HANBiT Electronics STORiUM User manual

Front-runner ofinformation& communication
HANBiT Electronics Co.,LTD.[www.hbe.co.kr]
USER SMANUAL
PortableFlash MemoryDiskDrive

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 2/20 www.hbe.co.kr
INDEX
1. Introduction
1.1 About COMBO MP3 N Drive 3
1.2 Features 3
2. HowtouseCOMBO MP3 NDrive
2.1 Mechanical parts 5
2.2 Howto install battery 5
2.3 Function 6
3. Howtoinstall/ Modify/Repair / Removedriver
3.1 Windows98 /98SE installation 10
3.2 Modify/ Repair driver for Windows 98 / 98SE 11
3.3 Remove driverfromWindows 98 /98SE 12
3.4Windows 2000 / ME/XP Installation 14
4. Remove COMBO MP3N Drivefrom Computer 14
5. Linux2.4.0 or/ Mac 8.6 upinstallation 14
6. Important Notices14
Notice
Someofcomputers mayhave power leakyorotherproblems,toavoidanydirectdamage
CausedtoCOMBO MP3 N Drive, Wesuggest you useextensioncable,USB hubor
DockingstationtoconnectCOMBO MP3N Drivetoyour computer. Do notstraightlyplug

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 3/20 www.hbe.co.kr
COMBOMP3 N Drive to computer.
1. Introduction
1.1 About COMBO MP3 N Drive
COMBO MP3 N Drive is more thana MP3Player Beinga smartcustomer,youpayforone
COMBO MP3 NDrivepricebutenjoydoubleeffects.Our COMBO MP3 stores notonlyMP3
format butalso all kinds ofdata. It delicately combines MP3 Playerwitha removable harddrive.
Furthermore, COMBOMP3 NDriveis absolutelyuserfriendlythatyou simplyplugit into USB
portofyournotebookor desktop Computer.Youcan enjoylisteningtoyourfavorite music in
parallel with keeping dataReading/ Writingthroughtheharddrivefunction.Withthe long-
lasting Li-battery,itis so convenient thatyoucantakeourCOMBOMP3 NDrive whereveryou
goanddowhatever you want. Itschicoutlookandmini designis alsoforuser sconsideration.
Ifyouare lookingforinnovative,attractiveand pragmatic high-techproduct,COMBO MP3N
Drive will be yourbest choice.
1.2 Features
Current available: 64MB/ 128MB / 256MB
Support music format: MP3
Earphonejack: 2.5 mm
Audiooutput:5mW+5mW
Outerfrequencyrange:20HZ –20KHZ
Battery: Lithium-ION 500mA 3.7V, continueusing at least 7.5hours atfull-charge.
Support USBspecification revision 1.1
Transferring rateup to12Mbit persecond at “Full Speed”
Supportpowersaving mode toreduce powerconsumptionwhilenoplaying MP3
SupportWindows 2000,ME, XP, Mac OS 8.6 orabove andLinux 2.4.0orabove
withoutdevice driver
SupportWindows 98 /98SEwith device driver

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 4/20 www.hbe.co.kr
Power LED:
(i) Orange LEDon indicates batteryin charge.
Plug COMBO MP3N Drive intoUSBport tore-charge batterythroughcomputer
(ii) GreenLED on indicatesbattery in full charge.
Play LED:
(i) Red LED indicates youareusing MP3 playermode
(ii) RedLED quicklyflashes whennoMP3 filefound.
(iii) Red LED slowlyflashes when you pauseMP3 player.
(iv) Green LED indicates you areusingUSBremovablediskmode.
(v) GreenLEDblinking whenyouare reading/writing from/on USB removabledisk.
Write/Delete protection switch
HotPlug & Play –Enableyou to install COMBO MP3NDrive at anytime
Durable solid-state storage –data retentionforatleast 10years
Erase Cycles:1,000,000 times
Acoustic noise:0dB(at one meter)
No external powerisrequired - DC 4.5V~ 5.5V fromUSBport
Low Powerconsumption –Write 39.1mA~ 39.4mA/
Read 35.0mA ~ 36.1mA.
Read/Write Speed of USBinterface:Read 800KB /Write 600KB
Size:91.2x30.4 x 26.3 mm
Unit weight:30g(notincludingbattery)
CE and FCC certificateof approval.
2. HowtouseMP3 player
2.1 Mechanical parts

