Hanasis HIT Guide

HIT ※ Please read and learn the manual carefully for your safety and proper way of use.
e-Manual

Safety precautions
Preview
Specification & options
Overview
Contents
System Introduction
Remove the protective tape
Adjusting Viewing Angle
System On
System Installation
BIOS Setup
BIOS
Touch Screen
MSR
Kitchen Printer Bell
Using the Product
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
System Block Diagram
MotherBoard Layout
Setting Jumper
Appendix
I/O Pin Assignment
MSR
Stand
Storage (HDD / SSD)
Assembly & Disassembly
Rear Cover
EMI
Wall mount
9.7” Second Monitor(Touch)
ㆍInstall / Connect Cable
ㆍSystem Setup
Customer Display
ㆍInstall / Connect Cable
ㆍSystem Setup
ㆍCOM1 ~ COM4
ㆍMSR, HDMI
ㆍDC-IN, DC-OUT
ㆍLAN, USB

Safety precautions
Do not block the ports(holes), Vents, etc, of the system and do not insert objects.
Damage to a component within the system may cause electric shock or fire.
Do not touch the system plug or power cord with wet hands. There is a danger of electric shock.
Do not exceed the standard capacity(Voltage/current) of a multiplug or power outlet extension when using it for the product.
There is a danger of electric shock or fire hazard.
Do not unplug the power cord by pulling the cable only. If the cord is damaged, it may cause electric shock.
Connect the power cord to the AC adaptor firmly. Use only the AC adaptor supplied with the product.
Otherwise, there is a danger of fire due to an incomplete contact.
Do not use the system in a humid location such as a bathroom or sauna.
Please use the system within the recommended temperature and humidity range(10~32˚C, 20~80% RH).
Avoid direct sunlight when the system is in an air-tight location such as inside a vehicle.
There is a danger of a fire hazard. The system may overheat and also present opportunity to thieves.
For your security and to prevent damage, please read the following safety instructions carefully.
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Preview
Overview
Specification
System
Introduction
Safety precautions

Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Preview
Overview
Specification
System
Introduction
Safety precautions
Thank you for purchasing Hanasis's POS.
(Product specifications may differ according to region and may be changed without prior notice)
■System preview
Preview
Class-A digital device
A digital device that is marketed for use in a commercial, industrial or business environment,
exclusive of a device which is marketed for use by the general public or is intended to be used in the home.
This product is developed and tested on the basis of our reliability and outstanding technology.
This product has applied exclusive and emotional design and also provides wide expandability such as device.
This product has applied low power atom platform design, 15” P-CAP(TFT) touch screen and 9.7” dual monitor expandability.
This will allow users to save maintainance cost and will provide comfortable user experience.
This product is designed for users to fix easily by using hand screws in system main body and stand, and also by decreasing the number of screws.
This product has acquired domestic and international standard, applied a technology patent that is created by Hanasis.
registered trademark
The symbol mark is the foundation element that symbolizes the Hanasis corporation and it is also a symbol of communication at both home and abroad.
The basic concept is a leading IT industry. It embodies Hanasis's corporate goal to link world faster by using advanced IT technology.
The symbol mark express Hanasis's industry representative. The symbol expresses the image of network envrionment and advanced technology in dynamic way.

◆ Specifications ◆ Options
Specifications & Options
OS
Wall Mount
Touch Panel
Dual Display
Customer Display
Secure Card
Reader
Case Color
Microsoft
®
POSReady7 / Windows 10 IoT
Fixed Type , Swivel Type
(75x75, 100x100mm VESA)
15"Bezel type, 5-Wire Resistive
15”Bezelless type, Projected Capacitive Touch
9.7”, TFT-LCD, 1024x768, LED panel (Touch)
VFD type, 20 Characters X 2 Lines, Serial(RS-232C)
EMV1, EMV2, MSR ISO Track2
WiFi 802.11n, 150Mbps ↑ (External USB Module)
Processor(CPU) &
Chipset
Memory
Storage
Display
VGA / DVI
HDMI
LAN
Serial(RS-232C)
Parallel(LPT)
PS/2
USB
Audio
Speaker
Cooler & FAN
Power Adaptor
Dimension(mm)
Weight
Intel
®
Celeron
®
J1800 Dual Core (2.41 GHz 1M Cashe)
Intel
®
Celeron
®
J1900 Quad Core (2.0 GHz 2M Cache)
System on chip (SoC)
2GB DDR3L SoDIMM (Up to 8GB)
2.5”, SATA-III HDD 500GB↑ or SSD 64GB↑
15", 1024 X 768, 24Bit
Luminance : 300 cd/㎡, Backlight : LED
-
1 EA (Intel
®
HD Graphics)
1 EA (RealTek Gigabit LAN)
5 EA (DSUB-9p x 2EA / RJ-45 x 3EA)
-
-
4 EA (I/O) (USB3.0 & 2.0)
2 EA (Rear) (USB2.0)
1 EA (Line-Out)
1 EA (1W)
Fanless
60[W] Adaptor
Input AC 100~240V/50~60HZ, DC 12V/5A
384(W) x 347(H) x 225(D) (With Stand, With SCR)
OS Supported
Microsoft
®
POSReady7 / Windows 10 IoT
Linux / Android
4.8 kg
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Preview
Overview
Specification
System
Introduction
Safety precautions
Black & White
Bezelless type only
White & BWhite & Blacklack
BezelBezel type only type only BBlacklack

