HAMPTON BAY GSS00227B User manual

THANK YOU
Item # 000 000 000
Model # GSS00227B
USE AND CARE GUIDE
STATESVILLE 3 PERSON STEEL SWING WITH POLYESTER CANOPY
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
y through the purchase of this swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Care and Cleaning........................................................10
Assembly ........................................................................5
Package Contents.................................................................... 4
2
Table of Contents
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Warranty
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
Contact the Customer Service Tea
Safety Information
PRODUCTCAUTION
SAFETY WARNINGS
Safety Information .......................................................2
Product Caution .................................................................... 2
CAUTION: When not in use, securetheproductin a
cool and covered location.
!
Safety Warnings ..................................................................... 2
WARNING: This swing unit is heavy and may require
two adults for safe assembly.
WARNING: Please keep children out of the assembly
area during assembly.
WARNING: Weight limit for the swing chair is 250 lbs
(113.39 kg) for each seat.
Table ofContents ........................................................2
This swing was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for normal
outdoor use; however, the manufacturer recommends storing and / or covering this swing when any formidable / severe weather is
approaching. Do not locate the product near open flame. Do not use the product as a support. Do not shake, lean, or climb on the product.
Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is NOT intended for
commercial use and will void the warranty.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
m at 1-855-HD-HAMPTON or visit www.HamptonBay.com.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
DD
CC
BB
AA EE
II
HH
GG
FF
MM
LL
KK
JJ
NOTE: Hardware not shown to actual size.
NN
Part Description Quantity
AA
BB
M8x100 bolt and nut
Description QuantityPart
M8x50 bolt and nut
CC M8x45 bolt and nut
4+1
2+1
4+1
4+1
4+1
DD M8x30 bolt and nut
EE
FF
M6x55 boltand nut
M6x40 bolt
GG M6x30 bolt and washer
8+1
2+1
2+1
HH M6x30 bolt
6+1
2
2
2
1
II
JJ
M6x15 bolt
Hook
KK Knob
LL Connector
MM Hex wrench
1 NN Wrench
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A
B
Top bar
Description QuantityPart
Leg
C Left side bar
1
4
1
1
1
1
1
1
1
D Right side bar
E
F
Seat
Back
G Left arm
H Right arm
3
I
J
Curved bar
Support bar
4
2
K
Swing pipe
LCanopy
2
M
Cup holder
A
B
C
M
E
D
F
G
H
K
L
I
J

1
l
5
Assembly
Attach two sets of the legs (B) to the top bar (A) using M8x100 bolts and nut (AA).
Attach the two connectors (LL) to the legs (B) and the top bar (A) using M8x45 bolts and nuts (CC) and M8x50 bolts and nuts (BB).
ASSEMBLING THE SWING FRAME
Attach the left side bar (C) and the right side bar (D) to the legs (B) using M6x40 bolts (FF).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
A
B
BB
LL
AA
CC
FF
FF D
C

2
l
6
Assembly (continued)
Attach the arms (G & H) to the seat (E) using M8x30 bolts and nuts (DD).
Attach the arms (G & H) to the back (F) using M6x30 bolts and washers (GG) and M6x15 bolts (II).
ATTACHING THE ARMS AND THE SWING PIPES TO THE SEAT AND THE BACK
Attach the swing pipes (K) to the arms (G & H) using M6x55 bolts and nuts (EE).
Connect the top of the two swing pipes (K) together by using the hooks (JJ).
GG
DD
F
K
H
E
G
G
K
K
F
EE
II
EE
E
JJ

3
7
Assembly (continued)
Attach the whole seat to the swing frame using the hooks (JJ).
ATTACHING THE SEAT TO THE SWING FRAME
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
JJ

4
8
Assembly (continued)
Attach the two curved bars (I) to the support bars (J) using M6x30 bolts (HH).
Fully tighten all of the bolts on the top frame using the hex wrench (MM) before placing the canopy (L).
Place the canopy (L) on the assembled top frame.
ASSEMBLING THE TOP FRAME AND THE CANOPY
L
J
I
HH
HH
HH
I

5
9
Assembly (continued)
Tighten the Velcro (1) on the two sides of the top frame.
Attach the assembled top frame to the assembled swing frame using the screw knobs (KK) on both sides.
ATTACHING THE TOP FRAME TO THE LEGS
Place the cup holders (M) to the side bars (C & D) on both sides.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
M
KK
1
D
C

6
10
Assembly (continued)
Once all of the bolts are in place, fully tighten all of the bolts.
Make sure that the swing is tightly assembled and stable before use.
TIGHTENING THE BOLTS
Care and Cleaning
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Keep the swing away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Store the swing in a dry, sheltered place when not in use.
Do not clean with abrasive materials, bleach, or solvents.

Questions,problems,missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
