Hama 00054852 User manual

F
D
GB
E
Quick Guide
Kurzanleitung
Notice d’utilisation
Instrucciones breves
Краткое руководство
Istruzioni brevi
Beknopte bedieningsinstructies
Σύντομες οδηγίες
Krótka instrukcja obsługi
Rövid útmutató
Stručný návod
Stručný návod
Instruções resumidas
Kısa kullanımkılavuzu
Instrucțiuni scurte
Snabbguide
Lyhyt ohje
Kort vejledning
Kortveiledning
Mini Soundbar with subwoofer
Mini Soundbar mit Subwoofer
RUS
PL
P
I
H
TR
FIN
NL
CZ
RO
DK
GR
SK
S
N
00054852
(SIRIUM3800ABT)

Further information and features are
available on:
WeitereInformationen und Features nden
Sie hier:
00054852
Alexa Voice Service /Alexa Voice Service
Voice Control
Sprachsteuerung
ü
Number of Microphones
Anzahl der Mikrofone 3
Microphone Array
Mikrofon-Array Far-Field
Connectivity/Konnektivität
WiFi (Standard); (Encryption, WPS)
WiFi (Standard); (Verschlüsselung, WPS)
WiFi 2.4GHz (b/g/n)
2x2 Mimo; WPA,
WPA2, WPS
Bluetooth (Standard) 4.0
USB Playback
Digital Optical IN
ü
Digital Coaxial IN
ü
RCA(Cinch) IN
ü
AUX-IN
ü
Equalizer /DSP /Equalizer /DSP
Proles
Prole
3modes (CINEMA,
MUSIC, VOICE)
Streaming / Streaming
WiStream (DLNA compatible)
WiStream (DLNA-kompatibel)
ü
UPNP
ü
Speaker/ Lautsprecher
Full Range Driver
Vollbereich-Lautsprecher 2x 2.5"
Frequency Range
Frequenzreichweite 20 Hz ~20KHz
Amplier Class
Amplier-Klasse Class D
Other Details and Specication/
AndereDetails und Spezikationen
Remote
Fernbedienung Hama SRC-1805
Batterys
Batterien 2x AAA
Wall Mount Possibility
Möglichkeit zur Wandaufhängung
ü
Power Consumption Soundbar
Energieverbrauch Soundbar
max. 30 W
Standby: <3W
Power Consumption Subwoofer
Energieverbrauch Subwoofer
max. 45 W
Standby: <0.5 W
Dimensions (W xHxD)
Größe (B xHxT)
43.5 cm x10.2 cm x
8.4 cm
Weight
Gewicht
Subwoofer 5285 g
Soundbar 1743 g
Subwoofer/ Tieftöner
Driver
Treiber 1x 6.5"
Frequency Range
Frequenzreichweite 20 Hz ~150 Hz
Amplier Class
Amplier-Klasse Class D
Standards &Decoders/Standards &Decoder
Dolby Certication
Dolby zertiziert Dolby 2.1
Max. Audio Resolution (Hi-Res)
Max. Tonauösung (Hi-Res) 192 kHz /24bit
Supported Hi-Res Audio Codecs
Unterstützte Hi-Res Audio Codecs FLAC, ALAC

1 2
2 4 6 8
3 4
5 6 87 9 10
1
3
99
75
USB
Optical
Coaxial
AUX
Dolby
Bluetooth
Line-IN
Streaming
A
D
B
1

56
1
3
79
10 12
13 16
15
2
8
11
14
4
C
BASS –
VOL +
VOL –
BASS +
CINEMA MUSIC VOICE
Coax IN Line-IN AUX
Bluetooth Optical IN

