Hammer HNC3 825 Quick guide

Operating instructions
Keep this manual to hand and in good condition for future reference!
Please read this operating manual carefully before using the machine!
Translation of the original operating instructions
HNC3 825 /
HNC3 825 perform
CNC Machining Centre
500034-900A, 5, en_GB

©2022
FELDER KG
KR-Felder-Straße 1,A-6060 HALL in Tirol, AUSTRIA
Telephone: [phone]
Email: [e-mail]
Internet: www.felder-group.com

3
HNC3 825 / HNC3 825 perform
Table of contents
Table of contents
1 Information about the manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Symbol legend. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Contents of the operating manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Liability and warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5 Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Responsibilities of the operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Requirements of the personnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Making changes and modifications to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Work safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.6 Personal protective equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.6.1 Prohibitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.6.2 Mandatory safety equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.7 Residual risks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.7.1 Transport, setup, installation and disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.7.2 Operate, maintain and troubleshoot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.8 Foreseeable misuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 Technical information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1 Technical information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2 Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Operation and storage conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.4 Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.5 Dust extraction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.6 Dust emission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.7 Noise emissions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5 Machine overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1 Safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1.1 Main switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1.2 Emergency stop button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.1.3 Protective housing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2 Pictograms, signs and labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.3 Information on the machine data plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6 Transporting, packing, storing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.1 Transport inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.2 Packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.3 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4
Table of contents
7 Setup and installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.1 Unpack machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.2 Remove transport bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.3 Commission the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.4 Mount the extraction hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.5 Mount the perform extraction hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.6 Attach the dust extraction hose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.7 Connect electrics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.8 Mount the router motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.9 Install software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.10 Integrate external software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8 Adjustments and tool changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.1 Mounting the router tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.2 Adjust the extraction hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.2.1 Adjust the perform extraction hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.3 Assemble and load the grease gun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
9 Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.1 Switch on the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.2 Operate machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.3 Switch off the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.4 Processing information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.4.1 Compensate for any bend in the workpiece. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.4.2 Influence of the tool on working accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
10 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
10.1 Maintenance schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
10.2 Lubricate the drive spindles and guiding carriage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
10.3 Check / replace the drive belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
10.4 Check protective equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
11 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
11.1 What to do in the event of malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
11.2 What to do after rectifying the fault. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
11.3 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
12 About spare parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
13 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

5
HNC3 825 / HNC3 825 perform
Information about the manual
1 Information about the manual
1.1 Symbol legend
Safety instructions
Safety instructions in this manual are indicated with symbols. The safety instruc-
tions are introduced by key words which state in words the extent of the hazard.
Comply with safety instructions under all circumstances, and act with care in order
to avoid accidents, personal injury, or material damage.
DANGER
… indicates a situation of immediate danger which will result in
death or severe injuries if it is not avoided.
WARNING
… indicates a situation of possible danger which can result in
death or severe injuries if it is not avoided.
CAUTION
… indicates a situation of possible danger which can result in
minor or slight injuries if it is not avoided.
NOTICE
… indicates a situation of possible danger which can result in
material damages if it is not avoided.
Tips and recommendations
… emphasises useful tips and recommendations as well as infor-
mation for efficient and trouble-free operation.
Symbols Explanation
Result is okay.
Result is not okay.
Procedure if result is not okay.

