HAMPTON BAY TOBAGO 151-101-NASEC User manual

THANK YOU
USE AND CARE GUIDE
TOBAGO ARMLESS CHAIR SECTION
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
HAMPTONBAY.COM
Item
# 658 896
Model #151-101-NASEC
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
this armless chair section. We strive

2
Table of Contents
Safety Information
DANGER: Please keep children out of the assembly area
during assembly.
IMPORTANT: Please check the tightness of bolts
periodically.
Warranty
Table of Contents.......................................................
Safety Information......................................................
Warranty .....................................................................
2 Year Frame, Weave and Fabric Limited Warranty
Pre-Assembly............................................................
Planning Assembly......................................................
Hardware Included.....................................................
Package Contents .....................................................
Assembly .................................................................
What Is Covered...........................................................
What Is Not Covered......................................................
2
2
2
2
2
2
3
3
3
4
5
2 YEAR FRAME/ WEAVE/ FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat frame with one-step liquid wax for maximum protection against
UV light and salty, damp air. When not in use, store furniture in a cool, dry place. If your set includes cushions or mesh fabric, they may
be cleaned by hand with a mild solution of soap and water. Rinse cushion thoroughly and allow to drip dry. Do not machine wash or
tumble dry, as cushions may shrink. Do not use bleach or solvents on fabrics.
You may contact our customer service department with any questions by phone at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Care Instructions...... ................................................ 2
Care Instructions
We warrant the frame, weave and fabric to be free of manufacturing defects to the original purchaser for two years.
..............

3 HAMPTONBAY.COM
Pre-Assembly
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
DD Wrench 1
DD
Please contact 1-855-HD-HAMPTON for further assistance.
PLANNING ASSEMBLY
It will take two people about 20 minutes to complete the assembly process.
Part Description Quantity
AA 6
BB 10
CC 10
Washer (D6)
AA BB CC
Bolt cap
Bolt (M6x35)
EE
EE
Bolt (M6x48) 4
HH
HH Plastic clamp 2

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
B1 1
C1 1
D1 1
C1
D1
Back panel
Seat panel
B1
比例0.300
F
E
E1
F1
Seat cushion
U-shaped panel
Back cushion
比例0.300

5 HAMPTONBAY.COM
Assembly
Please contact 1-855-HD-HAMPTON for further assistance.
1 Attaching the seat panel to the back panel
□
□
IMPORTANT:
Do not fully tighten the bolt (AA)
Place the back panel (B1) upside down on a flat smooth surface.
until the end of Step 3.
2Attaching the U-shaped panel
□Align the U-shaped panel (D1) to the seat panel (C1) and the back panel (B1) .
Attach the seat panel (C1) to the back panel (B1) with a washer (BB) and a bolt (AA) using the wrench (DD).
DD BB
AA
B1
C1
B1
C1
D1

6
Assembly
Attaching the U-shaped panel (continued)
□
Secure the U-shaped panel (D1) to the back panel (B1) and the seat panel (C1) with washers (BB) and bolts (AA and EE) using the wrench (DD).
□Fully tighten all the bolts (AA and EE) when all the bolts are in place.
AA
BB
DD
B1
D1
C1
AA
BB
DD
B1
D1
C1
BB
EE
DD
3

Assembly
7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
5 Placing cushions
□
Place the seat cushion (E) and the back cushion (F) on the armless
chair section.
4 Covering the bolts
□Cover all the bolts (AA and EE) with bolt caps (CC).
□Adjust foot glides to stabilize the armless chair section.
CC
E
F
Use plastic clamps (HH) to secure the left arm chair section (1) and the right arm chair section (3) to the armless chair section (2)
to form a 3-seat sofa. See diagram below. (Note : (1) and (3) are not included in Model # 151-101-NASEC.)
HH
6 Using clamps
1 2 3

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. – 6.00 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
