HAMPTON BAY MIX AND MATCH FTS70660-W User manual

USE AND CARE GUIDE
MIX AND MATCH STEEL SLAT TOP SQUARE DINING TABLE
THANK YOU
y through the purchase of this table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 1001 869 472, 1003 291 844
1003 291 848
Model # FTS70660, FTS70660-W
FTS70660-BLK

2
Table of Contents
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Care and Cleaning..........................................................7
5
4
Table of Contents..........................................................2 Pre-Assembly ................................................................ 3
Package Contents...................................................................
Assembly..........................................................................
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
CAUTION: When not in use, secure the product in a cool
and covered location.
!
CAUTION: Do not place heavy objects on the table top.
!
WARNING: This table unit is heavy, and may require two
adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This table was as made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this set
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
Please keep children out of the assembly area before assembly.
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
3.
This table is not intended to support an umbrella. Umbrellas must
have a suitable base or stand.
4.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
AA M8x50 bolt 4+1
4+1
BB M8 spring was erh
CC M8 washer 4+1
DD
M6x15 combination bolt 8+1
EE
Hex wrench
FF Wrench 1
1
AA
EE FF
BB CC DD
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
2 YEAR FRAME WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Hamptonbay.com
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Table top 1
B
C
Table leg 4
Leg connector 1
DUmbrella ring cover 1
A
C
B
D

5
1
l
Assembly
Attaching the table legs to the table top
Place the table top (A) upside down on a soft surface.
Attach the table legs (B) to the table top (A) using M8x50 bolts (AA), M8 spring washers (BB) and M8 washers (CC).
AA BB CC
A
B
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

6
2
l
Assembly (continued)
Attaching the leg connectorto the tablelegs
Attach the leg connector (C) to the table legs (B) using M6x15 combination bolts (DD).
B
DD
C
DD

3
l
Assembly (continued)
Tightening the bolts
Once all of the bolts are in place, fully tighten the bolts.
Turn the table right side up.
Put the umbrella ring cover (D) into the table top (A).
Ensure the table is tightly assembled and stable before use.
7
Care and Cleaning
For best results, cleanthe table with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the table in a dry, sheltered place when notin use.
Keep the table away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
D
A

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
Factory table ID # FTS70660