2
GQuick Guide
Controls and Displays
ASoundbar control panel
1. [POWER] button
2. [MODE] button
3. [ACTION /MICROPHONE MUTE] button
4. [VOLUME] +/- buttons
5. Network status LED
6. Streaming status LED
7. Bluetooth/USB status LED
8. Optical/Coaxial status LED
9. AUX/Line In status LED
10. Dolby status LED
BRear
1. Line In socket L/R
2. AUX In socket
3. Coaxial socket
4. Optical In socket
5. [PAIRING] button (pairing with network)
6. USB playback
7. [PAIRING] button (pairing with subwoofer)
8. Mains lead
9. Thread for attaching to the wall bracket
Important note –Operating instructions:
•This is aquick guide to provide you with the most important basic information, such as safety warnings and how to
get started using the product.
•Forthe sake of protecting the environment and saving resources, Hama dispenses with printed operating instructions
and provides them only in the form of PDF les /eManuals on www.hama.com.
•Use the search function with the item number of your product to easily nd the product documentation.
•Alternatively,scan the QR code below to be taken directly to the location of the operating instructions.
•Save the operating instructions to your computer’sharddrive for futurereference, or print it out if necessary.
CRemote Control
1. [POWER] button
2. [MUTE] button
3. [ACTION] button
4. [MUTE] button for microphone
5. [BASS] +/- buttons
6. [VOLUME] +/- buttons
7. CINEMA
8. MUSIC
9. VOICE
10. COAX IN mode
11. LINE IN mode
12. AUX IN mode
13. BLUETOOTH mode
14. [FORWARD] button
15. [PLAY/PAUSE] button
16. OPTICAL IN mode
DSubwoofer
1. [PAIRING] button subwoofer

3
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to
draw your attention to specichazards and risks.
Note
This symbol is used to indicate additional information or
important notes.
Risk of electric shock
This symbol indicates product parts energized with a
dangerous voltage of sucient magnitude to constitute
arisk of electric shock.
2. Package Contents
•Soundbar
•Subwoofer
•Remote control
•2x AAA batteries
•1xoptical signal cable
•AC/DC adapter
•Quick guide, brochure
3. Safety Notes
•The product is intended for private, non-commercial use
only.
•Protect the product from dirt, moistureand overheating
and use it in dry rooms only.
•As with all electrical devices, this device should be kept
out of the reach of children.
•Do not drop the product and do not expose it to any
major shocks.
•Do not operate the product outside the power limits
given in the specications.
•Keep the packaging material out of the reach of children
due to the risk of suffocation.
•Dispose of packaging material immediately according to
locally applicable regulations.
•Do not modify the device in any way.Doing so voids the
warranty.
Risk of electric shock
•Do not open the device or continue to operate it if it
becomes damaged.
•Do not use the product if the AC adapter,adapter
cable or power cable is damaged.
•Do not attempt to service or repair the device
yourself.Leave any service work to qualied experts.
Warning –Batteries:
•When inserting batteries, note the correct polarity (+
and -markings) and insert the batteries accordingly.
Failuretodosocould result in the batteries leaking
or exploding.
•Do not allow children to change batteries without
supervision.
•Do not mix old and new batteries or batteries of a
different type or make.
•Remove the batteries from products that arenot
being used for an extended period
•Do not short-circuit batteries.
•Do not charge batteries.
•Do not throw batteries in a re.
•Keep batteries out of the reach of children.
4. Before getting started
Getting started with the remote control
Open the battery compartment cover.Itis located on the
rear of the remote control and can be opened by sliding it
in the direction indicated.
TwoAAA batteries areincluded in the delivery,they should
be inserted in the battery compartment of the remote
control. Observe the correct polarity when inserting
batteries. The polarity (+ /-)is indicated in the battery
compartment.