6
Information about the manual
1.2 Contents of the operating manual
●This operating manual describes the safe and proper use of the machine.
●All specified safety information and instructions as well as the local accident
prevention regulations and general safety regulations applicable to the area
of use must be adhered to.
●All instructions in this manual must be strictly followed without exception.
●The operating manual is an integral part of the machine. It must therefore be
kept in the direct vicinity of the machine and be accessible at all times.
●The operating manual must always accompany the machine.
1.3 Liability and warranty
●The contents and instructions in this manual have been compiled in consider-
ation of current regulations and state-of-the-art technology as well as based
on our know-how and experience acquired over many years.
●The manufacturer shall not be liable for damage and/or faults resulting from
the disregard of instructions in the manual.
●The text and images do not necessarily represent the exact product that has
been delivered. The images and graphics are not depicted on a 1:1 scale.
The product that has been delivered, may have custom-built specifications,
add-on options or recent technical modifications and may therefore deviate
from the descriptions, instructions and images contained in the manual.
●We reserve the right to make technical changes to the product in order to
improve the properties of use and further product development.
●The guarantee period is in accordance with national guidelines. Details may
be found on our website, www.felder-group.com.
●Should any questions arise, please contact the manufacturer.
1.4 Copyright
●This instruction manual is to be treated as confidential. It is intended solely
for those people who are to work on or with the machine.
●All descriptions, texts, drawings, photos and other depictions are protected
by copyright and other commercial laws.
●Any unauthorised use is prohibited.
●This manual, in its entirety or parts thereof, may not be transferred to
third parties or copied in any way or form, and its contents may not be
used or otherwise communicated without the express written consent of the
manufacturer. Infringement of these rights may lead to a claim for compensa-
tion. The right to further claims is reserved.
●We reserve all rights in exercising commercial protection laws.

7
HNC3 825 / HNC3 825 perform
Information about the manual
1.5 Training
●All those appointed to work on or with the machine must have fully read and
understood the manual before commencing any work. This requirement must
be met even if the appointed person is familiar with the operation of such a
machine or a similar one, or has been trained by the manufacturer.
●Knowledge about the contents of this manual is a prerequisite for protecting
personnel from hazards and avoiding mistakes so that the machine may be
operated in a safe and trouble free manner.
●It is recommended that the operator requests proof from the personnel that
the contents of the manual have been read and understood.

8
Safety instructions
2 Safety instructions
2.1 Intended use
●The machine described in this manual is intended solely for the processing
of wood, synthetic materials, and similar machinable materials. Operational
safety is only guaranteed when the machine is used for the intended pur-
poses.
●Any use, other than that of the machine‘s intended purpose shall be consid-
ered improper and is therefore not permitted. All claims regarding damage
resulting from improper use that are made against the manufacturer and its
authorised representatives will be rejected.
●The operator is solely liable for any damage that results from improper use
of the machine.
●The term “proper use” also refers to correctly observing the operating con-
ditions as well as the specifications and instructions in this manual. The
machine may only be operated with parts and accessories recommended by
the manufacturer.
●The machine described in this manual is intended solely for private sector
use and for individual or small production series in the commercial sector.
2.2 Responsibilities of the operator
●This manual must be kept in the immediate vicinity of the machine.
●The manual must be accessible at all times to all persons working on or with
the machine.
●The machine may only be operated if it is in proper working order and in
safe condition.
●The general condition of the machine must be checked and the machine
must be inspected for visible defects each time before it is switched on.
●Do not leave the machine running unattended.
●Secure the switched-off machine against unauthorised operation (padlock on
the main switch, remove the key from the operating mode selector switch,
block off the area around the machine, pull out the mains plug etc.).
●In addition to the safety advice and instructions specified in this operating
manual, any local accident prevention regulations and general safety regula-
tions applicable to the machine's area of use, as well as any applicable
environmental protection regulations, must be observed and complied with.
●The operator and designated personnel are responsible for the trouble-free
operation of the machine as well as for clearly establishing who is in charge
of installing, servicing, maintaining and cleaning the machine. Keep children
away from machines, tools and accessories.
2.3 Requirements of the personnel
●Only authorised and trained personnel may work on and with the machine.
"Qualified personnel" is a term that refers to those who – due to their
professional training, know-how, experience, and knowledge of relevant reg-
ulations – are in a position to assess delegated tasks and recognise potential
risks.
●Personnel must be briefed about all functions and potential dangers of the
machine.

