HAMPTON BAY GFM00471A User manual

Item # 1003 516 705
Model# GFM00471A
10x10 FT. PERGOLA
THANK YOU
We appreciate the trust and conidence you have placed in Hampton Bay through the purchase of this pergola. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1003 516 705
Model #GFM00471A

Table of contents .................................................................2
Safety Information ...............................................................2
Product Caution ........................................................................2
Safety Warnings ........................................................................2
Warranty...................................................................................2
What is covered ........................................................................2
What is not covered ..................................................................2
Pre-assembly ..........................................................................3
Planning assembly ....................................................................3
Hardware included ....................................................................3
Packaging contents ...................................................................4
Assembly ...............................................................................5
Care and Cleaning ...............................................................17
2
Warranty
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
2 YEAR LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover commercial
We reserve the right
to make substitutions with similar merchandise, if the model in question is no longer in production.
We warrant the frame and the fabric to be free of manufacturing defects to the original purchaser for two years.
Safety Information
PRODUCT CAUTION
SAFETY WARNINGS
This pergola was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for normal
outdoor use; however, the manufacturer recommends storing and / or covering this pergola when any formidable / severe weather is approach-
ct. Children
under the age of 10, near the product, should be supervised by a competent adult at all times. This product is NOT intended for commercial use
and will void the warranty.
!
WARNING: Please keep children out of the assembly area
before assembly.
!
WARNING: This pergola unit is heavy, and may require two
adults for safe assembly.
CAUTION : Do not locate the product near any heat source.
Table of Contents
CAUTION: When not in use, secure the product in a cool and
covered location.
!
WARNING:
gazebo fabric.
!
WARNING: This application of any foreign substance to the
ineffective.
!
WARNING: This gazebo is made with fabric that meets
proof. The fabric will burn if left continuous contact with any

AA BB CC DD EE
BB
CC
M6x55 combination bolt
M6x70 combination bolt
16+1
26+1
DD Ground spike 16+1
EE Hex wrench 2
Part Description Quantity
AA M6x20 combination bolt 24+1
3
Pre-Assembly
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
PLANNING ASSEMBLY
NOTE: More than one person may be required to
assemble this product.
NOTE: Hardware not shown to actual size.
HARDWARE INCLUDED

4
Pre-Assembly (continued)
PACKAGE CONTENTS
B
C
Top bar
Post
7
4
D Thin shade rod 4
E Thick shade rod 2
F Canopy 1
Part Description Quantity
A2
A1
Left connector bar
Right connector bar
2
2G End tip 4
H Inner tip
Post base plate
10
I
Top bar connector
4
J
Tube cover
4
K
Plastic connector 1
8
L1
Plastic connector 2
2
L2 2
Part Description Quantity
F
J
J
G
G
HHH
A2
J
G
B
A1 B
B
JB
B
B
B
K
D
L2
E
L1
I
C
C
C
C
K
I
I
I
K
D
D
L1
L2
E
A1
A2
K
K

1
5
Insert the left connector bar (A2) into the right connector bar (A1), align the holes and secure the connector bars
(A1 & A2) with M6x20 combination bolts (AA).
ATTACHING THE BRACKETS
Assembly
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE : Fully tighten all bolts using the hex wrench (EE).
A2A1
AA
AA
A1
A2
A1 A2

2
Insert the end tips(G) into the top bar (B) and align the holes. Repeat this step for another top bar (B).
INSERTING THE END TIPS
Assembly (continued)
6
GB
G
G
B

3
ATTACHING THE TWO TOP BARS TO THE CONNECTOR BARS
Attach the two top bars(B) to theassembled left and rightconnector bars (A1 & A2) byusing the top bar connectors (J).
Secure the top bar connectors (J) with M6x20 combination bolts(AA) and M6x70 combination bolts (CC), as shown below.
Assembly (continued)
NOTE : Make surethe screwholes on the assembled left and right
connector bars (A1 & A2) are facing inside.
7HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
B
G
G
G
A1
A2
G
A2
A1
J
J
J
J
A1
CC
AA
G
J
B
G
AA
CC
A2
B
J

