HAMPTON BAY CRESTRIDGE FCS60610R-2PK User manual

THANK YOU
ly create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
CRESTRIDGE SPRING DINING CHAIR – 2PK
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Item # 1000 000 000
Model # FCS60610R-2PK
1000 000 000
FCS60610R-2PK-B

2
Table of Contents
Table of Contents................................ . . . . 2
Important Safety Instructions ......................... . 2
What is covered ................................ . . . 3
What is not covered ................................3
Warranty ................................ . . . . . . . . . . 3
Pre-Assembly.................................. . . . . . 3
Planning Assembly ............................ . . . . . 3
Hardware Included ............................ . . . . . 4
Package Contents . ............................ . . . . . 4
Care and Cleaning ............................... . . . . 7
Assembly. . . . . . ................................. . . . . 5
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS CHAIR WAS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure
to obey this caution could result in injury.
WARNING: This chair unit is heavy, and may
require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for the chair is 250lbs
(113.39Kg) for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
Save These Instructions .............................
Read All Instructions Before Use.......................
2
2

3 HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for
the fabric.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing,and abusive use. In addition, purchased parts are not covered under this
warranty. We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HOMEDEPOT.ca.
Pre-assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.

M6x15 Combination Bolt
M6x30 Combination Bolt
8+1
12+1
AA
BB
M6x25 Bolt4+1 CC
Hex Wrench 1 DD
Part Description Quantity
4
Pre-assembly (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
PACKAGE CONTENTS
Part Description Quantity
A Sling Bucket 2
B Right Arm 2
C Left Arm 2
DConnector Bar 2
ESupport Bar 2
A
B
C
E
D
AA BB CC DD

5 HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1Connecting The Sling Bucket, Connector Bar,And Support Bar To The Right Arm
2Connecting The Sling Bucket, Connector Bar,And Support Bar To The Left Arm
Place the right arm (B) on a soft surface.
Attach the sling bucket (A) to the right arm (B)
using M6x30 combination bolts (BB).
Attach the connector bar (D) to the right arm (B)
using M6x15 combination bolts (AA).
Insert the support bar (E) to the right arm (B).
Do not tighten all bolts at this step.
Attach the sling bucket (A) to the left arm (C)
using M6x30 combination bolts (BB).
Attach the connector bar (D) to the left arm (C)
using M6x15 combination bolts (AA).
Insert the support bar (E) to the left arm (C).
Do not tighten all bolts at this step.
BB
AA
AA
BB
BB
C
E
BB
BB
D
AA
AA
BB
B
A
E
D

6
Assembly (continued)
3Securing The Support Bar
4Tightening All Bolts
Turn the chair right side up.
Tighten the support bar (E) to the two chair
arms (B&C) using M6 x25 bolts (CC).
Do not fully tighten all bolts at this step.
Once all of the bolts are in place, fully tighten all the bolts
using the hex wrench (DD).
Ensure all connections are secure before use.
CC
E

Care
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach,or solvents.
Store the chair in a dry sheltered place when not in use.
Care and Cleaning
7 HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Retain this manual for future use.