9
HNC3 825 / HNC3 825 perform
Safety instructions
●If the personnel lack the necessary knowledge for working on or with the
machine, they must be trained. Responsibility for working with the machine
(installation, service, maintenance, overhaul) must be clearly defined and
strictly observed.
●Only those people who can be expected to carry out their work reliably may
be given permission to work on or with the machine.
●Personnel must refrain from working in ways that could harm others, the
environment or the machine itself.
●It is absolutely forbidden for anyone who is under the influence of drugs,
alcohol or reaction-impairing medication to work on or with the machine.
●When appointing personnel to work on the machine, it is necessary to
observe all local regulations regarding age and professional status.
●The machine may only be operated by an adult, that is without mental
limitations or under the supervision of such a person.
●All operators must ensure that unauthorised persons are kept at a safe dis-
tance from the machine.
●Personnel are obliged to immediately report any irregularities with the
machine that might compromise safety to the operator.
2.4 Making changes and modifications to the machine
●In order to avoid potential hazards and to ensure optimum performance, no
modifications, alterations or changes may be made to the machine that have
not been explicitly approved by the manufacturer.
●All the pictograms, signs and labels affixed to the machine must be kept
visible, readable and may not be removed.
●Pictograms, signs and labels that have become damaged or unreadable
must be replaced promptly.
2.5 Work safety
●Following the safety advice and instructions given in this manual can prevent
bodily injury and material damage while working on and with the machine.
●Failure to observe these instructions can lead to bodily injury and damage to
or destruction of the machine.
●Disregard of the safety advice and instructions given in this manual as well
as the accident prevention regulations and general safety regulations appli-
cable to the operative range of the machine shall release the manufacturer
and their authorised representatives from any liability and from any compen-
sation claims.
2.6 Personal protective equipment
When using the machine, the operator must wear suitable personal protective
equipment, as there are machine elements or media that can be dangerous.

10
Safety instructions
2.6.1 Prohibitions
It is forbidden to wear loose clothing, wide sleeves, too long and wide trousers,
shirts etc. when working with the machine. It is forbidden to wear belts, scarves,
ribbons, back straps, necklaces, bracelets, open long hair without a hairnet etc.
when working with the machine. These elements may become caught in the
moving parts of the machine and pose a considerable danger. Operators are
strictly forbidden to wear moccasins, clogs, crocs, slippers or any other footwear
which jeopardises their freedom of movement or stability.
When working on or with the machine, the following must be strictly observed:
Note
Long, loose hair is forbidden.
With long hair and beards a hair net must be worn.
Wearing of jewellery (Necklaces, watches, rings, long earrings
etc.) forbidden!
2.6.2 Mandatory safety equipment
When working on or with the machine, the following must always be worn by
personnel:
Note
Protective clothes:
Sturdy, tight-fitting clothing (tear-resistant, no wide sleeves, etc.)
Protective footwear:
To protect the feet from heavy falling objects and prevent sliding
on slippery floors.
Heat-resistant and media-resistant protective gloves:
Protection from cuts, skin damage and burns.
●Handling of hot components.
●Handling of working materials hazardous to health.
●Handling of chemicals.
Respiratory protection:
Protection from harmful fumes and dusts. Observe the safety data
sheets of the media used.
●Handling of diverse adhesives (e.g.: PUR).
●Dust-producing activities.
●Maintenance work.

11
HNC3 825 / HNC3 825 perform
Safety instructions
Note
Ear protection:
Protection from noise emissions by the machine.
2.7 Residual risks
The machine has undergone a hazard analysis. The design and construction of
the machine are based on the results of this analysis and correspond to state-of-
the-art technology.
The machine is considered operationally safe when used properly. Even if all of
the safety measures are complied with, there are still certain associated risks that
must be considered when working on the machine:
Improper operation of the machine
Serious injuries
●Work on the machine may only be carried out by authorised, trained per-
sonnel who are familiar with how to operate the machine and are in strict
observance of all safety instructions.
●If possible, only perform work when the machine is disconnected from all
energy sources and an unintentional restart is prevented.
●The machine has to be switched off when carrying out any work on the
machine.
●Disconnect machine from power supply before carrying out work at elec-
trical devices.
●Do not deactivate or bypass protective devices.
Missing personal protective equipment
Serious injuries
●Wear suitable personal protective equipment.
Pointy tools and sharp objects
Cuts and stab wounds
●Use protective gloves.
Dust-emitting activities
Beech- and oak wood dust are classified as carcinogenic. The dusts of other
woods are under suspicion to be carcinogenic. Dust-emitting activities can cause
severe health damage.
●Use dust mask during dust-emitting activities.
●Use low-dust cleaning methods.