4
INSERTING THE INNER TIPS
Insert the inner tips (H) into the top bar (B) and align the holes. Repeat this step for the other four top bars (B).
Assembly (continued)
8
B
HH
HB

5ATTACHING THE TOP BARS TO THE CONNECTOR BARS
Attach thetop bars (B) to the assembled left and rightconnector bars (A1 & A2) using M6x70combination bolts (CC), as shown below.
Assembly (continued)
9HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
B
H
H
B
A1
A2
A2
A1
CC
H
A1&A2
B
H

6ATTACHING THE POST BASE PLATES TO THE POSTS
Attach the post base plates (I) tothe four posts (C) using M6x20 combination bolts (AA).
Assembly (continued)
10
NOTE : Fully tighten all bolts using the hex wrench (EE).
CI
I
C
AA

7ATTACHING THE POSTS TO THE ASSEMBLED STRUCTURE
Align the holesand attach the posts (C) to theassembled structureusing M6x20 combination bolts (AA) and M6x70
combination bolts (CC).
Assembly (continued)
11 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE : : Suggestusing two ladders to assemblethis step.
G
CC AA
CC
AA
CC
J
A1&A2
C
C
B
B
A1 A2
B
C
J
J
G
G

8ATTACHING THE POSTS TO THE ASSEMBLED STRUCTURE
Align the holes and attach the other two posts (C) to the assembled structure using M6x20 combination bolts (AA) and
M6x70 combination bolts (CC).
Once all of the bolts are in place, fullytighten the bolts.
Assembly (continued)
12
NOTE : : Suggest using two ladders to assemble this step.
G
CC AA
CC
AA
CC
J
A1&A2
C
B
C
C
A1
A2
B
B
G
G
J
J

9ATTACHING THE CANOPY
Attach the canopy (F) to the assembled structure, as shown below.
Assembly (continued)
13 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
F

Assembly (continued)
10 ATTACHING THE THICK SHADE RODS
Insert the thickshade rods (E) through thecanopy (F), asshown below.
Attach the plastic connector 1(L1) and the plastic connector 2(L2) to the rightand the left side of the thick shade
rod (E), repeat this step for another side.
14
F
L1
F
L1
L2
L1
E
E
1
23
E
L2

Assembly (continued)
11 ATTACHING THE THIN SHADE RODS
Insert the thin shade rods (D) through the plastic connector 1 (L1) and plastic connector 2 (L2), as gure 1.
Connect the tube covers (K) to the top of the thin shade rods (D), align the holes and secure the thin shade rods (D) using
M6x55 combination bolts (BB), as gure 2.
Place the tube covers (K) to the end of the thin shade rods (D), align the holes and secure the thin shade rods (D) using
M6x55 combination bolts (BB), as gure 3.
15 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
F
F
31
2
CD
C
D
D
C
K
KK
K
K
KK
L2 L1
L1
D
D
C
C
K
D
CK
BB
BB
C
D
L1&L2

Assembly (continued)
12 INSTALLING THE GROUND SPIKES
Insert the ground spikes (DD) through the post base plates (I) and into the ground.
16
C
C
C
DD
C
C
I
I
II
I

Assembly (continued)
13 COMPLETING THE ASSEMBLY
Ensure all connections are secure before use.
To adjust the length of the canopy (F), keep the plastic connectors 1 (L1) and the plastic connectors 2 (L2) in
unlock position. The length of the canopy (F) cannot be adjusted when the plastic connectors 1 (L1) and the plastic
connectors 2 (L2) in lock position.
17 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
For best results, clean the pergola with damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the pergola, sheltered place when not in use.
nd.
D
D
L2 L1
L1
D
D
F
Unlock
D
D
L2 L1
L1
D
D
F
F
F
Lock
D
L1&L2
D
L1&L2
D
D
L2 L1
L1
D
D
F

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
