HAMPTON BAY A211030204 User manual

THANK YOU
We appreciate the trust andconfidence you have placed in Hampton Bay through the purchase of this Chair. We strive to continually create quality
products designed to enhance your home. Visit usonline to see ourfull line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!
Item# 1001 431 841
Model# A211030204
USE AND CARE GUIDE
ADIRONDACK CHAIR - CHILI
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
WWW.HOMEDEOPT.CA

2 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
Table of Contents
Table of Contents..........................................................2
Important Safety Instructions ......................................2
Warranty.........................................................................2
Pre-Assembly ................................................................3
Planning assembly...................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Assembly ........................................................................5
Care and Cleaning ........................................................ 7
Important Safety Instructions
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is
used by, or near children, or disabled persons.
2. Use this furnishing only for its intended use as described
in these instructions. Do not use attachments not
recommended by the manufacturer.
3. Some parts may contain sharp edges. Wear protective
gloves.
4. Please count the parts before assembly.
5. Set up your furniture properly. Ensure that all parts are
assembled properly and fully tightened as per
instructions. When placing in the desired location, ensure
that all legs are resting on the same surface. You may
adjust the leg levelers as required to ensure that the item
stands in a level position.
6. Examine occasionally to ensure that there are no loose
parts. If loose parts are found, they must be re-tightened
fully before additional use.
DANGER: Keep children and parts away from the
assembly area.
WARNING:
To avoid destroying the finish, please handle
the surface by using a soft cloth instead of your bare hands.
Due to the nature of iron, surface oxidation (rusting) will
occur once these protective coatings are scratched. We
recommend immediate touch-up with rust inhibiting paint
(not included).
CAUTION: Do NOT over tighten any of the bolts or nuts.
Warranty
1 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the
item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of 1 year.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling or disassembling
the product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit WWW.HOMEDEPOT.CA.
Production Number: 2021100339

3 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included
and Package Contents lists. If any part ismissing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
TOOLS REQUIRED
Phillips head screwdriver (not included).
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
--AA
--BB --CC
--DD --EE --FF -- GG
--HH --II --JJ
Part
Part Number
Description
Quantity
AA
H010030061
Bolt M8*57
6+1
BB
H010030060
Bolt M6*40
4+1
CC
H030072984
Screw ST4.2*40
4+1
DD
H040050019
Lock Nut M8
6+1
EE
H050050011
Plastic Washerφ35*φ9*3mm 4+1
FF
H050050012
Plastic Washer
φ
35*
φ
19*3mm
4+1
GG
H050050013
Plastic Washerφ25*φ9*3mm 2+1
HH
H050050014
Washer
φ
19*
φ
9*1mm
16+1
II
H090010012
Wrench 13 mm
1
JJ
H090030002
Allen Key 4*60
1

4 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
PACKAGE CONTENTS
--A --B
--C --D
--E --F
--G --H
Part
Part Number
Description
Quantity
A P001600119Seat 1
B P004000121Back Support 1
C P005400240 Right Leg 1
D P005400241 Left Leg 1
E P001400139Right Arm 1
F P001400140 Left Arm 1
G P000500809Wood Hinge 2
H P003900051 Wood Slat 1

5 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
1Attaching the Right and Left Leg
□Attach the right leg (C) and left leg (D) to the seat (A) using bolts (AA), washers (HH/EE), and nuts (DD). Use the wrench (II) to hold the
nuts (DD) in place while you tighten with the Key (JJ).
NOTE:To avoid destroying the finish, do notput the parts on the ground directly. Ensure you attach the plastic washers in each
wood join part of the chair. Failure to attach these plastic washers will cause the chair to not fold properly and damage to the chair.
AA 2
DD 2
EE 2
HH 4
II 1
JJ 1
2
Attaching the Wood Slat
□
Attach the wood slat (H) to the legs (C/D) using screws (CC). Tighten with a Phillips screwdriver.
NOTE:To avoid destroying the finish, do notput the parts on the ground directly. Ensure you attach the plastic washers in each
wood join part of the chair. Failure to attach these plastic washers will cause the chair to not fold properly and damage to the chair.
CC
4
H
A
D
C
H
A
H
JJ
C
CC
AA
HH
A
C
C
D
D
C
H
DD
A
HH
II
EE
Assembly

6 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly (continued)
3Attaching the Hinges and Chair Back to the Seat
□Attach the bottom brace of the chair back (B) to the hinges (G) using bolts (BB), washers (HH/FF). Tighten the bolts (BB) with the
Allen Key (JJ). Attach the hinges (G) to each side of the seat (A) using bolts (AA), washers (HH/EE), and nuts (DD) as shown. Use the
wrench (II) to hold the nuts (DD) in place while you tighten with the Key (JJ).
NOTE:To avoid destroying the finish, do notput the parts on the ground directly. Ensure you attach the plastic washers in each
wood join part of the chair. Failure to attach these plastic washers will cause the chair to not fold properly and damage to the chair.
AA
2
BB
2
DD
2
EE
2
FF
2
HH
6
II
1
JJ
1
4
Attaching the Left /Right Arm
□
Attach the back of the left arm (F) to the middle brace of the chair back (B) using a bolt (BB), washers (HH/FF). Tighten the bolt
(BB) using the Allen key (JJ). Attach the front of the left arm (F) to the top of the left leg (D) using a bolt (AA), washers (HH /GG),
and nut (DD). Tighten the bolt (AA) using the Allen key (JJ) and wrench (II). Use the wrench (II) to hold the nut (DD) in place
while you tighten with the key (JJ). Repeat these steps for the right arm (E).
NOTE:To avoid destroying the finish, do notput the parts on the ground directly. Ensure you attach the plastic washers in each
wood join part of the chair. Failure to attach these plastic washers will cause the chair to not fold properly and damage to the chair.
AA
2
BB
2
DD
2
FF
2
GG
2
HH
6
II
1
JJ
1
G
A
JJ
AA
EE
HH
JJ
B
E
F
B
F
II
DD
HH
BB
GG
FF
HH
HH
B
BB
DD
JJ
HH
G
FF
HH
II
B
JJ
A
A
D
F
D
C
AA
G
G

7 WWW.HOMEDEPOT.CA.
Please contact 1-855-HD-HAMPTON for further assistance.
5Folding the Chair
□You can fold the chair when it is not in use.
Care and Cleaning
□Before using, clean the Chair completely with a soft dry towel.
□Do not put your Chair in wet conditions, such as rain where there is a risk of rust developing.
□When not in use, store in a cool, dry area.
Assembly (continued)

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
WWW.HOMEDEPOT.CA
Retain this manual for future use.