12
Safety instructions
Disorder at the workplace
Loose objects or objects that are lying around can cause severe injuries.
●Ensure that there is sufficient space to work around the machine.
●Remove loose objects from the working area.
●Keep the work area orderly and clean.
Insufficient lighting of the installation room
Serious injuries
●Light installation room sufficiently.
Standing on the machine
The covers or projecting components of the machine are not suitable for standing
on them. If the machine falls down, severe breaks can occur.
●It is forbidden to climb onto the machine.
Noise pollution by machine operation
Severe hearing damage
●Use hearing protection.
Decommissioned safety devices
The machine is equipped with diverse protective devices with safety function.
When protective devices are decommissioned, the safety function is no longer
ensured. Decommissioned safety devices can cause severe injury.
●Do not deactivate or bypass protective devices.
Foreign bodies in the materials to be processed
Foreign bodies in the materials to be processed can cause sparks, which can lead
to fire. These fires can cause severe burns or smoke poisoning.
●Use high-quality materials.
●Remove dust deposits in the machine and in the production area daily.
Disruption of the energy supply
The disruption of the energy supply can cause workpieces to rotate longer than
the largest deceleration time. This can cause cuts or severed limbs.
●Wait for all parts to be still.
●Disconnect machine from all energy sources and secure against restarting.
Damage to electrical components or their insulation
Damaged electrical components or damage to their insulation cause deadly elec-
tric shocks.
●Work on electrical fittings may only be carried out by qualified personnel
and in strict observance of the safety instructions.
●Disconnect machine from power supply and secure against restarting before
carrying out work at electrical devices.

13
HNC3 825 / HNC3 825 perform
Safety instructions
2.7.1 Transport, setup, installation and disposal
Improper transport
Improper transport can cause the machine to tilt or fall. This can cause severe
crushing.
●Carry out transport according to the specifications in this instruction.
●Move unauthorised people out of the area.
●Always clean and tidy the work area and cordon it off.
●Ensure that there is room to escape should the machine fall.
●Only use suitable lifting gear that has a sufficient load-carrying capacity.
●Only attach lifting equipment to the attachment points provided. Never lift
the machine by its protruding parts.
●Observe the machine's centre of gravity.
●Take measures to prevent the machine from slipping.
●Never lift loads over a person.
●Do not stop below suspended loads.
●Keep enough distance to the machine during transport.
●Transport the machine as carefully as possible. Avoid mechanical vibration.
●Chains, belts, ropes or other hoisting devices must be equipped with safety
hooks.
●Do not use any torn, frayed or knotted chains, belts or ropes.
●Ensure that chains, belts and ropes do not lie against sharp edges.
Incorrect setup and installation
Serious injuries and material damage.
●Machine may only be set up by authorised, trained personnel who are
familiar with how to operate the machine and are in strict observance of all
safety instructions.
●Before assembling and installing the machine, check to make sure it is com-
plete and in good condition.
●Only assemble and install the machine if the machine and all of the parts
are complete and intact.
●Do not setup machine in areas with high electromagnetic fields.
●Keep the work area orderly and clean. Components and tools that are not
put in their correct place or put away may cause accidents.
●Do not setup machine on escape routes.
●Only place machine within buildings.
●Place the machine on a level, sufficiently stable, non-slip and vibration-free
surface.
●The foundation must comply with the norms stipulated in the technical lay-
outs.
●Use safety equipment according to regulations and check that they function
correctly.
●The load bearing capacity, the coating and the surface of the floor must not
be affected in the long term.
●The working area must be adequately lit.