4
5. Getting started
Warning
•Connect the product only to asocket that has been
approved for the device. The socket must be installed
close to the product and must be easily accessible.
•Disconnect the product from the power supply using
the on/off switch –ifthis is not available, unplug the
power cordfromthe socket.
•When using amult-socket power strip, make sure
that the sum power draw of all the connected devices
does not exceed its maximum throughput rating.
•If you will not be using the product for along period
of time, disconnect it from mains power.
Turning on the product
•Connect the power cables of the soundbar and the
subwoofer to properly installed power sockets.
•Press [POWER](1) to switch on the soundbar.
Alternatively,press the [POWER]button (1) on the
remote control.
Note –Turning on for the rst time
•In the as-shipped state, the soundbar and subwoofer
arealready paired.
•When switched on for the rst time, the soundbar is
in ‘First-time setup of device’ mode as soon as the
network status LED (5) pulsates.
6. Setting up the soundbar
Note
•To be able to use the product’sfull range of functions,
you must additionally download the Amazon Alexa
app and create an Amazon account. Forthis purpose,
follow the instructions in the Amazon Alexa app.
Further information can be found at www.amazon.
co.uk
•Make surethat your terminal device has the necessary
ports for connection to the soundbar.Please refer to
the operating instructions for the terminal device you
areusing.
6.1. Downloading the Hama Smart Audio app
Note
The following operating systems aresupported:
•iOS 8orhigher
•Android 4.4.2 or higher
•Open the iTunes App StoreorGoogle Play Storeonyour
smartphone.
•Use the search function to nd the app.
•Download the app in the usual way and install it on your
smartphone. To do this, follow the instructions on your
smartphone.
6.2. First-time setup of the device with the Hama
Smart Audio app (ALEXA function)
Note –WLAN (wireless network)
•Ensurethat the router is switched on, is functioning
correctly and that thereisaconnection to the internet.
•Activate the WLAN function of your router.
•Followyour router´s operating instructions as regards
the correct functioning of the WLAN connection.
•Make surethat the soundbar is in WLAN pairing mode.
The network status LED (5) pulsates.
•Make surethat the Hama Smart Audio app is installed
on your smartphone.
•Open the Hama Smart Audio app and tap
[CONFIGURE].
•Then tap [Add MoreSpeakers].
•Open your smartphone’sWLAN settings by tapping
[OPEN Settings].
•Search for the Hama SIRIUM3800ABT soundbar in
your smartphone’sWLAN settings.
•Connect your smartphone to the soundbar.
•Now open the Hama Smart Audio app on your
smartphone.
•Select the desired WLAN name (SSID).
•Now enter your network key and conrm with [Save].
•Conrm the selected settings by tapping [CONFIRM].
•The soundbar now connects to the network. After
successful connection, the message ‘Congured
Successfully Hama Soundbar’ is displayed on your
smartphone.
•The network status LED (5) is now constantly lit blue.
•Tap [Sources]atthe lower edge of the screen to set up
aconnection to your Amazon account.
•Then tap the [Amazon Alexa] button.
•Tap [Signinwith Amazon]toopen the Webbrowser
for entering your access data.
•Enter the access data for your Amazon account using
your smartphone’skeyboard.
•Alternatively,you can create anew Amazon account by
tapping [Create anew Amazon account].

5
•After successful sign-in, you return to the Hama Smart
Audio app.
•Now select the language that you want Alexa to respond
to in future.
•Open the Amazon Alexa app and enter your access data
once again.
•Then specify your personal settings (time zone, device
name, etc.) in the Amazon Alexa app. Further information
can be found at www.amazon.co.uk -> Help and
Customer Service.
Note -Alexa Push to talk/function key
•Brieypress the [Action /Microphone mute] button
(3) on the soundbar to activate Alexa during audio
operation or high volume. Alternatively,press the
Action button (3) on the remote control.
•Press and hold the [Action /Microphone mute] button
(3) for about 3seconds to switch off the microphone.
Alternatively,press the [MUTE]button (4) on the
remote control. The soundbar will now no longer
respond to the wake worduntil the microphone is
activated again. If the microphone is switched off,the
soundbar can still be operated using the buttons on
the soundbar or remote control.
7. Bluetooth pairing
Youcan pair your terminal device with the soundbar via
Bluetooth and use the soundbar as aplayback device for
audio signals. Youcan control playback directly on your
terminal device or using the remote control. The volume
can also be controlled directly on the soundbar.
Note –Bluetooth®
•Check whether your mobile device (smartphone,
tablet, etc.) is Bluetooth®-capable.
•Note that the maximum range for Bluetooth®is 10
metres without obstacles such as walls, people, etc.
•The Bluetooth®connection may be disrupted by other
Bluetooth®devices/connections in the vicinity.
•It is only possible to connect the soundbar to one
terminal device.
•Note that compatibility depends on the supported
Bluetooth®proles as well as the Bluetooth®versions
being used. (See Technical specications, operating
instructions of the terminal device in use)
•Make surethat your Bluetooth-capable terminal device
is on and Bluetooth is activated.
•Activate the Bluetooth mode by repeatedly pressing the
[MODE]button (2) on the soundbar.
•Alternatively,press [Bluetooth] (13) on the remote
control.
•The Bluetooth status LED (7) begins to pulsate blue.
•Press and hold [MODE](2) for about 5seconds to
activate the pairing mode. The Bluetooth status LED (7)
begins to ash quickly.
•Open the Bluetooth settings on your terminal device and
wait until Hama SIRIUM3800ABT appears in the list of
Bluetooth devices found.
•If necessary,start searching for Bluetooth devices on
your terminal device.
•Select the Hama SIRIUM3800ABT soundbar in the
list of available devices and wait until the soundbar is
shown as connected in the Bluetooth settings on your
terminal device.
•The Bluetooth status LED (7) is now constantly lit blue.
•Start and control audio playback using the controls of
your terminal device or the remote control.

