HAMPTON BAY OAK HEIGHTS MOTION D12237-DS User manual

Item# 1001 412 844/
1001 412 840
Model #D12237-DS/
D12237-DS-B
USE AND CARE GUIDE
OAK HEIGHTS MOTION DINING CHAIR
HAMPTONBAY.COM
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
1-855-HD-HAMPTON

Table of Contents
Table of Contents
Warranty
Pre-assembly
Assembly
Care and Cleaning
Warranty
2 YEAR FRAME AND FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer's responsibility for freight and packaging charges to and from our service center.
This warranty does not cover commercial use, hardware, acts of nature, re, freezing and abusive use.
In addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions
with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
2
Motion Dining Chair Package Contents
What is Not Covered
What is Covered
............................................2
............................................2
.................................................2
.................................................3
...............................................3
.................................................2
............................................................5
...................4
..............................................6
Hardware Included ................................................... 3
Planning Assembly
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR COMMERCIAL USE.
For a copy of our full limited warranty, please contact our customer service team below.

Pre-assembly
PLANNING ASSEMBLY
Please read complete instruction manual prior to assembly!
Identify all parts packed in the carton against the parts list. Remove all protective materials and
place the parts on a nonabrasive surface to avoid scratching.
NOTE: More than one person may be required to
complete the assembly of this product.
HARDWARE INCLUDED
NOTE: Tools not shown to actual size.
3
AA BB CC
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part Description Quantity
AA 8
BB
CC
DD
M6 Hex bolt cap
M6*20 Hex bolt
M6 Washer
DD
1
Wrench
8
8

MOTION DINING CHAIR PACKAGE CONTENTS
Part Description Quantity
D
A
4
2
2
2
A
2
D
Pre-assembly (continued)
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
C
Seat frame
Stem bracket
B
Base
C
Seat cushion
2

□
1
5
A
2
Assembly
Attaching the arms
□
□
□Place the base (C) on a flat surface and align the stem
under the seat frame (A) with the hole on the base.
Push down firmly to lock the seat frame (A) and base (C)
together.
Connecting the base and seat
Attach the stem bracket (B) to the seat frame (A) using the
washers (BB) and hex bolts (AA).
Ensure all bolts are aligned and assembled correctly.
Tighten all hex bolts (AA) with the wrench (DD). Attach the
hex bolt caps (CC).
B
BB
AA
CC
B
A
C
A
3Adding the cushions
□
D
Place the seat cushion (D) onto the chairs.

Care and Cleaning
Do not allow water to build up in frames. This will cause corrosion and possible freezing damage in cold climates..
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners. Some cleaners may be
□Rinse with clean water and dry with asoft, absorbent cloth towel.
□Treat frames with a liquid wax for maximum protection against UV rays and/or salty, damp air.
□
marked as natural, but some ingredients may cause discoloration or have an adverse reaction to your nish.
6

Retain this manual for future use.