14
Safety instructions
Deficient installation of the extraction hoses
The deficient installation of the extraction hoses can cause fire and explosions in
the extraction system. This can cause severe personal and material damage.
●Only use flame-retardant extraction hoses.
●Only use electroconductive extraction hoses.
●Ground extraction hoses against electrostatic charge.
Improper work at the electrical units
Deadly electric shocks
●Work on electrical fittings may only be carried out by qualified personnel
and in strict observance of the safety instructions.
●Disconnect machine from power supply and secure against restarting before
carrying out work at electrical devices.
Indirect touch with residual currents
Deadly electric shocks
●Equip the machine's supply line with a fault-current circuit breaker.
2.7.2 Operate, maintain and troubleshoot
Improper operation
Serious injuries
●Machine may only be operated by authorised, trained personnel who are
familiar with how to operate the machine and are in strict observance of all
safety instructions.
●It is absolutely forbidden for anyone who is under the influence of drugs,
alcohol or reaction-impairing medication to work on or with the machine.
Surpassing or falling below the allowed ambient temperature
Surpassing or falling below the allowed temperatures can cause malfunctions of
the machine and unpredictable machine movements, which can lead to severe
personal and material damage.
●Only operate machine within the listed temperature range.
Improper maintenance
Serious injuries
●Machine may only be maintained by authorised, trained personnel who are
familiar with how to operate the machine and are in strict observance of all
safety instructions.
●If possible, only perform maintenance work when the machine is discon-
nected from all energy sources and an unintentional restart is prevented.
●Disconnect machine from power supply before carrying out work at elec-
trical devices.
●Properly reinstall all components after the maintenance work and check for
function.
●As part of the machine maintenance, the whole machine, including the
safety devices, must be checked regularly for damage.

15
HNC3 825 / HNC3 825 perform
Safety instructions
Improper replacement or reparation of safety devices with safety function
Serious injuries
●Only let safety devices be replaced or repaired by expert personnel of the
Felder Group.
Dust deposits
Dust build-ups can ignite when in contact with hot parts or cause an explosive
atmosphere due to resuspension. Fire or explosion events can cause serious inju-
ries.
●Clean production area as needed.
●Open fire, smoking and cleaning with compressed air forbidden.
●Only carry out spark-producing work and hot work after work release
process.
Improper correction of malfunctions
Serious injuries
●Wait for all parts to be still.
●Disconnect machine from all energy sources and secure against restarting.
2.8 Foreseeable misuses
The examples given highlight possible dangers. No claims of completeness.
This information is intended to enable users to assess hazards and risks.
General misuse:
●Disregard operating instructions.
●Operating the machine, even if the operation manual is not complete or is
not available in the language of the country it is being operated in.
●Placing objects or tools on the work surface.
●Use of tools or materials which are not intended for processing on the
machine.
●Inserting tools that are either not allowed, or not authorised in the machine.
●Using modified tools.
●Using spare parts, accessories and equipment that have not been approved
by the manufacturer.
●To change or modify the machine.
●To adapt, remove or bridge the safety equipment.
●Intentionally trigger safety equipment.
●Climb on the machine.
Misuse during operation:
●Operating the machine carelessly.
●Operating the machine without using the appropriate safety equipment.
Check the correct functioning of the safety equipment regularly.
●Processing of overly large or heavy workpieces.
●Processing very small workpieces without assistance.

16
Safety instructions
○Keep accessories at hand.
●Processing of unsuitable materials such as steel.
●Processing workpieces that are not fixed or insufficiently fixed.
Maintenance misapplication:
●Service work carried out by untrained or unauthorised personnel.
●Non-observance of the maintenance guidelines.
○To ensure quick and unmistakable communication, visual contact with the
operators must be kept at all times.
○Operators should repeat and confirm instructions before they are carried
out.
○Wait for all the moving parts to come to a standstill.
○Following the maintenance work, reinstall the safety equipment and
check that they are functioning properly.
○Only start the machine when there is no one within the safety zone.
○Maintenance technicians need to be fully aware of how the machine
operates and moves, and they must be familiar with the exact operating
sequence.
○Keep a record of all maintenance work.
●Non-observance of usage and damage tracks.
●Whilst maintenance work is being carried out, secure the area around the
machine.
○Whilst maintenance work is being carried out, put up a sign that states
"Machine under maintenance".

