, 21, 22 20
17
14
SEE FIG. 6
3415 2
9
16
85
6
23
7
FIG. 8
24
25
26
