Hama Q-68HR User manual

Q-68HR00137431
Device Overview
How to wear your Q-Band HR+?
User Manual
EN
Wear Q-Band HR+ on your wrist
12
45
Chargeyour Q-Band HR+
FastenQ-Band HR+ with clasp 3Detecting your Heart Rate
Change the wristband
Put on the wristband with the screen facing up
and the band wrapped around your wrist. Slide
one band through the loop of the other band,and
align the clasp along the band to findthe holes
wherebest fitthe clasps.
Video Demo:
http://ww2.voiis.com/igotu-life/wear/Q-Band-HR-Plus
Please makesurethe wristband is worn as tightly as
possible on the wrist without anydiscomfort, in order
to enhance the accuracy of heart rate signals that
aredetected.
Wear the wristband three fingers away fromyour
wrist. When “-----“ text appears on the screen,
please staystillbriefly forabout 10 seconds to obtain
aheartratereading.
Squeezeboth clasps into the holes on the wristband
until youhear aclick, indicating the band is securely
fastened.
Note: The wristbands areboth replaceable and
reversible.
Remove the wristbands by sliding out both bands fromthe slots on both sides
of the core.
Insert the new bands into the slots on both sides of the core.
Important Notice:
Failuretofollow the instructions above might cause damage to the device.
1.
2.
1.
2.
ReversibleWristband Clasp
CoreT ouch Button
Metallic contact forcharging
Optical Sensor
2
1
Video Demo
Charging icon
1
2
3
To charge your Q-Band HR+, place it in the charging boxatthe other end
of the USB cable. Close the boxafterwards, and makesurethe Q-Band
HR+ is securely covered. Plug the USB connector to either aPCorpower
adapter to start charging.
Important Notice:
The product is shipped with the screen and keys locked, and willbeunlockedonce it is
charged via USB connection. Please makesurethe "Charging" icon appears while it is
being charged, indicating thedevice is connectedcorrectly and getting charged.

00137431 Q-68HR
Get Started with Q-Band HR+
Download i-gotU Life App
12
34
Start Using Q-Band HR+
5Screen Description
Setup Q-Band HR+
Features of Q-Band HR+ &i-gotU Life App
User Manual
Download i-gotU Life app fromGoogle PlayorApp Storeonyour
smartphone:
https://play.google.com/store/apps/details?id=com.mobileaction.ilife
http://appstore.com/igotulife
Apk download: http://global.mobileaction.com/download/apk
Supported Device
AnyAndroid smartphone(v4.3 and up) with built-in 4.0
Bluetooth connectivity; or
iPhone 4s and later models, iPad 2and later models,
and iPod Touch (allwithiOS version 7.0and up).
Acomplete list of supported smartphone models or
mobile devices can be found at:
http://ww2.voiis.com/qband/devices.html
Your Q-Band HR+ can be configured directly on the i-gotU Lifeapp.
Firsttime setup:
Charge the device to unlock the keyand screen.
Open the i-gotU Lifeapp.
ASetup Wizard willbelaunched automatically.
Follow the on-screen instructions to proceed with moresettings.
Set up anew device from Settings:
Open the i-gotU Lifeapp.
Tapthe app icon at the upper left corner to open function menu.
Choose Settings.
Tap Setup New Device under MORE DEVICE SETTINGS.
Follow the on-screen instructions to continue.
Note
Your personal information is used to calculate your Base Metabolic
Rate (BMR), which determines your calories burned.
1.
2.
3.
4.
1.
2.
3.
4.
5.
1. Switch betweendifferent function modes
2. Change display information
3. Q-Band HR+ modes
1. Tapthe button twice to wake up the device screen.
2. Long-press the button on the Q-Band HR+ untilyou see4icons
on the screenfor mode selection.
3. Tapthe button twice to switch mode.
4. You’ll be entering the selected mode in 3seconds.
Information shown on the screen willvary as youpress the
button on the Q-Band HR+ to toggle between screens.
Daily mode: Analyzes your dailydata, includingsteps taken
and calories burned.
Sleep mode: Tracks your sleep pattern and quality.
Sports mode: Startsaworkout and displays information
including duration, steps taken, calories burned, and distance
traveled duringthe workout.
Nap mode: Awakes youvia vibration after ashort nap.
1
2
3
4
5
6
7
8
9
10
Connecting
Disconnected
Alarm
Daily Mode
Date
OverallProgress
(the average of Calories +Steps)
Battery Status
Steps
Calories
Heart Rate
11
12
13
Aerobic (Zone3and above)
Duration
Distance
Silent Alarm
Notification
Online Help
Manual download
Frequently Asked Questions
Silent alarm of Q-Band HR+ gives youawake-up alert via soft
vibrations. While in the sleep mode, the alarm can be dismissed by
long-pressing the button on Q-Band HR+.Bypressing the button once,
the alarm willnot be dismissed but alert youagain in 5minutes. Alarm
settingscan be changed in: open i-gotU Lifeapp >Menu >Silent Alarm.
Youwillbenotified with incoming calls, SMS, E-Mail, or alerts fromthe
social apps via vibration. When notified about an incomingcallonan
Android smartphone, youmay reject the callbylong-pressing the button
on Q-Band HR+. Notification can be set up from: i-gotU Life App Menu
-> Notification.
•
•
•
Important Notice
Please makesureyour Q-Band HR+isfully charged when used forthe
first time. It takes about 2hours beforeitisfully charged.
Although the device is usable in the rain, its use under water is
prohibited. Please avoid showering or sauna/steam bathing because
high temperature, steam and water jet maycause damage to the
device.
Please do not use anycorrosivechemical to clean the device.
The built-in Li-Polymer Battery might be damaged if it remains low
voltage foralongtime. It is suggested that youcharge the battery once
every three months to prolong the battery'slifetime, even though you
don't use the device very oftenordonot plan to use it forawhile.
1.
2.
3.
4.
13 524
6
8
7
9
10
11
12
13
Android: http://ww2.voiis.com/igotu-life/help.html?language=en
iOS: http://ww2.voiis.com/igotu-life/help.html?language=en&platform=ios
http://www.mobileaction.com/download/Q-Band_download.jsp
http://www.mobileaction.com/Q68HR-FAQ
Recycling Information
Note on environmental protection:
After the implementation of the European Directive2012/19/EU and 2006/66/EU in the
national legal system, the following applies: Electric and electronic devices as wellas
batteries must not be disposed of with household waste. Consumers areobliged by law
to return electrical and electronic devices as wellasbatteries at the end of their service
lives to the public collecting points set up forthis purpose or point of sale. Details to this
aredefined by the national lawofthe respectivecountry.This symbol on theproduct,
the instruction manual or the package indicates that aproduct is subject to these
regulations. By recycling, reusing the materials or other forms of utilising old
devices/batteries, youare making an important contribution to protecting our
environment.
Declaration of Conformity
Hereby,Hama GmbH &CoKGdeclares that the radio equipment type [00137431] is in
compliance with Directive2014/53/EU.The full text of the EU declaration of conformityis
available at the following internet address: www.hama.com -> 00137431 -> Downloads.
Frequency band(s)
Maximum radio-frequency power transmitted
2402 –2408 MHz
0.55 mW EIRP
