HAMPTON BAY L-PB136PST User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this bench. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!
Item #1002 033 939
Model #L-PB136PST
USE AND CARE GUIDE
BENCH
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Table of Contents
Table of Contents................................................................... 2
Safety Information................................................................. 2
Warranty................................................................................ 2
What is Covered .......................................................................2
What is Not Covered ................................................................2
Pre-Assembly ........................................................................ 3
Planning Assembly...................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Assembly ...............................................................................5
Care and Cleaning..................................................................6
Safety Information
1. Some parts may contain sharp edges. Wear protective
gloves as necessary.
2. Please count the parts before assembly.
DANGER: Keep children and parts away from the assembly
area.
WARNING: To avoid destroying the finish, please handle the
surface by using a soft cloth instead of your bare hands. Due
to the nature of iron, surface oxidation (rusting) will occur
once these protective coatings are scratched. We
recommend immediate touch-up with rust inhibiting paint
(not included).
CAUTION: Do NOT over tighten any of the bolts or nuts.
NOTICE: This product is for outdoor use only.
Warranty
2 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the
item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of 2 years.
WHAT IS NOT COVERED
We do not reimburse for transportation or delivery costs, or compensate the individual or any outside party for assembling or disassembling
the product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Hamptonbay.com.
Production Number: 20181419

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING INSTALLATION
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package
Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
HARDWARE INCLUDED
____AA ____BB ____CC
Part Part No Description Quantity Additional
AA H06025C11 Bolt M6X25 12 1
BB H06015C11 Bolt M6X15 4 1
CC H06002C12 Hex wrench M6 1 0
NOTE: Hardware not shown to actual size.

4 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PACKAGE CONTENTS
A
B
C
D
E
Part Part No Description Quantity
A P30007A01102 Left arm 1
B P30008A01102 Right arm 1
C P30104A01102 Chair back 1
D P30205A01102 Seat board 1
E P14406A01102 Support bar 1

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1Attaching the back 2Attaching the seat
□Connect the left arm (A) to the chair back (C) with three
bolts (AA). Repeat for the right arm (B). Loosely-tighten the
nuts by using the hex wrench (CC). Do not overtighten.
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
□
A
ttach the seat board (D) to the right arm (B) using three
bolts (AA). Loosely-tighten using the hex wrench (CC).
Repeat for the left arm (A). Do not completely tighten the
bolts (AA).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
3Assembling the leg connector
□Attach the support bar (E) to the left arm (A) using two bolts
(BB). Repeat for the right arm (B).
□Fully tighten all connections on the assembly using the hex
wrench (CC).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.

6 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
□Before using, clean the bench completely with a soft dry towel.
□Do not put your bench in wet conditions where there is a risk of rust developing.
□When not in use, store in a cool, dry area.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
