HAMPTON BAY GCS00180B User manual

THANK YOU
ay through the purchase of this wicker swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #1000 051 042
Model #GCS00180B
USE AND CARE GUIDE
SOLAR LED LIGHTED WICKER SWING
Questions, problems, missing parts?
Before returning to the store call Hampton Bay Customer Service.
8 a.m. - 6 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ......................................................................2
What is Not Covered ................................................................2
Pre-Assembly ................................................................3
Planning Assembly ..................................................................3
Hardware Included ..................................................................3
Package Contents....................................................................4
Assembly....................................................................... 5
Care and Cleaning.......................................................11
Warranty
2 YEAR FRAME AND 2 YEAR LIMITED FABRIC WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, re, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
Safety Information
Safety Information .......................................................2
This swing was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is not intended for
inclement / severe weather in any form including, but not limited to: rain, hail, sleet, snow and / or wind. The manufacturer recommends that
with formidable weather approaching that you store and / or cover this set. Do not locate product near open ame. Do not use product as a
support. Do not shake, lean or climb on product. Children under the age of 10, near the product, should be supervised by a competent adult
at all times. This product is NOT intended for commercial use and will void the warranty.
SAFETY WARNINGS
WARNING: Children under the age of 10 should always
be under supervision by a competent adult at all times.
WARNING: Weight Limit: 250 Lbs (113.39kg)
for each seat.
CAUTION: Do not locate the product near any
heat source.
CAUTION: Never use this product as a support. Do
not shake, lean, or climb on the swing at any time.
!
!
C
AUTI
O
N:
D
o not
l
ocate t
h
e pro
d
uct near any
h
eat source.
CAUTION: When not in use, secure the product in a
cool and covered location.
!
WARNING: This swing unit is heavy, and may require
two adults for safe assembly.
PRODUCT CAUTION
Product Caution .....................................................................2
Safety Warnings ......................................................................2

3
Planning Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
complete the assembly of this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA M8x102 Bolt and nut 6+1
BB M8x70 Bolt and washer 4+1
CC M8x35 Bolt and washer 4+1
DD M6x40 Bolt and washer 8+1
AA BB CC DD EE
Part Description Quantity
EE M6x35 Bolt 2+1
FF M6x30 Bolt and nut 4+1
GG Hook 2
HH Wrench 2
FF GG HH
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
K
P
L
A
D
B
H
I
C
G
F
E
Part Description Quantity
A
B
C
D
Top bar
Leg
Side bar
Connector bar
1
4
2
2
E
F
Seat
Seat cushion
1
1
Part Description Quantity
I
J
K
L
Short swing pipe
Left curved bar
Right curved bar
Middle support bar
2
1
1
1
M
N
Front light tube
Back light tube
1
1
0
N
J
M
GPillow 2
HLong swing pipe 2
OCanopy 1
PScrew knob 2

1
5
Assembly
Attach two set of legs (B) to the top bar (A) using M8x102 bolts and nuts (AA).
Attach the two connector bars (D) to the legs (B) and the top bar (A) using M8x102 bolts and nuts (AA) and
M8x70 bolt and washers (BB), as shown below.
NOTE: Loosely tighten all bolts using the wrench (HH).
BB
Assembling the swing frame
BB
AA
DD
AA
AA
D
B
B
C
DD
ABB
D
C
Attach both side bars (C) to the legs (B) using M6x40 bolt and washers (DD).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

2
l
6
Assembly (continued)
Attaching the front and back swing pipes to the seat
Attach the long swing pipes (H) to the front arm of the seat (E) using M8x35 bolt and washers (CC).
Attach the short swing pipes (I) to the back arm of the seat (E) using M8x35 bolt and washers (CC).
Connect the top of the two swing pipes (H and I) together by using the hooks (GG).
NOTE: Loosely tighten all bolts using the wrench (HH).
E
H
I
H
I
CC
GG
GG
GG

3
7
Assembly (continued)
Attach the seat (E) to the swing frame using the hooks (GG).
Place the cushion (F) and pillows (G) on the seat (E).
Attaching the seat to the swing frame
F
G
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
GG
E
NOTE: Customer has the option to use the swing either with
or without the cano
py
.

4
l
8
Assembly (continued)
Assembling the top frame
Attach the back light tube (N) and front light tube (M) to the left curved bar (J) and right curved bar (K) using M6x30 bolts
and nuts (FF).
Insert the light tube plugs into the plug holes on the left curved bar (J), as shown below.
NOTE: Loosely tighten all bolts using the wrench (HH).
M
N
FF
J
K
FF

5
9
Assembly (continued)
Attach the middle support bar (L) to the right curved bar (K) and left curved bar (J) using M6x35 bolts (EE).
Tighten all bolts on the top frame using the wrench (HH) before placing the canopy.
Place the canopy (O) on the assembled top frame.
Placing the canopy
EE
O
KL
J
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

6
l
10
Assembly (continued)
Attaching the top frame to the legs
Attach the assembled top frame to the top bar (A) using the screw knobs (P) on both sides.
Connect the plug on the top bar (A) to the charger in the canopy.
O
P
