HAMPTON BAY 141-034-SEC2-NP User manual

THANK YOU
USE AND CARE GUIDE
EDINGTON CURVED LOVESEAT SECTIONAL - NO PILLOWS
YOW Item # 715 184
Model # 141-034-SEC2-NP
1-855-HD-HAMPTON
HAMPTONBAY.COM
Thank you for choosing Hampton Bay!
is loveseat sectional. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
THD Item # 1001 552 422
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 7.00 p.m. EST, Monday - Friday,
9.00 a.m. - 6.00 p.m. EST, Saturday

2
Table of Contents
Safety Information
DANGER: Please keep children out of the assembly area
during assembly.
Warranty
Table of Contents........................................................2
Safety Information.......................................................2
Warranty...................................................................... 2
Pre-assembly
(Left Arm Sectional Chair)
.............3
Planning Assembly ................................................................3
Hardware Included.................................................................. 3
Package Contents .................................................................. 4
5.....................
............................................
.ylbmessA
................................................................ 2
What Is Covered
What Is Not Covered ................................................................ 2..
.... ..
................................................................ 2
Care Instructions ..
FIVE YEAR FRAME /TWO YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat the frame with liquid wax for maximum protection against UV
light and salty, damp air. When not in use, store the furniture in a cool, dry place. If your set includes cushions or mesh fabric, they may be
cleaned by hand with a mild solution of soap and water. Rinse the cushions thoroughly and allow to drip dry. Do not machine wash or tumble
dry, as the cushions may shrink. Do not use bleach or solvents on fabrics.
You may contact our customer service department with any questions by phone at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Five Year Frame / Two Year Fabric Limited Warranty................. 2
Care Instructions
two years.
IMPORTANT: Please check the tightness of bolts
periodically.
...
6..................ylbmessA (Right Arm Sectional Chair)

3
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING ASSEMBLY
.ssecorpylbmessaehtetelpmocotsetunim02tuobanosrepenoekatlliwtI
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Bolt (M8x25) 2
BB Bolt 1
AA BB
HAMPTONBAY.COM
CC
CC Bolt (M6x42)
2
DD Bolt (M6x20) 2
EE
Bolt cap (D8)
3
FF
Hex wrench (M8)
3
GG 1
HH
Bolt cap (D6)
4
II
Washer (D6)
4
JJ Hex wrench (M6)
1
DD
EE FF GG HH
II JJ
(M8x20)
Washer (D8)
KK
KK Plastic clamp 1
LL Plastic clamp 1
LL
Part Description Quantity
AA Bolt (M8x25) 2
BB Bolt 1
CC Bolt (M6x42)
2
DD Bolt (M6x20) 2
EE
Bolt cap (D8)
3
FF 3
HH
Bolt cap (D6)
4
II
Washer (D6)
4
(M8x20)
Washer (D8)
Left Arm Sectional Chair Right Arm Sectional Chair

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Back panel 1
1
C
E
D
B Seat panel
1
DBack cushion 1
E Armrest 1
C Seat cushion
Part Description Quantity
A2 Back panel 1
1
C
E
D
B2 Seat panel
1
DBack cushion1
E2 Armrest 1
C Seat cushion
2
2
2
Left Arm Sectional Chair
Right Arm Sectional Chair

5
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly (Left Arm Sectional Chair)
1 Attaching the
seat panel
to the back panel
□
□
Attach the armrest (E) to the back panel (A) at the tab (1) with washers (HH) and bolts (DD) using the wrench (JJ). (Fig. 1)
HAMPTONBAY.COM
2 Attaching the
armrest
□
□
Attach the seat panel (B) to the back panel (A) with washers (EE) and bolts (AA) using the wrench (GG). (Fig. 3)
Fully tighten all the bolts (AA,BB,CC and DD).
A
B
E
A
HH
DD
JJ
Fig. 1
GG BB EE
Fig. 2
EE
AA
GG JJ CC
HH
A
BE
Fig. 4
E
Fig. 3
Attach the armrest (E) to the back panel (A) at the tab (2) with washer (EE) and bolt (BB) using the wrench (GG). (Fig. 2)
1
2
Do not fully tighten bolts (DD) and (BB) until the end of step 2.
Attach the seat panel (B) to the armrest (E) with washers (HH) and bolts (CC) using the wrench (JJ). (Fig.4)

6
Assembly (Right Arm Sectional Chair)
3 Attaching the
seat panel
to the back panel
□
□
Attach the armrest (E2) to the back panel (A2) at the tab (a) with washers (HH) and bolts (DD) using the wrench (JJ). (Fig. a)
4 Attaching the
armrest
□
□
Attach the seat panel (B2) to the back panel (A2) with washers (EE) and bolts (AA) using the wrench (GG). (Fig. c)
Fully tighten all the bolts (AA,BB,CC and DD).
B2 E2
GG
BB
EE
Fig. b
EE
AA
GG JJ CC
HH
Fig. d
Fig. c
Attach the armrest (E2) to the back panel (A2) at the tab (b) with washer (EE) and bolt (BB) using the wrench (GG). (Fig. b)
b
Do not fully tighten bolts (DD) and (BB) until the end of step 4.
Attach the seat panel (B2) to the armrest (E2) with washers (HH) and bolts (CC) using the wrench (JJ). (Fig.d)
A2
HH
DD
JJ
E2
a
Fig. a
A2
Fig. d
B2 E2
A2
A2
E2

7
Assembly (continued)
5Attaching the bolt caps
6 the two sectional chairs togetherPutting
□Cover all the bolts (AA, BB) with bolt caps (FF).
□Place seat cushions (C) and back cushions (D)on the loveseat. Secure cushions to the frame with hook and loop straps.
□Cover all the bolts (CC, DD) with bolt caps (II).
II
FF
FF
II
D
C
II
II
FF
FF
KK
Use the plastic clamps (KK,LL) to secure the left arm sectional chair to the right arm sectional chair to form a loveseat.
LL
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM
□
Level the loveseat with foot glides at the bottom of each leg.□

1- 855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 7.00 p.m. EST, Monday - Friday,
9.00 a.m. - 6.00 p.m. EST, Saturday