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 5/20 www.hbe.co.kr
Neckstrap foreasycarry
Earphone
PowerLED
PlayLED
USBconnector
Cap
Write protect switch
Clip
Batterycover
2.2 Howtoinstall battery
1. Please remove batterycoverbypress twosides and takeout
2. Connect battery s cord tothe powerport.
3. Putbackbatterycover.
4. Please connectto USBporttocharge batterywhenyoufirst time use it.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 6/20 www.hbe.co.kr
2.3 Function:MP3 playermode
1. Poweron whenearphone plugged.
(earphone port is 2.5mm)
2. Play/Pause: Press Control Switch buttononce.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 7/20 www.hbe.co.kr
3. Slidetorightsideandhold:volumeraise.
Slide toleftsideand hold: volumelowdown
4. Quickpull toright side:next song.
Quickpull toleftside:previous song.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 8/20 www.hbe.co.kr
5. Power LED:
(i) OrangeLEDonindicatesbatteryin charge.
PlugCOMBOMP3N DriveintoUSB portto
Re-charge batterythroughcomputer.
(ii) GreenLED onindicatesbatteryis in full charge
6. Play LED:
(i) RedLED indicates you areusingMP3 Playermode.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 9/20 www.hbe.co.kr
(ii) Red LED quicklyflasheswhennoMP3file found.
(iii) RedLED slowlyflashes when you pauseMP3player.
(iv) GreenLED indicates you areusingUSB removable diskmode.
(v) Green LEDblinking whenyouarereading/ writingfrom/onUSBremovable
disk.
7. Read/Write protection
8. To charge battery:takeoffcapand plugintoUSB port ofnotebookordesktop
computerto chargebattery.Forbetter usage, please charge
atleast 1hourand45minutes.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 10/20 www.hbe.co.kr
3. HowtoInstalldriver
3.1 Windows98/98SE Installation
(1) GotoCD orfloppydiskdriverin “MyComputer.”
(2) Execute “Setup.exe”bydoubleclickontheicon.
(3) System will install all thenecessaryfiles into yourWindows operating system..
Aftersetupinstallation completed, click “OK”torestart computer
.
Onceinstallationis finished completely, you can see “removable disk”in
“My Computer”whenyouplug COMBO MP3 NDrive

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 11/20 www.hbe.co.kr
3.2 Modifyor Repairdriver for Win98 / Win98SE
(1) Ifyouhave installed thedriveronce before,whenexecute the “Setup.exe”
fileagain. You will see thefollowing screen. Ifsomehow the driveriswrong or
damaged, You can select “Repair”
Select “Modify”or “Repair”and thenclick “Next.”
(2) Selectall files andclick “Next.”

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 12/20 www.hbe.co.kr
(3) Click “Finish”tocompletemodification
3.3 Removedriverfrom Win98 / Win98SE
(1) To removedriverfrom operating system. Execute the “Setup.exe.”
filefromCD driverdiskagain, Select “Remove”andclick “Next”

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 13/20 www.hbe.co.kr
(2) System will then ask you confirmdeletionClick “OK”.
(3) This screen mayormaynotappear. It s system asksyouto doubleconfirm the
files fordeletion.Justclick “Yes.”
(4) Click “Finish”to completetheprocess of removing device driverfrom system.
3.4 Windows 2000 /Windows ME / XP Installation

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 14/20 www.hbe.co.kr
Fortheseoperating systems, No driveris needed,because Windows has built-in
drivertosupport USBremovable disk.Simplyplug COMBOMP3N Drive into the
USBportand itwill berecognized bythesystem. System will setupCOMBOMP3 N
Drive automatically without anyfurtherinstallationof driver.
4. Remove COMBO MP3 N Drive
Afterusing COMBO MP3N Driveplease choose oneof themethodsbelowaccordingto
your OperatingsystemtoremoveCOMBOMP3 N Drive fromUSB port.
Windows98/98SELED:You could unplugCOMBOMP3 NDrivefromUSBportdirectly
Oncethe LEDstops blinkingand its iconwoulddisappearautomatically
WindowsMe/2000/XP:Clicktheicon ofCOMBOMP3 NDriveat theright down corner
And a “StopUSBMass StorageDevice –Drive(H)”Menu appearsClick the menu, andthe
below Windowappears,tellingyou “theUSB Mass Storage Device,device can besafely
Removedfrom thesystem”
Click “OK”to close the Window, thenYoucansafelyremove COMBOMP3 N Drive.
5. Linux2.4.0 or /Mac 8.6 upInstallation
Again,No driverisrequiredforthese two operatingsystems,Simply plugthe COMBO
MP3 N Drive,you couldunplug COMBOMP3 N Drive intothe USBportand the System
Will automaticallyfindCOMBO MP3 N Drive,AfterusingCOMBOMP3 N Drive, you
Couldunplug COMBO MP3N Drive from USBportdirectlyonce theLEDstops blinking
Thenits iconwoulddisappearautomatically.
For Linux User, Please refer to Importantnotices.
6. Important Notices
(i) In OSWindows98/98SE, ifyoudon t set up installationfirstly, system will ask you
to put driverdiskforrunning installation. Be suretounplug COMBO MP3 N Drive before
running setup programs. Ifyou install thedriverwithCOMBOMP3NDriveplugged, it
maycausesetup errororfailure.
(ii) If youplugCOMBOMP3 N DriveintotheUSBport. SystemcanfindCOMBOMP3 N
Drivebut youareunable toaccess COMBOMP3 NDrive. Please FormatCOMBOMP3
N Drive.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 15/20 www.hbe.co.kr
(iii) Beforeunplugged COMBO MP3 N Drive fromUSBport inWindows ME/2000/XP
makesure you goto the right hand bottom of thescreen tostop theUSBdevice.
Otherwise, Itmayresult inlosing data thatyou have saved on COMBOMP3 NDrive
(iv) Linux uses a so-called “USBManager.”Which doesautomaticallyload kernel
modules(drivers)forUSBdevices, Its loads onlydrivers for devices that arepresent
on theUSB bus toreducememoryusage, Perdefault, theUSBManagerdoesnot
come with theUSB Drivepre-configured. However,youcan easilyconfigurethe
USB Managerto automaticallyrecognize the USBDrive yourself. Justadd the following
To theconfiguration file.
usbmgr.conf (usuallyin/etc/ usbmgr): vendor0xd7dproduct 0x100modulescsi_mod,
usb_storage.
This line identifies the USBDriveand tells the USBManagerto load theSCSI as well as
TheUSB storagemodules,The SCSImodules is needed inorder to talktobothSCSI
And USB storage devices, While theusb_storagemodule isneededto talkto USB
Storage devices.
Do not forget toeitherreload theUSBManager sconfiguration ortorestartthe USB
Manager
Forinstance, doas root: /etc /init.d/usbmgrreload