17
HNC3 825 / HNC3 825 perform
Declaration of Conformity
3 Declaration of Conformity
EG-Declaration of Conformity according to Machine Guidelines 2006/42/EC
Machine number reference:
The machine number is printed on the cover sheet of the operating manual.
We hereby declare that the machine indicated below, which corresponds to the design and construction of
the model we placed on the market, conforms with the health and safety requirements as stated by the EC
guidelines (see table).
Manufacturer Felder KG
KR-Felder-Straße 1
6060 Hall in Tirol
Product designation CNC portal machine
Manufacturer Hammer
Model type HNC3 825
The following EC guidelines were applied 2006/42/EC
2014/30/EC
This EC Declaration of Conformity is valid only if the CE label has been affixed to the machine. Modifying
or altering the machine without the express written agreement of the manufacturer shall render the warranty
null and void. The signatory of this statement is the appointed agent for the compilation of the technical
information.
Prof. h.c. Ing. Johann Georg Felder
CEO Felder KG
KR-Felder-Straße 1, A-6060 HALL in Tirol
Date: 1.2.2022

18
Declaration of Conformity
UKCA - Declaration of Conformity
Declaration of Conformity according to UK Directive S.I. 2008/1597
Machine number reference:
The machine number is printed on the cover sheet of the operating manual.
We hereby declare that the machine indicated below, which corresponds to the design and construction of
the model we placed on the market, conforms with the health and safety requirements as stated by the UK
guidelines (see table).
Manufacturer Felder KG
KR-Felder-Straße 1
6060 Hall in Tirol
Product designation CNC portal machine
Manufacturer Hammer
Model type HNC3 825
The following EC guidelines were applied S.I. 2008/1597 - Supply of Machinery (Safety) Reg-
ulations 2008
S.I. 2016/1091 - Electromagnetic Compatibility Reg-
ulations 2016
This Declaration of Conformity is only valid if the UKCA label is affixed to the machine. Modifying or altering
the machine without the express written agreement of the manufacturer shall render the warranty null and
void. The signatory of this statement is the appointed agent for the compilation of the technical information.
Prof. h.c. Ing. Johann Georg Felder
CEO Felder KG
KR-Felder-Straße 1, A-6060 HALL in Tirol
Date: 1.2.2022

19
HNC3 825 / HNC3 825 perform
Technical information
4 Technical information
4.1 Technical information
All technical information is for the standard equipment without spindle and extrac-
tion hood.
Machine
Data Value Unit
Total length 1111 mm
Total width 766 mm
Total height 685 mm
HNC3 825 weight approx. 85 kg
HNC3 825 perform weight approx. 103 kg
Packaging including machine
Data Value Unit
Total length 1150 mm
Total width 800 mm
Total height 861 mm
HNC3 825 weight approx. 112 kg
HNC3 825 perform weight approx. 130 kg
ZY
X
Fig. 1: Machine axes

20
Technical information
Data Value Unit
X-axis 825 mm
Y-axis 479 mm
Z-axis 160 mm
Additional technical information
Data Value Unit
Portal clearance width 625 mm
Portal clearance height 160 mm
Table surface 1005 x 574 mm
T grooves in the table for M6 17.5 x 7.5 mm
Drive spindle Z axis trapezoidal
threaded spindle
14 x 6 mm
Drive spindle X- / Y-axis ball screw
spindle
16 x 10 mm
Axis drive
Data Value Unit
Axis drive step motor NEMA 24 
Power supply 2.8 A
Step angle (full step) 1.8 °
Holding torque 1.06 Nm
Step mode ⅛- 1600 
