INSTALLATION
EN ⁄ Instructions for use ⁄ assembly instructions 02
DE ⁄ Gebrauchsanleitung ⁄ Montageanleitung 03
Lesezeichen
AXOR Edge
46432009
02
ASSEMBLY (see page 04)
EN
SAFETY NOTES
Gloves should be worn during installation to prevent
crushing and cutting injuries.
The product may only be used for bathing, hygienic
and body cleaning purposes.
Do not allow the streams of the shower touch sensitive
body parts (such as your eyes). An adequate distance
must be kept between the shower and you.
The product may not be used as a holding handle. A
separate handle must be installed.
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and
tested as per the applicable standards.
⁄ The plumbing codes applicable in the respective
countries must be observed.
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
Hot water temperature:
Recommended hot water temp.:
Thermal disinfection:
⁄ Safety against backflow
⁄ The product is exclusively designed for drinking water!
SYMBOL D ESC RI P TION
Do not use silicone containing acetic acid!
ADJUSTMENT (see page 08)
To adjust the hot water limiter. Using a hot water
limiter in combination with a continuous flow
water heater is not recommended.
DIMENSIONS (see page 12)
FLOW DIAGRAM (see page 12)
Hand shower
Bath Spout
SPARE PARTS (see page 15)
CLEANING (see page 10)
OPERATION (see page 09)
MAINTENANCE (see page 13)
The check valves must be checked regularly
according to DIN EN 1717 in accordance with
national or regional regulations (at least once a
year).
(1 MPa = 10 bar = 147 PSI)
max. 70°C
65°C
70°C / 4 min
03
MONTAGE (siehe Seite 04)
DE
SICHERHEITSHINWEISE
Bei der Montage müssen zur Vermeidung von
Quetsch- und Schnittverletzungen Handschuhe
getragen werden.
Das Produkt darf nur zu Bade-, Hygiene- und
Körperreinigungszwecken eingesetzt werden.
Der Kontakt der Brausestrahlen mit empfindlichen
Körperstellen (z. B. Augen) muss vermieden werden. Es
muss ein ausreichender Abstand zwischen Brause und
Körper eingehalten werden.
Das Produkt darf nicht als Haltegriff benutzt werden. Es
muss ein separater Haltegriff montiert werden.
Große Druckunterschiede zwischen den Kalt- und
Warmwasseranschlüssen müssen ausgeglichen
werden.
MONTAGEHINWEISE
⁄ Vor der Montage muss das Produkt auf Transportschä-
den untersucht werden. Nach dem Einbau werden
keine Transport- oder Oberflächenschäden anerkannt.
⁄ Die Leitungen und die Armatur müssen nach den
gültigen Normen montiert, gespült und geprüft werden.
⁄ Die in den Ländern jeweils gültigen Installationsrichtlini-
en sind einzuhalten.
TECHNISCHE DATEN
Betriebsdruck:
Empfohlener Betriebsdruck:
Prüfdruck:
Heißwassertemperatur:
Empfohlene Heißwassertemperatur:
Thermische Desinfektion:
⁄ Eigensicher gegen Rückfließen
⁄ Das Produkt ist ausschließlich für Trinkwasser konzi-
piert!
SYMBOLERKLÄRUNG
Kein essigsäurehaltiges Silikon verwenden!
JUSTIERUNG (siehe Seite 08)
Einstellen der Warmwasserbegrenzung. In
Verbindung mit Durchlauferhitzern ist eine
Warmwassersperre nicht zu empfehlen.
MASSE (siehe Seite 12)
DURCHFLUSSDIAGRAMM
(siehe Seite 12)
Handbrause
Wanneneinlauf
SERVICETEILE (siehe Seite 15)
REINIGUNG (siehe Seite 10)
BEDIENUNG (siehe Seite 09)
WARTUNG (siehe Seite 13)
Rückflussverhinderer müssen gemäß DIN
EN 1717 regelmäßig in Übereinstimmung mit
nationalen oder regionalen Bestimmungen auf
ihre Funktion geprüft werden (mindestens einmal
jährlich).
max. 1 MPa
0,1 - 0,5 MPa
1,6 MPa
(1 MPa = 10 bar = 147 PSI)
max. 70°C
65°C
70°C / 4 min
04
15487187
1
2SW 17 mm 3SW 30 mm
4 5
1.
3.
SW 24 mm
(14 Nm)
1.
2.
2.
Montage Montage
05
3.
1.
1.
6 7
2.
2.3.
8
SW 27 mm
9
10 11
SW 3 mm
(4 Nm) SW 3 mm
(4 Nm)
2.
SW 3 mm
(4 Nm)
1.
1.
2.
3. 4.
Montage
06
13 14
1615
1.
2.
3.
(1,5 Nm)
1.
2.
5.
6.
4.
12 1.
2.
3.
Montage
07
1.
2.
3. 1918
17
Montage
08
60 °C 10 °C 0,3 MPa
65
34
36°C
38°C
43°C
60°C
55°C
50°C
1 2
SW 3 mm
4 x
SW 3 mm
(5 Nm)
JustierungJustierung
09
max. 1,45 m
1.
2.
close ⁄ schließenopen ⁄ öffnen
hot ⁄ warm cold ⁄ kalt
Bedienung
10
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www
.axor-design.com
/
cleaning
-recommendatio
n
www
.axor-design.com
/
cleaning
-recommendatio
n
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
www
.axor-design.com
/
cleaning
-recommendatio
n
www.axor-design.com/
cleaning-recommendation
www.axor-design.com/
cleaning-recommendation
EN ⁄ Cleaning recommendation ⁄ Warranty ⁄ Contact
DE ⁄ Reinigungsempfehlung ⁄ Garantie ⁄ Kontakt
Reinigung Reinigung
