HAMPTON BAY West Palm RTS699T User manual

THANK YOU
y through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
135431
Model RTS699T
USE AND CARE GUIDE
West Palm 5-Piece Chat Set
Brown Finish / Blue Cushions
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
HOMEDEPOT.MX
01 800 004 6633

2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Warranty
Safety Informat oni
PRODUCT CAUTION
This set was made for the explicit purpose ofproviding outdoor functions and is not to be used as a toy. This productis intended fornormal
outdoor use; however, the manufacturer recommends storing and / or covering this set when any formidable/ severe weather is approaching.
hildren under
the age of 10, near the product, should be supervised by a competent adult at all times.
SAFETY WARNINGS
Safety Information .......................................................2
ProductCaution .................................................................... 2
WARNING: Weight limit for the chairs is 250 lb (113.39 kg)
for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a cool
and covered location.
!
WARNING: Do not place heavy objects on the chair.
Safety Warnings .................................................................... 2
Pre-Assembly ................................................................3
ChairPackageContents ....................................................... ... 4
Chair Assembly............................................................. 5
Care and Cleaning........................................................ 9
Table of Contents
Table of Contents..... .......... .............................. ............2
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
Contact the Customer Service Team at 018000046633 or visit www.homedepot.mx
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We
reserve theright to make substitutions with similar merchandise, if the model in question is no longer in production.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware notshown to actual size.
AA M6x14 BOLT 4+1
4+1
4+1
4+1
BB
CC
HH
AA
Part
Description Quantity
4+1
M8x1.25 JAM NUT
II
1 4 mm ALLEN KEY WRENCH
JJ
1 6 mm ALLEN KEY WRENCH
KK
1 10 & 13 mm ALLEN KEY WRENCH
M6x16 BOLT
M6x25 BOLT
DD M8x45 BOLT
EE
8+1
d6.5xD13x1.0 WASHER
FF
8+1
d8.5xD17x1.6 WASHER
GG
2
WASHER
BB CC DD EE
FF GG HH II JJ
KK
Please contact 018000046633 for further assistance.
HOMEDEPOT.MX

Part Description Quantity
A Seat Assembly 1
2
1
B Arm
C
1D
Support Frame
Base Assembly
1
E
1F
Back Cushion
Seat Cushion
A
B
E
F
4
Pre-Assembly (continued)
CHAIR PACKAGE CONTENTS
D
B
C

5
Chair Assembly
1Connecting the chair arm to the chair seat assembly
Place the seat assembly (A) onto a non-abrasive surface, such as a carpet.
Fasten the arms (B) to the seat assembly (A) by using M6x25 bolts (CC) and d6.5xD13x1.0 washers (EE).
B
A
B
Loosely tighten all of the bolts using the hex wrench (II).NOTE:
CC
EE
EE CC
Please contact 018000046633 for further assistance.
HOMEDEPOT.MX

BB
A
l
6
Chair Assembly (continued)
2Connecting the chair arm to the chair seat assembly
Fasten the arms (B) to the seat assembly (A) by using M6x14 bolts (AA).
AA
AA
Loosely tighten all of the bolts using the hex wrench (JJ).NOTE:

l
7
Chair Assembly (continued)
3Connecting the chair support frame to the chair seat assembly
Turn the seat assembly upside down and place the support frame (C) onto the brace of the seat assembly (A).
Fasten them together by using M6x16 bolts (BB) and d6.5xD13x1.0 washers (EE).
A
C
BB
BB
EE
EE
Please contact 018000046633 for further assistance.
Loosely tighten all of the bolts using the hex wrench (II).NOTE:
HOMEDEPOT.MX

l
8
Chair Assembly (continued)
4Connecting the chair base assembly to the chair support frame
Fasten the base assembly (D) to the support frame (C) by using M8x45 bolts (DD), d8.5xD17x1.6 washers
(FF and GG), and M8x1.25 jam nuts (HH).
D
D
C
C
DD
FF
FF
HH
HH
FF
FF
DD
GG GG
Loosely tighten all of the bolts using hex wrenches (JJ and KK).NOTE:

9
l
Chair Assembly (continued)
5Tightening the bolts
Care and Cleaning
For best results, clean the set with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the set in a dry, sheltered place when not in use.
Keep the set away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet,
snow, or wind.
Place cushions (E and F) onto the chair.
Once all of the bolts are in place, fully tighten the bolts.
Ensure all connections are secure before use.
E
F
Please contact 018000046633 for further assistance.
HOMEDEPOT.MX

Retain this manual for future use.
Questions,problems,missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
HOMEDEPOT.MX
01 800 004 6633