6
8. Connection via Auxiliary Input /Line In
Youcan use the analogue audio inputs (Line In /AUX) to
connect mobile devices (for example, smartphone, tablet
PC, MP3 player,etc.) and older analogue sources (CD/DVD
player etc.) to the soundbar and play their audio signals
using the soundbar.For the connection, you can use either
a3.5-mm audio cable (jack cable) or an RCAcable.
Note
•Switch off the soundbar beforeconnecting aterminal
device.
•Do not bend or crush the cable.
•Forplayback using the LINE In connection, connect your
terminal device to the soundbar using the LINE In socket
(1) and an RCAcable, and select the LINE In mode.
•Forplayback using the AUX connection, connect your
terminal device to the soundbar using the AUX socket
(2) and a3.5-mm audio cable (jack cable), and select
the AUX mode.
•Press [POWER](1) to switch on the soundbar.
•Activate the Line In or AUX mode by repeatedly pressing
the [MODE] button (2) on the soundbar.
•The AUX/Line In status LED (9) is lit redifthe LINE IN
mode was selected, blue if the AUX mode was selected.
•Alternatively,press [AUX](12) on the remote control for
aconnection using a3.5-mm audio cable (jack cable), or
[LINE In](11) for aconnection using an RCAcable.
9. Connection via optical/coaxial input
Youcan use the soundbar’sdigital audio inputs to connect
your terminal device (for example, TV set) and play its
audio signals using the soundbar Forthe connection, you
can use either an optical signal cable or acoaxial cable.
Note
•Switch off the soundbar beforeconnecting aterminal
device.
•Remove the protective caps from both ends of the
optical signal cable beforeconnection.
•Do not bend or crush the cable.
•Forplayback using the optical audio input, connect one
end of the optical signal cable (supplied) to the optical
audio input (4) on the soundbar,the other end to the
optical audio output on your terminal device; then select
the Optical mode.
•Forplayback using the coaxial audio input, connect one
end of acoaxial cable to the coaxial audio input (3) on
the soundbar,the other end to the coaxial audio output
on your terminal device; then select the Coaxial mode.
•Press and hold [POWER](1) for about 3seconds to
switch on the soundbar.
•Activate the Optical or Coaxial mode by repeatedly
pressing the [MODE]button (2) on the soundbar.
•The Optical/Coaxial status LED (8) is lit blue if the
Optical mode was selected, redifthe Coaxial mode was
selected.
•Alternatively,press [Optical In](16) on the remote
control for aconnection using an optical signal cable, or
[Coax In](10) for aconnection using acoaxial cable.
10. Care and Maintenance
•Only clean this product with aslightly damp, lint-free
cloth and do not use aggressive cleaning agents.
•If you do not use the product for along time, turn off
the device and disconnect it from the power supply.
Storeitinaclean, dry place out of direct sunlight.
11. Warranty Disclaimer
Hama GmbH &Co. KG assumes no liability and provides
no warranty for damage resulting from improper
installation/mounting, improper use of the product or from
failuretoobserve the operating instructions and/or safety
notes.
12. Service and Support
Please contact Hama Product Consulting if you have any
questions about this product.
Hotline: [phone] (German/English)
Further support information can be found here:
www.hama.com
