HAMPTON BAY ANDREWS T05F2U0Q0056R User manual

Item #000-000
Model #T05F2U0Q0056R
USE AND CARE GUIDE
ANDREWS 5-PIECE DINING SET
THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of th
is dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 6 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents........................................................ 2
Warranty...................................................................... 2
What is Covered...................................................................... 2
What is Not Covered................................................................ 2
Pre-Assembly........................................................................... 2
Planning Assembly...................................................................
2
Hardware Included................................................................... 3
Chair Package Contents............................................................4
Chair Assembly...........................................................5
Table Assembly...........................................................7
Care and Cleaning.......................................................9
Warranty
1 YEAR FRAME AND FABRIC WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty
does not cover commercial use, hardware, acts of nature, re, freezing and abusive use. In addition, purchased parts are
not covered under this warranty. We reserve the right to make substitutions with similar merchandise, if the model in
question is no longer in production.
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non -abrasive surface such as carpet or cardboard.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
NOTE: More than one person may be required to
complete the assembly of this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA M8 Nut 16
BB M8 Spring washer 16
CC M8 Washer 16
DD M8x35 Hex bolt 16
EE Metal Sheet 8
Part Description Quantity
FF M6x20 Bolt 8
GG M6x25 Bolt 8
HH M6 Washer 16
II Hex Wrench 1
JJ Wrench 2
FF GG HH IIAA BB CC DD EE JJ

3HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
CHAIR PACKAGE CONTENTS
Part Description Quantity
A Chair frame 4
B Chair connector 4
C Chair base 4
D Tile 1
C
B
A

4
Pre-Assembly (continued)
TABLE PACKAGE CONTENTS
Part Description Quantity
D Table frame 1
E Table leg 4
F Leg connector 1
G Tile 9
F
E
E
E
E
G
D

1
l
5
Chair Assembly
Connecting the chair connector to the chair
Place the chair frame (A) upside down on a soft surface.
Attach the chair connector (B) to the chair frame (A) by inserting M8x35 hex bolts (DD) through metal sheets (EE), the chair frame
(A), the chair connector (B), M8 washers (CC), and M8 spring washers (BB) into M8 nuts (AA).
Tighten all of the bolts with hex wrench (II) and wrench (JJ).
B
A
DD
AA
BB
CC
EE
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

2
l
6
Chair Assembly (continued)
Connecting the chair base to the chair
Insert the chair connector (B) into the chair base (C).
B
C

1
l
7
Table Assembly
Attaching the table legs
Place the table frame (D) upside down on a soft surface.
Attach each of the table legs (E) to the table frame (D) with M6x20 bolts (FF) and M6 washers (HH).
NOTE: Loosely tighten all bolts using the hex wrench (II).
FF
HH
D
E
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

2
l
8
Table Assembly (continued)
Attaching the leg connector
Attach the leg connector (F) to the table legs (E) with M6x25 bolts (GG) and M6 washers (HH).
Tighten all of the bolts.
GG
HH
F
E

3
l
9
Table Assembly (continued)
Adding the tiles
Turn the table over so it is right side up.
Carefully place the 9 tiles (G) on the table.
G
Care and Cleaning
For best results, clean the frames with a damp cloth and dry the frames thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the table and chairs in a dry, sheltered place when not in use.
Keep the table and chairs out of re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or
wind.
NOTE: Optional to remove center tile to place umbrella.
Replace with center tile when umbrella is not in use.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