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 16/20 www.hbe.co.kr
USB STORIUM COMBO MP3 N DRIVE Specification
Capacity 64, 128, 512MB
Transferring rate 12Mbit /sec (at full speed)
ReadPerformance 800KB/sec
Write Performance 600KB/sec
O/S(AvailableO/S) Windows 98/98SE/2000/ME/XP
Mac OS9.x,Linux 2.4.0 orHigher
Drive Support Win98 Install driver
Win ME Patchdriver
PowerSupply No externalpower is required
(DC 4.5V ~ 5.5VformUSB port)
DataRetention 10 Years
LED State LED Indicator when Gray Whale is in use
powerconsumption Read: 35.0mA~36.1mA
Write: 39.1mA~ 39.4mA
Size 91.2×30.4×26.3 mm
Weight 30g
EraseCycles 1,000,000 times
Acousticnoise 1,000G(maximum)
Supportmusic format MP3
Audiooutput 5mW+5mW
Battery Lithium-ION 500mA3.7V(6 hourlasting)
Certificateofapproval CE, FCC

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 17/20 www.hbe.co.kr
※CustomerSupport
Inquiries can bemadeto CustomerSupportbyphone: [phone], 1914,1915
ore-mail afterconnectingto ourwebsite www.hbe.co.kr and clickingonthe A/S Corner
※Notice
Part orallofthisUser sManual maynotbecopiedwithoutpriorapprovalby
HANBiTElectronics,Ltd. and any other illegal use ofit isprohibited.
HANBiTElectronics,Ltd. hasnolegalliabilityfortechnical oreditorialerrorsof the
contentsofthisUser sManual,whichis subjecttochangewithoutprior notice.
HANBiTElectronics, Ltd.is not responsiblefortheloss of dataduring theuseof
the product.
※Caution:Safe removal of equipment
Please be sure tonotethefollowingforsafe use.
●WhenremovingCOMBO MP3 NDrive fromandinsertingit into USBport withO/S
priorto Windows98, removeit aftertheactivationof the mouse pointeris completed.
●Windows98: Make sure toremoveitwhenLED is not lighted.
●WindowsME, 2000, XP: Remove theequipment safelybyexecutingthe "hardware
separation”or ”takeout”(small-sized)icons that areonthe bottomright of theWindows or
usingthe Hardware Wizardinthe control panel.Iftheequipmentis separated ortaken
out before executing equipmentremoval, the computercouldstopoperatingorthe data
couldbe lost.
●Mac: Remove aftermoving the iconanddumpingit into thewastebasket.
●Linux:Remove aftercarrying the “unmount”command.

H
anbit ElectronicsCo,Ltd.All r
ights
r
eserved
Rev.002003-02-20 Page 18/20 www.hbe.co.kr
HANBiTElectronics Co.,Ltd
Address : 414-5Woncheon-Dong, Paldal-Gu, Suwon-City, Kyungki-Do, Korea (ZIP442-823 )
Telephone :+82 (31) - 218 - 1900/ Facsimile :+82 (31) - 217 -1926
E-mail : [e-mail] /[e-mail]/[e-mail]
URL: www.hbe.co.kr