Overview
Second Monitor(9.7")
I/O Ports
Cable Vent
External USB(2ports)
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Preview
Overview
Specification
System
Introduction
Safety precautions
Cable Space
COM2COM1 COM3 COM4 MSRLAN USB USB LINE-OUT HDMI
Dual Monitor
OUT(12V) IN(12V)
POWER
2 4 7 8 10 5 61 3 9
1. 12V DC (OUT)
2. DIN 4pin 12V DC (IN)
3. D-SUB 9pin (Serial,COM)
4. LAN(RJ-45)
5. USB 2.0
6. USB 3.0
7. LINE-OUT(Audio)
8. HDMI (Second Monitor)
9. COM (8pin RJ-45)
10. MSR (8pin RJ-45)
기기(모델)명 :
제 품 코 드 :
정 격 전 압 :
제조자/제조국 :
인증받은 자 :
인 증 번 호 :
제조번호
포스시스템 ( HIT )
HIDNWWPRD-S59700A
DC 12V 5.0A
하나시스(주) / 대한민국
하나시스(주)
MSIP-REM-HS7-HIT
HIDNWWPRD-141001
Rating Label
I/O port
MSR
Power Button & Lamp
[ Bottom View ]

Protective Tape
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Remove
the protective tape
System On
Adjusting
Viewing Angle
System
Introduction
Before you setup the product.
Remove the protective tape before install.
Remove the Protective Tape

5˚
Adjusting Viewing Angle
50˚
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Remove
the protective tape
System On
Adjusting
Viewing Angle
System
Introduction
For optimal viewing, it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own
preference. You are able to adjust the monitor's angle from 5°to 50°.

System On
OUT(12V) IN(12V)
POWER
3
3
1
I/O Ports Cover
Datachment
Handle
Stand Cover
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Remove
the protective tape
System On
Adjusting
Viewing Angle
System
Introduction
Connect the power cable to the adaptor firmly. Use only the adaptor supplied with the product.
Otherwise, there is a danger of fire due to an incomplete contact. Do not touch the system plug or power cable with wet hands
Please always check
the directions.
①Separate the cover rear stand, as shown in drawing.
②Separate the I/O ports cover.
③Connect the power cable.
④Press Power button to turn the system on.

Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
Touch Screen
System
Introduction
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
Do not apply a severe impact to the touch screen or press the screen with a sharp object such as a ball-point pen.
This may damage the touch screen.
■Touch Point Setup
Touch Screen
When you use the touch screen for the first time or the pointer does not precisely match your touch, calibrate the touch screen
in the ‘eGalaxTouch’. The calibration process for the touch screen may differ depending on the operating system and may not be available in
some operating systems. The following descriptions assume the Windows POSReady2009 operating system.
① Click start→All Programs→eGalaxTouch→Configure Utility
② Click the 'Tools' tab and ‘4Points Calibration’
③ When the Calibration window appears, touch the point represented by the “+”.
④ The “+” is displayed from the bottom left to the top left of the screen sequentially.
⑤ The Touch screen input points are calibrated.

1
2
3
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
Touch Screen
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
Learn the proper way of using card reader before using the product.
When the card is inappropriately recognized, the red ligth will be turned on with the beep sound.
①Grab your credit card as the picture shows.
※ Make sure the magnetic side of the card towards out side.
②Push your credit card in the direction of the arrow.
③Slide down your credit card gently in the direction of the arrow.
■Proper way of using the card reader
MSR

■
[ Printer : SRP-330II, GIANT-100 ][ Extension Cable ][ POS ]
1: N.C
2: DSR
3: TXD
4: RXD
5: RTS
6: CTS
7.GND
8: DTR
POS
(COM3,4)
1: N.C
2: DSR
3: TXD
4: RXD
5: RTS
6: CTS
7.GND
8: DTR
Kitchen Printer
(Serial, RJ-45)
18
8
1
Extention Cable port
(Serial, RJ-45)
COM3 COM4 MSR
Extension
Cable port
(COM3, 4)
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
Touch Screen
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
In order to connect POS device with kitchen printer, please regard to the following connection drawing.
You must use the interchangable gender that is provided by Hanasis.
Cable connection specification for kitchen printer serial cable
Kitchen Printer Bell

Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
Touch Screen
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
Backup your current Window user environment into restore field.
It is much easier to operate if you know where the data is being backed up.
Storage Backup■
Winclon (Backup)
①Connect the keyboard and mouse to the system.
After turning on the system, follow the on-screen instructions:
press <F11> when the “F11 to WinClon ...” message appears on the screen within 2 to 4 seconds (PC POST process).
② When WinClon appears on the screen, press <F10> key on your keyboard or click the mouse to select “Backup”.
③ After entering the password, press the <OK> button to continue the backup. (Password: pos)
(The programs may vary depending on different model.)
You need to connect keyboard before you turn the power on.
Location of backup image
pos
Password
OK

Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
Touch Screen
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
■Storage Backup(The programs may vary depending on different model.)
If you recover the Hard disk, all the data of the system will be deleted.
Please save all the important data in the external storage before you start recovering.
You can recover quickly despite when you are not able to boot from the OS or when having any problems.
Keyboard and mouse must be connected.
Winclon (Restore)
①Connect the keyboard and mouse to the system.
After turning on the system, follow the on-screen instructions:
press <F11> when the “F11 to WinClon ...” message appears on the screen within 2 to 4 seconds (PC POST process).
②When WinClon appears on the screen, press <F2> key or <F3> on your keyboard or
click the mouse to select “Recover recent state” or “Recover initial state”.
③ After entering the password, press the <OK> button to continue the restore. (Password: pos)
pos
Password
OK
※ Recover initial state” is restored to the factory default state.
※ Recover recent state” is restored to the most recent backup of Windows.

▶
Drivers
Utility
Manual
MSR
HDD AlignTool
AdobeReader
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
Touch Screen
MSR
Kitchen Printer Bell
Winclon (Backup)
Winclon (Restore)
POS Driver & Utility
All the drivers and data that are provided with your purchase are in the D drive of the storage.
POS Driver and Utility
It is the contents from the D:\Utility.
There are install files in each folders.

COM4 MSR
1
2
3
4
I/O Ports Cover
Screw
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
MSR
Stand
Storage(HDD/SSD)
Cover Rear
EMI
Second Monitor
VFD
Wall Mount
■ MSR separation
MSR
When reassembling the card reader, you must assemble tightly otherwise the card will not be recognized by the reader.
① Separate the cover cable by pushing it upwards.
② Disconnect MSR connector.
③ Remove 2 hand screws.
④ Separate the MSR by pushing it in the direction of the arrow.

■
2
3
a
Lever
1
Insertion Point
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
MSR
Stand
Storage(HDD/SSD)
Cover Rear
EMI
Second Monitor
VFD
Wall Mount
The stand is heavy so please be careful with it. When reassembling, for your safety,
you must put the lever in the correct insertion point.
Stand separation
① Lift the lever(ⓐ).
② Pull the stand in the direction of the arrow indicated.
③ Lift up and remove the stand.
Stand

■
Cover Storage
1
4
3
2
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
MSR
Stand
Storage(HDD/SSD)
Cover Rear
EMI
Second Monitor
VFD
Wall Mount
①Separate the cover storage.
②Rotate(Counter Clockwise) the screw.
③Pull the storage out of the system.
④Separate the storage from the bracket storage.
⑤Replace the new storage into the bracket storage and assemble in reverse order.
Care must be taken when removing the storage and bracket to avoid injury.
Save all your data before clicking on Shut down. Disconnect the power cable from the system.
Storage(HDD, SSD) Replacement
Storage

■
Cover Rear
Stand
MSR
Second Monitor
I/O Ports Cover
1
Coin Screw
Cover Rear
2
3
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
MSR
Stand
Storage(HDD/SSD)
Cover Rear
EMI
Second Monitor
VFD
Wall Mount
1) Before you lay down the product, please remove anything that could damage the product and touch panel,
and then spread a clean fabric or cloth before you start the operation.
2) The disassembling and assembling process require professionality.
If you attempt to disassemble without any expertise, it may cause product trouble so please be careful.
Cover Rear separation
①Separate the cover cable, second monitor, stand, MSR
※ Please refer to related contents for the separation.
②Remove the coint screw.
③Separate the coverrear by pushing it in the direction of the arrow.

1
Cover Rear
MSR
Second Monitor
I/O Ports Cover
Stand
2 Screw
3
EMI
■
EMI
Contents
System
Installation
Using
the product
Assembly &
Disassembly
BIOS
Appendix
System
Introduction
MSR
Stand
Storage(HDD/SSD)
Cover Rear
EMI
Second Monitor
VFD
Wall Mount
Check the caution for disassembling before disassemble EMI.
EMI separation
①Separate the cover cable, second monitor, MSR, stand and rear
cover. ※ Please refer to related contents for the separation.
② Remove the 2 screws.
③ Separate the EMI by pushing it in the direction of the arrow.
