HAMPTON BAY APH03715K01 User manual

Item #658477
Model #APH03715K01
USE AND CARE GUIDE
NILES PARK 18 IN. ROUND CAST TOP SIDE TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this dining table.
We strive to continually create quality products designed to enhance your home.
Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
Table of Contents
3 Year Frame Limited Warranty
What is Covered
We warrant the frame to be free of manufacturing defects to the original purchaser for three years.
What is Not Covered
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact Customer Care at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
Warranty
Table of Contents
Warranty
What is Covered
What is Not Covered
Pre-Assembly
Planning Assembly
Hardware Included
Package Contents
................................2
..............................................2
.....................................2
...............................2
......................................3
..................................3
..................................3
...................................4
Assembly
Maintenance
Care and Cleaning
.............................................5
.......................................6
..............................6

3
Pre-Assembly
PLANNING ASSEMBLY
Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid
scratching. If you are missing any parts or are unsure how to proceed with the assembly, call our Customer Service Team at 1-855-HD-HAMPTON.
Do not attempt assembly if any parts are missing or damaged.
Two people may be required to assemble the table.
Damage to welds or frames resulting from over tightened bolts or improper assembly is not covered under our warranty. Please read all
instructions carefully before assembly. If you have any questions regarding your assembly, call our Customer Service Team at 1-855-HD-HAMPTON.
NOTE: Hardware not shown to actual size.
HARDWARE INCLUDED
Part Description Order Part # Quantity
1/4 in. x 18 mm Bolt
1/4 in. x 28 mm Bolt
Ø6.5 x 1.0 mm Washer
Bolt Cover
Hex Bolt Driver
Foot Cap (Preassembled)
4
8
12
12
1
4
AA
BB
CC
DD
EE
FF
HW0035
HW0084
HW0004
HW0105
HW0006
FC0614
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
____FF
____DD
____CC
____AA ____BB ____EE

4
Pre-Assembly (continued)
PACKAGE CONTENTS
B C
A
Part Description Order Part # Quantity
Tabletop
Leg Connector Bracket
1
1
A
B
AT71905
AT71906
Table Leg 4C AT71907

5
Assembly
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
2
Attaching the leg connector bracket
3
Tightening the nuts to the bolts
□ Use the hex bolt driver (EE) to tighten all bolts (AA) and (BB).
□ Do not over tighten. Over tightening may strip bolts.
□ Cover all bolts (AA) and (BB) with covers (DD).
1Attaching the table legs
□ Place the tabletop (A) up-side down on a flat, solid surface.
□ Attach a table leg (C) to the tabletop (A) using a 1/4 in. x
18 mm bolt (AA) and washer (CC) as shown in the diagram.
□ Guide the 1/4 in. x 18 mm bolt (AA) through the hole in the
table leg (C), and into the pre-drilled hole in the tabletop (A).
□ Hand tighten three to four turns only. (Do not tighten
completely. Some adjustments may be necessary to ensure
proper alignment of the table legs.)
□ Repeat for the other three legs.
□ Attach a leg (C) to the leg connector bracket (B) using two
1/4 in. x 28 mm bolts (BB) and washers (CC) as shown in the
diagram.
□ Guide two 1/4 in. x 28 mm bolts (BB) through the holes in the
leg connector bracket (B) into the pre-drilled holes in the
legs (C).
□ Hand tighten only.
□ Repeat for the other three legs.
A
C
FF (Preassembled)
DD
AA
CC
CC
BB
DD
B

6
Maintenance
Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frame. To thoroughly drain the frame, remove the foot
caps and tilt the frame, if necessary, to remove all water. This is critical. Water allowed to accumulate inside the frame and then exposed to
sub-freezing temperatures can cause damage to the frame tubing. Such damage is not covered under the warranty. Always clean, drain, and dry
thoroughly before storing for the winter. For best results, always store or cover your furniture when not in use. We recommend commercially
available outdoor furniture covers. Any small nicks or scratches can be covered with a light application of touch-up paint.
Care and Cleaning
Use mild soap and warm water. Do not use abrasive materials, cleansers, or bleach products. Rinse with clean water and dry thoroughly.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
