HAMPTON BAY Delaronde 4 Piece Conversation Set... User manual

Item # 1000 845 506
Model # GLS-61155-4DSX
Delaronde 4 Piece Conversation Set
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service 8.00am. - 6.00pm., EST, Monday - Friday
1-855-HD-HAMPTON
www.homedepot.ca
THANK YOU!
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of the
Delaronde 4 Piece Conversation Set. We strive to continually create quality products designed to
enhance your home. Visit us online to see our full line of products available for your home improve-
ment needs.
Thank you for choosing Hampton Bay.

Table of Contents
Safety Information
Warranty
Table of Contents ............................................ 2
Safety Information ........................................... 2
Warranty .......................................................... 2
Warranty ............................................... 2
What is Covered ................................... 2
What is Not Covered ............................ 2
Pre-Assembly ................................................. 3
Planning Assembly .............................. 3-5
Hardware Included .............................. 3-5
Package Contents ............................... 6-8
Assembly ....................................................... 9-14
Care and Cleaning ......................................... 15
TWO YEAR LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center. This warranty does not cover commercial use, hardware, acts of nature, re, freezing and
abusive use. In addition, purchased parts are not covered under this warranty. We reserve the right to
make substitutions with similar merchandise, if the model in question is no longer in production.
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
2
WARNING: Do not stand or put heavy
things on furniture.

Pre-Assembly (Lounge Chair)
PLANNING ASSEMBLY
It will take 2 people about 20 minutes to complete the assembly process of the 2
Delaronde Lounge Chairs.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA1
BB1
CC1
DD1
PVC Bolt Cover
M6X20 Bolt
Steel Washer
Wrench
8
8
8
1
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
3
AA1
DD1
BB1 CC1

Pre-Assembly (Love Seat)
PLANNING ASSEMBLY
It will take 2 people about 20 minutes to complete the assembly process of the 1
Delaronde Love Seat.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA2
BB2
CC2
DD2
EE2
PVC Bolt Cover
M6X20 Bolt
M6X45 Bolt
Steel Washer
Wrench
9
8
1
9
1
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
4
AA2
EE2
BB2 CC2 DD2

Pre-Assembly (Co󰀨ee Table)
PLANNING ASSEMBLY
It will take 1 person about 10 minutes to complete the assembly process of the 1
Delaronde Co󰀨ee Table.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA3
BB3
CC3
DD3
EE3
PVC Bolt Cover
M6X15 Bolt
M6X30 Bolt
Steel Washer
Wrench
12
4
8
12
1
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
5
AA3
EE3
BB3 CC3 DD3

Pre-Assembly (Lounge Chair Cont.)
PACKAGE CONTENTS
Part Description Quantity
A1
B1
C1
D1
E1
F1
Lounge Chair Back
Lounge Chair Seat
Arm Rest - Left (When sitting)
Arm Rest - Right (When sitting)
Lounge Chair Back Cushion
Lounge Chair Seat Cushion
2
2
2
2
2
2
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
6
A1
D1
C1
F1
B1
E1

Pre-Assembly (Love Seat Cont.)
PACKAGE CONTENTS
Part Description Quantity
A2
B2
C2
D2
E2
Love Seat Back
Love Seat Seat
Arm Rest - Left (When sitting)
Arm Rest - Right (When sitting)
Love Seat Back Cushion
Love Seat Seat Cushion
Toss Pillow
1
1
1
1
2
1
2
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
7
A2
D2
C2
F2
B2
E2
G2
F2
G2

Pre-Assembly (Co󰀨ee Table Cont.)
PACKAGE CONTENTS
Part Description Quantity
A3
B3
C3
D3
Table Rim
Table Leg
Connector Shelf
Table Glass
1
4
1
1
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
8
A3
D3
C3
B3

Assembly (Lounge Chair)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
9
1 2
Secure Arm Rest Right (D1) and Arm Rest
Left (C1) to Lounge Chair Seat (B) with
hardware as directed.
IMPORTANT: Do not fully tighten bolts before
all bolts are assembled.
Line up two pre-welded pins on Lounge
Chair Back (A1) into two holes on Lounge
Chair Seat (B1) rear bar.
Secure Lounge Chair Back (A1) to Lounge
Chair Seat (B1) with hardware as directed.
B1
D1
C1
CC1BB1AA1

Assembly (Lounge Chair Cont.)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
10
3
Tighten all hardware.
Set up each Lounge Chair with Lounge Chair Back Cushion (E1) and with Lounge Chair Seat
Cushion (F1).
A1
E1
F1

Assembly (Love Seat)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
11
1 2
Secure Arm Rest Right (D2) and Arm Rest
Left (C2) to Love Seat Seat (B2) with
hardware as directed.
IMPORTANT: Do not fully tighten bolts before
all bolts are assembled.
Line up two pre-welded pins on Love Seat
Back (A2) into two holes on Love Seat Seat
(B2) rear bar.
Secure Love Seat Back (A2) to Love Seat
Seat (B2) with hardware as directed.
B2
D2
C2
DD2 BB2 AA2

Assembly (Love Seat Cont.)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
3
Tighten all hardware.
Set up Love Seat with Love Seat Back Cushion (E2), Love Seat Seat Cushions (F2) and Toss
Pillows (G2).
E2
12
F2
G2

Assembly (Co󰀨ee Table)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
1 2
Secure Table Legs (B3) to Table Rim (A3)
with hardware as directed.
IMPORTANT: Do not fully tighten bolts before
all bolts are assembled.
IMPORTANT: Do not fully tighten bolts before
all bolts are assembled.
Secure Connector Shelf (C3) to Table Legs
(B3) with hardware as directed.
B3
A3
AA3
BB3
DD3
C
AA3 CC3
DD3
13

Assembly (Co󰀨ee Table Cont.)
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
3
Place Table Glass (D3) on Table Rim (A3).
Enjoy!
D3
A3
14

Care and Cleaning
www.homedepot.ca
Please contact 1-855-HD-HAMPTON for further assistance.
Before using, wipe with a clean dry cloth. Please be aware that sharp objects will cause damage to
furniture. When not in use, store the furniture in a cool dry place.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.homedepot.ca
15

Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service 8.00am. - 6.00pm., EST, Monday - Friday
1-855-HD-HAMPTON
www.homedepot.ca
Retain this manual for further use.
